PACEMARK 4410/
MICROLINE 4410
PRINTER
MAINTENANCE MANUAL
ODA/OEL/INT
1999. 3. 26 Rev.1
1 / 214
40496501TH Rev.1

Advertisement

Table of Contents
loading

Related Manuals for Oki PACEMARK 4410

Summary of Contents for Oki PACEMARK 4410

  • Page 1 PACEMARK 4410/ MICROLINE 4410 PRINTER MAINTENANCE MANUAL ODA/OEL/INT 1999. 3. 26 Rev.1 1 / 214 40496501TH Rev.1...
  • Page 2 Rev.No. Date Corrected items Person in Page Description of change change 40496501TH Rev.1...
  • Page 3 PREFACE This maintenance manual describes how to maintain the Pacemark 4410/Microline 4410 printer in the field. This manual is for customer engineers. For further information, refer to the Users Manual for handling or operating the equipment. 40496501TH Rev.1...

  • Page 4: Table Of Contents

    CONTENTS 1. CONFIGURATION ..................6 1.1 Basic System Configuration............... 6 1.2 Printer Specifications ................. 7 1.3 Option Specifications ................. 8 1.4 Basic Specifications ................9 2. THEORY OF OPERATION ................ 12 2.1 Electrical Operation ................12 2.1.1 Summary ....................12 2.1.2 Microprocessor and the peripheral circuit ..........
  • Page 5 3.3.16 Operator Board (POA Printed Board) ............70 3.3.17 Ribbon Feed Assy ................... 71 3.3.18 Printing Head ................... 72 3.3.19 Head Cable ..................... 73 3.3.20 Ribbon Protector ..................74 3.3.21 Space Motor Fan ..................75 3.3.22 Junction Board ..................76 3.3.23 Cover Open Switch Assy / Ribbon Rotation Sensor .......

  • Page 6: Configuration

    CONFIGURATION Basic System Configuration The basic system configuration of Pacemark 4410/ Microline 4410 is illustrated in Figure 1.1. Inter lock SW 40496501TH Rev.1...

  • Page 7: Printer Specifications

    Printer Specifications This printer unit is composed with the following hardware. • Printer mechanism • Main control/Motor driver board • Head driver board • Interface/Motor/Sensor board (including IEEE 1284 bidirectional parallel interface and RS- 232C serial interface) • Motor/Sensor and AG sensor boards •...

  • Page 8: Option Specifications

    Option Specifications Options available for Pacemark 4410/ Microline 4410 are as follows. (1) Interface boards (a) Oki-HSP (MUPIS) Network card (b) 300/500 Series Serial/ HSP Adapter • RS232C • RS422A • Current Loop 40496501TH Rev.1...

  • Page 9: Basic Specifications

    Basic Specifications (1) Dimensions Width: 768mm(30.24inches) Length: 385mm(15.16inches) Height: 358mm(14.09inches) (2) Weight Approx. 42kg (92.6lbs) (3) Form Continous Paper One-part paper Ream weight: 45 to 90g/m (12 to 24 lb) Multiple-part paper Max.0.79mm(0.031inches)total thickness(with front feed) Max.0.36mm(0.014inches)total thickness(with rear feed) Paper type Ream weight Number of sheet...
  • Page 10 (5) Maximum Number of Dot Columns per Line a) Graphics Single Density Double Density Quadruple Density 1,632 3,264 b) Text Print Mode Character Pitch (CP) 10 CPI 12 CPI 15 CPI 17.1 CPI 20 CPI ML, EPSON, IBM UTILITY 1,632 1,958 2,448 2,798...
  • Page 11 Packing : 12" Drop (14) Noise The 8-second average noise is Max. 55 dBA in quiet utility mode. (ISO 7779) (15) Ribbon Genuine OKI cartridge ribbon Ink color : Black Ribbon life : Approximately 15 million characters (Characters in Utility mode)

  • Page 12: Theory Of Operation

    THEORY OF OPERATION Electrical Operation The electrical operation of the printer circuit is described in this section. 2.1.1 Summary Fig. 2-1 shows the block diagram of the printer. The control board is made up of the microprocessors, peripheral circuits, drive circuits, sensors and interface connectors.
  • Page 13 Figure 2.1 40496501TH Rev.1...
  • Page 14 (2) PG ROM (IC46) This is a 256 x16 bits (4M bit) EPROM with the control program for the printer stored. The MPU executes instructions under this program. The program ROM is assigned to the program memory area of the MPU and is fetched by the RD signal of the MPU.
  • Page 15 (3) DRAM(IC28) The RAM is CMOS dynamic RAM with (256K x 16 bit) configuration, and used as buffers (such as receiving buffer, printing buffer, DLL buffer and working buffer). The following shows the examples of the memory access operation. NHDC LSI DRAM A16~BHE DRAMA0~A9...
  • Page 16 (4) CG ROM (IC48) This is a 256K x 16 bits (4M bits) EPROM with the font data for the characters stored. CG ROM is assigned to the program memory area of the MPU and is fetched by the RD signal of the MPU.
  • Page 17 (5) EEPROM(IC40) The EEPROM is a CMOS serial I/O type memory which is capable of electrically erasing and writing 1,024 bits. The EEPROM contains menu data. The following shows the memory access operation. NHDC LSI EEPROM EEPROMWR-P EEPROMCS-P EEPROMRD-P EEPROMCLK-P PRE = O Read cycle timing (READ) PE = X...
  • Page 18 (6) Main LSI (IC38: MSM91U036) MSM91U036 is control LSI for head data, DC motor and modification of print data, which has the following functions. (a) Head data control It distributes print data stored in the DRAM over wire arrangements of the print head and outputs it as dot data in synchronism with print timing.
  • Page 19 Main LSI A16~BHE AD0~AD15 MPU CLOCK A16~BHE A16~BHE AD0~AD15 A0–A15 D0–D15 AD0~AD15 A0–A15 D0–D15 Figure 2.6 40496501TH Rev.1...
  • Page 20 (7) NHDC LSI(IC27: TC190G08CF-7036) This LSI controls timer, interruption, memories, printing, external interface, motor drive interface. (a) Timer control It controls the watchdog timer for detecting any out-of-control program, baud rate generator for setting the baud rate of the serial interface, and pulse generation timer for AG plus count.

  • Page 21: Initialization

    2.1.3 Initialization This printer is initialized when the power is tumed on or when the I-PRIME-N signal is input from the host side via the parallel interface. For the initialize operation, the RESET-N signal is first output from the reset circuit to reset the MPU and LSIs.

  • Page 22: Interface Control

    Interface control The PM4410 is provided with the centronics parallel interface and RS-232C serial interface as standard features.Also, it can be connected to option OKI HSP or Opt. Card. The interface cable can be connected simultaneously with these interfaces. These interfaces can be switched with the menu switch on the operation panel, in addition, you can designate auto-select for them.

  • Page 23: Serial Interface

    2.1.6 Serial Interface The MPU sets the baud rate which is selected with the menu switch for the NHDC LSI and have the serial I/F LSI to output the clock frequency of the baud rate. Input signals from the serial I/F (DSR, CTS, CD and RD) are converted into TTL level ones by the Line driver/receiver and input to the serial I/F LSI and NHDC LSI.

  • Page 24: Printing Operation

    2.1.7 Printing operation The time chart for the spacing and printing, line feed operations are as shown below. The spacing, printing and line feed operations are controlled by the MPU. The MPU also controls the entire timing of these operations. Acceler- Constant speed Deceler-...

  • Page 25: Printhead Control

    2.1.8 Printhead control The printhead is controlled by the Main LSI and NHDC LSI. Printing is synchronized with the ITOUT signal from the NHDC LSI. Control Board Driver Board NHDC LSI A/D bus DRIVER Print Head Print Data Print Data HEAD1-P~ HEAD1~ HEAD18-P...
  • Page 26 Basic drive time (1)+(2)+(3) Basic drive time Dot magnet drive coil current signals (D1–D18) signals (D1–D18) Figure 2.12 40496501TH Rev.1...

