- Page 1 BARCO PROJECTION SYSTEMS GRAPHICS 6500 R9001950 R9001959 OWNER'S MANUAL Date : Rev. : Art. No. : 30012001 R5976183...
- Page 2 Produced by BARCO NV, Januari 2001. All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
-
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS TABLE OF CONTENTS ...................... 1-1 PACKAGING AND DIMENSIONS ..................2-1 Projector Packaging ............................. 2-1 Way of Packaging ..................................... 2-1 To unpack ......................................2-1 Hint ........................................2-1 Contents of the complete unit (box) : ............................... 2-1 Lens Packaging ............................ -
Page 4: Table Of Contents
Table of Contents IEEE 1394 Input ....................................4-8 RS232 Connection ............................4-9 RS232 in / RS232 out ..................................4-9 Applications : ....................................4-9 Set up of the Baud Rate for Communication with a Computer : ....................4-9 Communication port for communication with peripherals ................4-9 Configurations of the port. - Page 5 Table of Contents AUTO IMAGE ADJUSTMENT .................... 7-1 Auto Image Adjustment ..........................7-1 Why Auto Image ? .................................... 7-1 Start Up ......................................7-1 Adjust ................................7-1 What can be done ? ..................................7-1 Image Adjustment ..................................... 7-1 Action ................................7-2 What can be done ? ..................................
- Page 6 Table of Contents To change the noise reduction value : ............................8-12 Audio Tuning ............................... 8-13 Start Up ......................................8-13 Available items ....................................8-13 Volume, Balance, Bass and Treble ......................8-13 How to adjust ? ....................................8-13 Fade ................................8-14 Purpose ......................................
- Page 7 Table of Contents Changing the shutdown setting ................................ 9-2 Lens Adjustments ............................9-3 What can be done ? ..................................9-3 Zoom/Focus/Shift ..................................... 9-3 Text Box Position ............................9-4 What can be done ? ..................................9-4 How to change the setting ? ................................9-4 Quick Access Keys ............................
- Page 8 Start Up ......................................10-6 BARCO logo ............................... 10-6 What can be done ? ..................................10-6 How to add the BARCO logo or to change a setting ? ........................10-6 Available settings .................................... 10-7 Panel Adjustments ............................10-7 Warning ......................................10-7 Start Up ......................................
-
Page 9: Packaging And Dimensions
Packaging and Dimensions PACKAGING AND DIMENSIONS Projector Packaging Way of Packaging The projector is packed in a carton box. To provide protection during transportation, the projector is surrounded with foam. The package is secured with banding and fastening clips. To unpack First release the fastening clips and remove the banding. -
Page 10: Projector Case
Packaging and Dimensions Projector Case Dimensions The dimensions are given in mm. 25.4 mm = 1" 82.7 211.4 169.5 139.6 148.9 380.6 526.8 371.2 53.5 202.4 53.5 29.6 187.2 152.6 152.6 5976183 BARCOGRAPHICS 6500 31012001... -
Page 11: Installation Guidelines
Installation Guidelines INSTALLATION GUIDELINES Safety warning Before installing the projector, read first the safety instructions Installation Guidelines Ambient Temperature Conditions Careful consideration of things such as image size, ambient light level, projector placement and type of screen to use are critical to the optimum use of the projection system. -
Page 12: Which Screen Type
Installation Guidelines Which screen type? There are two major categories of screens used for projection equipment. Those used for front projected images and those for rear projection applications. Screens are rated by how much light they reflect (or transmit in the case of rear projection systems) given a determined amount of light projected toward them. -
Page 13: Lenses
Use the lens formulas to find the best corresponding PD with regard to the measured projector-screen distance for the required screen width. The desired lens is determined. Available lenses The projector is supplied without any lens. The following lenses are available, or will become available (contact a Barco service center) as an option : Lenses Standard version QFD(1.27:1) R9840400 QFD(2.5:1) -
