Grill Guide For Model BQ04028 LP Gas Barbecue Grill FOR YOUR SAFETY: 1. Read this Grill Guide before attempting to assemble or operate your grill. 2. Follow all safety instructions. 3. Check for leaks according to directions in this Grill Guide before operating your grill, even if a retailer assembled this grill.
Safety Precautions Always read and follow all DANGER, WARNING, AND FOR YOUR SAFETY notices in this Grill Guide. Failure to do may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. 1.
Table of Contents Safety Precautions……….……………………………..……………...…………...…… 2 Table of Contents…………………….…………………………………..……….……...3 Warranty……………………………….………………………………………….…….. 4 Customer Support Center……………….………………………………………….…….4 Assembly Instructions...…………………………………………………………..…..5-16 General Information and Operation………………..………………………………..17-25 Trouble Shooting Guide………………………………………………....….26-27 Owner Registration Card……………….……………………………………...28-29 Write down here and keep for future reference Kmart Corporation Date of Purchase: _________________ 3100 West Big Beaver Road Troy MI 48084-3163 Serial Number: ___________________...
Customer Support Center Thanks for purchasing a BBQ Pro™ Grill. We’re here to help you maximize your enjoyment and appreciation your new grill. Please don’t hesitate to contact us should you have any questions regarding assembly, performance, warranty, or accessories.
7.) Do not use a Power Screwdriver for assembly as you could strip the threads on the Nuts and Bolts. 8.) The propane tank for this grill is sold separately. See the LP Gas and Cylinder Information later in this guide. BQ04028 ! WARNING ! Failure to follow all Danger,...
Page 6
BQ04028 Detail Parts List 1. Thermometer 35 Cooking Grate 2. Thermometer Seat 36 Gas Hose 3. Stainless Steel Lid - Outer 37. Regulator and Hose 4. Logo Plate 38. Firebox - Front 5. Lid Side Panel - Left 39. Control Panel 6.
Page 9
! WARNING ! DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES MAY EXPLODE OR LEAK.
General Information and Instructions Your new BBQ Pro™ Grill has been designed and manufactured to high quality standards. It will provide you with many years of enjoyment with a minimal amount of maintenance. Please keep in mind the following FOR YOUR SAFETY.
Page 19
! WARNING ! 1. Do not attempt to use a cylinder with any other type of connection device. 2. Do not attempt to use a cylinder with a larger capacity LP CYLINDER FILLING AND EXCHANGE Some areas only allow you to exchange your empty cylinder for a replacement that is already full. Other areas allow you to refill your cylinder.
DANGER Bubbles indicate a leak. In that case, call your LP dealer or fire department immediately. TRANSPORTATION AND STORAGE 1. Always use the Safety Cap when transporting or storing your cylinder. 2. Do not store in a building, garage, or other enclosed area. 3.
Page 21
The regulator must enter the cylinder valve in a straight line. Center this nipple of the regulator into the cylinder valve. Q.C.C.1 Type 1 Connector ! WARNING ! 1. Do not connect this grill to any unregulated sources of propane. 2.
Grill Placement ! FOR YOUR SAFETY ! ! AVERTISSEMENT ! 1. Minimum clearance from sides and back 1. Dégagement minimal a respecter entre of unit to adjacent combustible les cotes et l’arrière de l’appareil et uns construction below top of unit, 24 inches construction combustible adjacente (60 cm) from sides and 24 inches (60 cm) située au-dessous de la partie...
Page 23
LIGHTING THE MAIN BURNERS USING ELECTRONIC IGNITION 1. Open the lid. 2. Ensure all burner control knobs are in the “Off” position. 3. Turn on the LP gas by turning the hand wheel on the cylinder valve. 4. Turn one burner control knob marked with an igniter flame “ ”...
TURNING OFF YOUR GRILL 1. Turn off the gas supply at the LP tank by turning the valve clockwise. 2. Turn all burner control knobs to the “Off” position. Cleaning Your Grill ! WARNING ! 1. Do not clean any part of your barbecue grill in a self-cleaning oven. 2.
CLEANING THE BURNERS 1. Ensure the LP gas is turned off at the LP cylinder. 2. Remove the cooking grates, heat diffusers, and grease tray. 3. Remove the cotter pins located under neath the back end of each burner. 4. Lift each burner up and out. 5.
Page 26
DIRECT 1. Used to sear meats. After searing, some food will finish cooking using the indirect method. 2. Usually used for quicker cooking foods. 3. Turn all burners to “High” and close the hood to cook, placing food directly over the heat source. INDIRECT 1.
Trouble Shooting Guide BURNER WILL NOT LIGHT 1.) Gas supply is turned off. Turn on gas at LP cylinder. 2.) Out of propane. Check to be sure you still have propane in your tank. 3.) Regulator is not properly seated into the tank valve. Remove and reattach. Hand tighten only. 4.) Crimped fuel supply hose.
3.) Gas is leaking from a faulty connection or damaged hose. Perform a leak test and inspect for leaks. Tighten or replace parts as necessary. Customer Support PHONE: 1-800-933-0527 Hours 8:30am to 5:00 pm Central time FAX: 1-847-252-1001 WEBSITE: http://www.omahagrills.com MAIL: Customer Support –...
Page 30
Place Postage Stamp Here WARRANTY REGISTRATION BBQ PRO GRILLS 1375 MITCHELL BLVD. SCHAUMBURG, IL 60193...
