- Page 1 2013 M{zd{ Mx-5 MI{T{ Smart Start Guide zoo}-zoo} 1526336_13a_Mazda_MX5_SSG_060713b.indd 1 6/7/13 3:38 PM...
-
Page 2: Advanced Keyless Entry System
Door Request Switch ADVANCED KEYLESS ENTRY SYSTEM • T his system allows you to lock/unlock the doors, open the trunk lid, and even start the engine without ever taking the key out. While Carrying the Advanced Key… Lock • U nlock the driver’s door by pushing Unlock the driver’s door request switch once. • U nlock both doors by pushing the driver’s door request switch twice OR by pushing the passenger’s door request switch once. Trunk • L ock both doors by pushing the Panic Alarm driver’s door or passenger door request... -
Page 3: Starting The Engine
www.MazdaUSA.com STARTiNg ThE ENgiNE While Carrying the Advanced Key… • S tart the engine by pushing the start knob in and turning it (like a normal key) while pushing the clutch pedal (manual transmission) or the brake pedal (automatic transmission). • S hut the engine OFF by turning the start knob to the ACC position and then pushing in and turning to the Lock position. NOTE: The KEY indicator light will illuminate gREEN when the advanced key is detected. If the KEY indicator light flashes gREEN, the advanced key transmitter battery power is low. • I f the advanced key cannot be used due to a malfunction or dead advanced key battery, use the auxiliary key to lock/unlock the doors and to start the engine. NOTE: Key Indicator Light may flash if the key is placed in the cup holder. The key may not be detected in the cup holder. With the Auxiliary Key… To start engine, remove the start knob cover by squeezing both... -
Page 4: Seat Controls
Seats SEAT CONTROLS height Adjustment Lever Recline Lever Raise or lower seat height by repeatedly Pull up to adjust pulling up or pushing down on the lever. seatback angle. Slide Release Lever Pull lever up to move seat backward or forward. Seat Warmers The driver and passenger seats can be warmed by rotating the applicable seat warmer dial while the ignition is ON. • S eat temperature increases as the number on the dial increases. • When the seat warmers are not needed, rotate the dials to 0. NOTE: The seat heaters may not turn on if the seats are warmer than the thermostats low point (such as if the top is down and the seats are warmed by the sun on a cold sunny day or the ambient temperature is high). Behind Seat Storage (Soft Top Only) Move seatbacks forward to access the seat back trim storage boxes. -
Page 5: Fuel Door Release
Fuel www.MazdaUSA.com FUEL DOOR RELEASE The fuel door release is in the seat side box located between the seats. 1 P ull handle to open the seat side box. 2 To open the fuel door, pull the fuel door release. FUEL DOOR To avoid scratching the paint during refueling, secure the fuel filler cap tether over the hook as shown. FUEL REqUiREMENTS 91-octane fuel is recommended. If 91-octane fuel is not available, fuel as low as 87-octane can be used temporarily for emergency purposes. Use of fuel lower than 91-octane can decrease performance, cause knocking/ engine noise, deteriorate shift quality, and possibly increase fuel consumption. Refueling the vehicle with correct octane fuel a couple of times will restore vehicle performance and shift quality. 1526336_13a_Mazda_MX5_SSG_060713b.indd 4 6/7/13 3:38 PM... -
Page 6: Driver's View
Driver’s View BLUETOOTh ® LighTiNg/ hANDS-FREE/ CRUiSE AUDiO CONTROL TURN SigNALS CONTROL (P. 9) (P. 25) DYNAMiC STABiLiTY CONTROL (DSC) TRUNK RELEASE hOOD TiLT STEERiNg RELEASE WhEEL LEVER 1526336_13a_Mazda_MX5_SSG_060713b.indd 5 6/7/13 3:38 PM... - Page 7 www.MazdaUSA.com PASSENgER WiPER/ hAzARD AiRBAg OFF WAShER AUDiO WARNiNg iNDiCATOR (P. 10) (PP. 23-24) POWER RETRACTABLE hARDTOP (if equipped) (P. 18) CLiMATE ACCESSORY AUx jACK SEAT (P. 12) CONTROL SOCKET WARMERS (PP. 21-22) (P. 3) This indicator light illuminates to remind you that the front passenger’s front/side airbags and seat belt pretensioner will not deploy during a collision. The reason for this is that the weight in the seat is less than approximately 66 lb. Always wear your seat belt and if a front facing child seat must be used, you must deactivate the passenger airbag. See the Owner’s Manual for important information on this safety feature. 1526336_13a_Mazda_MX5_SSG_060713b.indd 6 6/7/13 3:38 PM...
