User Manual

DE40C
DE46C
DE55C
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00299B-03

Advertisement

Table of Contents
loading

Related Manuals for Samsung DE40C

Summary of Contents for Samsung DE40C

  • Page 1: User Manual

    User Manual DE40C DE46C DE55C The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. BN46-00299B-03...

  • Page 2: Table Of Contents

    Cleaning Storage Safety Precautions Symbols Electricity and Safety Installation Operation PREPARATIONS Checking the Contents Removing the Packaging (for DE40C and DE46C models only) Removing the Packaging (for DE55C models only) Checking the Components Parts Control Panel Reverse Side Anti-theft Lock...
  • Page 3 Table Of Contents CONNECTING AND USING Before Connecting A SOURCE DEVICE Pre-connection Checkpoints Connecting and Using a PC Connecting to a PC Changing the Resolution Connecting an External Monitor Connecting to a Video Device Connection Using the AV Cable Connection Using the Component Cable Connection Using an HDMI-DVI Cable Connection Using an HDMI Cable Connecting to an Audio System...
  • Page 4 Table Of Contents What is MDC? Connecting to MDC Connection Management Auto Set ID Cloning Command Retry Getting Started with MDC Main Screen Layout Menus Screen Adjustment Sound Adjustment System Setup Tool Settings Other Functions Troubleshooting Guide SCREEN ADJUSTMENT Picture Mode If the input source is PC, DVI or DisplayPort If the input source is AV, Component, HDMI Backlight / Contrast / Brightness /...
  • Page 5 Table Of Contents Advanced Settings Dynamic Contrast Black Tone Flesh Tone RGB Only Mode Colo(u)r Space White Balance 10p White Balance (Off / On) Gamma Expert Pattern Motion Lighting (Off / On) Picture Options Colo(u)r Tone Colo(u)r Temp. Digital Noise Filter MPEG Noise Filter HDMI Black Level Film Mode...
  • Page 6 Table Of Contents MagicInfo Lite Settings Wi-Fi Direct Soft AP AllShare Settings Using the AllShare Play Function Device Name SYSTEM Multi Control Configuring settings for Multi Control Time Clock set Sleep Timer On Timer Off Timer Holiday Management Language Rotate menu Eco Solution Energy Saving Eco Sensor (Off / On)
  • Page 7 Table Of Contents Screen Burn Protection Pixel Shift Timer Immediate Display Side Gray Ticker Video Wall Video Wall Format Horizontal Vertical Screen Position Source AutoSwitch Settings General Max. Power Saving Game Mode BD Wise Menu Transparency Sound Feedback Auto Power Standby Control Lamp Schedule OSD Display...
  • Page 8 Table Of Contents PC Module Power Synced Power-On Synced Power-Off SUPPORT Software Update By USB Alternative Software Contact Samsung Contents Home MagicInfo Lite AllShare Play Source ALLSHARE PLAY What is AllShare Play? Read the following before using AllShare Play with a USB device...
  • Page 9 Table Of Contents Videos / Photos / Music Play Option menu Supported Subtitle and AllShare Play file formats Subtitle Supported image resolutions Supported music file formats Supported Video Formats MAGICINFO LITE File Formats Compatible with MagicInfo Lite Player Contents MagicInfo Lite Player Network Schedule Local Schedule Internal AutoPlay...
  • Page 10 Viewing the details of the content that is running Changing the settings for the content that is running TROUBLESHOOTING Requirements Before Contacting Samsung Customer Service Center GUIDE Testing the Product Checking the Resolution and Frequency Check the followings. Q & A...
  • Page 11 Table Of Contents Optimum Picture Quality and Afterimage Burn-in Prevention Optimum Picture Quality Prevention of Afterimage Burn-in Correct Disposal Correct Disposal of This Product (Waste Electrical & Electronic Equipment) Correct disposal of batteries in this product Terminology INDEX Table Of Contents...

  • Page 12: Before Using The Product

    © 2012 Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.

  • Page 13: Cleaning

    Before Using the Product Cleaning Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched. Take the following steps when cleaning. The following images are for reference only. Real-life situations may differ from what is shown in the images.

  • Page 14: Safety Precautions

    Before Using the Product Safety Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.

  • Page 15: Electricity And Safety

    Before Using the Product Electricity and Safety The following images are for reference only. Real-life situations may differ from what is shown in the images. Warning Do not use a damaged power cord or plug, or a loose power socket. An electric shock or fire may result.

  • Page 16: Installation

    Do not disconnect the power cord while the product is being used. The product may become damaged by an electric shock.  Only use the power cord provided with your product by Samsung. Do not use the power cord with other products. A fire or electric shock may result.
  • Page 17 Before Using the Product Keep the plastic packaging out of the reach of children. Children may suffocate.  Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.) The product may fall and become damaged and/or cause an injury. ...

  • Page 18: Operation

    SAMSUNG time) may seriously affect its performance. Be sure to consult Samsung Customer Service Center if you want to install  the product at such a place. Operation Warning There is a high voltage inside the product.
  • Page 19 Be sure to power off the product and disconnect the power cord when water  or other foreign substances have entered the product. Then contact Samsung Customer Service Center. Product failure, an electric shock or fire may result.  Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.
  • Page 20 Before Using the Product Caution Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels. Activate power-saving mode or a moving-picture screen saver if you will not  be using the product for an extended period of time. Disconnect the power cord from the power socket if you do not plan on using the product for an extended period of time (vacation, etc).
  • Page 21 Before Using the Product Exercise caution when adjusting the product angle or stand height. Your hand or finger may get stuck and injured.  Tilting the product at an excessive angle may cause the product to fall and  an injury may result. Do not place heavy objects on the product.

  • Page 22: Preparations

    Checking the Contents The appearance of the actual product may differ from the images shown. 1.1.1 Removing the Packaging (for DE40C and DE46C models only) Open the packaging box. Be careful not to damage the product when you open the packaging with a sharp instrument.

  • Page 23: Removing The Packaging

    Preparations 1.1.2 Removing the Packaging (for DE55C models only) Remove the black locking device at the bottom of the box. Using the grooves in the box, lift and remove the top of the box. Check the components and remove the styrofoam and plastic bag. The appearance of actual components may differ from the image shown.

  • Page 24: Checking The Components

    Preparations 1.1.3 Checking the Components Contact the vendor where you purchased the product if any components are missing.  The appearance of the components and items sold separately may differ from the image shown.  A stand is not provided with the product. To install a stand, you can purchase one separately. ...
  • Page 25 Preparations Items sold separately The stand is not supplied.  The following items can be purchased at your nearest retailer.  Wall-mount Kit Stand RS232C-Stereo cable DVI cable HDMI-DVI cable DP cable HDMI cable Video cable Component cable Stereo cable AV cable RCA stereo cable External sensor Kit...
  • Page 26 Preparations RS232C(OUT) Adapter RS232C(IN) Adapter The RS232C adapter can be used to connect to another monitor using the D-SUB (9-pin) type RS232C cable. Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the product. 1 Preparations...

  • Page 27: Parts

    Preparations Parts 1.2.1 Control Panel Panel Key POWER Remote sensor Speaker Panel Key Buttons Description Power on the product. If you press the [ ] button when the product is turned on, the control menu will be displayed. To exit the OSD menu, press and hold the panel key for at least one second.
  • Page 28 Preparations Control menu If you press the [ ] button on the panel key ("1.2.1 Control Panel") when the product is turned on, the control menu will be displayed. CONTENT Return Icons Description Select the connected input source. Move the panel key right to select Source ] in the control menu.

  • Page 29: Reverse Side

    Preparations 1.2.2 Reverse Side The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. RS232C IN RS232C IR / AMBIENT SENSOR IN AUDIO RGB / DVI / HDMI / AV / COMPONENT AUDIO IN POWER...

  • Page 30: Anti-Theft Lock

    Preparations Port Description Receives the remote control signal via the external sensor board and [IR OUT] outputs the signal via LOOPOUT. [RJ45] Connects to MDC using a LAN cable. Assembling the Holder-Wire stand 1.2.3 Anti-theft Lock An anti-theft lock allows you to use the product securely even in public places. ...

