- Page 1 Prizelawn ® COMMERCIAL BROADCAST SPREADER MODEL CBR MODEL CBR III SS OWNER’S MANUAL...
- Page 2 ASSEMBLY Remove the spreader and components from carton and LOCKWASHER place hopper up-side down on a padded surface as shown. Insert ends of leg into handle 1/4-20 X 2” Hex Bolt brace as shown and align holes. Attach brace and leg to 1/4-20 NUT frame using (4) 1/4-20 x 2”...
-
Page 3: Operation
1/4 Dia. Clevis Pin Install control tube to handle lever with (1) 1/4 dia. clevis pin Handle and a 3/32” dia. cotter pin. Slip Lever opposite end of control tube over 3/32” Dia. lower control rod making sure Cotter Pin shutoff plate is between the lower rod and the control tube. - Page 4 PATTERN ADJUSTMENT Discharge Chute Normal spreading of materials Settings requires no adjustment (factory Discharge setting “A”) unless stated on the Chute package. In those cases where the spread pattern has shifted, the pattern can be adjusted left and Knob right by loosening the two knobs on the discharge chute and moving the chute closer or farther away from Impeller...
-
Page 5: Application Rate
APPLICATION RATE EXAMPLE: Product weight: 25 lbs. Knowing the effective pattern width (for sq. ft. coverage: 5,000 sq. ft. example, 10 feet), measure a distance equal 2500 lbs. - 5,000 sq. ft. to 100 square feet (10’ x 10’ swath width). = .5 lbs. -
Page 6: Maintenance
The following provides approximate Prizelawn settings when only the product III SS ® weight, square foot coverage, and visual inspection of the material is available. FERTILIZER BAG RATE APPROX. SPREAD Pounds of fertilizer used PARTICLE SIZE SETTING WIDTH per 1,000 sq. ft. of (IN FEET) coverage Large, heavy... -
Page 7: Calibration Instructions
PSB. In all other instances, such charges shall be paid by Purchaser. Except for loss or damage caused by PSB's negligence, Purchaser relieves PSB of responsibility for all risks of loss or damage to the Product and its parts during the period the products are in transit to and from PSB. - Page 8 Rate Plate* 14932 15191 Free Wheel 15033 15033 Rate Control Knob* 12704 12704 Agitator 14510 14510 Pointer* 12708 12708 Fastener Package 15035-1 15035-1 Spring Housing Assembly* 12702-2 12702-2 Hopper Cover 14606-1 14606-1 © 2004 PSB COMPANY *Parts included in hopper assembly...
