American Standard Colony Pressure Balance Bath/Shower Fitting T372.128 Specification Sheet

T375.128 Bath/Shower Trim Shown
GENERAL DESCRIPTION:
TRIM KIT
FloWise water saving showerhead offers 40% water
savings at maximum 1.5gpm/5.7L/min. flow rate. Slip-on
diverter spout. Available with lever or metal lever handle.
Available in Bath/Shower and Shower Only combinations.
ROUGH VALVE BODY
Cast brass body, washerless ceramic disc valve cartridge
with back to back capability, and hot limit safety stop.
Cycles from "off" to "cold" to "hot". Pressure balancing
cartridge maintains constant output temperature in
response to changes in relative hot and cold supply
pressure. 1/2" inlets and outlets (choice of direct sweat,
threaded, or PEX). Available with screwdriver stops.
Rough-in plaster guard designed for use as thin-wall
mounting adaptor.
SUGGESTED SPECIFICATION:
Bath/shower fitting shall feature water saving showerhead with Max. 1.5gpm/5.7L/min. flow rate. Shall feature a cast brass body. Shall
feature ceramic disc valve cartridge which is capable of back-to-back installation. Fitting shall be equipped with pressure
balancing cartridge engineered to eliminate cross flow and avoid failure due to mineral deposits. Shall also feature hot limit safety
stop. Fitting shall be: Rough Valve Body - American Standard Model # R11____, Trim Kit - American Standard Model #
T37_.____.____.
© 2008 AS America Inc.
PRESSURE BALANCE BATH/SHOWER FITTING
MODEL NUMBER:
TRIM KITS:
T375.128 Colony BATH/SHOWER Trim Kit
Lever Handle. FloWise Showerhead. L ESS Valve Body.
T375.248 Colony BATH/SHOWER Trim Kit
Metal Lever Handle. FloWise Showerhead. L ESS Valve Body.
T372.128 Colony SHOWER ONLY Trim Kit
Lever Handle. FloWise Showerhead. L ESS Valve Body.
T372.248 Colony SHOWER ONLY Trim Kit
Metal Lever Handle. FloWise Showerhead. L ESS Valve Body.
ROUGH VALVES:
R110 Pressure Balance Rough Valve Body only
Direct sweat inlets/outlets. LESS trim.
R110SS Pressure Balance Rough Valve Body only
with Screwdriver stops
Direct sweat inlets/outlets. Screwdriver stops. LESS trim.
R115 Pressure Balance Rough Valve Body only
Female thread inlets/outlets. LESS trim.
R115SS Pressure Balance Rough Valve Body only
with Screwdriver stops
Female thread inlets/outlets. Screwdriver stops. LESS trim.
R117 Pressure Balance Rough Valve Body only
PEX inlets/Direct sweat outlets. LESS trim.
R117SS Pressure Balance Rough Valve Body only
with Screwdriver stops
PEX inlets/Direct sweat outlets. Screwdriver stops. LESS trim.
PRODUCT FEATURES:
Flowise Water Saving Showerhead:
water usage. Max. 1.5gpm/5.7L/min. flow rate.
Cast Brass Valve Body:
lifetime. Ideal material for prolonged contact with water.
Ceramic Disc Valve Cartridge:
drip-free performance. Allows easy fine tuning of temperature
(125˚handle rotation from off to hot).
Pressure Balancing Valve Cartridge:
output temperature in response to changes in hot and cold
supply pressure. Diaphragm system engineered to eliminate
cross flow. Avoids failure due to mineral deposits - ideal for use
in hard water.
Back-to-Back Capability:
quickly and easily.
Adjustable Hot Limit Safety Stop:
hot water allowed to mix with cold. Reduces the risk of
accidental scalding.
Exclusive Plaster Guard:
protect valve during installation and serve as a mounting
plate for thin-wall installations. 2 piece design allows valve to
be tested prior to trim installation.
Wide Rough-in Range:
B27
COLONY
WITH FloWise SHOWERHEAD
®
Saves up to 40% in
Durable - Quality that will last a
Assures a lifetime of
Maintains constant
Hot and cold can be reversed
Limits the amount of
Plaster guard is designed to
From 1-5/8" to 3-1/4".