  • Page 31: Remote Control

    Preparations 1.2.4 Remote Control Using other display devices in the same space as the remote control of this product can cause the  other display devices to be inadvertently controlled. Remote control button functions may differ for different products.  Power on the product.
  • Page 32 Preparations Adjusting the OSD with the Remote Control Open the OSD menu. Select from Picture, Sound, Network, System Support in the displayed OSD menu screen. Change settings as desired. Finish setting. Close the onscreen display (OSD) menu. To place batteries in the remote control 1 Preparations...
  • Page 33 Preparations Remote Control Reception Range Use the remote control within 7m to 10m from the sensor on the product at an angle of 30˚ from the left and right. Store used batteries out of reach of children and recycle.  Do not use a new and used battery together.

  • Page 34: Connection Using An Ir Stereo Cable

    Preparations 1.2.5 Connection Using an IR Stereo Cable Turn off the device before connecting the External Sensor Kit. After it is connected, turn on the device. Controlling more than one display product using your remote control IR OUT AMBIENT SENSOR IN Connect the [IR OUT] port on the product to the [IR / AMBIENT SENSOR IN] port on the other ...

  • Page 35: Before Installing The Product (Installation Guide)

    Make sure to install the specified wall mount.  1.3.1 Tilting Angle and Rotation Contact Samsung Customer Service Center for further details. 15 Û The product can be tilted at a maximum angle of 15 from a perpendicular wall surface.

  • Page 36: Ventilation

    35 C. Figure 1.1 Side view 2. Installation on an Indented Wall Contact Samsung Customer Service Center for further details. Figure 1.3 Top view Plane view Minimum 40 mm...

  • Page 37: Dimensions

    Preparations Dimensions Unit: mm Model name DE40C 919.6 885.6 498.2 532.0 35.1 DE46C 1054.5 1018.1 572.7 608.5 35.1 DE55C 1249.5 1209.6 680.4 721.0 35.1 All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice.

  • Page 38: Installing The Wall Mount

    We recommend you contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.
  • Page 39 Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury  when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

  • Page 40: Remote Control

    Preparations Remote Control 1.6.1 Cable Connection RS232C Cable Interface RS232C (9 pins) TxD (No. 2), RxD (No. 3), GND (No. 5) Bit rate 9600 bps Data bits 8 bit Parity None Stop bit 1 bit Flow control None Maximum length 15m (only shielded type) Pin assignment ...
  • Page 41 Preparations RS232C cable  Connector: 9-Pin D-Sub to Stereo Cable -P1- -P1- -P2- -P2- --------> STEREO Female <-------- PLUG (3.5ø) --------- LAN Cable Pin assignment  1 2 3 4 5 6 7 8 Pin No. Standard Color Signal White and orange Orange White and green Blue...
  • Page 42 Preparations Connector: RJ45  Direct LAN cable (PC to HUB) RJ45 MDC RJ45 MDC Signal Signal <--------> <--------> <--------> <--------> Cross LAN cable (PC to PC) RJ45 MDC Signal Signal <--------> <--------> <--------> <--------> 1 Preparations...

  • Page 43: Connection

    Preparations 1.6.2 Connection Connection 1  RS232C RS232C RS232C RS232C Connection 2  RJ45 RJ45 1 Preparations...
  • Page 44 Preparations Connection 3  RJ45 RS232C RS232C RS232C RS232C 1 Preparations...

  • Page 45: Control Codes

    Preparations 1.6.3 Control Codes Viewing control state (Get control command) Header Command Data length Checksum Command 0xAA type Controlling (Set control command) Header Command Data length Data Checksum Command 0xAA Value type Command Command type Command Value range Power control 0x11 Volume control 0x12...

  • Page 46: Power Control

    Preparations To control all devices connected by a serial cable simultaneously irrespective of IDs, set the ID as  "0xFE" and transmit commands. Commands will be executed by each device but ACK will not respond. Power control Function  A product can be powered on and off using a PC. Viewing power state (Get Power ON / OFF Status) ...

  • Page 47: Volume Control

    Preparations Volume control Function  The volume of a product can be adjusted using a PC. Viewing volume state (Get Volume Status)  Header Command Data length Checksum 0xAA 0x12 Setting the volume (Set Volume)  Header Command Data length Data Checksum 0xAA...

  • Page 48: Input Source Control

    Preparations Input source control Function  The input source of a product can be changed using a PC. Viewing input source state (Get Input Source Status)  Header Command Data length Checksum 0xAA 0x14 Setting the input source (Set Input Source) ...
  • Page 49 Preparations  Header Command Data length Ack/Nak r-CMD Val1 Checksum "Input 0xAA 0xFF ‘A’ 0x14 Source" "Input Source": An input source code to be set on a product  Header Command Data length Ack/Nak r-CMD Val1 Checksum 0xAA 0xFF ‘N’ 0x14 "ERR"...

  • Page 50: Screen Mode Control

    Preparations Screen Function  The screen mode of a product can be changed using a PC. Screen mode cannot be controlled when the Video Wall function is enabled. This control can only be used on models that include a TV. Viewing screen status (Get Screen Mode Status) ...

  • Page 51: Screen Size Control

    Preparations Screen size control Function  The screen size of a product can be changed using a PC. Viewing the screen size (Get Screen Size Status)  Header Command Data length Checksum 0xAA 0x19  Header Command Data length Ack/Nak r-CMD Val1 Checksum...

  • Page 52: Pip On/Off Control 0X3C 0~1

    Preparations PIP On/Off control Function  The PIP mode of a product can be turned on or off using a PC. Only available on models that have the PIP function.  The mode cannot be controlled if Video Wall is set to On. ...
  • Page 53 Preparations Auto adjustment control (PC and BNC only) Function  Automatically adjust the PC system screen using a PC. Viewing auto adjustment state (Get Auto Adjustment Status)  None Setting auto adjustment (Set Auto Adjustment)  Header Command Data length Data Checksum "Auto...

  • Page 54: Video Wall Mode Control 0X5C 0~1

    Preparations Video Wall Mode Control Function  Video Wall mode can be activated on a product using a PC. This control is only available on a product whose Video Wall is enabled. This function is not available in MagicInfo. Viewing video wall mode (Get Video Wall Mode) ...

  • Page 55: Safety Lock 0X5D 0~1

    Preparations Safety Lock Function  PC can be used to turn the Safety Lock function on or off on a product. This control is available regardless of whether or not the power is turned on. Viewing the safety lock state (Get Safety Lock Status) ...

  • Page 56: Connecting And Usinga Source Device

    Connecting and Using a Source Device Before Connecting Check the following before you connect this product with other devices. Devices that can be connected to this product include PCs, camcorders, speakers, set top boxes and DVD/Blu-ray Disc players. 2.1.1 Pre-connection Checkpoints Before connecting a source device, read the user manual provided with it.

  • Page 57: Connecting And Using A Pc

    Connecting and Using a Source Device Connecting and Using a PC 2.2.1 Connecting to a PC Do not connect the power cable before connecting all other cables.  Ensure you connect a source device first before connecting the power cable. A PC can be connected to the product in a variety of ways.
  • Page 58 Connecting and Using a Source Device Connection Using an HDMI-DVI Cable HDMI IN RGB / DVI / HDMI / AV / COMPONENT AUDIO IN When you connect a PC to the product using an HDMI-DVI cable, set Edit Name DVI PC to access video and audio content stored on the PC.
  • Page 59 Connecting and Using a Source Device Connection Using an DP Cable DP IN 2 Connecting and Using a Source Device...

  • Page 60: Changing The Resolution

    Connecting and Using a Source Device 2.2.2 Changing the Resolution Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture quality. The picture quality of TFT-LCDs may degrade if the optimum resolution is not selected. Changing the Resolution on Windows XP Go to Control Panel Display...
  • Page 61 Connecting and Using a Source Device Changing the Resolution on Windows 7 Go to Control Panel Display Screen Resolution, and change the resolution. 2 Connecting and Using a Source Device...

  • Page 62: Connecting An External Monitor

    Connecting and Using a Source Device Connecting an External Monitor DP OUT DP IN The following images are for reference only. Real-life situations may differ from what is shown in the images. 2 Connecting and Using a Source Device...

  • Page 63: Connecting To A Video Device

    Connecting and Using a Source Device Connecting to a Video Device Do not connect the power cable before connecting all other cables.  Ensure you connect a source device first before connecting the power cable. You can connect a video device to the product using a cable. ...

  • Page 64: Connection Using An Hdmi-Dvi Cable

    Connecting and Using a Source Device 2.4.3 Connection Using an HDMI-DVI Cable HDMI IN RGB / DVI / HDMI / AV / COMPONENT AUDIO IN Audio will not be enabled if the product is connected to a video device using an HDMI-DVI cable. ...