  • Page 27: Print Compensation Control

    2.1.9 Print Compensation Control The print compensation can be made as shown below: (a) Simultaneous Compensation of the number of impact pins The NHDC LSI is provided with the compensation table for each pin to make necessary compensation. Number of impact pins Many Drive time Short...

  • Page 28: Line Feed

    (2) Slit encoder As the space motor rotates, it generates feedback pulse signals SPA-P and SPB-P. The Main LSI detects the edge pulses from these signals and multiplies the frequency to output the S720-P signals as the normalized timing to NHDC LSI to generate head drive timing. SPA-P SPB-P 1/360"...

  • Page 29: Bail, Tractor Switching, Ag, Ribbon Motor Control

    2.1.12 Bail, tractor switching, AG, ribbon motor control Bail, tractor switching, AG and ribbon motor control is as shown below. The AG motor is locked with AGHOLD-P. MO ø1 MO ø2 MO ø3 MO ø4 MO OVDV AGHOLD-P Figure 2.16 40496501TH Rev.1...

  • Page 30: Operation Panel

    2.1.13 Operation Panel The clock synchronization OPCLK of NHDC LSI is used to input the switch data and output the LED data and LCD data through the operation panel control LSI (IC1: BU6152S). BU6152S NHDC LSI OPDATAOUT-P OPSCLK-N SCKN Command LED driver and Data OPSQCR-N...
  • Page 31 Figure 2.18 40496501TH Rev.1...

  • Page 32: Alarm Circuits

    2.1.14 Alarm circuits (1) Driver circuit abnormality detection alarm. This protective circuite prevents secondary troubles by stopping the power supply upon detection of an abnormality in the print head, SP motor driver circuit or other motor driver circuits. This circuit monitors the driving time by means of the signals (DT1COM1, SPV, LF COM, AG- MCOM, RBN-MCOM, TR-MCOM, BEIL-MCOM and RENCOM) connected to the overdrive signals for each driver circuit.
  • Page 33 (6) Head thermistor short/open alarm circuit The head thermistor voltage is monitored physically. When short or open circuit occurs, the HDTHALM-N signal is input to the sub LSI (IC18) and read by the MPU. The MPU stops the printing operation, informs the host of the short/open alarm, and lights the alarm lamp. When the head is unloaded, the head thermistor becomes open, resulting in this alarm.

  • Page 34: Power Supply Circuit

    2.1.15 Power supply circuit This switching type power supply circuit supplies the +5 VDC, ±12 VDC and +44 VDC. FUSE Noise filter +44 V primary Rectification and +44V circuit switching circuit smoothing circuit ACIN POWALM-P Switching Alarm control POWOFF-P control circuit circuit POWDWN-P +5 V and ±12 V...

  • Page 35: Mechanical Operation

    Mechanical Operation 2.2.1 Printhead mechanism and operation (See Figure 2-13) Teh printhead is a spring charged 18-pin driving head using a permanent magnet. It is attached to the carriage, which moves in parallel with the platen. Electrically, this unit is connected to the control circuits through the control board.
  • Page 36 (2) Motion of Printhead (Fig.2-14) The armature usually looses the armature sprint with a permanent magnet, making it to be attracted by the core. In this time, the print wire integrated with the armature is also in reset state, When the magnet coil is energized by a print command sent from the device controller, a magnetic flux will generate in the opposite direction against that of the permanent magnet and a restoring force of the armature in the opposite direction against the core, and then the print wire impinge on the platen.

  • Page 37: Spacing Operation (See Figure.2-15)

    2.2.2 Spacing operation (See Figure.2-15) Spacing is effected by driving the carriage assembly installed to the main shaft and slide beam set in parallel with the platen by the DC servo motor. (a) DC motor with motor (b) Carriage frame (c) Carriage shaft (d) Space belt (e) Sensor...

  • Page 38: Head Gap Adjusting

    2.2.3 Head gap adjusting The auto gap adjusting mechanism automatically adjusts the space between the platen and print head according to the thickness of papers. This mechanism does this driving the platen back and forth with the AG motor (pulse motor), and effects the auto gap motion after the reverse motion of the platen.
  • Page 39 (1) AG detection mechanism Carriage frame AG press plate Platen sheet guide Platen Moving direction of platen Coil Sensor frame Eccentric collar Core Bearing EI sensor Deflecting direction of sensor frame Cam roller Figure 2.23 (2) AG sensor slit disk driving mechanism Platen Platen Bearing...
  • Page 40 (3) AG detector detail drawing Head AG plate Paper AG sensor flame Ferrite core Figure 2.25 40496501TH Rev.1...

  • Page 41: Ribbon Drive (See Figure)

    2.2.4 Ribbon drive (See Figure) The ribbon feed mechanism feeds the ink ribbon and functions by driving the ribbon motor (pulse motor). (1) Ribbon cartridge This has a mechanism of capable of printing clear characters at all times by using a one-way- feed endless ribbon.

  • Page 42: Paper Feed Mechanism

    2.2.5 Paper Feed Mechanism The line feed on the print paper is driven by the LF motor (pulse motor) and done by rotating the sheet feeder and feed roller. (1) Front tractor The rotation of the LF motor rotates the drive shaft through the LF gear, change gear and front tractor drive gear, driving the pin belt of hte front tractor Assy.
  • Page 43 (2) Rear tractor The rotation of the LF motor rotates 2 drive shafts through the LF gear, change gear and rear tractor drive gear A/B, driving the pin wheel and pin belt of the tractor Assy. This feeds a continuous paper set on the pin belt. Simultaneously, this drives the feed roller F/R through the mini-pitch belt following LF gear to carry the paper in synchronization with the tractor.
  • Page 44 (3) Tractor changing motion The front tractor and rear tractor are switched by exclusive tractor change motor (pulse motor). Operating keys on the operating panel and receiving a command rotates the tractor change motor, moving the tractor change lever back and forth through gears so that the change gear moves transversely.
  • Page 45 • Rear tractor drive Rear drive shaft Front drive shaft Change lever Front tractor drive gear Change gear Rear tractor drive gear LF gear Change motor • Front tractor drive Figure 2.30 40496501TH Rev.1...

  • Page 46: Bail Feed Mechanism (See Figure )

    2.2.6 Bail Feed Mechanism (See Figure ) This mechanism automatically opens the bail for pulling a paper into, and closes it after the paper passes through the bail. This function is operated by exclusive bail motor (pulse motor). The bail motor rotates depending on the position of a paper, moving the bail lift lever (L) back and forth through gears.
  • Page 47 (i) Close position Bail lift lever Bail lift pin Close Close (ii) Open position Close Open (iii) Half open position Open Half open Figure 2.32 40496501TH Rev.1...

  • Page 48: Paper End Detection Mechanism (See Figure )

    2.2.7 Paper End Detection Mechanism (See Figure ) (1) Front/ Rear form end detection mechanism (when the form with sprocket holes is used) The form prevents the paper end lever tip end from coming into the hole on the sheet feeder cover rib and the microswitch is set to the ON state.
  • Page 49 (3) Rear tractor Form Sheet feed cover rib Pin tractor L Micro switch Paper end lever Figure 2.34 Rear form end detection mechanism 40496501TH Rev.1...