-
Page 8: Instrument Cluster
Instrument Cluster FUEL gAUgE TAChOMETER DAShBOARD ENgiNE OiL iLLUMiNATiON PRESSURE gAUgE gLOSSARY OF WARNiNg AND iNDiCATOR LighTS NOTE: See Owner’s Manual for more details and explanations. Low Fuel Level Automatic Transmission Malfunction Dynamic Stability Control Turn Signals/hazard (DSC)/Traction Control Warning indicator Lights System (TCS) Off indicator Light Key Warning (p. 2) DSC OFF switch pushed and... -
Page 9: Door Ajar
www.MazdaUSA.com ODOMETER/ SPEEDOMETER iNFO AMBiENT ENgiNE COOLANT TEMPERATURE TRiP METER TEMPERATURE BUTTON gAUgE iNFO Door Ajar Push INFO button to display the Brake Warning Light following below the odometer: Parking brake on/low brake • Trip Meter A fluid/malfunction • Trip Meter B Cruise Main indicator • Average fuel economy Light On ( AMBER • Ambient Temperature Display Cruise Set indicator Light On ( gREEN NOTE:... - Page 10 Lights LighTiNg CONTROL/TURN SigNAL LEVER : Turns tail, parking, dashboard, : Turns fog lights on only and headlights on. when headlights are on. Push for high Beams Pull to Flash high Beams : Turns tail, parking, and dashboard lights on. 1526336_13a_Mazda_MX5_SSG_060713b.indd 9 6/7/13 3:38 PM...
- Page 11 Wipers www.MazdaUSA.com WiNDShiELD WiPER/WAShER CONTROL LEVER MiST Pull to dispense washer fluid 1526336_13a_Mazda_MX5_SSG_060713b.indd 10 6/7/13 3:38 PM...
-
Page 12: Automatic Transmission
Transmission AUTOMATiC TRANSMiSSiON (if equipped) Lower gear Sport A/T Manual Shift Mode The Sport A/T Manual Shift Mode gives you the feel of driving a manual transmission by allowing you to manually shift to control engine rpm and torque when more control is desired. higher To Use Manual Shift Mode: gear... -
Page 13: Speed Manual Transmission
PORTABLE AUDiO PLAYER iNTEgRATiON USiNg ThE AUx jACK Your vehicle is equipped with an AUX or Auxiliary auxiliary jack that will allow you to play jack your portable audio player through the vehicle’s audio system. Learn the system when parked and do not let it distract you while driving. NOTE: You will need an audio cable with an 1/8 inch (3.5 mm) mini stereo plug (available as a Genuine Mazda accessory) to connect your portable audio player into the aux jack. Refer to the Owner’s Manual for additional information. Locate the AUX jack below the climate controls. 2 Plug 1/8 inch mini stereo plug into the portable audio player and into the AUX jack. Turn portable audio player on. Turn the vehicle audio system on. 4 Push the AUX button on the audio face or the MODE button on the steering wheel controls. 5 U se the portable audio player controls to play music. iMPORTANT: Set the volume level on your portable audio player to the highest level before distortion starts, then adjust the volume on the audio system. - Page 14 Mirror AUTO-DiMMiNg MiRROR AND hOMELiNK ® homeLink Auto-Dimming Rear Auto-Dimming Auto-Dimming Light indicator Light Sensor Auto-Dimming Mirror • A uto-Dimming will automatically darken your rearview mirror to reduce headlight glare from vehicles behind you. • A uto-Dimming is activated every time the vehicle is started. NOTE: In addition to the auto-dimming mirror’s rear light sensor, there is also a front light sensor (not shown). Do not place or hang any objects over the front or rear mirror light sensors, otherwise, the auto-dimming mirrors will not operate properly. homeLink ® • T his feature provides a convenient way to replace up to three transmitters such as garage door openers, home lighting remotes and other radio frequency devices. • Refer to your Owner’s Manual for complete programming details. 1526336_13a_Mazda_MX5_SSG_060713b.indd 13 6/7/13 3:39 PM...
- Page 15 Wheel www.MazdaUSA.com ALUMiNUM WhEEL CARE Your aluminum wheels have a protective coating on them. Only use a mild soap or neutral detergent with a sponge or soft cloth to clean them. CAUTiON: Using a wire brush, polishing compound, solvent, or any type of abrasive cleaner may damage the protective coating. PERSONALizE YOUR Mx-5 WiTh gENUiNE MAzDA ACCESSORiES Go to www.MyMazda.com, then select “Accessories” below the MyMazda Home header for a complete listing of available accessories for your Mazda MX-5. iNSTANT MOBiLiTY SYSTEM (iMS) The IMS emergency flat tire repair kit (located in the trunk) is for a temporary repair of a slightly damaged flat tire, resulting from running over nails, or similar sharp objects on the road surface. Refer to your Owner’s Manual for complete details. 1526336_13a_Mazda_MX5_SSG_060713b.indd 14 6/7/13 3:39 PM...