  • Page 65: Connecting To An Audio System

    Connecting and Using a Source Device Be sure to use an HDMI cable with a thickness of 14 mm or less.  Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection  error may occur.

  • Page 66: Connecting The Network Box (Sold Separately)

    Connecting and Using a Source Device Connecting the network box (Sold separately) 2.5.1 MagicInfo To use MagicInfo, a network box (sold separately) must be connected to the product. For details on how to connect to a network box, refer to the user's manual provided with the network box upon purchase.
  • Page 67 Connecting and Using a Source Device Select the default application you want to run when MagicInfo starts. MagicInfo Setup Wizard - v.1.12 Select Application - step 1 MagicInfo Pro (LAN, WAN based version) MagicInfo-i Premium (Web-based version) Select Later < Back(B) Next(N) >...
  • Page 68 Connecting and Using a Source Device Select a language. (The default language is English.) MagicInfo Setup Wizard - v.1.12 Select Language -step 3 Select the language you want to install on the system for menus and dialogs. Current Language Engilsh Chinese [Traditional] German English...
  • Page 69 Connecting and Using a Source Device Double-check the settings you have just configured. MagicInfo Setup Wizard - v.1.12 Setup Information 1. Application : MagicInfo Pro [LAN,WAN based version\ 2. Internet Protocol [TCP/IP] IP : 192.168.0.102 3. Language : English 4. Screen Type : Landscape Do not show again <...

  • Page 70: Changing The Input Source

    Connecting and Using a Source Device Changing the Input source 2.6.1 Source MENU Support Contents Home Source ENTER Source allows you to select a variety of sources and change source device names. Source You can display the screen of a source device connected to the product. Select a source from Source List to display the screen of the selected source.

  • Page 71: Using Mdc

    Using MDC MDC (Multiple Display Control) is an application that allows you to easily control multiple display devices simultaneously using a PC. Configuring Settings for Multi Control MENU System Multi Control ENTER Assign an individual ID to your product. 3.1.1 Configuring settings for Multi Control ID Setup ...

  • Page 72: Mdc Program Installation/Uninstallation

    Using MDC MDC Program Installation/Uninstallation 3.2.1 Installation Insert the installation CD into the CD-ROM drive. Click the MDC Unified installation program. If a software installation window is not displayed on the main screen, install with the MDC Unified execution file in the MDC folder on the CD. Select a language for installation.

  • Page 73: What Is Mdc

    Using MDC What is MDC? Multiple display control "MDC" is an application that allows you to easily control multiple display devices simultaneously using a PC. 3.3.1 Connecting to MDC Using MDC via RS-232C (serial data communications standards) An RS-232C serial cable must be connected to the serial ports on the PC and monitor. RS232C IN / OUT 3 Using MDC...
  • Page 74 Using MDC Using MDC via Ethernet Enter the IP for the primary display device and connect the device to the PC. One display device can connect to another using an RS-232C serial cable. Connection using a direct LAN cable RJ45 Multiple products can be connected using the [RJ45] port on the product and the LAN ports on the HUB.

  • Page 75: Connection Management

    Using MDC 3.3.2 Connection Management Connection management includes the Connection list and Connection list modification options. Connection list - Connection list shows the details of the connections such as connection setting (IP/ COM, Port No, MAC, and Connection Type), connection status, Set ID Range, and detected devices. Each connection can contain a maximum of 100 devices connected in serial daisy-chain fashion.

  • Page 76: Auto Set Id

    Using MDC 3.3.3 Auto Set ID Auto Set ID feature assigns a Set ID for all the LFDs connected in daisy-chain of a selected connection. There can be a maximum of 100 LFDs in a connection. The Set ID is assigned sequentially in the daisy- chain running from 1 to 99, and then finally to Set ID 0.

  • Page 77: Cloning

    Using MDC 3.3.4 Cloning Using the Cloning feature, you can copy the setting of one LFD and apply it to multiple selected LFDs. You can select specific tab categories or all tab categories for cloning, using the copy setting option window.

  • Page 78: Command Retry

    Using MDC 3.3.5 Command Retry This feature is used to specify the maximum number of times the MDC command will be retried in case of there being no reply or a corrupted reply from an LFD. The retry count value can be set using the MDC options window.

  • Page 79: Getting Started With Mdc

    Using MDC 3.3.6 Getting Started with MDC To start the program, click Start Programs Samsung MDC Unified. Click Add to add a display device. If the connection is established via RS232C, go to Serial and specify the COM Port. ...
  • Page 80 Using MDC If the connection is established via Ethernet, enter the IP that was entered for the display  device. 3 Using MDC...

  • Page 81: Main Screen Layout

    Using MDC 3.3.7 Main Screen Layout Change the status of a display device or the properties of the program. Menu Bar View a list of connected display devices or device groups. Device Category View a list of schedules for display devices. Schedule Category Select the display device you want to adjust.

  • Page 82: Menus

    Using MDC 3.3.8 Menus You can power on or off a selected device or change the input source or volume of the device. Choose display devices from the list of sets, and select the Home tab. Home Select an item and change the corresponding setting. Power On: Power on a selected display.
  • Page 83 Using MDC Alert Fault Device  This menu shows a list of display devices which have following errors - fan error, temperature  error, brightness sensor error, or lamp error. Select a display device from the list. The Repair button will be enabled. Click the refresh button to refresh the error status of the display device.

  • Page 84: Screen Adjustment

    Using MDC 3.3.9 Screen Adjustment The screen settings (contrast, brightness, etc.) can be adjusted. Choose display devices from the list of sets, and select the Picture tab. Custom Select an item and change the corresponding screen setting. Color and Tint are not available if the input source is PC. ...
  • Page 85 Using MDC Green Customize the intensity of green color for the selected display device.  Blue Customize the intensity of blue color for the selected display device.  Options Dynamic Contrast Adjust the Dynamic Contrast for the selected display device. Gamma Control Change the gamma value for the selected display.
  • Page 86 Using MDC HDMI Black Level Adjust the HDMI Black Level for the selected display device. Size Picture Size Adjust the screen size for the selected display device. The Detail item will be disabled if Picture Size is set to a mode that does not support detailed configuration.

  • Page 87: Sound Adjustment

    Using MDC 3.3.10 Sound Adjustment You can change the sound settings. Choose display devices from the list of sets, and select the Sound tab. The Bass or Treble item will be disabled if the item is not supported by the selected set. Bass Adjust the bass for the selected display.

  • Page 88: System Setup

    Using MDC 3.3.11 System Setup Choose display devices from the list of sets, and select the System tab. Video Wall The Video Wall function can be used to display part of a whole picture or repeat the same picture on each of connected multiple display devices.
  • Page 89 Using MDC Select the number of horizontal display devices. A maximum of 15 displays can be arranged in a row. A maximum of 6 can be assigned to V if 15 is assigned to H. Select the number of vertical display devices. A maximum of 15 displays can be arranged in a row.
  • Page 90 Using MDC Basic information required to adjust PIP will appear in the menu screen. PIP will be disabled when Video Wall is ON.  Note that Picture Size is disabled when PIP is ON.  PIP Size View the PIP Size of the current display. PIP Source Select a PIP input source.
  • Page 91 Using MDC General User Auto Color Automatically adjust the screen colors. Available only in PC mode. Auto Power Set the product to automatically power on. Standby Control Set the standby mode to activate if an input source is not detected. Fan &...
  • Page 92 Using MDC Security Safety Lock Lock the on-screen menus. To unlock the menus, set Safety Lock to Off. Button Lock Lock the buttons on the display device. To unlock the buttons, set Button Lock to Off. OSD Display Source OSD Select whether to display a message when the Source is changed.
  • Page 93 Using MDC Time Clock Set Change the current time on the selected display device according to the time set on a PC. If the time is not set on the display device, null values will be displayed. Timer On Time: Set the time to power on the selected display device. ...
  • Page 94 Using MDC Once: Activate the timer only one time.  EveryDay: Activate the timer every day.  Mon~Fri: Activate the timer from Monday through Friday.  Mon~Sat: Activate the timer from Monday through Saturday.  Sat~Sun: Activate the timer on Saturdays and Sundays. ...
  • Page 95 Using MDC Screen Burn Protection Pixel Shift Move the screen slightly at specified time intervals to prevent screen burn-in. Screen Saver This function prevents screen burn-in when the screen of the selected display device is left idle for an extended period of time. Interval: Set the interval to activate the Screen Saver.
  • Page 96 Using MDC Safety Screen The Safety Screen function can be used to prevent screen burn-in when a stationary image displays on the screen of a display device for an extended period of time. Lamp Control Lamp Control is used to adjust the backlight to reduce power consumption. Automatically adjust the backlight of the selected display device at a specified time.