Page 14: Lens Formulas To Calculate The Projector Distance
QFD(7.0:1) Metric PD = 7.021 x SW + 0.047 + 0.0093/SW PD = 7.021 x SW + 1.85 + 14.41/SW Lens program to calculate the projector distance is available on the BARCO webside : http://www.barco.com/projection_systems/customer_services/lens_program.asp How to install the lens? Follow the next procedure : 1. -
Page 15: Cleaning The Lens
Installation Guidelines Image 3 Image 4 Cleaning the Lens To minimize the possibility of damaging the optical coating or scratching exposed lens surface, we have developed recommendations for cleaning the lens. FIRST, we recommend you try to remove any material from the lens by blowing it off with clean, dry deionized air. -
Page 16: How To Replace The Batteries In The Rcu
1. The common address can be zero (0) or one (1). The standard RCU are setup for common address zero. To change the common address of the RCU, contact a BARCO service center. If it is necessary to program the projector address into the RCU, see chapter 'Getting Started'. -
Page 17: Connections
Connections CONNECTIONS Power connection to Projector AC Power (mains) cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. The power input is auto-ranging from 90 to 240 VAC. S -V IDE O I EEE 1394 M OUSE... -
Page 18: Lamp Run Time
The total lifetime of the lamp for a safe operation is 1000 hours max. Do not use it longer. Always replace with a same type of lamp. Call a BARCO authorized service technician for lamp replacement. Lamp Run Time Warning Using a lamp for more than 1000 hours is dangerous as the lamp could explode. -
Page 19: Switching Off
Connections Switching Off To switch off: - First press STANDBY key for 2 seconds. When the message 'Saving data, please wait' is displayed, do not press any longer on the standby key otherwise the projector will restart. Let cool down the projector at least 10 min. - Switch off the projector with the power switch. -
Page 20: 5-Cable Input Slot (Slot 1)
Connections 5-cable Input Slot (slot 1) Slot 1 has 5 BNC input terminals. VIDEO S-VIDEO S DI IEE E 1394 M OU SE 10/100 MONITOR C OM PUTER Which signals can be connected to the 5-cable input The following signals can be connected to these BNC connectors : Connector name Input signal RGBHV... -
Page 21: Computer Input/Monitor Output
Connections Possible indication : RGB [HS&VS] = RGB analog signals, separate sync is horizontal and vertical sync. RGB CS = RGB analog signals, separate sync is composite sync. RGB CV = RGB analog signals, separate sync is composite video or tri-level sync. RGB-SOG = RGB analog signals, sync on green is composite sync. -
Page 22: Video Input
Connections How to select Slot 2 Key in 2 on the RCU or the local keypad. Video Input What can be connected Composite video signals from a VCR, OFF air signal decoder, etc... 1 x BNC or cinch 1.0Vpp ± 3 dB No loop through. -
Page 23: Serial Digital Input / Serial Digital Output (Optional)
Connections Pin configuration mini DIN plug ground luminance ground chrominance luminance 1.0Vpp ± 3 dB chrominance 282 mVpp ± 3 dB How to select Slot 4 Key in 4 on the RCU or the local keypad. Serial Digital Input / Serial Digital Output (optional) What can be connected to this input ? Full compatibility with digital Betacam, or digital video sources. -
Page 24: Ieee 1394 Input
Connections IEEE 1394 Input What can be connected to IEEE 1394 input? This input allows to display video in DV format on the 1394 bus (also called FirewireTM or i.LinkTM). When a DV camcorder is in camera mode or in VCR mode, playing a tape, it will broadcast the compressed video and audio on the 1394 bus. -
Page 25: Rs232 Connection
Connections RS232 Connection RS232 in / RS232 out To connect a Computer, e.g. IBM PC (or compatible), Apple Macintosh to the RS 232 input of the projector to allow communicate between the computer and the projector. S-VIDEO MOU SE 10/100BASE-T R S232 IN RS232 OUT C OMM. -
Page 26: Mouse
Connections MOUSE When available ? Mouse function is only available with the Executive Remote Control (Order number : R9829960). The computer can then be controlled via the projector. How to activate ? To activate this mouse function, handle as follow : Start up your computer with the computer mouse plugged in. -
Page 27: Audio Connections
Connections Audio Connections What is available ? Three audio inputs and one audio output are available. Each audio input can be associated with an input source using the control software of the projector. e.g. source 1 can be locked with audio input B. How to lock an audio input ? Locking an audio input to a source input : Press ENTER to start up the adjustment mode. - Page 28 Connections 4-12 5976183 BARCOGRAPHICS 6500 31012001...
