NETGEAR WNCE2001 Installation Manual

WNCE2001_IG.fm Page 1 Friday, April 9, 2010 3:14 PM
Universal WiFi Internet Adapter (WNCE2001)

Package Contents

Power
adapter
WNCE2001
USB power
Ethernet cable
cable
Top and Back Views
Reset WPS
Power
WLAN
button button
LED
LAN
LED
LED
What is WPS?
If you have a NETGEAR router, this feature is called Push 'N' Connect. Look for the
the NETGEAR router supports WPS. For non-NETGEAR routers, please refer to the user manual to determine if the router supports WPS.
Once you know whether your router supports WPS, choose the appropriate installation method below.
Installation with WPS
Step 1:
Connect the WNCE2001
to your TV, XBox, or Blu-ray
player using the Ethernet
cable (included) and one
of the power connection
options. For more information
on power-up methods,
see "Power Connection
Options" on the reverse side.
Step 2: Push the WPS button on the
WNCE2001. The WLAN LED
will blink amber and green,
showing that the WPS is
running.
Step 3:
Push the WPS button on your router. The WLAN LED
on the WNCE2001 will stay green for
5 seconds when the wireless connection has been
established.
Step 4: Congratulations! Your installation is complete.
Power
Ethernet
Port
WPS (WiFi Protected Setup) is a simple and secured way to connect a device to an existing network.
or
Installation without WPS
Step 1:
Step 2
Step 3:
Step 4:
Step 5:
WPS
button
Step 6:
symbols on the router to make sure
Please disconnect any wireless connection to the router
and/or remove the Ethernet cable currently connected to
the computer. You may restore the connection after the
WNCE2001 installation is complete.
: Connect the WNCE2001 to your computer, using the
Ethernet cable (included) and one of the power connection
options. For more information on power-up methods,
see "Power Connection Options" on the reverse side.
Open your Internet browser and it will automatically take you
to the setup page. Follow the instructions on the setup page,
then return to this guide and continue to Step 4.
Disconnect the Ethernet and USB cables from your computer.
Connect the WNCE2001 to your TV, Box, or Blu-ray player.
If your device doesn't have a USB port, see
"Power Connection Options" on the reverse side.
Congratulations! Your installation is complete.