  • Page 50: Parts Replacement

    PARTS REPLACEMENT The section explains the procedures for replacement of parts, assemblies, and units in the field. Only the removal procedures are explained here. Reverse the procedure for the installation. Precautions for Parts Replacement (1) Before starting parts replacement, remove the AC cable and interface cable. (a) Remove the AC cable and the interface cable in the following procedure: Turn off ("o") the power switch of the printer ii) Disconnect the AC inlet plug of the AC cable from the AC receptacle.
  • Page 51 (10) Disassembly prohibited parts The following units and parts should not be disassembled because they cannot reassembled if they are broken apart.) Unit Disassembly prohibited parts Details Print head Print head Print head unit Printer Unit Space motor Motor unit Ribbon pulse motor Autogap motor Tractor change motor...
  • Page 52 [Service Tools] Table 3-1 shows the tools required for field replacement of printed circuit boards and units. Table 3-1 Service Tools Service Tools Q' ty Place of use Remarks No. 1-100 Philips 2~2.5 mm screws screwdriver No. 2-250 Philips 3~5 mm screws screwdriver, Magnetized No.

  • Page 53: Parts Layout

    Parts Layout Cover Assy Rear Cover Assy Access Print head Sheet guide Cover-Assy-Side(R) Printer Unit Plate Front (stuk) Guide Paper B Driver Board Cover Rear B Operation panel Assy Cover Assy Front Power Supply Assy Control Board Door Assy Front Cover Assy Lower Cover Assy Side(L) Figure 3-1...

  • Page 54: How To Change Parts

    How to Change Parts This section explains how to change parts and assemblies appearing in the disassembly diagram below. 40496501TH Rev.1...

  • Page 55: Cover-Assy-Access / Cover-Assy-Side (R) / Cover-Assy-Side (L) /Cover-Assy-Front / Frame-Assy-Rear / Plate-Front (Stuck)

    3.3.1 Cover-Assy-Access / Cover-Assy-Side (R) / Cover-Assy-Side (L) /Cover-Assy-Front / Frame- Assy-Rear / Plate-Front (stuck) (1) Remove Guide Sheet 1 and Cover Assy Access 2. (2) Unscrew 2 screws 3 and the screw 4 and the screw 5, then remove Cover Assy Side (R) 6, sliding it to the arrow direction.

  • Page 56: Printer Unit

    3.3.2 Printer Unit (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew 4 screws 2 which fix Printer Unit 1. (3) Unplug I/F Connecting Cable 4 and Head Cable 5 from Control Board 3.

  • Page 57: Control Block [Control Board (Pma Printed Board), Driver Board (Pda Printed Board)]

    3.3.3 Control Block [Control Board (PMA Printed Board), Driver Board (PDA Printed Board)] (1) Remove Cover Rear (B). (See 3.3.1) (2) Unscrew 2 screws 1 and unplug all the connecting cords to Control Block 2. (3) Remove Control Block 2, sliding it into the arrow direction. [Control Board (PMA Printed Board) and Driver Board (PDA Printed Board)] Unscrew 2 screws 3 then pull Driver Board (PDA Printed Board) 4 upward and release it from the connecting position to Control Board (PMA Printed Board) 5.

  • Page 58: Power Supply Assy

    3.3.4 Power Supply Assy (1) Remove Guide Paper (B), Cover Blank Lower and Rear Cover (B). (See 3.3.1) (2) Unplug connectors to Power Supply Unit 1. (3) Unscrew the screw 2 and release Earth Wire 3. (4) Unscrew the screw 4 and remove Bracket PG 5. (5) Unscrew 2 screws 6.

  • Page 59: Pg Cooling Fan

    3.3.5 PG Cooling Fan (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear. (See 3.3.1) (2) Unplug the connectors 2 to Junction Board (PRA Printed Board)(CN13)1. (3) Unscrew 2 screws 3 and remove PG Cooling Fan 4. (4) For installation, reverse the removal procedure.

  • Page 60: I/F Board (Pha Printed Board)

    3.3.6 I/F Board (PHA Printed Board) (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew the screw 1 and remove Cable Holder 2. (3) Unscrew 2 screws 3 and remove I/F Board Holder Cover 4.

  • Page 61: Ag Board (Pga Printed Board) / Connector Cord

    3.3.7 AG Board (PGA Printed Board) / Connector Cord (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug the connectors 0 to Junction Board (PRA Printed Board)(CN3) 9. (3) Unscrew the screw 1.

  • Page 62: Ag Motor Assy

    3.3.8 AG Motor Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew 2 screws 1 and remove Bail Gear Assy 2. (3) Unscrew 2 screws 3 and remove AG Motor Assy 4.

  • Page 63: Mini Pitch Belt

    3.3.9 Mini Pitch Belt (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew 2 screws 1 and remove Shaft Support Plate (press fit) 2. (3) Screw down the screw 3 and turn Idle Pulley Assy 4 into the right direction.

  • Page 64: Tractor Change Motor Assy

    3.3.10 Tractor Change Motor Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Printer Unit. (See 3.3.2) (3) Remove I/F Board. (See 3.3.6) (4) Release the cords from Cord Clamp 3 on the cord route.

  • Page 65: Bail Motor Assy

    3.3.11 Bail Motor Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug the connectors 1 from I/F Board (PHA Printed Board)(CN2) B. (3) Unplug the connectors A from I/F Board (PHA Printed Board)(CN11) B.

  • Page 66: Lf Motor Assy

    3.3.12 LF Motor Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove I/F Board. (See 3.3.6) (3) Remove Printer Unit. (See3.3.2) (4) Remove Tractor Change Motor Assy.

  • Page 67: Head Cooling Fan 1

    3.3.13 Head Cooling Fan 1 (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug the connector 1 from Junction Board (PRA Printed Board)(CN6) 6. (3) Release the cords from the cord clamps on the cord route.

  • Page 68: Head Cooling Fan 2

    3.3.14 Head Cooling Fan 2 (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew the screw 1 and remove Cable Holder Cover 2. (3) Unplug the connector 3 from I/F Board (PHA Printed Board)(CN6) 6.

  • Page 69: Space Motor

    3.3.15 Space Motor (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Printer Unit. (See 3.3.2) (3) Remove the stopper 1. (4) Screw down 2 fixing screws 2 on Idle Pulley Bracket.

  • Page 70: Operator Board (Poa Printed Board)

    3.3.16 Operator Board (POA Printed Board) (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug the connector 2 from Operator Board (POA Printed Board)(CN1) 1. (3) Unscrew 2 screws 3 and Remove Operator Block Assy 4.

  • Page 71: Ribbon Feed Assy

    3.3.17 Ribbon Feed Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug the connector 1 from Junction Board (PRA Printed Board)(CN9) 7. (3) Unscrew 2 screws 2 and remove Ribbon Feed Assy 3.

  • Page 72: Printing Head

    3.3.18 Printing Head (1) Lean Frame Assy Rear backward and open Access Cover. (2) Move the printing head to the recess on the right seen from the front. (3) Pull out Ribbon Guide 1 upward. (4) Unscrew 2 screws 2 and remove Printing Head 3 from the connector. (5) For installation, reverse the removal procedure.

  • Page 73: Head Cable

    3.3.19 Head Cable (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Printing Head. (See 3.3.18) (3) Remove Printer Unit. (See 3.3.2) (4) Remove Cable Holder Cover.

  • Page 74: Ribbon Protector

    3.3.20 Ribbon Protector (1) Remove Printing Head. (See 3.3.18) (2) Open Access Cover 1. (3) Unscrew the screw 2 and remove the cord clamp 3. (4) Unscrew the screw 4 and remove Paper Width Sensor 5. (5) Unplug the connector 6. (6) Remove 2 Ribbon Guide Posts 7 and 2 washers 8.

  • Page 75: Space Motor Fan

    3.3.21 Space Motor Fan (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Printer Unit. (See 3.3.2) (3) Unscrew 2 screws 1 and unplug the connector 2 from Junction Board (PRA Printed Board) (CN12) 4, then remove Space Motor Fan 3.