-
Page 16: Manual Convertible Top
Convertible Top MANUAL CONVERTiBLE TOP When raising or lowering the manual convertible top, the vehicle must be stopped on level ground with parking brake set, windows lowered a minimum of 1 inch and all items in the convertible top storage area removed. NOTE: When the latch is released, the audio volume may drop to zero for one second. See the owner’s manual for audio system operation differences with top up and down. To Lower: Push release button A while pulling latch B rearward to disengage. gOOD - OK CAUTiON: DO TO LOWER NOT LOWER SOFT TOP SOFT TOP! CAUTiON: Before lowering soft top, please pay close attention to the folding points on each side of the soft top, and make sure nothing is stored in the well otherwise damage could occur. Pull front of top rearward to release from windshield header. • If opening from inside • If opening from outside vehicle, vehicle, use either handle. grasp side of top, near windshield header. 1526336_13a_Mazda_MX5_SSG_060713b.indd 15 6/7/13 3:39 PM... - Page 17 www.MazdaUSA.com Fold back top and push firmly on front of top to securely lock in open position. NOTE: If manual soft top does not fold easily, then slowly lower it while pushing down on the upper part of rear glass with your hand. Raise wind blocker. To Raise: Lower wind blocker. Pull unlock lever to release top from open position. 1526336_13a_Mazda_MX5_SSG_060713b.indd 16 6/7/13 3:39 PM...
- Page 18 Push lever on top latch forward until lock button clicks and top latch is securely locked. WARNiNg: if red indicator is visible on release button, top is not securely latched. NOTE: Manual Convertible Top Maintenance: Remove leaves or other matter that may accumulate around the area where the soft top meets the vehicle body to prevent water drainage outlets from becoming clogged. Clogged water drainage outlets may result in water intrusion into the passenger compartment. For detailed maintenance of the water drains, refer to MyMazda.com or consult an Authorized Mazda Dealer. 1526336_13a_Mazda_MX5_SSG_060713b.indd 17 6/7/13 3:39 PM...
-
Page 19: Power Retractable Hardtop
www.MazdaUSA.com POWER RETRACTABLE hARDTOP When raising or lowering the power retractable hardtop, the vehicle must be stopped on level ground with parking brake set and ignition on. Shift manual transmission to neutral or shift automatic transmission to Park or Neutral. NOTE: When the latch is released, the audio volume may drop to zero for one second. See the owner’s manual for audio system operation differences with top up and down. To Lower: Push release button A while pulling latch B rearward to disengage. The indicator light will illuminate when the latch is disengaged indicating the top can be opened. CAUTiON: Before lowering top, make sure nothing is stored in the well otherwise damage could occur. Push and hold the open button. The indicator light will flash during the opening operation. Open button indicator light • Windows automatically lower, deck raises, top lowers, and then deck closes. NOTE: A beep sounds and the indicator light turns off to confirm operation is complete. 1526336_13a_Mazda_MX5_SSG_060713b.indd 18 6/7/13 3:39 PM... - Page 20 Convertible Top Raise wind blocker. To Raise: Lower wind blocker. Push and hold the close button. The indicator light will flash during the closing operation. Close button • Windows automatically lower, deck raises, top raises, deck closes. NOTE: A beep sounds and the indicator light turns off to confirm operation is complete, only after the hard top is locked in place. 1526336_13a_Mazda_MX5_SSG_060713b.indd 19 6/7/13 3:39 PM...
- Page 21 www.MazdaUSA.com Push lever on top latch up until lock button clicks and top latch is securely latched. WARNiNg: if red indicator is visible on release button, top is not securely latched. NOTE: • If open/close button is released during operation, the operation will stop and a beep will sound. • If trunk is open, a beep sounds when pushing open/close buttons and top will not operate until trunk is closed. • If beep sounds when vehicle is placed in gear, verify the power retractable hardtop is fully lowered/raised and the latch is closed if in raised position. • In case of a power loss, the tools for manually raising the power retractable hardtop are located in the glove compartment; see Owner’s Manual for manual operating instructions. 1526336_13a_Mazda_MX5_SSG_060713b.indd 20 6/7/13 3:39 PM...