  • Page 97: Tool Settings

    Using MDC 3.3.12 Tool Settings Security Panel Control Turn on or off the screen of a display device. Remote Control Enable or disable the remote control. Reset Reset Picture Reset the screen settings. Reset Sound Reset the sound settings. Reset System Reset the system settings.
  • Page 98 Using MDC Edit Column Options Language: Select a language to use in the MDC program. After selecting a language, restart the MDC program to use the selected language. Command Retry Count: Specify the number of retry attempts when a command fails. Error Status Interval: Specify the time interval to query the display device in order to check if "Fault Device"...
  • Page 99 Using MDC Edit Column Select the items you want to display in the list of sets. Information View the program information. 3 Using MDC...

  • Page 100: Other Functions

    Using MDC 3.3.13 Other Functions Resizing a Window Place the mouse pointer on a corner of the program window. An arrow will appear. Move the arrow to customize the size of the program window. 3 Using MDC...
  • Page 101 Using MDC Group Management Creating Groups Create groups and manage the list of sets on a group basis. Duplicate group names cannot be used. Right-click and select Group Edit in the display device list section on the left side of the program window.
  • Page 102 Using MDC Add on the sub level: Create a sub-group under the selected group.  Enter the group name. Deleting Groups Select a group name, and click Edit. In the Edit Group window displayed, click Delete. Click Yes. The group will be deleted. Renaming Groups Select a group name, and click Edit.
  • Page 103 Using MDC Schedule Management Creating Schedules Create and register a schedule on a group basis. Click All Schedule List in the schedule section on the left side of the program window. The Add button will be enabled in the middle. Click the Add button.
  • Page 104 Using MDC Click Add below the Device Group item, and select the group you want to add a schedule to. Select Date&Time/Action and click OK. The schedule will be added and a list of schedules will appear in the set list window. Device Group: Select a group.

  • Page 105: Troubleshooting Guide

    Using MDC 3.3.14 Troubleshooting Guide Issue Solution The display you want to control Check the connection of the RS232C cable (check that the does not appear on the system cable is properly connected to appropriate serial port). information chart. Check that another display with a duplicate ID is not connected.
  • Page 106 Using MDC How display properties are shown when multiple displays are used When no display is selected: The default value is displayed. When one display is selected: Settings for the selected display are displayed. When two displays are selected (e.g. in sequence of ID 1 and ID 3): The settings for ID 1 are displayed before the settings for ID 3.

  • Page 107: Screen Adjustment

    Screen Adjustment Configure the Picture settings (Brightness, Colo(u)r Tone, etc.). The layout of the Picture menu options may vary depending on the product. Picture Mode MENU Picture Picture Mode ENTER Select a picture mode (Picture Mode) suitable for the environment where the product will be used. Different Picture Mode options are displayed depending on the current input source.

  • Page 108: Picture Mode

    Screen Adjustment 4.1.2 If the input source is AV, Component, HDMI Dynamic: This mode is suitable when the ambient light is bright.  Standard: This mode is generally suitable for any environment.  Natural: Suitable for reducing eye strain.  Movie: This mode reduces eye fatigue.

  • Page 109: Picture Size

    Screen Adjustment Screen Adjustment MENU Picture Screen Adjustment ENTER Screen Adjustment provides various picture size and aspect ratio options. Select an option using the arrow keys, and the press [ ]. Use the arrow keys to select an option in the sub-menu, and then press [ Different Screen Adjustment...

  • Page 110: Zoom/Position

    Screen Adjustment Do not set your product to 4:3 format for a long time. The borders displayed on the left and right, or top and bottom of the screen may cause image retention (screen burn) which is not covered by the warranty.

  • Page 111: Pc Screen Adjustment

    Screen Adjustment Press the button to select Zoom/Position. Select the Zoom or Position. Press the [ ] button. Press the / / / button to move the picture. Press the [ ] button. Select Close by pressing the buttons sequentially. If you want to reset the picture to its original position, select Reset in the...

  • Page 112: Advanced Settings

    Screen Adjustment Advanced Settings MENU Picture Advanced Settings ENTER To use, select an option using the up and down arrow keys, and then press [ ]. Use the arrow keys to change the value or setting, and then press [ Advanced Settings Dynamic Contrast Black Tone...

  • Page 113: Dynamic Contrast

    Screen Adjustment Input Source Picture Mode Advanced Settings Component, HDMI Standard Dynamic Contrast Black Tone Flesh Tone Only Mode Colo(u)r Space White Balance Gamma Expert Pattern Motion Lighting Movie Dynamic Contrast Black Tone Flesh Tone Only Mode Colo(u)r Space White Balance White Balance Gamma Expert Pattern...

  • Page 114: White Balance (Off / On)

    Screen Adjustment Reset: Resets the White Balance to its default settings.  4.5.7 10p White Balance (Off / On) Controls the white balance in 10 point interval by adjusting the red, green, and blue brightness. Interval: Select interval to adjust. ...

  • Page 115: Picture Options

    Screen Adjustment Picture Options MENU Picture Picture Options ENTER Select an option using the arrow keys, and the press [ ]. Use the arrow keys to change the setting, and then press [ Picture Options Colour Tone Colour Temp. 10000K Digital Noise Filter MPEG Noise Filter HDMI Black Level...

  • Page 116: Colo(U)R Tone

    Screen Adjustment Input source Picture Mode Picture Options DisplayPort Information Colo(u)r Tone Colo(u)r Temp Dynamic Backlight Advertisement Colo(u)r Tone Colo(u)r Temp Digital Noise Filter MPEG Noise Filter Dynamic Backlight Calibration Dynamic Backlight HDMI Dynamic, Natural, Colo(u)r Tone Colo(u)r Temp Digital Noise Filter Movie, Standard MPEG Noise Filter...

  • Page 117: Hdmi Black Level

    Screen Adjustment Medium High Auto  4.6.5 HDMI Black Level Selects the black level on the screen to adjust the screen depth. Normal  Available only in HDMI mode (AV Timing : 480p, 576p, 720p, 1080i, 1080p). 4.6.6 Film Mode Sets the product to automatically sense and process film signals from all sources and adjust the picture for optimum quality.

  • Page 118: Sound Adjustment

    Sound Adjustment Configure the sound (Sound) settings for the product. Sound Mode MENU [ Sound Sound Mode ENTER Use the up and down arrow keys to select an option, and then press [ Sound Sound Mode Standard Sound Effect Speacker Settings Reset Sound The displayed image may differ depending on the model.

  • Page 119: Sound Effect

    Sound Adjustment Sound Effect MENU [ Sound Sound Effect ENTER Speaker Select is set to External, Sound Effect is disabled.  Available only when Sound Mode is set to Standard.  Virtual Surround (Off / On)  This function provides a virtual 5.1 channel surround sound experience through a pair of speakers using HRTF(Head Related Transfer Function) technology.

  • Page 120: Speaker Settings

    Sound Adjustment Speaker Settings MENU [ Sound Speaker Settings ENTER Speaker Select (External / Internal)  If you are listening to the sound track of a broadcast or movie through an external receiver, you may hear a sound echo caused by the difference in decoding speed between the products speakers and the speakers attached to your audio receiver.

  • Page 121: Network

    Network Network Setting 6.1.1 Connecting to a Wired Network There are three ways to attach your product to your LAN using cable. You can attach your product to your LAN by connecting the LAN port on the back of your product to ...

  • Page 122: Wired Network Settings

    Set the network connection to use Internet services such as perform software upgrades. Network Settings No network cable or Samsung Wireless LAN Adapter connected. Please plug in a network cable or a Samsung Wireless Start LAN Adapter. Cancel The displayed image may differ depending on the model.
  • Page 123 Network Automatic Network Settings Use the Automatic Network Settings when connecting your product to a network that supports DHCP. To set up your product cable network connection automatically, follow these steps. How to set up automatically Go to the Network Settings screen.
  • Page 124 Network If you make a mistake when entering a number, re-enter the number to correct it. You can also press the up or down arrow button to change the number one unit at a time. When done entering the Address, press [ Press the down arrow key to go to the Subnet Mask fields, and then press [...

