Page 1: User Manual
® FREE Record Lifetime Updates Video Magellan RoadMate ® ® User Manual 6230-LM... -
Page 2: Important Safety Warnings
It is your responsibility to comply with all traffic laws and to use the Magellan RoadMate and mounting options in such a manner that the user is in compliance with applicable laws. - Page 3 Only use the car charger approved for/supplied with your Magellan RoadMate receiver. Use of another type of car charger will result in fire or electric shock. For safety reasons, the battery in your Magellan RoadMate receiver will stop charging when the ambient temperature is less than 32°F (0°C) or more than 113°F (45°C).
- Page 4 The Magellan RoadMate receiver must be installed and operated at a distance no closer then 8 inches (20 cm) from the user.
-
Page 5: Table Of Contents
Contents IMPORTANT SAFETY WARNINGS .............ii 1 Magellan RoadMate GPS Receiver with DVR ........1 Magellan RoadMate Controls and features .............. 2 Reset ..............................2 2 Fundamentals ..................3 Battery Levels ........................3 Viewing the Battery Level Indicator ...................3 Speaker Volume ......................3 Changing the Volume from the Map Screen ..............3 Changing the Volume from Settings ..................3... - Page 6 Excluding a Maneuver ......................17 Types of Routes ......................17 Changing the Routing Method ..................18 Compare Routing Methods ....................18 To Change the Default Routing Method ..............18 Special Routing Functions ..................18 Cancelling a Route ........................ 18 RoadMate 6230-LM User Manual Page vi...
- Page 7 Setting Auto Zoom on Turns ..................... 27 Setting Highway Lane Assist ....................27 Sound ..........................28 Setting Volume from Settings .................... 28 Turning Button Sounds On/Off ..................28 Turning Smart Volume On/Off ..................28 Navigation ........................28 RoadMate 6230-LM User Manual Page vii...
- Page 8 Regions ..........................30 GPS ..........................30 Setting the GPS Position ...................... 30 Viewing the GPS Status ....................... 30 Default System Settings ....................30 Restoring All Default System Settings ................30 Product Information ....................30 Viewing Product Information .................... 30 RoadMate 6230-LM User Manual Page viii...
-
Page 9: Magellan Roadmate Gps Receiver With Dvr
1 Magellan RoadMate GPS Receiver with DVR The Magellan ® RoadMate ® receiver is a • Save location information to create a map vehicle navigation product with Digital Video later of the places you went. Recorder (DVR) functionality. • Save all or part of the video for later It uses GPS signals from satellites to viewing. -
Page 10: Magellan Roadmate Controls And Features
Available for use as external card reader for DVR playback on a PC. Video In 2.5mm AV In. Connect audio/visual display from optional Magellan Backup Camera. Note: Cameras for other devices may require adapter. USB Connector Connect to power source* or personal computer** Reset The reset button is located on the back of the receiver in the upper right corner. -
Page 11: Fundamentals
2 Fundamentals Battery Levels The Magellan RoadMate receiver has an internal battery that is charging whenever the receiver is connected to external power. 3. Tap Changing the Volume from Settings 1. Access the Main Menu. 2. Tap the Settings icon . -
Page 12: Brightness
Address Book Access the Address Book The Main Menu screen is the center for all where you can save ad- available functions of the Magellan RoadMate dresses and destinations receiver. The Main Menu contains large, easy to have available when to access icons for all the major functions. -
Page 13: Keypad
(Entering street) Brings up a The keypad is the most common method for list of streets beginning with entering data into the Magellan RoadMate the characters entered. receiver. Understanding the keypad while entering an address is an important part of Selecting From List using your Magellan RoadMate receiver. -
Page 14: Smart City Search
Smart City Search The Magellan RoadMate receiver utilizes a feature known as “Smart City Search”. Smart City Search attempts to predict the city you are looking for. This prediction is based upon two factors; your position and cities you’ve gone to before. -
Page 15: Map Screen
(H) Access volume, brightness controls. (G) Access OneTouch Menu. OneTouch Menu (I) Access OneTouch Menu for instant access gives you instant access to your saved to your saved search criteria and favorite search criteria and favorite destinations. destinations. RoadMate 6230-LM User Manual Page 7... -
Page 16: Setting Map Options
You can set which POIs are displayed on the map as you drive. Set checkmarks for each item you want displayed. Auto Zoom on Turns Check to enable, uncheck to disable. Highway Lane Assist Check to enable, uncheck to disable. RoadMate 6230-LM User Manual Page 8... -
Page 17: Panning On The Map
(optional) Tap List Categories to select a Add To Trip: the selected destination is category for this address. New categories added to the end of the current trip. can be added from the Select Category RoadMate 6230-LM User Manual Page 9... -
Page 18: Maneuver List (Itinerary)
