- Page 1 OPERATION AND PARTS MANUAL COLLOMIX Hand Mixers CX100HF CX100HFE CX300HF CX400HFE CX600HF CX600HFE Revision #3 (03/11/08) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
-
Page 2: Silicosis/Respiratory Warnings
CX-HF HAND MIXERS — SILICOSIS/RESPIRATORY WARNINGS WARNING WARNING SILICOSIS WARNING RESPIRATORY HAZARDS Grinding/cutting/drilling of masonry, concrete, metal and Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give other materials can generate dust, mists and fumes off dust or mists containing crystalline silica. -
Page 3: Table Of Contents
CX-HF HAND MIXERS — TABLE OF CONTENTS Component Drawings STOW CX-HF SERIES Mixer Assembly (CX100) ........18-21 HAND MIXERS Mixer Assembly (CX300) ........22-25 Silicosis/Respiratory Warnings ........2 Mixer Assembly (CX400) ........26-29 Table Of Contents ............. 3 Mixer Assembly (CX600) ........30-33 Parts Ordering Procedures ........ -
Page 4: Parts Ordering Procedures
Parts Department: STOW CONSTRUCTION EQUIPMENT STOW CONSTRUCTION EQUIPMENT STOW CONSTRUCTION EQUIPMENT STOW CONSTRUCTION EQUIPMENT STOW CONSTRUCTION EQUIPMENT A DIVISION OF MULTIQUIP INC. Toll-free nationwide — 800-427-1244 POST OFFICE BOX 6254 CARSON, CA 90749 888-252-STOW [888-252-7869] 310-537-3700 Toll-free FAX — 800-6-PARTS-7... -
Page 5: Safety Message Alert Symbols
CX-HF SERIES HAND MIXERS — SAFETY MESSAGE ALERT SYMBOLS FOR YOUR SAFETY AND THE SAFETY OF OTHERS! HAZARD SYMBOLS Safety precautions should be followed at all times when Rotating Parts operating this equipment. Failure to read and understand the Safety Messages and Operating Instructions could result in injury to yourself and others. -
Page 6: Rules For Safe Operation
■ NEVER use accessories, attachments, or replacement parts safety decals when they become difficult to read. which are not recommended by Multiquip for this equipment. ■ ALWAYS check the machine for loosened threads or bolts Damage to the equipment and/or injury to user may result. - Page 7 CX-HF SERIES HAND MIXERS — RULES FOR SAFE OPERATION ■ DO NOT spray water onto electric motor. Do not expose Maintenance Safety equipment to rain or wet conditions. Water entering the ■ NEVER lubricate components or attempt service on a running equipment will increase the risk of electric shock.
-
Page 8: Symbols Used
CX-HF SERIES HAND MIXERS — SYMBOLS USED Some of the following symbols may be used on this equipment. Familiarize yourself with them and their meaning. Proper interpretation of these symbols will allow you to operate the equipment better and safer. Symbols Name Designation/Explanation... -
Page 9: Specifications
CX-HF SERIES HAND MIXERS — SPECIFICATIONS i r e i f i o i t a t l s t t i x i r e t r e t c n i c n i c n i c n i l e v e s i i s s... -
Page 10: General Information
CX-HF SERIES HAND MIXERS — GENERAL INFORMATION Application Ensure that the extension cable is carefully laid out avoid- ing wet areas , sharp edges and locations where vehicles The Stow CX-HF Series Hand Mixers are designed for mixing might run over it. liquid and power-based products such as paints, mortar, adhesives, plaster, and similar substances used in the Unroll the extension cable fully or it will overheat and could... - Page 11 CX-HF SERIES HAND MIXERS — GENERAL INFORMATION Paddles The CX-HF Series Hand Mixers can use different paddles depending on the application it will be used for. See table below for the available paddles. — l a i " 4 " 4 "...
-
Page 12: Components
Refer to Figure 1 for the location of the following mixer gear (slow or fast) at which the unit is operating (not components. applicable on CX100HF/CX100HFE). Ventilation Slits — These openings allow ventilation to Protection Frame Fastening Screws — Holds the the unit to prevent overheating. -
Page 13: Setup
CX-HF SERIES HAND MIXERS — SETUP A 120V/230V power supply can also be used. Make Assembly sure that the power supply conforms to the Before using the hand mixer, the following steps need to be specifications on the nameplate of the mixer. Voltage performed. -
Page 14: Operation
CX-HF SERIES HAND MIXERS — OPERATION When submerging the mixing tool in the mixing material CAUTION or when lifting out the mixing tool, always reduce the speed. When the mixing tool is fully submerged, ALWAYS hold the machine with both hands while working. increase the speed again to ensure that the motor is adequately cooled. -
Page 15: Maintenance
CX-HF SERIES HAND MIXERS — MAINTENANCE Mixer Storage CAUTION For storage of the mixer for over 30 days, the following is ALWAYS disconnect the mixer from the power supply recommended: before cleaning, changing the mixing paddle or performing any maintenance. Clean the mixer and mixing tool. -
Page 16: Explanation Of Code In Remarks Column
Multiquip. A blank entry generally indicates that the item is not sold separately or is not sold by Multiquip. Other entries will be clarified in the “Remarks” Column. PAGE 16 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08) -
Page 17: Suggested Spare Parts
CX-HF SERIES HAND MIXERS — SUGGESTED SPARE PARTS CX100HF/CX100HFE/CX300HF/CX300HFE/CX400HFE/CX600HF/CX600HFE (1 TO 4 UNITS) QTY. DESCRIPTION 2 ..CM20509 ..SPRING FOR BRUSH ASSY (CX100, CX300, CX400) 1 ..CM20567 ..BRUSH SET (CX100, CX300, CX400) 2 ..CM20569 ..BRUSH HOLDER (CX600) 1 .. -
Page 18: Mixer Assembly (Cx100)
CX100 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 18 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08) - Page 19 ARMATURE, OEM10 230V ......... 1 ..CX100HFE ONLY CM20591 ARMATURE, OEM10 110V ......... 1 ..CX100HF ONLY CM20556 FIELD COIL, OEM10/20 230V ......1 ..CX100HFE ONLY CM20592 FIELD COIL, OEM10/20 110V ......1 ..CX100HF ONLY CM20707 SPINDLE CM20548 MIDDLE SHAFT CM20502...