-
Page 29: Getting Started
Getting Started GETTING STARTED Remote Control & Local Keypad How controlling the projector ? Location of the local keypad Remote control Overview of Terminology EXIT ENTER PAUSE TEXT PHASE SHARPN STANDBY EXIT TINT COLOR ENTER BRIGHTN TEXT PAUSE CONTR SHARPN TINT BRIGHTN TREBLE... -
Page 30: Operating The Projector
Getting Started Attention : Switching to Stand-by. When the projector is running and you want to go to stand-by, press the stand-by key for 2 seconds until the message 'Saving data, please wait' is displayed. Do not press any longer on the stand-by key otherwise the projector will restart. Operating the Projector Switching on... -
Page 31: Lamp Run Time
Getting Started Lamp Run Time Remaining Lamp run time 20 h Lamp run time is 1000 hours. Operating the lamp longer than 1000 hours may damage the projector. Please replace the lamp. WARNING Lamp run time is 1000 hours Operating the lamp longer than 1000 hours may damage the projector. -
Page 32: Quick On Screen Color Change
Getting Started ZOOM/FOCUS ZOOM with éor ê FOCUS with çor è <ENTER> to Shift <EXIT> to return é ê ç è SHIFT SHIFT with éor ê, çor è <ENTER> to Shift <EXIT> to return Quick On Screen Color change é ê... -
Page 33: Using The Rcu
Getting Started Using the RCU Pointing to the reflective screen Ceiling Screen IR sensor Hardwired Remote Input. MOUSE 10/10 0B ASE -T RS23 2 IN CO MM. PO RT V IDE O S -VIDE O I EE E 13 94 RS232 O UT MON ITO R H /C... -
Page 34: Projector Address
Getting Started Projector address Why a projector address ? Set up an Individual Projector Address. How to control the projector or projectors. Before using the RCU. Common Address Displaying the Projector Address on the Screen. PROJECTOR ADDRESS How to Program an Address into the RCU? -
Page 35: Sound Controls
Getting Started Controlling the Projector Input Selection Picture controls. BRIGHTNESS 'brightness' Sound Controls... -
Page 36: The Pause Key
Getting Started The Pause key. The Selection key. -
Page 37: Start Up Of The Adjustment Mode
Start up of the Adjustment Mode START UP OF THE ADJUSTMENT MODE Adjustment Mode Start Up All source parameters, picture and audio tuning, and geometry are made while in the 'Adjustment Mode'. Press the ADJUST or ENTER key to enter the 'Adjustment mode'. You are now in the 'Adjustment Mode'. -
Page 38: Remark
Start up of the Adjustment Mode When your password is correct, you gain access to the selected item. When your password is wrong. The error message "Invalid password" is displayed on the screen. Press EXIT to continue and to return to the Service menu. Error Invalid password <EXIT>... -
Page 39: Auto Image Adjustment
Auto Image Adjust AUTO IMAGE ADJUSTMENT Auto Image Adjustment Why Auto Image ? Auto image will center the image on the LCD panel when a file is loaded. Start Up Handle as follow to start up the auto image function : Push the cursor key é... -
Page 40: Action
Auto Image Adjust Action What can be done ? The action function can be toggled between : - full automatic - on new file - manual [full automatic] : the best fitting file will be loaded automatically when a source is selected. At the same time the image will be automatically centered on the active surface of the LCD. -
Page 41: Random Access Adjustment Mode
Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE Random Access Mode Overview Flowchart... -
Page 42: Possible File Manipulations
Random Access Adjustment Mode Starting Up é ê ENTER ADJUSTMENT MODE Select a path from below : AUTO IMAGE RANDOM ACCESS INSTALLATION SERVICE Source 01 Select with é or ê then <ENTER> <EXIT> to return. Picture Service Connecting a new Source. Start up the File Service. -
Page 43: Load File
Random Access Adjustment Mode Load File é ê ENTER è ç ENTER FILE SERVICE LOAD FILE FILTER LIST [All] Filename Resolution LOAD E D I T ----------------------------------------------------- RENAME Video525.s01 1 675x240i COPY Video525.c01 1 675x240i Video525.c02 1 675x240i ----------------------------------------------------- Active file : Video525.c50 Select with é... -
Page 44: How To Start Up The Edit Menu
Random Access Adjustment Mode How to start up the Edit menu ? é ê ENTER ENTER FILE SERVICE EDIT FILE LOAD Filename Resolution EDIT ----------------------------------------------------- RENAME Video525.s01 1 675x240i COPY Video525.c01 1 675x240i Video525.c02 1 675x240i ----------------------------------------------------- Active file : Video525.c50 Select with é... - Page 45 Random Access Adjustment Mode "Horizontal Total Pixels" "Active Pixels" "Horizontal Start "Horizontal Period" "Vertical Total Lines" "Active Lines" Vertical start Interlaced [On] or [Off] Read AMDS Options EDIT FILE OPTIONS Source number Clamp position [leading] Clamp delay Clamp width Field polarity [pos] Field select [both]...