  • Page 76: Junction Board

    3.3.22 Junction Board (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug all the connectors from the above. (3) Unscrew 2 screws 1 and remove Junction Board (PRA Printed Board) 2. (4) Unscrew 3 screws 3 and remove Junction Board Bracket 4.

  • Page 77: Cover Open Switch Assy / Ribbon Rotation Sensor

    3.3.23 Cover Open Switch Assy / Ribbon Rotation Sensor (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Head Cooling Fan 1. (See 3.3.13) (3) Unscrew 2 screws 1 and 2 screws 2, and remove Ribbon Bracket 3.

  • Page 78: Interlock Switch / Interlock Switch Cord Assy

    3.3.24 Interlock Switch / Interlock Switch Cord Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unplug 4 cables 1. (3) Unscrew 2 screws 2 and remove Interlock Switch 3.

  • Page 79: Knob Bracket Assy

    3.3.25 Knob Bracket Assy (1) Remove Bail Motor. (See 3.3.11) (2) Unscrew the screw 1 and remove the gear 2. (3) Unscrew 2 screws 3 and remove Knob Bracket Assy 4. (4) Unscrew 2 screws 5 and remove AG Sensor Cover 6. (5) Unscrew the screw 7 and remove Knob Cover 8.

  • Page 80: Space Belt

    3.3.26 Space Belt (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Space Motor. (See 3.3.15) (3) Remove Printing Head. (See 3.3.18) (4) Remove Idle Pulley 1 from Idle Pulley Bracket, then remove Space Belt 2.

  • Page 81: Ag Sensor Frame / Start Searching Sensor

    3.3.27 AG Sensor Frame / Start Searching Sensor (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew 2 screws 1 and remove Rear Plate 2. (3) Unscrew 2 screws 3 and remove AG Sensor Cover 4.

  • Page 82: Paper Jam Sensor Assy / Bail Pe Sensor Assy

    3.3.28 Paper Jam Sensor Assy / Bail PE Sensor Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Unscrew the screw 1 and release the latch, then remove Paper Jam Sensor Assy 2. (3) Unscrew the screw 3 and release the latch, then remove Bail PE Sensor Assy 4.

  • Page 83: Sprocket Assy (L) (R) (Front Tractor)

    3.3.29 Sprocket Assy (L) (R) (Front Tractor) (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Printer Unit. (See 3.3.2) (3) Remove Space Motor Fans.

  • Page 84: Sheet Feeder Assy (L) Rear / Sheet Feeder Assy (R) Rear

    3.3.30 Sheet Feeder Assy (L) Rear / Sheet Feeder Assy (R) Rear (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Printer Unit.
  • Page 85 Align the hole positions [When mounting] Wave Eling Drive shaft Washer Bush Releasing the Gear latches R Side View 40496501TH Rev.1...
  • Page 86 Wheel Match the direction of projections Wheel Pin wheel Match the position of marks Rear tracor Assy Gears phase drawing 1. Matching the phase of pin tractors Match the direction of pin wheel projections on right/left pin tractor to that of mark on the 2 (rear tractor drive gear).

  • Page 87: Bail Assy

    3.3.31 Bail Assy (1) Remove Cover Assy Access / Cover Assy Side (R) / Cover Assy Side (L) /Cover Assy Front / Frame Assy Rear / Plate Front (stuck). (See 3.3.1) (2) Remove Mini Pitch Belt. (See 3.3.9) (3) Remove Bail Motor Assy (See 3.3.11) (4) Remove 2 Drive Pulleys 1.

  • Page 88: Adjustments

    ADJUSTMENTS (1) Be sure to carry out this adjustment with the printer mechanism mounted on the lower cover. (2) Be sure to carry out this adjustment operation on a level and highly rigid work table (flatness: less than 0.039 inch or 1 mm) so as to minimize adjustment error. [Service Tool] •...
  • Page 89 Item No. Items Standard Value Illustration Adjustment Method Protector Gap Adjustment 1Remove the Rear Cover (B), and set (1)Range Adjustment Dip Switch 1 on the board to “ON” DIP Switch (maintenance mode). Lower Cover Temporary Rear Cover (B) Maintenance DIP SW O N - L I N E E P S POWER...
  • Page 90 Item No. Items Standard Value Illustration Adjustment Method AG Plate Gap C=0.14±0.02mm 1Insert the thickness gauge between the AG frame and the AG plate to veri- AG Frame fy the gap value C is between 0.12 and AG Plate 0.16 mm. 2If adjustment is required, screw down the mounting screws and adjust the ec- centric collar to make the protector gap...
  • Page 91 Item No. Items Standard Value Illustration Adjustment Method LF Motor Belt Tension 200 ~ 250gf 1Adjust the LF motor belt tension, with the idle pulley assy, to produce the Drive Pulley A standard value when the belt is deflect- ed 1.5 mm at the middle of the LF gear and the drive pulley B.
  • Page 92 Item No. Items Standard Value Illustration Adjustment Method Auto Gap Motor Assy J=0.1mm 1Verify the backlash is 0.1 mm bet- Backlash ween the idle gear and the adjusting Mounting Screws Change Motor cam. 2If adjustment is required, screw down the 2 screws fixing the auto gap assy, Idle Gear and ensure the backlash between the idle gear and the adjusting cam.
  • Page 93 Item No. Items Standard Value Illustration Adjustment Method Installing print head 1In installing the print head, accurately bump it to the inpinging plate on the Mounting screw carriage frame. Print head Notes: The print head should be installed/ removed at 1-range position.(prevent protector deformation) Carriage frame 2How to tighten screws in installing...
  • Page 94 Item No. Items Standard Value Illustration Adjustment Method Correct the printing alignment in each "Registration1 ..7". (Note2)(Note3) Number Correction dot position of reverse printing Note2)After printing, change items with Printing position is shifted by 0.25mm to right of the reference position. 4 switch Printing position is shifted by 0.20mm to right of the reference position.

  • Page 95: Cleanig And Lubrication

    CLEANIG AND LUBRICATION Cleaning [Caution] Be sure to turn OFF the AC POWER switch before cleaning. Remove the AC Power cord from the printer. Avoid dust inside the printer mechanism when cleaning. If a lubricated part has been cleaned, be sure to apply lubricating oil to that portion after cleaning.

  • Page 96: Lubrication

    Lubrication This printer is designed to be maintenance free and requires no lubrication during normal operation. However it is necessary to apply lubricant in case the printer is disassembled, reassembled, cleaned or parts have been changed. (1) Cleaning time Remarks: 1) Turn off the power before cleaning.

  • Page 97: Right Side View

    Sliding Surface between Bail Life Lever and Shaft(at left and right) Bail Lift Lever Rack GEP- A (2 points at upper and lower) GEP- A (at left and right) Gear Teeth Surfasce GEP- A Shaft PM- B (2 points at left and right) Sliding Surface between Feed Shaft Bearing and Side Frame (at upper and lower) GEP- A (2 points at upper and lower)

  • Page 98: Left Side View

    Sliding Surface between Bail Life Lever and Stud(at left and right) GEP- A (at left and right) Shaft PM- B (3 points at left and right) Gear Teeth Surface GEP- A Sliding Surface between Bail Life Lever and Bail Motor Bracket GEP- A Adjusting Cam Surface GEP- A (at left and right)
  • Page 99 Sliding Surface between Platen Slide Plate and Platen TEP- A (2 points at upper and lower) Platen Slide Plate Platen Side Frame 40496501TH Rev.1...
  • Page 100 Feed Roller Shaft FU Sliding Surface between Pressure Roller Piece and Feed Roller Shaft (3 points) GEP- A Pressure Roller Piece Front Spring 40496501TH Rev.1...
  • Page 101 Gear Teeth Surfasce GEP- A Gear Teeth Surfasce GEP- A Gear Teeth Surfasce Gear Teeth Surfasce GEP- A GEP- A Between Gear and Bracket Between Gear and Shaft Between bush and Shaft GEP- A PM- B PM- B Between Gear and Bracket Between Gear and Shaft Between bush and Shaft GEP- A...
  • Page 102 Apply a small amount of Albania grease on the diagonally shaded section. (GEP- B ) Apply a small amount of Albania grease on the feed shaft sliding surface. (GEP- B )(top and bottom)(both right and left) Apply a small amount of Albania grease on the stud sliding surface.
  • Page 103 Apply a small amount of Albania grease on the stud sliding surface. (GEP- B )(both right and left) 40496501TH Rev.1...

