Summary of Contents for Kenmore 796.8107
- Page 1 Use & Care Guide Manual de Uso y Cuidado English / Español Model/Modelo: 796.8107#, 796.9107# Kenmore Elite ® Steam Dryer Secador con vapor # = color number, numero de color P/N MFL67731003 Sears Brand Management Corporation Hoffman Estates, IL 60179 U.S.A.
- Page 2 INSTALLATION INSTRUCTIONS CONNECTING GAS DRYERS GAS REQUIREMENTS (GAS MODELS ONLY) WARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Gas supply requirements: As shipped from the • Connect the dryer to the type of gas shown on factory, this dryer is configured for use with natural the nameplate.
- Page 3 INSTALLATION INSTRUCTIONS CONNECTING GAS DRYERS (continued) WARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Installation and service must be performed by a • If necessary, the correct nozzle (for the LP nozzle kit, qualified installer, service agency, or the gas supplier. order part number 383EEL3002D) should be installed Failure to do so can result in fire, explosion, or death. by a qualified technician and the change should be noted on the dryer.
- Page 4 INSTALLATION INSTRUCTIONS CONNECTING ELECTRIC DRYERS ELECTRICAL REQUIREMENTS Electrical Requirements for Electric Models Only WARNING: To help prevent fire, electrical shock, serious injury, or death, the wiring and grounding must conform to the latest edition of WARNING: the National Electrical Code, ANSI/NFPA 70 and all To reduce the risk of applicable local regulations.
- Page 5 INSTALLATION INSTRUCTIONS CONNECTING ELECTRIC DRYERS (continued) WARNING: Grounding through the neutral wire is prohibited for: (1) Connect the power cord to the terminal block. Connect new branch-circuit installations, (2) mobile homes, (3) each power cord wire to the terminal block screw that recreational vehicles, and (4) areas where local codes has the same colored wire. For example, connect the prohibit grounding through the neutral wire. black power cord wire to the terminal block screw with the black wire.
- Page 6 INSTALLATION INSTRUCTIONS VENTING THE DRYER IMPORTANT! CHECK YOUR EXHAUST SYSTEM FOR PROBLEMS The most common cause of dryer problems is poor • RESTRICTED OR DAMAGED VENT HOOD. Check exhaust venting. Before installing your new dryer, your vent hood outside. It must be clean and free of lint check the items listed below to make sure you get the buildup.
- Page 7 INSTALLATION INSTRUCTIONS VENTING THE DRYER (continued) Correct Venting Routing and Connecting Ductwork Follow the guidelines below to maximize dryer performance and reduce lint buildup and condensation in the ductwork. NOTE: Transition duct (from dryer to wall) and fittings are NOT included and must be purchased separately. •...
- Page 8 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS LEVELING THE DRYER REVERSING THE DOOR SWING The swing of the dryer door can be reversed to fit your WARNING: installation location. WARNING: • Wear gloves during installation. • Failure to follow these instructions can result in injury. THE DRYER DOOR IS VERY LARGE AND HEAVY.
- Page 9 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS FINAL INSTALLATION CHECK Testing Dryer Heating Once you have completed the installation of the dryer and it is in its final location, confirm proper operation with the following steps and tests. Close the dryer door. Is gas turned on? (Gas models only) Press the POWER button to turn the dryer on.
- Page 10 HOW TO USE WARNING: To reduce the risk of fire, electric shock, or injury to persons, read this entire manual, including the Important Safety Instructions, before operating this dryer. CONTROL PANEL FEATURES Iron Ready Drum Light Control Lock Loud Soft POWER (ON/OFF) BUTTON CYCLE MODIFIER BUTTONS Press to turn the dryer ON or OFF. Pressing the Use these buttons to adjust the settings for the POWER button during a cycle will cancel that cycle selected cycle.