-
Page 46: Rename A File
Random Access Adjustment Mode Field Polarity ENTER Field Select ENTER Vertical Refresh [sync/async] Vertical Sync Polarity ENTER EXIT CONFIRM EDIT FILE Save changes to file xga.c30? <ENTER> to confirm <EXIT> to return Rename a file Start Up é ê ENTER é... -
Page 47: How To Change The Characters
Random Access Adjustment Mode How to change the characters ? ç è é ê ENTER EXIT RENAME FILE Frome file name : Video525.s01 To file name : demo.c10 Select with é or ê Reprogram with ç or è or numeric keys <ENTER>... -
Page 48: Delete
Random Access Adjustment Mode Delete Start Up é ê ENTER é ê ENTER ENTER EXIT FILE SERVICE CONFIRM DELETE FILE DELETE FILE LOAD Filename Resolution E D I T ----------------------------------------------------- Delete file: RENAME Video525.s01 1 675x240i Video525.c01? COPY Video525.c01 1 675x240i DELETE Video525.c02 1... -
Page 49: Picture Tuning
Random Access Adjustment Mode Picture Tuning Start Up é ê ENTER PICTURE TUNING RANDOM ACCESS ADJUSTMENT MODE CTI [ON] COLOR TEMPERATURE FILE SERVICE GAMMA PICTURE TUNING DECODING [EBU] AUDIO TUNNING DYNAMIC COLOR DEPTH GEOMETRY NOISE REDUCTION IEEE 1394 INPUT BALANCE Select with é... -
Page 50: Color Temperature
Random Access Adjustment Mode Color Temperature Start Up é ê ENTER PICTURE TUNING COLOR TEMPERATURE CTI [ON] PROJECTOR WHITE COLOR TEMPERATURE COMPUTER 9300K GAMMA VIDEO 6500K DECODING [EBU] FILM 5400K DYNAMIC COLOR DEPTH BROADCAST 3200K NOISE REDUCTION INPUT BALANCE CUSTOM BALANCE Select with é... -
Page 51: Gamma
Random Access Adjustment Mode Gamma What can be adjusted ? How to change the gamma value ? é ê ENTER ç è EXIT PICTURE TUNING GAMMA = 1.9 CTI [ON] COLOR TEMPERATURE GAMMA menu 2 DECODING [EBU] DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with é... -
Page 52: Input Balance
Random Access Adjustment Mode To change the Dynamic Color depth value : é ê ENTER ç è EXIT PICTURE TUNING DYNAMIC COLOR DEPTH CTI [ON] COLOR TEMPERATURE GAMMA menu 2 DECODING [EBU] DYNAMIC COLOR DEPTH NOISE REDUCTION INPUT BALANCE Select with é or ê then <ENTER>... -
Page 53: Audio Tuning
Random Access Adjustment Mode é ê ENTER é ê ç è PICTURE TUNING INPUT BALANCE CTI [ON] WHITE BALANCE COLOR TEMPERATURE BLACK BALANCE GAMMA DECODING [EBU] DEFAULT COLOR DEPTH BLACK COLOR INPUT BALANCE Select with é or ê Select with é or ê then <ENTER>... -