  • Page 104: Troubleshooting And Repair

    TROUBLESHOOTING AND REPAIR Items to Check Before Repair (1) Check the inspection items specified in the instruction manual. (2) Find out as many details of the trouble as possible from the customer. (3) Inspect in the conditions as close as possible to those at the time the trouble occured. (4) Proceed with the repair as follows: Check the trouble status according to Table 6.1 for the details of the troble.

  • Page 105: Lamp And Lcd Display

    Lamp and LCD Display (1) Printer mode display Table 6.2 40496501TH Rev.1...
  • Page 106 40496501TH Rev.1...
  • Page 107 40496501TH Rev.1...
  • Page 108 40496501TH Rev.1...
  • Page 109 40496501TH Rev.1...

  • Page 110: Part Layout

    AC Inlet Control Block Assy Option Board MUPIS Card or PAA-PCB CN13 CN12 POWER SUPPLY UNIT Interface Assy LCD UNIT Operation Panel Assy...
  • Page 111 (2) Other Bail Open Switch Front Tractor On Switch Bail Motor Path-Change Motor 40496501TH Rev.1...
  • Page 112 (3) Option serial I/F card Serial CN1 Option serial I/F Card 40496501TH Rev.1...

  • Page 113: Connection

    Connection (1) Printhead Resistance of each coil should be about 5.8Ω PMA PCB PDA PCB Head connector Head pin number Head driver circuite diagram HDT1-01-N HDT1-01-N HD01-N HDT20-01-P HDT20-01-P HD01-P HDT1-02-N HDT1-02-N HD02-N HDT20-02-P HDT20-02-P HD02-P HDT1-03-N HDT1-03-N HD03-N HDT20-03-P HDT20-03-P HD03-P HDT1-04-N...
  • Page 114 (2) Line feed motor Resistance of each coil should be about 4.2Ω PMA-PCB PHA-PCB CN13 LFDV1 LFCOM LFDV3 LFDV2 LFDV4 (3) Space motor Resistance of motor should be about 1.08Ω PMA-PCB PRA-PCB CN10 Inter lock switch SP FOW SP REV 44VF1 SPACING 12Ω...
  • Page 115 (4) Ribbon motor Resistance of each coil should be about 155Ω PMA-PCB PRA-PCB RBN-MDV1 RBN-MCOM RBN-MDV3 RBN-MDV2 RIBBON RBN-MDV4 (5) Path-change motor Resistance of each coil should be about 90Ω PMA-PCB PHA-PCB PDA-PCB Path-change motor common drive circuite diagram TR-MDV1 TR-MCOM TR-MCOM TR-MDV3...
  • Page 116 (7) Bail motor Resistance of each coil should be about 90Ω PHA-PCB PMA-PCB BEIL-MDV1 BAIL-MCOM BEILMDV3 BAILMDV2 BAIL BEIL-MDV4 (8) Space Fan1 PRA-PCB PMA-PCB CN12 Space Fan1 SPFANDV-P SPFANALM1-P (9) Space Fan2 PMA-PCB Space Fan2 SPFANDV-P SPFANALM2-P (10) Head Fan1 PRA-PCB PMA-PCB Head Fan1...
  • Page 117 (11) Head Fan2 PHA-PCB PMA-PCB Head Fan2 HDFAN2DV-P HDFAN2ALM-P 1, 3, 5 2, 4, 6 (12) Power Fan PHA-PCB PMA-PCB CN13 Power Fan POWFANDV-P POWFANALM-P (13) space slit sensor PMA-PCB Slit sensor PHA-P PHB-P SPTH-P (14) Auto-gap slit sensor PRA-PCB PGA-PCB PMA-PCB Slit sensor...
  • Page 118 (15) Cover Open Switch/ Ribbon Jam Sensor PRA-PCB PMA-PCB Cover open switch COVEROPN 1SW-P NO NC *RTRCOVEROPNSW-P Ribon jam sensor RBNSEN-P SNS5V-1 * RTRCOVEROPNSW-P is unused. 180Ω 1/4W (16) Optical Sensor Optical sensor PDA-PCB PMA-PCB Head cable WITHSNS-P SNS5V-1 30~32 30~32 150Ω...
  • Page 119 (18) Paper Jam Sensor/ Bail Paper End Sensor Paper jam sensor PHA-PCB PMA-PCB SHEETJAM-P SNS5V-0 BEILPE-P 1,3,5 2,4,6 Bail paper end sensor 180Ω 1/4W 150Ω 1/4W (19) Bail Open Switch/ Front Tractor On Switch Bail open switch PHA-PCB PMA-PCB BEILOPNSW-P FTRONSW-P * COVEROPN0SW-P Front tractor on switch...
  • Page 120 (21) Rear Tractor Paper End Switch Rear tractor paper end switch PHA-PCB PMA-PCB RTRPESW-P 1,3,5 2,4,6 (22) Power Supply Unit Inlet Power supply unit PMA-PCB ACIN DCOUT1 Power circuit diagram AC-L AC-L +44V +44V 7~12 7~12 AC-N AC-N DCOUT2 +12V +12V -12V -12V...
  • Page 121 (23) Operation Panel LCD UNIT PMA-PCB PHA-PCB POA-PCB OPeration panel cirduit diagram SHIFTSWON-N SHIFTSWON-N BL5V OPSCLK-N OPSCLK-N OPDATAOUT-P OPDATAOUT-P OPDATAIN-P OPDATAIN-P OPQCR-N OPQCR-N BZON-P BZON-P +5VD +5VD 1,12 1,3,5 2,4,6 9,10 BL5V 40496501TH Rev.1...
  • Page 122 (24) Standard Interface PMA-PCB PHA-PCB CN14 Centronics interface code STROB-N STROB-N DATA1-P DATA1-P DATA2-P DATA2-P DATA3-P DATA3-P DATA4-P DATA4-P DATA5-P DATA5-P DATA6-P DATA6-P DATA7-P DATA7-P DATA8-P DATA8-P ACK-N ACK-N BUSY-N BUSY-N PERROR-P PERROR-P SELECT-P SELECT-P AUTOFD-N AUTOFD-N 1,3,5 2,4,6 16,33,19~30 16,33,19~30 17,37,38 17,37,38...
  • Page 123 (25) Short Plug * For setting details see the maintenance manual 10KΩ 1/10W IC45-BYTE IC47-BYTE PGROMCS-N CNIF-H 3.3KΩ 1/10W 10KΩ 1/10W PGROMSEL-N 3.9KΩ 1/10W CNPLOGIC-H 40496501TH Rev.1...
  • Page 124 (26) Others PMA-PCB PDA-PCB CN1 CN1 POWEROFF-P POWEROFF-P 68,69,70 68,69,70 +44VF +44VF 20,21 20,21 +12V +12V 35~40,75 35~40,75 73,74,76~80 73,74,76~80 +44V +44V 71,72 71,72 +12VR +12VR DVREV3-P DVREV3-P DVREV2-P DVREV2-P DVREV1-P DVREV1-P DVREV0-P DVREV0-P PMA-PCB PRA-PCB CN7 NOMOUNT NOMOUNT SPTH-P SPTH-P * ROHTAPHA-P * ROHTAPHA-P...
  • Page 125 (27) MUPIS Interface (Option) PMA-PCB MPSD03-P MPSD10-P MPSD02-P MPSD09-P MPSD01-P MPSD08-P MPSD07-P MPSRD-N MPSA08-P MPSA01-P MPSA02-P MPSA03-P MUPISARI-N MPSA04-P MPSA05-P MUPIS CARD MPSA06-P MPSA07-P MPSCE-N MPSDECORD1-P MPSCUREQ-N MPSOPREQ-N OPDCT0-N OPDCT1-N MPSD04-P MPSD12-P MPSD11-P MPSD05-P MPSD13-P MPSD06-P MPSD14-P MPSD00-P MPSD15-P MPSA00-P MPSA15-P MPSA14-P MPSA13-P...
  • Page 126 PE-N ACK-N SIFSEL-N BUSY-P IFDATA4-P MUPIS CARD IFDATA3-P IFDATA5-P IFDATA2-P IFDATA6-P IFDATA1-P IFDATA7-P IFDATA8-P SIFRST-P RSTIN-N SIFSTB-N SIFON-N SIFRD-N CNBARI-N 40496501TH Rev.1...
  • Page 127 (28) Option Interface Option Interface-PCB PMA-PCB PAA-PCB Attachment circuit diagram Serial Interface circuit diagram PE-P PE-P IFDATA8-P IFDATA8-P ACK-N ACK-N IFDATA7-P IFDATA7-P IFDATA6-P IFDATA6-P SIFSEL-N SIFSEL-N BUSY-P BUSY-P IFDATA5-P IFDATA5-P IFDATA4-P IFDATA4-P IFDATA4-P IFDATA4-P IFDATA3-P IFDATA3-P IFDATA3-P IFDATA3-P IFDATA5-P IFDATA5-P IFDATA2-P IFDATA2-P Interface...
  • Page 128 RD-N RD-N CE-N CE-N DECODE1 DECODE1 CUREQ-N CUREQ-N OPREQ-N OPREQ-N OPDCT0-N OPDCT0-N OPDCT1-N OPDCT1-N A5,A9,A13 A21,A25 A5,A9,A13 A2~A4,A5~A8, A21,A25 A10~A12,A14~A20, A22~A24,A26~A32 A2~A4,A5~A8, A10~A12,A14~A20, A22~A24,A26~A32 40496501TH Rev.1...
  • Page 129 (29) Continuous-Form Paper Cutter (Option) PMA-PCB PRA-PCB 39,41,43,44 39,41,43,44 44VF CUTMOVDV-P CONTINUOUS-FORM CUTM1-P PAPER CUTTER CUTM2-P CUTM3-P CUTM4-P RENCUT-N 40496501TH Rev.1...