  • Page 125: Connecting To A Wireless Network

    Network 6.1.3 Connecting to a Wireless Network To connect your product to your network wireless, you need a wireless router or modem and a Samsung Wireless LAN adapter (WIS10ABGN, WIS12ABGNX) , which you connect to your product back or side panel USB port.

  • Page 126: Wireless Network Setting

    Network The product may not recognize the “Samsung Wireless LAN adapter” if you connect it to the  product with a USB hub or USB extension cable other than the cable supplied with the product. 6.1.4 Wireless Network Setting Automatic Network Setup...
  • Page 127 Network Manual Network Setup Use the Manual Network Settings when connecting your product to a network that requires a Static IP address or if the automatic connection process has failed. Getting the Network Connection Values To view the Network connection values on most Windows computers, follow these steps. Right click the Network icon on the bottom right of the screen.

  • Page 128: Wps(Pbc)

    Network Repeat the entry process for each field in the Address. If you make a mistake when entering a number, re-enter the number to correct it. You can also press the button to change the number one unit at a time. When done entering the Address, press [ Press the...

  • Page 129: Network Status

    Network Network Status MENU Network Network Status ENTER You can check the current network and Internet status. Network Status Your wireless network and Internet connection are setup and ready to use. MAC Address 00 : 12 : fb : df : 29 : 76 IP Address ***.

  • Page 130: Magicinfo Lite Settings

    Network MagicInfo Lite Settings MENU Network MagicInfo Lite Settings ENTER Server Server (Setting the MagicInfo Lite Server IP)  Enter the server IP address and port number. Use 7001 as the port number.  If unable to connect to the server using port number 7001, check with your server administrator to find the correct port number and then change the port number.

  • Page 131: Wi-Fi Direct

    Network Wi-Fi Direct MENU Network Wi-Fi Direct ENTER Set to connect the product to wireless mobile devices. Using this function, you can connect wireless mobile devices with your product directly without a router. To use this function, your mobile device should be supported by the Wi-Fi Direct.

  • Page 132: Allshare Settings

    Network Return  Returns to the screen before entering the security key. The security key should consist of more than 8 digits.  Input the generated security key into the device you want to connect.  If network does not operate normally, check the security key again. An incorrect security key ...

  • Page 133: Device Name

    Network Device Name Select or enter a device name. This name can be shown on network remote controls over the network. 6 Network...

  • Page 134: System

    System Multi Control MENU System Multi Control ENTER Assign an individual ID to your product. 7.1.1 Configuring settings for Multi Control ID Setup  Assign an ID to a set. (Range: 0~99) Press to select a number, and press [ ID Input ...

  • Page 135: Time

    System Time MENU System Time ENTER You can configure Clock Set Sleep Timer. You can also set the product to automatically turn on or off at a specified time using the Timer function. 7.2.1 Clock set Set the clock to use the various various timer features of the product. Changing the Setting for Clock Clock Set ...

  • Page 136: On Timer

    System 7.2.3 On Timer On Timer so that your product turns on automatically at a time and on a day of your choosing. Timer: Set the on timer by making a selection from one of the seven options. Ensure you set the ...

  • Page 137: Holiday Management

    System 7.2.5 Holiday Management Timer will be disabled during a period specified as a holiday. Setting Holiday Management Add: Specify the period you want to add as a holiday.  Select the start and end dates of the holiday you want to add using the buttons, and click ...

  • Page 138: Language

    System Language MENU System Language ENTER Set the menu language. A change to the language setting will only be applied to the onscreen menu display. It will not be applied to other functions on your PC. Rotate menu MENU System Rotate menu ENTER Landscape: Display the menu in landscape mode (default).

  • Page 139: Eco Sensor (Off / On)

    System 7.5.2 Eco Sensor (Off / On) To enhance your power savings, the picture settings will automatically adapt to the light in the room. Adjusting the Backlight setting under Picture while Eco Sensor is on will disable the Off. Min. Backlight: When Eco sensor is On, you can manually adjust the minimum screen brightness.

  • Page 140: Security

    System Security MENU System Security ENTER Every time you access the Security functions, the PIN screen will appear and the default PIN number is “0-0-0-0". The PIN screen closes and the Security menu appears. Security Safety Lock Button Lock Change PIN The displayed image may differ depending on the model.

  • Page 141: Pip

    System MENU System ENTER If you have set Double ( ) mode in (Picture-in-Picture), you cannot adjust the Picture  Size. For PIP sound, refer to the Sound Select instructions.  If you turn the product off while watching in the PIP mode, the PIP function is reset to off. When ...

  • Page 142: Screen Burn Protection

    System 2 hours 4 hours 8 hours 10 hours  Screen Burn Protection MENU System Screen Burn Protection ENTER To reduce the possibility of screen burn, this unit is equipped with Pixel Shift screen burn prevention technology. Pixel Shift moves the picture slightly on the screen. The Pixel Shift Time setting allows you to program the time between movements of the picture in minutes.

  • Page 143: Timer

    System 7.9.2 Timer You can set the timer for Screen Burn Protection. Timer  Repeat: Display the image retention-preventive pattern set in Mode at specified time intervals  (Period). Period Time can be configured when Repeat is selected. Interval: Display the image retention-preventive pattern set in Mode for a specified period of time ...

  • Page 144: Side Gray

    System 7.9.4 Side Gray When the screen is set to aspect ratio, adjust the brightness of white margins on sides to protect the screen. Light Dark  7.10 Ticker Input text while a video or image is displayed and display the text on the screen. ...

  • Page 145: Video Wall

    System 7.11 Video Wall MENU System Video Wall ENTER Customize the layout of multiple displays that are connected to form a video wall. In addition, display part of a whole picture or repeat the same picture on each of the connected multiple displays. To display multiple images, refer to MDC Help or the MagicInfo user guide.

  • Page 146: Horizontal

    System 7.11.3 Horizontal This function automatically divides the screen according to the specified number of horizontal displays. Enter the number of horizontally arranged displays. The horizontal screen will automatically be divided according to the number entered. A maximum of 15 displays can be assigned to the horizontal arrangement. The screen can be divided into a maximum of 100 screens (horizontal and vertical screens ...

  • Page 147: Screen Position

    System 7.11.5 Screen Position You can customize the arrangement of split screens by moving displays identified with a number using Screen Position function. Select Screen Position to display the arrangement of displays (identified with a number) specified according to the Horizontal or Vertical settings. To customize the arrangement, move a number (display) using the direction buttons on the remote control and press [ A maximum of 100 displays can be arranged in Screen...

  • Page 148: Source Autoswitch Settings

    System 7.12 Source AutoSwitch Settings MENU System Source AutoSwitch Settings ENTER Turning on the display with Source AutoSwitch On, and the previous video source selection is not active, the display will automatically search the different video input sources for active video. Source AutoSwitch ...

  • Page 149: General

    System 7.13 General MENU System General ENTER General Max. Power Saving Game Mode BD Wise Menu Transparency Medium Sound Feedback Auto Power Standby Control Auto The displayed image may differ depending on the model. 7.13.1 Max. Power Saving Turns off the product to reduce power consumption after the PC has been left idle for a specified period of time.

  • Page 150: Bd Wise

    System 7.13.3 BD Wise Provides the optimal picture quality for Samsung DVD, Blu-ray and Home Theater products which support Wise. When BD Wise is turned On, the picture mode is automatically changed to the optimal resolution. Available when you connect Samsung products that support...

  • Page 151: Osd Display

    System 7.13.9 OSD Display Displays or hides a menu item on the screen. Source OSD No Signal OSD MDC OSD  7.13.10 Power On Adjustment You can set the warm-up time for the screen to turn on after the power button is pressed. (Range: 0 – 50 seconds) A warm-up time that is too short may damage the product due to overvoltage.

  • Page 152: Anynet+(Hdmi-Cec)

    Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it. You can only control Anynet+ devices using the product remote control, not the buttons on the ...