- Page 11 HOW TO USE OPERATING THE DRYER LOAD THE DRYER Load the dryer with the wet laundry from the washer. If the load is extra large, you may need to divide it into smaller loads for proper performance and fabric care. CLEAN THE LINT FILTER If the lint filter has not already been cleaned, lift out the filter and remove the lint from the last load.
- Page 12 IMPORTANT SAFETY INSTRUCTIONS ....3-6 GROUNDING REQUIREMENTS ........4 Congratulations on making a smart purchase. Your new FEATURES AND BENEFITS Kenmore Elite product is designed and manufactured ® Key Parts and Components ........7 for years of dependable operation. But like all products,...
-
Page 13: Cycle Guide
HOW TO USE CYCLE GUIDE The cycle guide below shows the available options and recommended fabric types for AUTO DRY cycles. *NOTE: The default time and actual time will vary depending on the size of the load and moisture content. Auto Dry Cycles Auto Dry cycles utilize a sensor that detects moisture levels in the clothes and adjusts the drying time as needed to ensure superior results. - Page 14 HOW TO USE CYCLE GUIDE The cycle guide below shows the available options and recommended fabric types for TIMED DRY cycles. Timed Dry Cycles Use Timed Dry cycles to select a specific amount of drying time and the drying temperature. When a TIMED DRY cycle is selected, the display shows the actual time remaining in your cycle.
- Page 15 HOW TO USE WARNING: To reduce the risk of fire, electric shock, or injury to persons, read this entire manual, including the Important Safety Instructions, before operating this dryer. SORTING LOADS LOADING THE DRYER WARNING: Fabric Care Labels To reduce the risk of Most articles of clothing feature fabric care labels that fire, electric shock, or injury to persons when using include instructions for proper care.
- Page 16 HOW TO USE TIME AND STATUS DISPLAY The Time and Status Display shows the cycle time, cycle progress, and vent status. When the dryer is turned on, the display will illuminate. TIME DISPLAY CHECK VENT INDICATOR (DUCT BLOCKAGE SENSING SYSTEM) When a cycle is selected, the display will indicate the default time for that cycle including selected The CHECK VENT duct blockage sensing system options or adjustments.
- Page 17 HOW TO USE CYCLE MODIFIER BUTTONS Each cycle has default settings that are selected NOTE: To protect your garments, not every dry level, automatically. You may also customize these settings temperature, or option is available with every cycle. using the cycle modifier buttons. AUTO DRY cycles are designed to properly care for specific fabrics and loads.
- Page 18 HOW TO USE CYCLE OPTIONS AND SPECIAL FEATURES Your dryer features several additional cycle options and special features to meet your individual needs. For all steam features, see the following pages. WRINKLE GUARD DRUM LIGHT Selecting this option will tumble the clothes after The drum is equipped with a blue LED that illuminates the cycle ends for a few seconds every few minutes when the dryer is turned on.
- Page 19 HOW TO USE STEAM FEATURES Using the STATIC SHIELD option WARNING: This option uses steam late in the drying cycle to reduce • Do not open the dryer door during Steam Cycles. the static electricity caused by dry fabrics rubbing Steam can cause severe burns. together.
- Page 20 HOW TO USE STEAM FEATURES (continued) Filling the Steam Feeder: Tap water Tap water ON LY Steam Steam ONLY Feeder Feeder Drawer Fill the steam feeder with ordinary tap water to the Pull out the drawer. MAX line or until the water touches the filter screen. Place the steam feeder in the drawer;...
- Page 21 USER MAINTENANCE INSTRUCTIONS WARNING: To reduce the risk of fire, electric shock, or injury to persons, read this entire manual, including the Important Safety Instructions, before operating this dryer. • Unplug the dryer or turn the power off before cleaning to avoid the risk of electric shock. Failure to follow this warning can cause serious injury, fire, electrical shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the dryer.