  • Page 130: Troubleshooting Flow Chart

    Troubleshooting Flow Chart 1 Power is not supplied. • The printer cannot be powered at all. : to A The printer changes off during initialization. : to B A Is the connection of AC cable properly made? • Properly reconnect the AC cable. •...
  • Page 131 B Can the printer be powered on and off when the CN3 cable of the PMA board is disconnected? • Replace the power supply unit. • Can the printer be powered on and off when the CN2 and the CN6 of the PMA board, and the CN5 of the PDA board is disconnected? •...
  • Page 132 2 The printer can be powered on, but stays still without displaying anything on the LCD. Can the printer recover after the program ROM is replaced? • End • Can the printer recover after the POA board is replaced? • End •...
  • Page 133 Alarm lamp flashes Message on the LCD “ERROR, CHANGE” : to I Alarm lamp flashes Message on the LCD “ERROR, OKI HSP CONNECT” : to J Alarm lamp flashes Message on the LCD “ERROR, OPT CARD CONNECT” : to K Alarm lamp flashes Message on the LCD “ERROR, HEAD THERMISTOR”...
  • Page 134 C Although the access cover is close, the printer is in cover open state. • Check that the cover open switch can normally switch on and off with manufacturing aid function. • Can it switch on and off normally? • Is the connection of cables to the CN1 and the CN4 on the PRA board properly made? •...
  • Page 135 D The printer does not operate. The alarm lamp flashes. The LCD reads “ERROR FUSE”. Is the connection of cable properly made to the CN3 on the PMA board? • Properly reconnect the cable. • Is the connection of cable properly made to the printer unit connector DCOUT2? •...
  • Page 136 E Alarm lamp flashes. Message on the LCD “ERROR, FLASH UNLOAD” Is a flash memory used? • Confirm the settings of the short plug T3 on the PMA board. 1-2 setting: FLASH ROM selected 2-3 setting: EP ROM selected • Has the EPROM been selected? •...
  • Page 137 F Spacing error, Alarm lamp flashes. Message on the LCD “ERROR, HOMING”, “ERROR, CENTER- ING” or “ERROR, SPACING”. Does the carriage catch a paper? • Remove the print paper. • Can the carriage run when the printer is powered on? •...
  • Page 138 Is the carriage belt loose? • Properly adjust the tension of the belt. • Is the connection of cable properly made to the CN8 on the PMA board? • Properly reconnect it. • Is the slit sensor cable at the lower part of space motor properly connected to the cable from the unit? •...
  • Page 139 G Alarm lamp flashes. Message on the LCD “ERROR AUTOGAP” Does the carriage run during initialization? • to G-1 • Does the platen normally move during initialization? • G-4 Is the connection properly made to the CN1 and the CN2 on the PRA board? •...
  • Page 140 Has the autogap slit sensor and autogap slit disk been installed in a proper position? • Reinstall them. • Is the gear between the autogap motor and platen in a normal state? Does it lose a tooth (teeth)? Is the load too heavy? •...
  • Page 141 Does the platen normally operate during initialization? • to G-4 • Can the printer recover after the head gap is readjusted? • End • Can the printer recover after the core gap is readjusted? • End • Is the connection of cables properly made to the CN1 and the CN3 on the PRA board, and the CN1 on the PGA board? •...
  • Page 142 Can the printer recover after the print start sensor and/or coregap cable is replaced? • End • Can the printer recover after the PMA board is replaced? • End • Can the printer recover after the connection cable between the CN2 on the PMA board and the CN1 on the PRA board is replaced? •...
  • Page 143 H The alarm lamp flashes after the motion of carriage. LCD reads “ERROR, BAIL”. Does the bail operate during initialization? • Is the connection of cables properly made to the CN2 and the CN1 on the PHA board? • Reconnect them properly. •...
  • Page 144 The alarm lamp flashes after the motion of carriage. LCD reads “ERROR, PATH CHANGE” Does the tractor change lever operate during initialization? • Is the connection of cables properly made to the CN1 and the CN7 on the PHA board? •...
  • Page 145 • Can the printer recover after the PMA board is replaced? • End • Replace the PAA board. K Alarm lamp flashes. Message on the LCD “ERROR, OKI HSP CONNECT” Is the connection between the PMA board and MUPIS card normal? • Properly reconnect it.
  • Page 146 M Alarm lamp flashes, Message on the LCD “ERROR, HEAD 1 FAN”, “ERROR, HEAD 2 FAN” and “ERROR, SPACE FAN” Can the printer recover after the FAN shown in the error message is replaced? • End • Can the printer recover after the PMA board is replaced? •...
  • Page 147 4 function is not started when the switch is pressed on the operator panel. Is the connection of cable between the CN1 on the POA board and the CN12 on the PHA board normal? • Properly reconnect the cable. • Check the electrical conductivity between the CN1 on the POA board and the CN12 on the PHA board.
  • Page 148 5 Alarm lamp flashes, LCD reads “ERROR, RIBON JAM” Is the ribbon feed during initialization? • Is the connection of cable properly made to the CN1 and the CN9 on the PRA board? • Properly reconnect it. • Is the connection of cable properly made to the CN2 on the PMA board? •...
  • Page 149 • Can the printer recover after the PRA board is replaced? • End • Replace the connection cable between the CN2 on the PMA board and the CN1 on the PRA board. 40496501TH Rev.1...
  • Page 150 6 Line feed trouble Printer status and Message on the LCD Alarm lamp flashes, Message on the LCD “ERROR, FEED JAM” : to P Paper has set on the tractor, but is not feed in. The LCD reads “OFF-LINE, PAPER END” : to Q Alarm lamp flashes, Message on the LCD “ERROR, PAPER JAM”...
  • Page 151 P Alarm lamp flashes. LCD reads “ERROR, FEED JAM” Is any paper jammed in the paper feeding route? • Remove the print paper. • Is the LF motor (tractor unit) running? • to P-1 • Is the connection of cables properly made to the CN1 and the CN13 on the PHA board? •...
  • Page 152 • Is the connection of cables properly made to the CN1 and the CN3 on the PHA board? • Properly reconnect it. • Is the connection of cable properly made to the CN6 connector on the PMA board? • Properly reconnect it. •...
  • Page 153 Q Paper has been set on the tractor, but is not feed in. Message on the LCD “OFF-LINE, PAPER END” • Confirm that the tractor being used (Front or Rear) is normally switched on/off according to the Maintenance manual. • Is the tractor normally switched on/off? •...
  • Page 154 R Alarm lamp flashes, Message on the LCD “ERROR, PAPER JAM” Is the paper on the feeding route torn? • Remove any torn paper and load a new paper. • Is the connection of cables properly made to the CN1 and the CN9 on the PHA board? •...
  • Page 155 7 Character and dot lack Is the trouble identified as character lack? • In the event of dot lack, go to S . • Can the self-test printing be normally performed? • Replace the PMA board. • Is the interface cable and/or network cable properly connected? •...
  • Page 156 S Has the headgap been accurately adjusted? • Readjust the headgap as stated in the Maintenance Manual. • Perform the head pin test as stated in the Maintenance Manual. • Is a particular pin lacked? • Go to D. • Can the printer recover after the print head is replaced? •...
  • Page 157 8 Thin printing Has the ink ribbon reached its life end? • Replace the ink ribbon. • Has the headgap been accurately adjusted? • Accurately readjust it. • Can the printer recover after the print head is replaced? • End •...
  • Page 158 9 The printer can normally operate, but not start printing. • In the event of the use of optional serial board, go to 9-1 . • In the event of the use of MUPIS card, go to 9-2 . • Can the printer perform the self-test. •...
  • Page 159 Can the printer perform the self-test? • Replace the PMA board. • Is the interface cable properly connected? • Properly reconnect it. • Do the settings of serial interface meet the system? • Accurately redo the settings. • Can the printer recover after the interface cable is replaced? •...
  • Page 160 • Can the printer recover after the network cable (LAN cable) to the MUPIS card is replaced? • End • Confirm if the printer recognizes the MUPIS card using the menu. Check If “OKI HSP” appears in Set when “Set-up” is selected for Group and “Host Interface” for Item in menu setting. If it can be found, the printer can be considered to recognize this card.