3. Tap Yes to confirm. 4. The Magellan RoadMate receiver recalculates the route and the Map screen is displayed. Changing Route Options The options for how a route is computed can be changed to Fastest Time, Shortest Distance, Mostly Freeways, Least Use of Freeways. -
Page 19: Onetouch Menu
OneTouch button. If you select Yes, you will need to enter your home address using the Enter Address keyboard. To use your current location for Home, just press the Use My Current Location button. RoadMate 6230-LM User Manual Page 11... -
Page 20: Saving A Poi Search Criteria To A Onetouch Icon
“All Subcategories” to select all the subcategories or continue defining your search criteria. 6. Using the keypad, enter a name for the button and tap RoadMate 6230-LM User Manual Page 12... -
Page 21: Selecting A Destination
The range of entered. acceptable street numbers is displayed before you start typing. Tap the when the street number is complete. RoadMate 6230-LM User Manual Page 13... -
Page 22: Tips On Entering Addresses Quickly
• When you are entering the name of a city name. or a street, Magellan software only displays Use the keyboard to enter the street those characters that appear in possible name. It is not necessary to enter search results. -
Page 23: City Centers
(e.g. Fastest Time). (optional) Tap Options if you want to change the routing method. 4. Tap the large GO button on the right to return to the Map screen and start navigating. Edit information: RoadMate 6230-LM User Manual Page 15... -
Page 24: Accessing An Address In Your Address Book
(e.g. Fast). 3. (optional) Tap Options if you want to change the routing method. 4. Tap the large GO button on the right to return to the Map screen and start navigating. RoadMate 6230-LM User Manual Page 16... -
Page 25: Traveling On A Route
When a destination is selected, the Magellan Excluding a Maneuver RoadMate offers the route with the default 1. This is used to modify the route to selected routing method first. -
Page 26: Changing The Routing Method
2. On the Main Menu, tap the Cancel Trip To change the routing method as you’re icon. establishing a trip, tap Options when the ‘Go’ screen is displayed. The Magellan RoadMate calculates the route and displays the travel time of each method. Compare Routing Methods... - Page 27 4. Tap the desired alternate route. You can also tap Route Options to change the routing method. RoadMate 6230-LM User Manual Page 19...
-
Page 28: Points Of Interest (Poi)
7 Points of Interest (POI) The Magellan RoadMate receiver has 4. POIs near your current position are preloaded POIs that can be used as a displayed. You can tap “Near...” for destination for a route. Selecting a restaurant different search criteria (Near Current or finding a gas station nearby is at your Position, Near City, or Near Address). -
Page 29: Creating A Route To A Poi By Name
Exit POIs button when it appears. 2. The list of the next highway exits and their distance from your current position appear. Highway Exit POIs are available on Interstates, freeways, and many state highways. RoadMate 6230-LM User Manual Page 21... -
Page 30: Using The Dvr
• Note - formatting removes any existing data D Lock current video segment from the card. E DVR Settings to return to the DVR screen. F Exit DVR G Date and time display Date and time is in Greenwich Mean Time RoadMate 6230-LM User Manual Page 22... -
Page 31: Automatic Recording
Recording segment number, position Locate and run the player program within the segment 1. Select and run the file “Magellan Player. Return to DVR screen exe”. (Details can vary according to the Select previous segment settings on your computer.) -
Page 32: Magellan Player
Magellan Player When you run “Magellan Player.exe”, the player will start up. • Multiple screens note: On some computers with multiple monitors, video performance may not be the same on all screens. Full list Short list Player controls Play faster - use while video is... -
Page 33: Playing Recordings
Select the segments to repair, or click Repair all. Click Repair. Language Selection To change the Player’s language selection, click The setting is displayed. Select a language from the drop-down, and click the Apply button. RoadMate 6230-LM User Manual Page 25... -
Page 34: Saving Recorded Video
120MB in size to Windows. The rest of the card’s capacity is reserved for DVR recording. • Remember - you must have a properly formatted card in the DVR card slot for the DVR to record video. RoadMate 6230-LM User Manual Page 26... -
Page 35: Settings
You can select whether to always use Setting Highway Lane Assist daytime colors, night color, or let the Magellan RoadMate receiver switch between them When Highway Lane Assist is checked, automatically a few minutes before sunrise the map will display highway signs as you and a few minutes after sunset. -
Page 36: Sound
Setting The Default Route Method 1. From the Main Menu screen, tap the Settings icon. 2. Tap Navigation Preferences. 3. Use the drop-down menu to select the default routing method. RoadMate 6230-LM User Manual Page 28... -
Page 37: Avoiding Unpaved Roads
5. The Visible checkbox determines if the speed limit icon is displayed on the screen. 6. Set the number of miles above the speed limit you want the warnings to be alerted or highways and other roads. RoadMate 6230-LM User Manual Page 29... -
Page 38: Keyboard
Serial Number and Software Version.) your receiver. Setting the GPS Position If the Magellan RoadMate receiver is transported over 800 km/500 mi while turned off, it may take a long time to find satellites and establish its location. Setting the GPS position...