Page 54: Fade
Random Access Adjustment Mode Mute Purpose How to stop sound reproduction ? é ê ENTER AUDIO TUNING VOLUME BALANCE B A S S TREBLE MUTE [OFF] FADE MODE [STEREO] VIDEO - AUDIO LOCK Select with é or ê then <ENTER> <EXIT>... -
Page 55: Video - Audio Lock
Random Access Adjustment Mode Video - Audio lock Purpose How to lock input source to an audio source ? é ê ENTER ç è ENTER AUDIO TUNING VOLUME BALANCE TREBLE MUTE [OFF] FADE MODE [STEREO] VIDEO - AUDIO LOCK Select with é or ê then <ENTER>... -
Page 56: Shift
Random Access Adjustment Mode Shift What can be done ? To start up the shift action : é ê ENTER é ê ç è GEOMETRY SHIFT SIZE SIDE KEYSTONE BLANKING ASPECT RATIO [5:4] OPTIONS Select with é or ê then <ENTER> <EXIT>... -
Page 57: Side Keystone
Random Access Adjustment Mode Side Keystone What can be done ? Aligning the keystone é ê ENTER ç è ç è GEOMETRY SHIFT SIZE SIDE KEYSTONE BLANKING ASPECT RATIO [5:4] OPTIONS Select with é or ê then <ENTER> <EXIT> to return. menu 1 Blanking What can be done ? -
Page 58: Adjusting The Blanking
Random Access Adjustment Mode Adjusting the blanking. é ê ENTER é ê GEOMETRY BLANKING SHIFT T O P BOTTOM SIZE LEFT SIDE KEYSTONE RIGHT BLANKING ASPECT RATIO [5:4] R E S E T OPTIONS Select with é or ê Select with é or ê then <ENTER>... -
Page 59: Options
Random Access Adjustment Mode Options How to change the geometry options ? é ê ENTER GEOMETRY OPTIONS GEOMETRY Use the same side SHIFT keystone correction SIZE for all files ? SIDE KEYSTONE [YES] BLANKING ASPECT RATIO [5:4] OPTIONS <ENTER> to toggle Select with é... -
Page 60: 1394 Setup
Random Access Adjustment Mode 1394 Setup Purpose How to start up ? é ê ENTER IEEE 1394 CONTROL 1394 SETUP AUDIODECODING: [ON] Select with é or ê then <ENTER> <EXIT> to return. menu 1 Audiodecoding Purpose How to toggle ? é... -
Page 61: How To Select A Function
Random Access Adjustment Mode How to select a function ? é ê ENTER é ê ENTER IEEE 1394 CAMCORDER CONTROL IEEE 1394 CONTROL PLAY PLAY FAST FORWARD STOP PLAY SLOW FORWARD CAMCORDER CONTROL PAUSE PLAY FAST REVERSE REWIND PLAY SLOW REVERSE FAST FORWARD Select with é... - Page 62 Random Access Adjustment Mode...