  • Page 153: Auto Turn Off (No / Yes)

    System Anynet+ Menu The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the product. Anynet+ Menu Description View PC Changes Anynet+ mode to PC mode. Device List Shows the Anynet+ device list. (device_name) MENU Shows the menu of the connected device menus.
  • Page 154 System Troubleshooting for Anynet+ Problem Possible Solution Anynet+ does not work. Check if the device is an Anynet+ device. The Anynet+ system  supports Anynet+ devices only. Check if the Anynet+ device power cord is properly connected.  Check the Anynet+ device’s Video/Audio/HDMI cable ...

  • Page 155: Divx® Video On Demand

    System 7.15 DivX® Video On Demand MENU System DivX® Video On Demand ENTER Shows the registration code authorized for the product. If you connect to the DivX web site and register using that code, you can download the VOD registration file. For more information about DivX®...

  • Page 156: Pc Module Power

    System 7.18 PC Module Power MENU System PC Module Power ENTER The PC module can be turned on/off separately from the LFD. PC module: Refers to network boxes or PIM. 7.18.1 Synced Power-On To turn on the PC module without turning on the LFD, select Off. ...

  • Page 157: Support

    Support Software Update MENU Support Software Update ENTER Software Update menu lets you upgrade your products software to the latest version. Current Version: This is the software version already installed in the product.  Be careful not to turn off the power until the upgrade is complete. The product will turn off and on automatically after completing the software update.

  • Page 158: Contact Samsung

    Support Contact Samsung ENTER [ MENU Support Contact Samsung View this information when your product does not work properly or when you want to upgrade the software. You can find information regarding our call centers and how to download products and software.
  • Page 159 Support 8.3.3 Source Source allows you to select a variety of sources and change source device names. You can display the screen of a source device connected to the product. Select a source from Source List to display the screen of the selected source. The input source can also be changed by using the SOURCE button on the remote control.

  • Page 160: Allshare Play

    Before connecting a USB device to the product, back up files to ensure your data is not damaged or  lost. Samsung Electronics is not liable for any damage or loss of data. Do not remove a USB device while it is loading.
  • Page 161 AllShare Play The screensaver activates if the product is left idle for a period of time specified in Auto Protection  Time. Power-saving mode on some external hard disk drives may automatically deactivate after  connecting to the product. File system and formats Allshare play may not function properly with unlicensed multimedia files.

  • Page 162: Using A Usb Device

    AllShare Play 9.1.2 Using a USB device Connecting a USB device Turn on your product. Connect a USB device containing photo, music and/or movie files to the USB port on the back or side panel of the product. A message "New device connected"...

  • Page 163: Connecting To A Pc Over A Network

    To view content saved on the PC, connect the product and PC to the same wireless router and visit  http://www.samsung.com to download the AllShare PC software. Ensure the product and PC are connected to the same network subnet. All IP addresses are made ...

  • Page 164: Using The Dlna Features

    Additional software may need to be installed on your mobile device. Refer to the mobile device user manual for details. A compatibility issue may occur if you play video after connecting your Samsung display product to a DLNA server made by a different manufacturer.

  • Page 165: Using The Basic Allshare Play Features

    AllShare Play Using the Basic AllShare Play Features MENU Support Contents Home AllShare Play ENTER [ AllShare Play A ll / My List / Recently Played My List Recently played files will be displayed here. Videos What's new Updated files will be displayed here. Photos Playlist Music...

  • Page 166: Playing Selected Files

    AllShare Play 9.2.2 Playing Selected Files Select files from the list of Videos, Photos, or Music files. Press TOOL on the remote control and select Play Selection. The option does not appear if a folder is highlighted by the cursor. Select files and press Play.

  • Page 167: Creating A Playlist (Playlist)

    AllShare Play 9.2.4 Creating a Playlist (Playlist) Create a list of files you want to play continuously. Select files from the list of Videos, Photos, or Music files. Press TOOL on the remote control and select Add to Playlist. The option does not appear if a folder is highlighted by the cursor. Select files and press Add.

  • Page 168: My List

    AllShare Play My List MENU Support Contents Home AllShare Play My List ENTER [ Access desired content more conveniently and quickly. To play files, select files or a playlist (Playlist) and press [ Recently played: Display video, photo or music files that were recently played. This mode is suitable ...

  • Page 169: Videos

    AllShare Play Videos MENU Support Contents Home AllShare Play Videos ENTER [ 9.4.1 Playing a Video Select the internal memory or a USB device. Select files from the list of files. Press the [ ] button or [ ] (Play) button. The file name appears on the top with its playing time.

  • Page 170: Photos

    AllShare Play Photos MENU Support Contents Home AllShare Play Photos ENTER [ 9.5.1 Viewing a Photo (or Slide Show) Select the internal memory or a USB device. Select a file from the list of files. Press the [ ] button. To view files manually, one at a time, press the left or right arrow buttons.

  • Page 171: Music

    AllShare Play Music MENU Support Contents Home AllShare Play Music ENTER [ 9.6.1 Playing Music Select the internal memory or a USB device. Select files from the list of files. Press the [ ] button or [ ] (Play) button. When the music is playing, you can search using the [ ] (REW) and [ ] (FF) button.

  • Page 172: Videos / Photos / Music Play Option Menu

    AllShare Play Videos / Photos / Music Play Option menu When playing video or photo files, you can press the TOOLS button to display an Options menu. Below are a series of tables listing the options available and the media each option applies to. Option Name Operations Videos...
  • Page 173 AllShare Play Option Name Operations Videos Photos Music Subtitle Setting Displays the Subtitle Setting. You can set up a subtitle option. Start Slide Show You can start or stop a slide show. Stop Slide Alternatively, use the button on the Show remote.

  • Page 174: Supported Subtitle And Allshare Play File Formats

    AllShare Play Supported Subtitle and AllShare Play file formats 9.8.1 Subtitle External Internal MPEG-4 timed text (.ttxt) Xsub   Container: AVI SAMI (.smi)  SubRip (.srt) SubStation Alpha   Container: MKV SubViewer (.sub)  Micro DVD (.sub or .txt) Advanced SubStation Alpha ...

  • Page 175: Supported Video Formats

    AllShare Play File Extension Type Codec Comments The Seek (jump) function is not supported. *.flac FLAC FLAC Supports up to 2 channel *.ogg Vorbis Supports up to 2 channel Supports up to WMA 10 Pro 5.1 *.wma channel. WMA lossless audio is not supported.
  • Page 176 AllShare Play Video content will not play, or not play correctly, if there is an error in the content or the container.  Sound or video may not work if the contents have a standard bitrate/frame rate above the  compatible Frame/sec listed in the table above.

  • Page 177: Magicinfo Lite

    MagicInfo Lite 10.1 File Formats Compatible with MagicInfo Lite Player [Read before using MagicInfo Lite Player] The file system supports FAT16, FAT32 and NTFS.  A file with a vertical and horizontal resolution larger than the maximum resolution cannot be ...

  • Page 178: Contents

    MagicInfo Lite 10.1.1 Contents Frame rate Bit rate File Audio Container Video Codec Resolution Extension Codec (fps) (Mbps) *.avi DIVX 3.11 / 4.x / 5.x / 6.x *.mkv *.asf MPEG4 SP / *.wmv *.mp4 *.mov LPCM H.264 BP / MP / *.3gp *.vro HE-AAC...
  • Page 179 MagicInfo Lite Video Video content without audio is not supported.  3D video is not supported.  Content with a resolution larger than the resolution specified in the table above is not supported.  Video content with a Bit rate or Frame rate larger than the rate specified in the table above can ...
  • Page 180 MagicInfo Lite Flash Compatible with Flash 10.1  Flash Animation  Compatible file format : SWF  Resolution : 1280 x 720  Caution  Performance comparable to Flash Player on a Windows operating system cannot be guaranteed Optimization is needed during content creation Flash Video ...
  • Page 181 MagicInfo Lite Compatible document file formats  Extension : pdf  Functions not supported  Content less than 1 pixel not supported because of performance degradation issue.  Masked Image, Tiled Image content not supported.  Content with Rotated Text, not supported. ...