- Page 20 CX100 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 20 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08)
- Page 21 MAIN CABLE 230V WITH CH-PLUG ....1 ..CX100HFE ONLY CM27053 MAIN CABLE 230V WITH UK-PLUG ....1 ..CX100HFE ONLY CM27035 MAIN CABLE 110V WITH UK-PLUG ....1 ..CX100HF ONLY CM27054 MAIN CABLE 110V WITH US-PLUG ....1 ..CX100HF ONLY CM20588...
-
Page 22: Mixer Assembly (Cx300)
CX300 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 22 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08) - Page 23 CX300 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PART NO PART NAME QTY. REMARKS CM20530 MOTOR HOUSING TOP CM20531 MOTOR HOUSING BOTTOM CM20705 GEAR HOUSING ASSY CM20553 PLATE ASSY CM20524 BAFFLE PLATE CM20529 RECTIFIER CM20526 AIR OUTLET CM20601 COVER BLACK CM20594 ARMATURE 110V CM20592...
- Page 24 CX300 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 24 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08)
- Page 25 CX300 HAND MIXER — MIXER ASSEMBLY (CONTINUED) MIXER ASSY. PART NO PART NAME QTY. REMARKS CM24060 CIRCLIP A15 X1.5 CM20571 CIRCLIP 20 CM20572 CIRCLIP 47 CM28548 PIN 5X5X10 CM20593 ACCELERATION SWITCH 110V CM29534 CAPACITOR CM27035 MAIN CABLE 110V WITH UK-PLUG CM27054 MAIN CABLE 110V WITH US-PLUG CM20588...
-
Page 26: Mixer Assembly (Cx400)
CX400 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 26 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08) - Page 27 CX400 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PART NO PART NAME QTY. REMARKS CM20530 MOTOR HOUSING TOP CM20531 MOTOR HOUSING BOTTOM CM20705 GEAR HOUSING ASSY CM20553 PLATE ASSY CM20524 BAFFLE PLATE CM20529 RECTIFIER CM20526 AIR OUTLET CM20688 COVER CM20715 ARMATURE CM20701 FIELD COIL...
- Page 28 CX400 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 28 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08)
- Page 29 CX400 HAND MIXER — MIXER ASSEMBLY (CONTINUED) MIXER ASSY. PART NO PART NAME QTY. REMARKS 24060 CIRCLIP A15 X1.5 20571 CIRCLIP 20 20572 CIRCLIP 47 28548 PIN 5X5X10 20703 SWITCH ASSY 20712 CURRENT LIMITER 20689 WIRE 23557 MAIN CABLE 230 V WITH EU PLUG 20692 WIRE 23556...
-
Page 30: Mixer Assembly (Cx600)
CX600 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 30 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08) - Page 31 CX600 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PART NO PART NAME QTY. REMARKS CM20532 MOTOR HOUSING TOP CM20533 MOTOR HOUSING BOTTOM CM20705 GEAR HOUSING ASSY CM20554 PLATE ASSY CM20646 RIGHT AND LEFT HANDLE ASSY CM20602 COVER CM20536 AIR OUTLET CM20535 BAFFLE PLATE CM20529...
- Page 32 CX600 HAND MIXER — MIXER ASSEMBLY MIXER ASSY. PAGE 32 — CX-HF SERIES HAND MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08)
- Page 33 CX600 HAND MIXER — MIXER ASSEMBLY (CONTINUED) MIXER ASSY. PART NO PART NAME QTY. REMARKS CM24060 CIRCLIP A15 X1,5 CM20571 CIRCLIP 20 CM20572 CIRCLIP 47 CM28548 PIN 5X5X10 CM20580 SWITCH 230V CX600HFE ONLY CM20597 SWITCH 110V CX600HF ONLY CM20649 KNOB SWITCH CM20650 LEVER CM20568...
-
Page 34: Terms And Conditions Of Sale - Parts
TERMS AND CONDITIONS OF SALE — PARTS Terms and Conditions of Sale STOW Construction Equipment PAYMENT TERMS DROP SHIPMENTS Terms of payment for unit sales are 2% 15 days The sender will be notified of any material STOW reserves the right to refuse Drop net 30 days from date of invoice unless received that does not meet the above Shipments outside the normal service area of... - Page 35 NOTE PAGE CX-HF SERIES MIXERS — OPERATION AND PARTS MANUAL — REV. #3 (03/11/08) — PAGE 35...
- Page 36 The information and specifications included in this publication were in effect at the time of approval for printing. Illustrations, descriptions, references and technical data contained in this manual are for guidance only and may not be considered as binding. Multiquip Inc. reserves the right to discontinue or change specifications, design or the information published in this publication at any time without notice and without incurring any obligations.