-
Page 63: Installation Mode
Installation Mode INSTALLATION MODE Installation Mode Start Up Push the cursor key é or ê to highlight 'Installation Mode' and then press ENTER. ADJUSTMENT MODE INSTALLATION INSTALLATION Select a path from below : INPUT SLOTS 800 PERIPHERALS NO SIGNAL CONFIGURATION OSD COLOR LENS RANDOM ACCESS... -
Page 64: Possible Results For The Input Slots
Installation Mode Possible results for the input slots : Source indication Video or S-Video Video S-Video RGB analog RGB-CV : separate sync is composite video signal on H/C input RGB-HS&VS : separate sync is horizontal and vertical sync RGB-CS : separate sync is composite sync RGB-SOG : sync on green Component video Component Video... -
Page 65: Lens Adjustments
Installation Mode Changing the Shutdown Time The shutdown time can be set between 5 min and 60 min. To set up the shutdown time, handle as follow : Push the cursor key é or ê to highlight 'No signal' (menu 1). Press ENTER to select. -
Page 66: Text Box Position
Installation Mode Text Box Position What can be done ? The text box position can be changed from bottom right to automatic, dependig the aspect ratio the projector chooses a position, to center, always in the center of the image. How to change the setting ? Push the cursor key é... -
Page 67: Start Up Mode
Installation Mode Start Up mode What can be done ? During start up, the projector can show first the identification screen or a blank screen. The projector can start up with auto power. The projector starts up in the same power condition as it was before power supply was interrupted. -
Page 68: Network Configuration
Installation Mode Network configuration What can be done ? The necessary network addresses (configuration) can be entered so that the projector can be connected to a LAN (local area network). Set up the network configuration To set up the network configuration, follow the next procedure : Push the cursor key é... -
Page 69: Defining The Infrared Communication Protocol
Installation Mode To define the output module : Push the cursor key é or ê to highlight '800 Peripheral' (menu 1). Press ENTER to select. Push the cursor key é or ê to highlight 'Output module' (menu 2). Press ENTER to toggle between 'Standard' or '5-cable'. INSTALLATION 800 PERIPHERAL 800 PERIPHERALS... -
Page 70: Available Patterns
Installation Mode OSD color (On-Screen Display) What can be done ? The highlighted items on the menus can be displayed in red, green or yellow. How to change this color setting ? Push the cursor key é or ê to highlight 'OSD color'. Press ENTER to select. -
Page 71: How To Install The Switching Mode
Installation Mode How to install the switching mode ? To install the switching mode, follow the next procedure : Push the cursor key é or ê to highlight 'Switching mode' (menu 1). Press ENTER to select. The switching mode menu will be displayed (menu 2). Select 'Switching' and press ENTER to toggle between [blanking] or [freeze]. - Page 72 Installation Mode 9-10 5976183 BARCOGRAPHICS 6500 31012001...
-
Page 73: Service Mode
All other password protected items are now available if you stay in the adjustment mode. ADJUSTMENT MODE SERVICE SERVICE Select a path from below : IDENTIFICATION BARCO LOGO CHANGE PASSWORD PANEL ADJUSTMENTS CHANGE LANGUAGE UNIFORMITY RANDOM ACCESS CHANGE PROJ. ADDRESS... -
Page 74: Identification
ENTER then <ENTER> then <ENTER> <EXIT> to return. <EXIT> to return. Select with é or ê then <ENTER> <EXIT> to return. BARCO LOGO SERVICE I2C DIAGNOSIS D C A STATUS : [ON] BARCO LOGO DECODER 12H # # #... -
Page 75: Change Password
How to enable or disable the password function ? This item is password protected when the password strap is installed. The password function is enabled when the password strap on the controller module is installed. Consult an authorised Barco service technician to change the strap position. -
Page 76: Projector Address
Service Mode Change Projector Address What can be changed ? Within the 'Change Projector Address' item, the follow items can be changed : - Projector address - Common address Start up Push the cursor key é or ê to highlight 'Change Projector Address'' (menu 1). Press ENTER to select. -
Page 77: Entering The New Common Address
Service Mode Entering the new common address Only addresses between 0 and 1 are valid. with the digit keys on the RCU or the local keypad or pushing the cursor key é or ê until the new value is reached. Change Baudrate PC Start Up Push the cursor key é... -
Page 78: Start Up
BARCO logo What can be done ? The BARCO logo can be added to the image, in overlay or on a background, on any place on the screen. How to add the BARCO logo or to change a setting ? Push the cursor key é... -
Page 79: Available Settings
OFF : no key on the RCU is used to display the BARCO logo. TEXT : the TEXT key on the RCU is used to display or to remove the BARCO logo with one single push on this key (only in operational mode). -
Page 80: Preset Input Balance
The following warning will be displayed : Preset Input Balance is reserved to qualified service personnel. If you are not qualified, press EXIT to cancel the preset input balance. SERVICE WARNING BARCO LOGO PANEL ADJUSTMENTS UNIFORMITY PRESET INPUT BALANCE I2C DIAGNOSIS... -
Page 81: Standard Source Set Up Files
Appendix A : Standard Source Set Up Files STANDARD SOURCE SET UP FILES NAME RESOLUTION FVERT FHOR FPIX PTOT PACT LTOT LACT Name : name of file, contains the settings Resolution : image resolution, when fol- 1600_48V 1600 X 600I 48,040 62,500 135,000 2160 1600 lowed by ...I means interlaced. - Page 82 Appendix A : Standard Source Set Up Files NAME RESOLUTION FVERT FHOR FPIX PTOT PACT LTOT LACT PAM800 1120 X 375I 44,936 36,443 50,000 1372 1120 PC98_1 640 X 400 56,416 24,823 21,050 848 PC98_2 1120 X 375I 39,994 32,835 47,840 1457 1120 PC98_3 1120 X 750...