  • Page 182: Magicinfo Lite Player

    MagicInfo Lite 10.2 MagicInfo Lite Player 10.2.1 Network Schedule Connecting to a server Network setup To run MagicInfo Lite, connect to a network. Refer to 121 page for details about the Network Settings menu. Server setup Go to MENU Network MagicInfo Lite Settings Server.
  • Page 183 MagicInfo Lite MagicInfo Lite Settings MENU Support Contents Home MagicInfo Lite ENTER Press the MagicInfo Lite button on the remote control. You can view whether the server is connected (approval) in the MagicInfo Lite menu screen. To view whether the server is connected when a network schedule is running, press INFO on the remote.
  • Page 184 MagicInfo Lite Approving a connected device from the server Access the server you have assigned to your device. Enter your ID and password to log in. Select Device from the top menu bar. Select Lite Device from the menus on the left. 10 MagicInfo Lite...
  • Page 185 MagicInfo Lite Select View Unapproved Lite Device from the sub-menus of Lite Device. Select the Approve button for your device from the list of unapproved Lite devices. Enter the information required to approve the device. Device Name: Enter the device name. ...
  • Page 186 MagicInfo Lite For further details on how to configure a schedule, refer to the <MagicInfo server user's manual>.  If a device is deleted from the list of devices approved by the server, the device will reboot to reset  its settings.

  • Page 187: Local Schedule

    MagicInfo Lite 10.2.2 Local Schedule Run a schedule created by Local Schedule Manager. Go to Local Schedule Manager Select the content you want to run This menu is disabled if there was no schedule run previously in Local Schedule Manager. Select Local Schedule in the...

  • Page 188: Internal Autoplay

    MagicInfo Lite 10.2.3 Internal AutoPlay Running Internal AutoPlay The option is enabled only when there is at least one content item, except for music files, in Internal Memory. Select Internal AutoPlay in the MagicInfo Lite Player menu screen. Play content, which has been copied to Internal Memory, in alphabetical order.

  • Page 189: Usb Autoplay

    MagicInfo Lite 10.2.4 USB AutoPlay Running Internal AutoPlay The option is enabled only when there is at least one content item, except for music files, in  AutoPlay. Ensure a USB device is inserted. Be sure to create a folder named "MagicInfoSlide" in the USB ...

  • Page 190: Local Schedule Manager

    MagicInfo Lite 10.3 Local Schedule Manager Configure the settings for playback from Local Schedule. Alternatively, select and play content from internal or USB memory according to the customized playback sequence. 10.3.1 Registering a Local Schedule Select Local Schedule Manager in the MagicInfo Lite menu screen.
  • Page 191 MagicInfo Lite Select Time to set the time you want to play content. Create Time --:-- am ~ --:-- pm Content No Item Time --:-- ~ --:-- Save Save Content No Item Cancel Return A maximum of 24 schedules can be created. ...
  • Page 192 MagicInfo Lite Select Duration Duration Content Duration Menu1.jpg 00:00:05 Menu2.jpg 00:00:05 Down Save Cancel Return Specify the sequence and time duration to play content files. Changing the playing sequence  Select a content file and change the sequence using the Down button.
  • Page 193 MagicInfo Lite Check that the schedule has been added to the Local Schedule Manager. Local Schedule Manager Create Storage Internal Memory Edit No Playing Schedule Delete All Schedule 2012.01.01_1834.lsch Info Copy Close Return 10 MagicInfo Lite...

  • Page 194: Modifying A Local Schedule

    MagicInfo Lite 10.3.2 Modifying a Local Schedule Ensure at least one Local Schedule is registered. Select Local Schedule Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return...
  • Page 195 MagicInfo Lite Change the details of the local schedule. Next, select Save. Edit Time 12:00 am ~ 12:00 pm Delete Content Menu1.jpg Menu2 Time --:-- am ~ --:-- pm Save Content No Item Cancel Time --:-- am ~ --:-- pm Content No Item Return...

  • Page 196: Deleting A Local Schedule

    MagicInfo Lite 10.3.3 Deleting a Local Schedule Ensure at least one Local Schedule is registered. Select Local Schedule Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return...

  • Page 197: Running A Local Schedule

    MagicInfo Lite 10.3.4 Running a Local Schedule Ensure at least one Local Schedule is registered. Select Local Schedule Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return...

  • Page 198: Stopping A Local Schedule

    MagicInfo Lite 10.3.5 Stopping a Local Schedule Selecting will change the running This function is enabled only when a schedule is running. Stop mode from local schedule to network schedule. Select Local Schedule Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager...

  • Page 199: Viewing The Details Of A Local Schedule

    MagicInfo Lite 10.3.6 Viewing the details of a Local Schedule Select Local Schedule Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return Select the local schedule you want to view the details of. Local Schedule Manager Create Storage...
  • Page 200 MagicInfo Lite The details of the schedule will be displayed. Information 2012.01.01_1834.lsch 12:00 am~12:00 pm, 2 File(s) - Menu1.jpg Menu2.jpg Close Return 10 MagicInfo Lite...

  • Page 201: Copying A Local Schedule (Local Schedule)

    MagicInfo Lite 10.3.7 Copying a Local Schedule (Local Schedule) Select Local Schedule Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return Select a storage device where the local schedule files to copy are saved. Local Schedule Manager Local Schedule Manager Internal Memory...
  • Page 202 MagicInfo Lite Select local schedule files and press Copy. Local Schedule Manager Create Storage Internal Memory Edit No Playing Schedule Delete All Schedule 2012.01.01_1834.lsch Info Copy Close Return A window appears asking if you want to copy the files to the Internal Memory memory device.

  • Page 203: Content Manager

    MagicInfo Lite 10.4 Content Manager 10.4.1 Copying content Select Content Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return Select the content you want to copy. Next, select Copy. If content under Internal Memory is selected: You can copy the content under...

  • Page 204: Deleting Content

    MagicInfo Lite 10.4.2 Deleting content Select Content Manager in the MagicInfo Lite menu screen. MagicInfo Lite MagicInfo Lite Player Local Schedule Manager Content Manager Close Settings Mode Server Local Schedule Connected Connected Return Select the content you want to delete. Next, select Delete. Content under Internal Memory memory can be deleted at the same time.

  • Page 205: Default Content Duration

    MagicInfo Lite 10.5 Settings Settings Default Content Duration Content Ratio Image Effect None Close Default Content None Screen Layout Landscape Delete All Content Safety Remove USB Device Return 10.5.1 Default Content Duration Specify the duration to play content. Image Viewer Time, PPT Viewer Time,...

  • Page 206: Screen Layout

    MagicInfo Lite 10.5.5 Screen Layout Change the screen orientation to landscape or portrait view. Landscape Portrait  10.5.6 Delete All Content Delete all the content files in Internal Memory. 10.5.7 Safety Remove USB Device Safely removes USB memory 10 MagicInfo Lite...

  • Page 207: When Content Is Running

    MagicInfo Lite 10.6 When Content is Running 10.6.1 Viewing the details of the content that is running Press the INFO button on the remote control. Software Version: Displays the software version of a device  Device Name: Displays the name of a device recognized by the server ...

  • Page 208: Changing The Settings For The Content That Is Running

    MagicInfo Lite 10.6.2 Changing the settings for the content that is running Press the TOOLS button on the remote control. Tools Picture Mode Standard Sound Mode Standard Background Music Background Music Setting Safety Remove USB Device Return You can change the Picture Mode Sound Mode setting or safely remove a USB device...

  • Page 209: Troubleshooting Guide

    11.1 Requirements Before Contacting Samsung Customer Service Center 11.1.1 Testing the Product Before calling Samsung Customer Service Center, test your product as follows. If the problem persists, contact Samsung Customer Service Center. Check if your product is operating normally by using the product test function.

  • Page 210: Check The Followings

    Troubleshooting Guide 11.1.3 Check the followings. Installation issue (PC mode) The screen keeps switching on and off. Check the cable connection between the product and PC, and ensure the connection is secure. ("2.2 Connecting and Using a PC") Blank spaces are found at the top and bottom Blank spaces on the screen are not caused by of the screen when an HDMI or HDMI-DVI the product.
  • Page 211 Troubleshooting Guide Screen issue The screen is not clear. The screen is blurry. Adjust Coarse and Fine. Remove any accessories (video extension cable, etc) and try again. Set the resolution and frequency to the recommended level. The screen appears unstable and shaky. Check that the resolution and frequency of the PC and graphics card are set within a range There are shadows or ghost images left on the...
  • Page 212 Troubleshooting Guide Remote control issue The remote control does not work. Make sure that the batteries are correctly in place (+/-). Check if the batteries are flat. Check for power failure. Make sure that the power cord is connected. Check for any special lighting or neon signs switched on in the vicinity.
  • Page 213 Troubleshooting Guide 11.2 Q & A Question Answer How can I change the Set the frequency on your graphics card. frequency? "Windows XP": Go to Control Panel Appearance and  Themes Display Settings Advanced Monitor and adjust the frequency in Monitor Settings. "Windows ME/2000": Go to Control Panel Display ...
  • Page 214 Troubleshooting Guide Question Answer How can I change the "Windows XP": Go to Control Panel Appearance and  resolution? Themes Display Settings and adjust the resolution. "Windows ME/2000": Go to Control Panel Display  Settings and adjust the resolution. "Windows Vista": Go to Control Panel Appearance and ...