-
Page 22: Manual Climate Control
Manual Climate Control Mode Selector Dial Temperature Fan Control Dial Control Dial Rotate the dial to Rotate the dial to set select airflow mode. Rotate the dial for desired fan speed. temperature control. R otate dial to OFF to NOTE: Turn the mode Push to recirculate turn system off. selector dial to an OPEN cabin air to MODE position for Push to maximum comfort while reduce outside manually turn air the roof is retracted. odors and improve conditioning on cooling (indicator Dashboard vents or off. on) or receive (Open Mode) fresh air D ashboard and (indicator off). -
Page 23: Automatic Climate Control
Automatic Climate Control Mode Selector Dial Temperature Fan Control Dial Control Dial Rotate the dial to select • R otate the dial airflow mode. to set desired Rotate the dial for fan speed. temperature control. AUTO: Place the Mode Selector Dial and the Push to • R otate dial to Fan Control Dial in the recirculate cabin OFF to turn AUTO position. The air to reduce system off. airflow mode and the outside odors Push to amount of airflow will be and improve manually turn air... -
Page 24: Audio Controls
Satellite Radio: Push the SIRIUS frequency. button for SiriusXM Satellite Radio ® • S eek Tuning: Push the SEEK/ If your vehicle is equipped with TRACK tuning buttons SiriusXM Satellite Radio (satellite ® to seek a higher or lower radio antenna on roof or trunk frequency with a station. lid), your new Mazda includes a • S can Tuning: Push the SCAN free introductory subscription button to automatically sample with a limited term trial offer. Call strong stations for a few 888-539-7474 to activate. See the seconds each. Push again Owner’s Manual and/or dealer for to cancel. details. Contact your Mazda dealer • P reset Channel: Push the about adding SiriusXM Satellite Preset Channel buttons (1-6) Radio if your MX-5 is not already ®... - Page 25 www.MazdaUSA.com TO LOAD/PLAY A CD (if equipped with 6-CD changer) 1. P ush the LOAD button. 2. A fter “IN” is displayed on the Information Display, insert the CD. 3. R epeat steps 1 and 2 until up to 6 CDs are loaded. To Change Music CD Push the DISC button ( or ) during playback. To Change MP3/WMA CD Push the DISC button ( or ) for 1.5 seconds or more during playback.
-
Page 26: To Make/Receive Hands-Free Call
Bluetooth ® PAiRiNg YOUR BLUETOOTh PhONE ® NOTE: • For safety reasons, you cannot pair a phone while driving. • B efore pairing your cell phone, you must manually turn on the Bluetooth function on ® the device. Refer to your device’s Bluetooth for steps to turn on Bluetooth ® ® For customer service and device compatibility: • Toll-free call: 800-430-0153 Website: www.MazdaUSA.com/bluetooth • iMPORTANT: Set the volume level on your cell phone to the highest level before distortion starts, then adjust the volume on the vehicle’s audio system. • W hen in range of another Wi-Fi device, the Bluetooth connection between your phone and the system may disconnect for a short time if you have Wi-Fi enabled Turn off Wi-Fi on your phone if needed. 1 M anually turn 7 A fter the beep, say 12 T he prompt will Bluetooth on... - Page 27 MyMazda.com—The Official Site for M{zd{ Owners Register today on MyMazda.com—the ultimate destination for Mazda Owners. Once registered, you’ll be able to take advantage of benefits exclusively for Mazda Owners: • I nsider access to exclusive events and promotions • Personalized maintenance schedules • Zoom-Zoom Owner Magazine • W arranty information and on-line Owner’s Manuals • Wallpaper, videos and other fun stuff...
- Page 28 • Pair Phone • Make a Call • T oll-Free Customer Service 800-430-0153 SChEDULED MAiNTENANCE Wiper/Washer........ When replacing or topping off engine oil, use Mazda Genuine oil. For optimal engine performance, use SAE 0W-20 engine oil. Please consult an Authorized Mazda Dealer for additional information. AUx jack ........*if equipped All items in the Customer Delivery Checklist have been reviewed with the customer and the first maintenance appointment has been scheduled:...
-
Page 29: Service Department
Customer Delivery Checklist DEALERShiP DATE SALES CONSULTANT CUSTOMER’S NAME E-MAiL PRESENTATiON OF OWNER’S MATERiALS: Review the following items with the customer Smart Start guide MyMazda.com • R emove this checklist from • O ffer to register customer on Smart Start Guide MyMazda.com • P ersonalization Features Owner’s Manual (refer to your Owner’s Manual) Maintenance Passport Warranty information Floor Mats Warranty Start Date:... - Page 30 Remember, to further enhance your driving experience, visit your local Mazda Service Center for your scheduled maintenance. It’s also the place where you can find a wide variety of tires, parts, and accessories that are just right for your vehicle. * See vehicle’s scheduled-maintenance program for details. ** Visit the Mazda Owners website at MyMazda.com/fullcircle to find a participating Mazda Full Circle Service Dealer. 1-800-222-5500 Customer Assistance Center: 1-800-866-1998 Roadside Assistance Contact: FREE FULL CiRCLE SERViCE iNSPECTiON We’re committed to providing...
