Hardware Interfaces:

Front Out
Rear Out
CEM/LFE
Alt Center
Line In
Mic In
S/PDIF Out
This port is for Left and Right Front audio speakers. It can
be used for regular speakers or Headphones.
This port is for Left and Right Rear audio speakers. It can
be used with regular speakers.
This port is for Center & Subwoofer (LFE) audio speakers.
It can be used with regular speakers.
This port is for Left and Right Back audio speakers. It can
be used with regular speakers.
This port is for Audio Line-in.
This port is for Microphone-in.
This port is for S/PDIF digital audio output with coaxial
cable to MD Player, AC-3 Decoder, Home Audio System.
Page 4
