JBL EON210P Specifications

Professional Series

Applications:
Live sound reinforcement, speech and vocals, music
playback in entertainment, A/V, and institutional
venues – especially when ease of use and portability
are important factors.
Amplification, mixing, and monitoring for electronic
musical instruments.
Everywhere you need to be heard.
Features:
300 watt High-Performance Powered Speaker System
Ultra Light Weight and Extremely Compact weighing
only (33 lbs)
Ergonomic soft touch top grip for easy handling
10" low-frequency driver
with neodymium magnet for low-distortion
and light weight
1" throat diameter next generation JBL neodymium
compression driver
Efficient Crown® Class-D amplifier technology
100° H x 60° V asymmetrical wave guide for uniform
audience coverage
8 chanel powered mixer with intuitive interface
On board digital multi-effects
Integrated 36 mm pole mount socket with
stabilizing securing screw
Highly designed composite enclosures for durability,
lightweight, and acoustic performance
The EON 210P is a self-contained, portable pa system
featuring multiple input channels with individual tone
controls, multiple digital effects and convenient output
routing capabilities that allow the user to integrate the
system into any number of audio environments. With
its lightweight and ergonomic design the EON 210P is
perfect for situations where ease and portability are just
as important as quality and flexibility.
The EON210P consists of two 10-inch, two-
way, powered loudspeakers, one with a detachable
powered mixer and the other with a detachable storage
compartment, one pair of unshielded speaker cables and
a power cord. Capable of reproducing full bandwidth
sound at high levels the 210P is comprised of a 250 mm
(10 in) woofer, a 37.5 mm (1.5 in) neodymium high
frequency compression driver coupled to a 100° H by 60°
V waveguide driven by a 300 watt Crown® Class-D power
amplifier and integrated mixer.
The attached mixer has 8 inputs: 4 mono inputs
comprised of a "peak LED", a combination input
connector, MIC/LINE selector, Treble and Bass controls,
a Reverb send and a channel volume control. The 2 stereo
inputs are where you will connect all of the microphones,
musical instruments, external sound sources (like MP3
or CD players), headphones in addition to any recording
devices or additional speakers like a personal monitor,
subwoofer or "Front of House" feed. The stereo inputs
labeled "STEREO IN 5/6" offer the option of using ¼"
phone plugs or RCA plugs and this channel has a volume
control. The input labeled "STEREO IN 7/8" is a 3.5 mm
stereo input of the type typically found on personal music
players. All of the inputs will route to the speakers and to
the MONITOR OUTPUT SECTION.
The system is also equipped with digital multi-effects
designed to enhance instruments or vocals. There are
four effects available on the EON 210P.
EON210P
Portable Self-Powered 10" Two-Way system with detachable powered mixer

Specifications:

System
System Type:
Maximum SPL Output:
Frequency Range (-10 dB):
Frequency Response (±3 dB):
AC input :
Amplification
Amplifier Design:
System Power Rating:
Output Connector:
Mixer
Input Connectors:
Channels
Input Impedance:
Phantom Power:
Output Connectors:
Signal Indicators:
Main Output LED Ladder
Signal Indicators: Ch 1-4
EQ:
System Limiter:
Speaker
LF Driver:
HF Driver:
Coverage Pattern:
Crossover Frequency:
Crossover Type:
Enclosure:
Suspension/ Mounting:
Handles:
Grille:
Shipping Package :
( H x W x D )
Net Weight of System:
JBL continually engages in research related to product improvement. Some materials, production methods and design
refinements are introduced into existing products without notice as a routine expression of that philosophy. For this reason, any
current JBL product may differ in some respect from its published description, but will always equal or exceed the original design
specifications unless otherwise stated.
Powered mixer with 2 two-way bass-reflex enclosures
124 dB peak system output (pink noise)
60 Hz - 20 kHz
75 Hz - 19 kHz
120 - 240 V 50/60 Hz, voltage selector switch sets operational range
Crown® Class D
300 Watts (2 x 150 W Stereo)
2 x 1/4" TS (unbalanced) amplifier outputs
8 inputs (4 Mono Mic/Line, 2 x Stereo)
1-4 are XLR / 1/4" jack combo connectors, XLR is a mic level input,
1/4" is a line level input. 5-6, one pair of 1/4" balanced TRS jacks
(stereo), and a pair of RCA jacks (stereo). 7-8 is a 3.5 mm stereo jack
Ch 1-4 Combo: XLR 3 K Ohms Balanced
Ch 1-4 Combo: TRS 20 K Ohms Balanced
Ch 5-6: TRS 25 K Ohms Balanced
Ch 5-6: RCA 12 K Ohms Unbalanced
Ch 7-8: 3.5 mm 30 K Ohms Unbalanced
30 V
Monitor outputs: one pair of 1/4" balanced TRS jacks (stereo), and a
pair of RCA jacks (stereo)
Headphone output: one 3.5 mm stereo jack
Limit: Red LED indicates limiter active condition
Signal: Green LED indicates signal present
Peak LED: Green = signal present, Red = input overload
Individual channel Bass and Treble controls, center detent, +/-6 dB
cut and boost
On Board DSP Limiting and Tuning
1 x JBL 328H 250 mm (10 in) woofer
1 x JBL 2414H-1 37.5 mm (1.5" ) annular polymer diaphragm,
neodymium compression driver
100º x 60º nominal
2 kHz
Passive network, 2nd order filters (-12 dB per octave)
for high pass and low pass filters
Polypropylene
36 mm pole socket with stabilizing screw
One on top
Powder coated perforated steel
21.5" x 26" x 13.75" (546 mm x 660 mm x 349 mm)
33 lbs. (19 lbs. for unit with powered mixer, 14 lbs. for unit with storage pod)