  • Page 215: Specifications

    Dimensions (W x H x D) 1054.5 x 608.5 x 35.1 mm 1249.5 x 721.0 x 35.1 mm Weight 16.4 kg 20.5 kg VESA 400 x 400 mm Model Name DE40C / DE46C / DE55C Display Color 16.7M Synchronization Horizontal 30~81kHz Vertical 56~75Hz Resolution...
  • Page 216 Specifications Model Name DE40C / DE46C / DE55C Environmental Operating Temperature : 0˚C ~ 40˚C (32˚F ~ 104˚F) considerations Humidity : 10% ~ 80%, non-condensing Storage Temperature : -20˚C ~ 45˚C (-4˚F ~ 113˚F) Humidity : 5% ~ 95%, non-condensing Plug-and-Play : This monitor can be installed and used with any Plug-and-Play compatible systems.

  • Page 217: Powersaver

    Power off Power State (Power Rating saving mode Rating Typical Button) (With PIM) Power Indicator Blinking DE40C 220 W 150 W 114 W Power DE46C 240 W 170 W 131 W Less than 1 W Less than 1 W Consumption...

  • Page 218: Standard Signal Mode Table

    Specifications 12.3 Standard Signal Mode Table This product can be set to only one resolution for each screen size to obtain the optimum picture  quality due to the nature of the panel. Using a resolution other than the specified resolution may degrade the picture quality.
  • Page 219 Specifications Sync Horizontal Vertical Pixel Clock Polarity Display Mode Frequency Frequency (MHz) (kHz) (Hz) (H/V) VESA, 1366 x 768 47.712 59.790 85.500 VESA, 1440 x 900 55.935 59.887 106.500 VESA, 1600 x 900(RB) 60.000 60.000 108.000 VESA, 1680 x 1050 65.290 59.954 146.250...

  • Page 220: License

    Specifications 12.4 License Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks. & DTS 2.0+ Digital Out and the DTS logos are trademarks of DTS, Inc.

  • Page 221: Appendix

    Appendix Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. NORTH AMERICA U.S.A 1-800-SAMSUNG (726-7864) http://www.samsung.com CANADA 1-800-SAMSUNG (726-7864) http://www.samsung.com/ca (English) http://www.samsung.com/ca_fr (French) MEXICO 01-800-SAMSUNG (726-7864) http://www.samsung.com...
  • Page 222 (Dutch) http://www.samsung.com/be_fr (French) BOSNIA 05 133 1999 http://www.samsung.com BULGARIA 07001 33 11 , normal tariff http://www.samsung.com CROATIA 062 SAMSUNG (062 726 7864) http://www.samsung.com CYPRUS 8009 4000 only from landline http://www.samsung.com (+30) 210 6897691 from mobile and land line Appendix...
  • Page 223 808 20 - SAMSUNG (808 20 7267) http://www.samsung.com RUMANIA 08008 SAMSUNG (08008 726 http://www.samsung.com 7864) TOLL FREE No. SERBIA 0700 Samsung (0700 726 7864) http://www.samsung.com SLOVAKIA 0800 - SAMSUNG (0800-726 786) http://www.samsung.com SPAIN 902 - 1 - SAMSUNG (902 172 678) http://www.samsung.com Appendix...
  • Page 224 Appendix EUROPE SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com SWITZERLAND 0848-SAMSUNG http://www.samsung.com/ch (7267864, CHF 0.08/min) (German) http://www.samsung.com/ch_fr (French) 0330 SAMSUNG (7267864) http://www.samsung.com ARMENIA 0-800-05-555 http://www.samsung.com AZERBAIJAN 088-55-55-555 http://www.samsung.com BELARUS 810-800-500-55-500 http://www.samsung.com GEORGIA 0-800-555-555 http://www.samsung.com KAZAKHSTAN 8-10-800-500-55-500 http://www.samsung.com (GSM: 7799) KYRGYZSTAN 00-800-500-55-500 http://www.samsung.com...
  • Page 225 1800 3000 8282 1800 266 8282 INDONESIA 0800-112-8888 http://www.samsung.com 021-5699-7777 JAPAN 0120-327-527 http://www.samsung.com MALAYSIA 1800-88-9999 http://www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 786) http://www.samsung.com PHILIPPINES 1-800-10-SAMSUNG (726-7864) http://www.samsung.com for PLDT 1-800-3-SAMSUNG (726-7864) for Digitel 1-800-8-SAMSUNG (726-7864) for Globe 02-5805777 SINGAPORE 1800-SAMSUNG (726-7864) http://www.samsung.com...
  • Page 226 Appendix MIDDlE EAST MOROCCO 080 100 2255 http://www.samsung.com OMAN 800-SAMSUNG (726-7864) http://www.samsung.com/ae (English) http://www.samsung.com/ae_ar (Arabic) SAUDI ARABIA 9200-21230 http://www.samsung.com/ae (English) http://www.samsung.com/ae_ar (Arabic) TURKEY 444 77 11 http://www.samsung.com U.A.E 800-SAMSUNG (726-7864) http://www.samsung.com AFRICA ANGOLA 91-726-7864 http://www.samsung.com BOTSWANA 0800-726-000 http://www.samsung.com CAMEROON 7095- 0077 http://www.samsung.com...

  • Page 227: Responsibility For The Pay Service (Cost To Customers)

     use of supplies or separatly sold product unspecified by Samsung.  repair from a person besides an engineer of outsourcing service company or partner of Samsung  Electronics Co., Ltd. remodeling or repairing the product by customer.

  • Page 228: Optimum Picture Quality And Afterimage Burn-In Prevention

    Due to the nature of the manufacturing of this product, approximately 1 pixel per million (1ppm) may  be brighter or darker on the LED panel. This does not affect product performance. The number of sub-pixels by LED panel type: DE40C, DE46C, DE55C: 6,220,800  "Auto Adjustment"...

  • Page 229: Prevention Of Afterimage Burn-In

    Appendix Prevention of Afterimage Burn-in What is afterimage burn-in? Afterimage burn-in should not occur when the LCD panel is operating normally. Normal operation refers to a continuously changing video pattern. If the LCD panel displays a fixed pattern for an extended period of time (more than 12 hours), a slight voltage difference may occur between the electrodes in pixels that control the liquid crystals.
  • Page 230 Appendix Regular Color Change  Type 1 Type 2 FLIGHT TIME FLIGHT TIME OZ348 20:30 OZ348 20:30 UA102 21:10 UA102 21:10 Use 2 colors Switch between 2 colors every 30 minutes as shown above. Avoid combinations of a text color and background color of contrasting brightness. ...

  • Page 231: Correct Disposal

    (India Only) For more information on safe disposal and recycling visit our website www.samsung.com/in or contact our Helpline numbers - 18002668282, 180030008282. Appendix...

  • Page 232: Terminology

    Appendix Terminology Dot Pitch The product and screen consist of red, green and blue dots. A shorter distance between the dots produces a higher resolution. Dot pitch refers to the distance between the shortest distance between dots of the same color. Dot pitch is measured in millimeters. Vertical Frequency The product displays a single image many times per second (like a fluorescent light that flickers) to display an image for a viewer to see.
  • Page 233 Appendix Multiple Display Control (MDC) MDC (Multiple Display Control) is an application that allows multiple display devices to be controlled simultaneously using a PC. Communication between a PC and monitor takes place using RS232C (serial data transmission) and RJ45 (LAN) cables. DVD (Digital Versatile Disc) DVD refers to a CD-sized mass storage disk where you can save multimedia (audio, video or game) applications using MPEG-2 video compression technology.
  • Page 234 Index Batteries Remote Control Reset All Resolution configuration Responsibility for the Pay Service (Cost to Contact SAMSUNG WORLD WIDE Customers) Content Manager Contents Home Correct Disposal Screen Adjustment Custom settings screen Screen Position Settings Sleep Timer Edit Name Software Update...

This manual is also suitable for:

De46cDe55c

Table of Contents
