- Page 1 US Operator’s manual Soff-Cut 2500 Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. HUSQVARNA CONSTRUCTION PRODUCTS...
-
Page 2: Table Of Contents
UNPACKING CONTENTS Your 2500 saw has been shipped from the factory thoroughly Content Page inspected. Only minimal assembly is required to start using Table of contents ………………………….. the saw. Remove the saw from the container using proper lift- Unpacking ..........ing techniques. -
Page 3: I Ntroduction, Personal Safety
The patented low noise and low dust blade block and skid plate technology in conjunction with the Husqvarna blades allows for Ultra Early Entry sawing the same day while minimizing chipping and spalling. The saw is a self-propelled style with electric switch controls for all functions and electric start. -
Page 4: Registration Of The Product
REGISTER THE PRODUCT Please register your new 2500 with Husqvarna Construction Products by mailing in the registration card that came with the machine or you can register on the internet site www.husqvarnawarranty.com Registration will allow us to contact in case of any critical updates or recalls on this machine. -
Page 5: Safety Warnings
• Do not operate the saw in areas of combustible material or • Use only Husqvarna Excel Series blades or blades marked fumes. Sparks may occur from the saw that could cause a fire or explosion. -
Page 6: Excel Series Blades
EXCEL SERIES BLADES The Excel Series of diamond blades have been designed specifically for the Soff-Cut Ultra Early Entry dry cutting system of green concrete. These specialty blades are designed to increase speed and life while cutting a wide range of aggregates. Choose the correct specification of diamond blade for your area as follows: Purple Excel Series 1000 XL10-1000... -
Page 7: What Is What
WHAT IS WHAT Model number and serial What is what? number Choke Circuit breaker C. Engine on/off switch D. Emergency stop switch Tachometer Hour meter/Volt meter G. Saw forward speed switch H. Guide switch Engine speed switch Transmission neutral light Digital display Max blade depth indicator M. -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Control panel To start the engine, turn the fuel valve (X) on by the carburetor on the side of the engine. Turn the key switch (C) to the “ON” or “1” position to activate the rocker switches. Raise the saw by pushing the blade rocker switch (O) on the instrument panel to the full up position. - Page 9 cont... Increase the forward speed if the saw is pulling left. Decrease the forward speed if the saw is pulling right. Do not force the saw. When approaching a wall, raise the front guide and use DIGITAL DISPLAY (K) the triangle guide at the back of the blade block to cut the last The digital display in the center of the instrument panel indi- few feet.
-
Page 10: Fuel And Fuel Safety Warnings
FUEL HANDLING OIL HANDLING NOTICE WARNING Used oil is a hazardous waste product. Dispose Taking the following precautions will lessen the risk of used oil properly. Do not discard with household of injury and property damage: waste. Check with your local authorities, service center, or dealer for safe disposal/recycling facility. -
Page 11: Engine And Transmission Maintenance
ENGINE AND TRANSMISSION MAINTENANCE Engine Oil Checking, Adding and Changing Oil Check the engine oil level (A) daily with saw fully lowered and Air filter the engine level. See the enclosed Kohler manual for more The air cleaner assembly (C) is a cyclone type that can be details. -
Page 12: Other Maintenance
Skid plate Inspect the skid plate daily for damage, excessive wear in the Do not modify the saw! Use only Husqvarna Construc- blade slot, burrs on the concrete surface side, twisting and free tion Products replacement parts. Use of unauthorized movement up and down when installed on the blade block. -
Page 13: Sawing Contraction Joints
Husqvarna sawed contraction joints should be a minimum of 1/8th the concrete depth and a minimum of 1”... -
Page 14: Maximizing The Soff-Cut System
Cut is being specified more today than ever, sometimes the ultra early-entry spec is not always followed on the job site. In order for the Soff-Cut system and an experienced Husqvarna contractor to do a satisfactory job, four components must exist to meet the “specification”:... -
Page 15: Troubleshooting
- Do not twist or move the saw sideways while cutting. Make - Use Husqvarna joint protectors at all cut intersections. gradual changes in pressure on the handlebar to control the saw in the cut. -
Page 16: Technical Specifications
EC DECLARATION OF CONFORMITY Husqvarna AB, SE-433 81 Göteborg, Sweden, tel: +46-31-949000, declares under sole responsibility that the Husqvarna Soff-Cut 2500 dating from 2010 serial numbers and onwards (the year is clearly stated on the rating plate, followed by the serial number), complies with the requirements of the COUNCILíS DIRECTIVE:... -
Page 17: Warranty
The use of any other blade except Husqvarna Construction Products blades and skid plates will void the warranty and could cause internal damage to the motor. - Page 18 www.husqvarnacp.com 1153476-95 Original instructions 2009-12-29 ´®z+UOe¶5y¨ ´®z+UOe¶5y¨...
