- Page 1 Instructions for Installation and Use Electric Multifunction Oven Models ST55X - ST52...
-
Page 2: Table Of Contents
Care and Cleaning Installation Electrical Connection After Sales Service Hotpoint Guarantee Key Contacts Retention of this Instruction Book This Instruction Book must be kept handy for reference as it contains important details on the safe and proper use of the appliance. -
Page 3: Introduction
The oven is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. Note: When the oven is first used, an odour may be omitted - this will cease after a short period of use. -
Page 4: For Your Safety
- grip the handle in the centre when opening the door. - stand back when openign the door to allow any build up of steam or heat to disperse. - use dry, good quality oven gloves when removing items. - take care to avoid heat/steam burns when operating the controls. -
Page 5: Know Your Oven
A. Control Panel B. Function Selector C. Temperature Control E. Oven indicator light - When lit, it indicates the ovens is heating up to the selected temperature. F. Grill Pan / Baking Tray G. Oven Shelf H. Guides for sliding the shelves or grill pan/baking tray in and out O. -
Page 6: The Controls
This mode is also ideal for cooking fish steaks, like sword- fish or tuna etc. The oven light To turn on the oven light, set the function selector “B” to the symbol. The light will stay on when any of the electrical heating elements in the oven come on. -
Page 7: Cooking Advice
4th shelf position from the bottom and take the food requiring less time out of the oven first. • Use the baking tray on the lower shelf position and the shelf on the upper;... -
Page 8: Cooking Chart
Lamb on the spit NB: cooking times are approximate and may vary according to personal taste. When cooking using the grill or fan assisted grill, the dripping pan must always be placed on the 1st oven rack from the bottom. Cooking Chart... -
Page 9: The Analogue Programmer
A click will indicate the operation is over. With the oven selector knob, select the desired cooking mode. To turn the oven off, set the same back to the “0” position. The Analogue Programmer Programming cooking with immediate start 1 Turn the knob anticlockwise until the desired cooking time is displayed in the window. -
Page 10: Care And Cleaning
DO NOT use aluminium foil to line the bottom of the oven. To avoid having to clean the bottom of the oven, you may be tempted to line it with some aluminium foil. We strongly advise against this. The aluminium foil sheet in direct contact with the heated enamel coating could melt and damage the enamel coating inside the oven irreversibly. -
Page 11: Installation
In order to ensure adequate ventilation, the back panel of the cabinet unit must be removed. Installing the oven so that it rests on two strips of wood is preferable. If the oven rests on a continuous, flat surface, there must be an aper- ture of at least 45 x 560 mm. -
Page 12: Electrical Connection
We recommend you use a power supply cable which is long enough to allow you to take the oven out of its recess in the event of maintenance operations (only use HAR - H 05 - RRF quality cables fitted with a plug conforming to the regulations in force. - Page 13 Notes...
-
Page 14: After Sales Service
Hotpoint appliance than us - the manufacturer" As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts and labour guarantee for the first 12 months. In addition to this you also have the advantage of free replacement parts for the first 5 years when fitted by a Hotpoint engineer. -
Page 15: Hotpoint Guarantee
All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer. -
Page 16: Key Contacts
Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in both the appliances and services we offer. (Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays) Note: Our operators will require the following information: General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB.