  • Page 161: Parts List

    Parts List The main component parts of this printer are described as follows. Name Part No. Total Assembling Diagram 40496501 (ODA) 40496502 (OEL) Printer Unit 40496601 Carriage Unit 40501901 Knob Assy 40782001 Ribbon Feed Assy 40506101 Sprocket Assy (L) 40507601 Sprocket Assy (R) 40508101 Sheet Feeder Assy (L) Rear...
  • Page 162 Total Assembling Diagram – 40496501 (ODA) / 40496502 (OEL) – 40496501TH Rev.1...
  • Page 163 Total Assembling Diagram – 40496501 (ODA) / 40496502 (OEL) – 1/2 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40496601 Printer Unit – – – – 2 4PB4053-1883P002 Cup Screw with Washer 3 40538101 Serial Dot Head-4410 4 40752201 PMA/PDA PCB –...
  • Page 164 Total Assembling Diagram – 40496501 (ODA) / 40496502 (OEL) – 2/2 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 33 D4-8G Screw (Bind) – – – – 34 S3-6HH Screw – – – – 35 PSW2W4-6C Screw 36 40658201 Guide - Sheet 37 40936201...
  • Page 165 Printer Unit – 40496601 –(1/3) 40496501TH Rev.1...
  • Page 166 Printer Unit – 40496601 –(2/3) 40496501TH Rev.1...
  • Page 167 Printer Unit – 40496601 –(3/3) 40496501TH Rev.1...
  • Page 168 Printer Unit – 40496601 – 1/6 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40799801 Flame - Main – – – – 2 40498401 Plate - Rear – – – – 3 40537701 Guide - Paper –...
  • Page 169 Printer Unit – 40496601 – 2/6 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 34 40500401 Platen – – – – 35 40500501 Guide Sheet (U) - Platen – – – – 36 40500601 Sheet Guide (L) A - Platen –...
  • Page 170 Printer Unit – 40496601 – 3/6 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 66 40794301 Fan Cover Bracket Assy – – – – 67 40506101 Ribbon Assy. - Feed – – – – 68 40558601 Bracket - Ribbon Cassette (L) Assy –...
  • Page 171 Printer Unit – 40496601 – 4/6 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 99 40906101 Tractor Change Lever Assy 100 40829301 LF Motor Assy 101 4LP-1313-33 Mini Pitch Belt 102 40511201 Gear - LF 103 40511301 Change Gear - Tractor 104 4LB-190700-4 Spring...
  • Page 172 Printer Unit – 40496601 – 5/6 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 130 40917301 Open Lever Plate – – – – 131 40644601 Platen Slide Plate – – – – 132 40788101 Plate - Guide Platen r –...
  • Page 173 Printer Unit – 40496601 – 6/6 Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 160 40534601 Connection Cord Wire 161 40513201 Holder AG PCB A – – – – 162 40511401 Idle pulley Assy 163 PSW2W3-6C Screw –...
  • Page 174 Carriage Assy. -Unit – 40501901 – 40496501TH Rev.1...
  • Page 175 Carriage Assy. -Unit – 40501901 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40502001 Frame - Carriage – – – – 2 40547701 Bias Roller Assy – – – – 3 40502601 Spring – – –...
  • Page 176 Knob Assy –40782001– 40496501TH Rev.1...
  • Page 177 Knob Assy – 40782001 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40646401 Bracket Assy - Knob 2 40794501 Knob Cover 3 4PP4043-2590P001 Bush 4 40646101 Idle Gear Shaft 5 4PP4122-1285P001 Gear (Z19-52) 6 4PP4043-2502P001 CSF Drive Gear 7 4PP4044-4193P001 Adjust Knob 8 SPP3-14SUS Spring Pin...
  • Page 178 Ribbon Assy. - Feed –40506101– 40496501TH Rev.1...
  • Page 179 Ribbon Assy. - Feed – 40506101 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40458201 Motor - Ribbon 2 40506201 Frame Assy. - Ribbon Feed – – – – 3 4PP4044-4161G001 Ribbon Drive Gear Assy –...
  • Page 180 Sprocket Assy (L) – 40507601 – 40496501TH Rev.1...
  • Page 181 Sprocket Assy (L) – 40507601 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 3PP4053-3747P001 Tractor Frame A – – – – 2 4PK4044-1936G001 Sheet Feeder Frame B (L) – – – – 3 40625201 Cover - Sheet Feeder (L) –...
  • Page 182 Sprocket Assy (R) – 40508101 – 40496501TH Rev.1...
  • Page 183 Sprocket Assy (R) – 40508101 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 3PP4053-3747P001 Tractor Frame – – – – 2 4LR-194630 Sprocket Frame B (R) – – – – 3 40625101 Cover - Sheet Feeder (R) –...
  • Page 184 Sheet Feeder Assy (L) Rear – 40508701 – 40496501TH Rev.1...
  • Page 185 Sheet Feeder Assy (L) Rear – 40508701 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40508801 Frame Sheet Feeder (L) – – – – 2 40508901 Guide Sheet (L) – – – – 3 3PP4043-2443P001 Sheet Feeder Cover (L) –...
  • Page 186 Sheet Feeder Assy (R) Rear – 40509101 – 40496501TH Rev.1...
  • Page 187 Sheet Feeder Assy (R) Rear – 40509101 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40509201 Frame Sheet Feeder (R) – – – – 2 40509301 Guide Sheet (L) – – – – 3 3PP4043-2450P001 Sheet Feeder Cover (R) –...
  • Page 188 Bail Assy – 40499601 – 40496501TH Rev.1...
  • Page 189 Bail Assy – 40499601 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40648701 Bail Sheet Guide – – – – 2 40613801 Sheet Guide Holder (R) Assy – – – – 3 40613601 Sheet Guide Holder (L) –...
  • Page 190 Lower Cover Assy – 40677101 – 40496501TH Rev.1...
  • Page 191 Lower Cover Assy – 40677101 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40518901 Cover - Lower – – – – 2 40898401 Bracket - PG – – – – 3 40557201 Rubber Dumper – –...
  • Page 192 Front Cover Assy – 40677201(ODA) / 40677202 (OEL) – 40496501TH Rev.1...
  • Page 193 Front Cover Assy – 40677201(ODA) / 40677202 (OEL) – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40677301 Cover Assy. - Front – – – – 2 40643601 Beam - Cover – – – – 3 40656101 Latch (A) –...
  • Page 194 Rear Cover Assy – 40678301 – 40496501TH Rev.1...
  • Page 195 Rear Cover Assy – 40678301 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40519701 Frame - Rear – – – – 2 40814501 Frame Bracket Assy. - Rear (L) – – – – 3 40814601 Frame Bracket Assy.
  • Page 196 Access Cover – 40520201 – 40496501TH Rev.1...
  • Page 197 Access Cover – 40520201 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40795901 Cover - Access (A) – – – – 2 40520401 Cover - Access (B) – – – – 3 40739501 Plate - Guide –...
  • Page 198 Frame Assy. - OpePane – 40755801 – 40496501TH Rev.1...
  • Page 199 Frame Assy. - OpePane – 40755801 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40678901 Frame - OpePane (Sticking) – – – – 2 40751001 POA-PCB 3 40742901 LCD Assy. 4 40666701 Sheet - OpePane 5 40519501 Frame - OpePane –...
  • Page 200 PMA/PDA PCB Assy – 40752201/4075202 – 5 or 7 4 or 6 12 or 13 1 or 2 40496501TH Rev.1...
  • Page 201 PMA/PDA PCB Assy – 40752201/4075202 – Recommended Q’ty Parts No. Name Q’ty/U RSPL Remarks 500 1000 2000 1 40750401 PMA-PCB – – – – (ODA) 2 40750402 PMA-PCB – – – – (OEL) 3 40750701 PDA-PCB 4 40751201 Control ROM Writing Specifications (ODA) 5 40751301 Font ROM Writing Specifications...

