Infinity Alpha
Series
™
The Alpha Series of loudspeakers continues Infinity's
longstanding commitment to accurate sound reproduction.
Our patented Ceramic Metal Matrix Diaphragm
drivers, precision dividing networks and rigid, heavily braced
enclosures combine to deliver uncompromised performance
in any stereo or multichannel home theater system.The Alpha 37c
is the perfect center channel loudspeaker to complete any home
theater system.
U
NPACKING THE
If you suspect damage from transit, report it immediately to
your dealer. Keep the shipping carton and packing materials
for future use.
P
LANNING
Placement
For best results, the Alpha 37c should be placed on top
of, or directly below, the television and aimed toward the
listening area (see Figure 1).
The terminal cup has an adjustable foot to angle the speaker
toward the listening position (see Figure 2).
An Important Note for Proper Installation
The Infinity Alpha 37c is magnetically shielded. When placing it
directly on top of a television, please follow the simple installation
guidelines below to prevent any interference with your television
picture.
1. Turn off the TV that the speaker will be placed on top of.
2. While keeping the front of the speaker facing forward, lift and
place the Alpha 37c on top of the TV.
3. Connect the speaker as described in this owner's guide.
4. You may now turn on the TV.
ALPHA 37c
2
™
(C.M.M.D.)
S
PEAKER
Y
S
OUR
YSTEM
F
1
– This overhead view shows a typical
IGURE
home theater plan.
Left
Center
Front
Channel
Channel
Couch
Left
Surround
Channel
F
2
IGURE
–
+
INPUT
Loosen thumbscrew.
–
+
INPUT
Slide rod down
the desired amount.
–
+
INPUT
Tighten thumbscrew.
Infinity
Right
Subwoofer
Front
(optional)
Channel
Right
Surround
Channel