-
Page 83: Source Numbers 81 - 86 And 91 - 96
Source Numbers 80 - 89 and 90 - 99 SOURCE NUMBERS 81 - 86 AND 91 - 96 Projector without any 800 peripheral connected. The source numbers 81 - 86 and 91 - 96 do not correspond to physical inputs. An additional adjustment file can be created for these source numbers. - Page 84 Source Numbers 80 - 89 and 90 - 99 Source numbers 81 - 86 Only valid if no input module is connected to slot 81 - 86 of a RCVDS05. The source numbers 81 - 86 correspond to the physical inputs 1 - 6 of the projector. e.g.
-
Page 85: Barco Control Manager
Barco Control Manager BARCO CONTROL MANAGER Control Manager Functionality Computer requirements Embedded projector software About the control manager Start Up ENTER image 1... -
Page 86: Information On The Start Up Page
Barco Control Manager Information on the Start Up page. Control manager Start Page Starting up the control manager image 2 Using the default window image 3... -
Page 87: Control
Barco Control Manager Control Start Up image 4 Available items... -
Page 88: Security
Barco Control Manager Security image 5 General Control image 6... -
Page 89: Source
Barco Control Manager Source image 7 Image Settings image 8 Attention :... -
Page 90: Image Enhancement
Barco Control Manager Image Enhancement image 9 Attention :... -
Page 91: Lens Adjustment
Barco Control Manager Lens adjustment image 10 Geometry adjustment image 11... -
Page 92: Blanking Adjustment
Barco Control Manager é ê ç è Blanking adjustment image 12... -
Page 93: Audio Adjustment
Barco Control Manager Audio adjustment image 13 Attention : Configuration Start Up image 14... -
Page 94: Available Items
Barco Control Manager Available items Security image 15... -
Page 95: Mail Setup
Barco Control Manager Mail Setup image 16... -
Page 96: Security
Barco Control Manager Security image 17... -
Page 97: Date & Time
Barco Control Manager Date & Time image 18... -
Page 98: Settings
Barco Control Manager Settings image 19 Source image 20... -
Page 99: Diagnostics
Barco Control Manager Diagnostics image 21 Available items... -
Page 100: General Status
Barco Control Manager General Status Job Log image 22 Advanced Diagnostics image 23... - Page 101 Cleaning the Dustfilter CLEANING THE DUSTFILTER Cleaning the dustfilter When should it be done ? Depending on the environement, the dust filters should be cleaned at least when replacing the lamp. When the projector operates in dusty environement, clean the dust filters earlier than when replacing the lamp. How to clean the dustfilter ? To clean the dustfilter, follow the next procedure : Turn the projector upside down.
-
Page 102: Cleaning The Dustfilter
Cleaning the Dustfilter 5976183 BARCOGRAPHICS 6500 31012001... -
Page 103: Index
Index INDEX Adjustment Mode Dust filter Start up 6-1 Cleaning the dustfilter D-1 Aspect Ratio 8-18 Audio Tuning 8-13 Fade 8-14 Mode 8-14 Edit File 8-3 Mute 8-14 Auto Image 7-1 Action 7-2 Image Adjustment 7-1 FCC Warning 2 Auto image File Service action 7-2 Copy a file 8-7... - Page 104 How to use 5-1 Installation 3-4 Terminology 5-1 Load File 8-3 Using the 5-5 MOUSE 4-10 Service Mode 10-1 BARCO logo 10-6 Change Baudrate PC 10-5 Change Language 10-3 Netwerk Connection 4-10 Change Projector Address 10-4 Network configuration 9-6 Common Address 10-4...
