SH103PX S KSO103PX S English Operating Instructions OVEN Contents Operating Instructions,1 Warnings,2 Description of the appliance,3 Installation,4 Electrical Connection,4 Start-up and use,6 Modes,7 Precautions and tips,11 Maintenance and care,11 Troubleshooting,14 Afetr Sales Service,15 Guarantee,16...
Warnings WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been...
Description of the appliance Overall view 1. POSITION 1 2. POSITION 2 3. POSITION 3 4. POSITION 4 5. POSITION 5 6. GUIDES for the sliding racks 7. DRIPPING PAN 8. GRILL 9. Control panel Control panel 1. MANUAL COOKING MODE Icons 2.
Installation Centring and fixing Secure the appliance to the cabinet by opening the oven door and inserting 4 screws into the 4 holes on the outer frame. ! Please keep this instruction booklet in a safe place for future reference. If the appliance is sold, given away or moved, please make sure the booklet is also passed on to the new owners so that they may benefit from the advice contained within it.
Page 5
If the appliance is installed with a junction box, an omnipolar circuit breaker APPLIANCE SPECIFICATIONS - with a minimum contact opening of 3mm - should be installed between the appliance and the mains. width 43.5 cm Dimensions* height 32,4 cm Power cable supply connection to the electrical mains: depth 41.5 cm Volume*...
Start-up and use 2. Set the desired time using buttons and . 3. Once you have reached the desired value, press the button again. WARNING! The oven is provided The lit symbol will remind you that the minute minder is on. with a stop system to extract the racks and prevent them from To cancel the minute minder, press the...
Oven light BARBECUE mode The light comes on when the oven door is opened or when a cooking mode starts. The top heating element and the rotisserie spit (where present) are activated. The high and direct temperature of the grill is recommended for food which button can be used to switch on the light at any time.
Programming cooking BEEF mode ! A cooking mode must be selected before programming can take place. Use this function to cook beef, pork and lamb. Place the food inside the oven while it is still cold. The dish may also be placed in a preheated oven. ! Once a cooking mode has been selected, the button is activated;...
Page 9
PIZZA • Use a lightweight aluminium pizza pan. Place it on the rack provided. For a crispy crust, do not use the dripping pan as this extends the total cooking duration and prevents the crust from forming. • If the pizza has a lot of toppings, we recommend adding the mozzarella cheese to the top of the pizza halfway through the cooking process.
Cooking advice table Modes Foods Weight Rack position Preheating Recommended Cooking (in kg) Temperature duration (°C) (minutes) Standard Sliding guide guide Manual rails rails Multilevel* 2 and 4 1 and 3 210-220 20-25 2 and 4 1 and 3 30-35 1 and 3 20-30 2 and 4...
Precautions and tips obligation, that when you dispose of the appliance it must be separately collected. Consumers should contact their local authority or retailer for information ! This appliance has been designed and manufactured in compliance with concerning the correct disposal of their old appliance. international safety standards.
Cleaning the oven door Replacing the light bulb Clean the glass part of the oven door using a sponge and a non-abrasive cleaning product, then dry thoroughly with a soft cloth. Do not use rough To replace the oven light bulb: abrasive material or sharp metal scrapers as these could scratch the surface Remove the glass cover of the Oven...
Page 13
Programming delayed automatic cleaning ! Programming is possible only after selecting the FAST CLEAN mode. 1. Press the button and set the end time using the buttons. 2. Once you have reached the desired end time, press the button again. 3.
Troubleshooting Problem Possible cause Solution The appliance has just been Set the clock. The “Clock button” and the connected to the electricity mains digits on the display flash. or there has been a blackout. A programmed cooking mode There has been a blackout. Reprogram the cooking mode.
Afetr Sales Service No one is better placed to care for your Hotpoint appliance during the course of its working life than us – the manufacturer. Essential Contact Information Hotpoint Service We are the largest service team in the country offering you access to 400 skilled telephone advisors and 1000 fully qualified engineers on call to ensure you receive fast, reliable, local service.
5 Year Parts Guarantee Hotpoint also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time.
