Features:

• High Efficiency Class D Topology
• Compact Size for Easy Installation
• Balanced Differential Input Circuitry
• Audiophile NJM2068M Operational Amplifiers
• Ultra High Speed IR Class D Chipset
• High, Band and Low Pass Crossovers
• ADAPT Power Management System
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Audio Precision Quality Control Verification
• High Temperature Plexiglass cover
• Signal Clipping Indicators
• RMD - Remote Monitoring Display Port
• RBCF- Remote Subwoofer Level Control included
(Ti2 1600.5)
Manual del Amplificador
Manuel del'amplifica teur
Características:
• Alta eficiencia de clase D Topología
• Tamaño compacto para fácil instalación
• Diferencial balanceada circuitos de entrada
• Audiophile NJM2068M amplificadores operacionales
• IR Chipset Ultra Alta Velocidad
• Crossovers paso alto y bajo
• ADAPT Sistema de Gestión de Energía
• Tecnología "Surface Mount Component"
• Conexiones directas de terminales de poder y de
parlantes
• Control de verificación de calidad de precisión de audio
• Cubierta de Plexiglás resistente a altas temperaturas
• RMD - Puerto de display para monitoreo remoto
• RBCF - Control de nivel de Subwoofer remoto incluido
(Ti2 1600.5)
Amplifier Manual
Models: Ti2 1000.4, Ti2 1600.5
Caractéristiques:
• Petit format pour faciliter l'installation
• Topologie de classe D de gamme complète
• Circuit équilibré Entrée différentielle
• Audiophile NJM2068M Amplificateurs opérationnels
• Haute Vitesse IR de classe D chipset
• Filtres croisés passe-haut et passe-bas
• ADAPT système d'alimentation
• Technologie de composant monté en surface
• Terminaux d'alimentation et de haut-parleurs à
insertion directe
• Vérification du contrôle de la qualité de la précision audio
• Couvercle de plexiglas résistant aux températures élevées
• RMD - Entrée De L'affichage de Tension a Distance
• RBCF- Niveau de contrôle de passe-bas inclus (Ti2 1600.5)

Advertisement

Table of Contents
loading

Summary of Contents for Phoenix Gold TI2 1600.5

  • Page 1 • RMD - Entrée De L’affichage de Tension a Distance • RBCF- Remote Subwoofer Level Control included • RBCF - Control de nivel de Subwoofer remoto incluido • RBCF- Niveau de contrôle de passe-bas inclus (Ti2 1600.5) (Ti2 1600.5) (Ti2 1600.5)
  • Page 2 RMS power rating shown here. All RMS power ratings and measurements are at 14.4 volts with no more than 1% THD. Ti2 1000.4 and Ti2 1600.5 feature ADAPT technology which provides the same power output from 11 to 15 volts with music material.
  • Page 3 Amplifier Owner’s Manual Key Fea tures BALANCED DIFFERENTIAL INPUTS ULTRA HIGH SPEED IR CLASS D CHIPSET Provides maximum rejection of unwanted noise from upstream State of the art IR20957 chipset switches at more than 300kHz components. for blistering audio performance. All four or five chipsets are sync’d together in unison to eliminate unwanted harmonics or AUDIOPHILE NJM2068M OP-AMPS distortion.
  • Page 4 Amplifier Owner’s Manual Ti2 1000.4 4 Channel Power Amplifier FRONT AND REAR INPUTS SENS Connect preamp signal cables from headunit to these inputs. The front Used to reach maximum amplifier power with a wide variety of headunits. and rear inputs must be used, if only the front input is used then the rear speaker outputs will have no output signal.
  • Page 5 The fuse must be located within 18 inches of the battery. SPEAKER OUTPUTS REMOTE Used to connect the amplifier to speakers. Ti2 1600.5’s minimum This must be connected to switched +12V, usually a trigger wire coming impedance is 4 ohms bridged or 2 ohms stereo on front and rear from the head unit or ignition.
  • Page 6 Amplifier Owner’s Manual Ti2 1000.4 Crossover settings All crossover frequency potentiometers have 41 detents or “clicks” so the end user can set the exact cross over frequency desired. FRONT AND REAR CHANNELS FRONT HP REAR HP REAR HP REAR LP clicks (45~4kHz) (45~4kHz)
  • Page 7 Amplifier Owner’s Manual INST ALLA TION NOTES: Ti2 1600.5 CRossover Settings All crossover frequency potentiometers have 41 detents or “clicks” so the end user can set the exact cross over frequency desired. FRONT AND REAR CHANNELS SUB CHANNEL FRONT HP...
  • Page 8 Manual del Amplificador Ti2 1000.4 Amplificador de Potencia de 4 Canales ENTRADAS DELANTERA y TRACERA SENS Conectar cables de señal de preamp del radio a estas entradas. Ambas Usado para alcanzar el máximo poder amplificado con una gran variedad de entradas, Front y Rear deben ser usadas, si solo se usa el Front no habrá...
  • Page 9 Manual del Amplificador Ti2 1600.5 Amplificador de Potencia de 5 Canales ENTRADAS SENS Conectar cables de señal de preamp del radio a estas entradas. Las Usado para alcanzar el máximo poder amplificado con una gran variedad de entradas frontales, traseros y sub debe ser utilizado. Si una entrada no se radios.
  • Page 10 Manuel de l’amplificateur Ti2 1000.4 amplifica teur de puissance ENTRÉE NIVEAU Sert à atteindre une puissance d’amplificateur maximale avec une grande variété Reliez les câbles de signal préampli de l’unité principale sur ces bornes. d’unités principales. FRÉQUENCE DE FILTRE PASSIF PASSE-BAS et CONFIG PASSE-HAUT FLAT : Croisé...
  • Page 11 SORTIES ENCEINTES BORNE TÉLÉCOMMANDE Utilisé pour connecter l’amplificateur aux haut-parleurs. Ti2 1600.5 impédance d Doit être relié à la borne +12 V commutée, généralement un fil d’amorçage ‘minimum est de 4 ohms ponté ou 2 ohms stéréo. Canal Subwoofer est stable à...
  • Page 12 LIMITED WARRANTY ON AMPLIFIERS Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge.