  • Page 202: Appendix A Pcb Layout

    Appendix A PCB LAYOUT (1) Circuit board PMA (Control) (2) Circuit board PDA (Driver) (3) Circuit board POA (Operation Panel) (4) Circuit board PHA (Interface) (5) Circuit board PRA (Connection) (6) Circuit board PGA (Sensor) (1) Circuit board PMA (Control) IC45 IC46 IC47 IC48 1 3 1 3 Short plug...
  • Page 203 (2) Circuit board PDA (Driver) (3) Circuit board POA (Operation Panel) POWER LED1 ALARM LED2 MENU CONFIG FF/LOAD PARK PATH TEAR SW10 SW11 SW12 STORE SHIFT SW13 ON-LINE ON-LINE GROUP ITEM OPTION LED3 (4) Circuit board PHA (Interface) CN12 CN14 CN15 CN13 CN11...
  • Page 204 (5) Circuit board PRA (Connection) CN13 (6) Circuit board PGA (Sensor) 404965601TH Rev.1...

  • Page 205: Appendix B Rs-232C Serial Interface Board (Option)

    19,200 bits per second. Two protocols are available: printer Ready/Busy and X-ON/X-OFF modes. For this serial interface to be installed in a Pacemark 4410 or Microline 4410, you need to have an adapter board (PAA PCB).

  • Page 206: Operation Description

    OPERATION DESCRIPTION Element Description (1) 80C51 with MASK ROM An eight-bit microprocessor controller that controls the following: (a.)Serial interface protocol and data transfer through a serial port. (b.)Message buffer. (c.) Transmission of parallel data to the printer. (2) SN75189 An RS-232C standard line receiver (3) SN75188 An RS-232C standard line driver.
  • Page 207 80C51 ADR latch IF WR 2764 DB0 to DB9 LS245 8 KB 8 KB Serial data control line +5 VD +9 V ±9 V power +12V Bus line –9 V supply circuit -12V +5 V Control line Figure B-2-1 Block Diagram 40496501TH Rev.1...
  • Page 208 2.2.1 Operation at power on After power is turned on, an RST OUT signal is sent from the printer control board to reset the printer. When the reset is canceled, the 80C51 CPU performs initialization. Initialization consists of setting the 80C51 timer, and setting the serial mode. 2.2.2.

  • Page 209: Local Test

    Local Test 2.3.1 Circuit test mode 2.3.1.1 Setting (1) Diagnostic test (set by menu) (2) Test connector Connect the test connector shown in Figure B-3-6 to the interface connector Equivalent to Cannon DB-25P Figure B-3-6 Test Connector Connection Diagram 40496501TH Rev.1...
  • Page 210 2.3.1.2 Function After the settings outlined in Section 3.3.1.1 are completed and power is turned on, the serial interface checks the message buffer memory and interface driver/receiver circuit. It then prints characters. To start and stop this test, push the SEL switch on the front of the printer. Details of this test are explained on the next page.

  • Page 211: Appendix C Maintenance-Support Function

    Appendix C Maintenance-Support Function Normal mode (1) DIP Switch Settings DIP Switch Function (O: ON, X: OFF, –: ignored) – – – – Normal mode (2) Power ON Switch Function Switch Function SEL/ MENU CON- PATH/ TEAR PARK RESET LOAD Starts menu mode Starts menu maintenance mode Starts demo-pattern self test...

  • Page 212: Maintenance Mode 1

    Maintenance mode 1 (1) DIP Switch Settings DIP Switch Function (O: ON, X: OFF, –: ignored) – – – Maintence function enabled mode (2) Power ON Switch Function Switch Function SHIFT CON- PATH/ TEAR PARK (Valid when DIP switch-1 is ON) LINE LOAD Starts learning function for slice level of...

  • Page 213: Maintenance Mode 2

    Maintenance mode 2 (1) DIP Switch Settings DIP Switch Function (O: ON, X: OFF, –: ignored) – – – Maintence information indication enabled mode (2) Operator panel switch Function Switch Function STORE SHIFT CON- PATH/ TEAR PARK (Valid when DIP switch-2 is ON) LOAD The LCD displays the maintenance information (total page number, number...

  • Page 214: Th Rev.1

    (4) Stored historical page number data This function counts a page each 11inch and stores it to EEPROM. The storage capacity for the counter is 3byte, which equals to pages for 70 years at 20000 pages/ month. As the printer has no function which is capable of resetting this counter, line feed frequency can be known since the printer's shipment.

This manual is also suitable for:

Microline 4410

Table of Contents