- Page 22 USER MAINTENANCE INSTRUCTIONS MAINTAINING THE EXHAUST SYSTEM The most common cause of dryer problems is poor exhaust venting. Poor exhaust venting may result from the following conditions: • DIRTY OR DAMAGED EXHAUST DUCTS • WRONG VENT MATERIAL • RESTRICTED OR DAMAGED VENT HOOD • EXCESSIVELY LONG VENT • THE USE OF PLASTIC OR FOIL VENTING Maintaining the Exhaust System...
-
Page 23: What To Do If You Smell Gas
IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. - Page 24 Kenmore Connect System ™ If you experience problems with your dryer, call Should you experience any problems with your 1-800-4-MY-HOME ® . Only use the Kenmore Connect dryer, it has the capability of transmitting data via System feature when instructed to do so by the your telephone to the Kenmore Connect Team.
- Page 25 TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE Problem Possible Cause Solutions *CHECK VENT is Exhaust system is too long or has Install a shorter or straighter duct run. See the blinking too many turns/restrictions. Installation Instructions for details. Partial blockage of the ductwork Ductwork should be checked/cleaned immediately.
- Page 26 TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE (continued) Problem Possible Cause Solutions Clothes take too long to Exhaust ducts are blocked, dirty, or Confirm that the exhaust duct is properly duct run is too long. configured and free of debris, lint, and obstructions. Make sure that outside wall dampers can open properly and are not blocked, jammed, or damaged.
- Page 27 TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE (continued) Problem Possible Cause Solutions Display shows error Temperature sensor failure. Turn off the dryer and call for service. code: tE1 or tE2 Lint on clothes Lint filter not cleaned properly. Remove the lint from the filter before every load.
- Page 28 TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE (continued) Problem Possible Cause Solutions Steam Features Not Work- Cannot see steam vapor at the Steam is released at different stages of the ing (continued) beginning of the cycle. cycle for each option. Steam cannot be seen, but condensation may form on the inside of the door when steam is being generated.
- Page 29 WARRANTY Kenmore Elite Limited Warranty When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect in material and workmanship within one year from the date of purchase, call 1-800-4-MY-HOME to arrange for free repair.
-
Page 30: Basic Safety Precautions
IMPORTANT SAFETY INSTRUCTIONS BASIC SAFETY PRECAUTIONS WARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Do not allow children to play on or in the dryer. Close • Read all instructions before using the dryer. supervision of children is necessary when the dryer is •... -
Page 31: Safety Instructions For Installation
IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS FOR INSTALLATION WARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Properly ground dryer to conform with all governing • Remove all packing items and dispose of all shipping codes and ordinances. Follow details in the installation materials properly. -
Page 32: Safety Instructions For Steam Functions
IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS FOR STEAM FUNCTIONS WARNING: To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions, including the following: • Do not open the dryer door during steam cycles. • Do not fill the steam feeder with gasoline, dry- Failure to follow these instructions can result in a cleaning solvents, or other flammable or explosive burn hazard. substances. Failure to follow these instructions can result in fire or death. - Page 33 FEATURES AND BENEFITS KEY PARTS AND COMPONENTS There are several important components that are referenced in this manual. EASY-TO-USE CONTROL PANEL Rotate the cycle selector knob to select the desired dry cycle. Add cycle options or adjust settings with the touch of a button. TIME AND STATUS DISPLAY The easy-to-read LED display shows cycle status and estimated time remaining.
- Page 34 INSTALLATION INSTRUCTIONS KEY DIMENSIONS AND SPECIFICATIONS Description Dryer (Gas and Electric) Electrical Requirements Refer to the rating label Gas Requirements* NG: 4–10 inches WC (Water Column) 2 / 4 Gas Requirements* LP: 8–13 inches WC Dimensions 29 in. (W) X 31 in.
- Page 35 INSTALLATION INSTRUCTIONS INSTALLATION WITH OPTIONAL PEDESTAL BASE OR STACKING KIT IMPORTANT: If you are installing your dryer using an optional pedestal base or stacking kit, refer to the instructions included with the accessory. Required Dimensions for Required Dimensions for Installation with Pedestal Installation with Stacking Kit 6 in.
