JBL EON510 Technical Manual

Technical Manual
JBL EON510/230
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• System Power Rating:
• Frequency Response:
• Frequency Range:
• LF Power amp:
• HF Power amp:
• Input Gain (input 3):
• Input Gain (input 1 & 2):
• Input Impedance:
• Boost EQ:
• Low Cut Filter
• Crossover Freqeuncy:
SYSTEM COMPONENTS:
• Low Frequency
Transducer:
• DC Resistance:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
280W continuous, 560W peak
70 Hz – 17 kHz (± 3 dB) (EQ in "Flat"
position
58 Hz – 18.5 kHz (-10 dB)
220W continuous at driver impedance
60W continuous at driver impedance
Mic position: -Infinity to +40 dB
Line position: -Infinity to +4 db (+20
dBu Max signal input)
-Infinity to +4 (+20 dBu Max signal
input)
64 K ohms (balanced), 32 K ohms
(unbalanced)
LF +3 dB Shelving, Filter @ 150 Hz
HF +2.5 dB Shelving Filter @ 4 kHz
Preset high pass @ 120 Hz
1.8 kHz
261F, 254 mm (10 in) Differential Drive
integrated woofer with dual 1.5" voice
coils
1.20 ohm ±10%
Warranty 59660
Owners manual
440941-001
(available on web-
site only)
Fillers, (2)
364893-001
Bag
322591-001
19"x16"x42" LG
.003 THKLDPE
CLEAR
Carton
364894-001
Cord, AC, Line
425-00000-00 120V
425-00000-01 230V
SYSTEM COMPONENTS:
• High Frequency
Transducer:
• DC Resistance:
• Input 3 connector:
• Input 1 & 2 connector:
• Output (Loop/Mix switch):
• XLR Pin Assignments:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test: 0.25 V Input, 20 Hz to 2 kHz
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
®
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, High Freq
2414H-1
(363858-001X)
-
+
GRN / BLK
BLU
BLU / BLK
(SEE SCHEMATIC PAGE)
(CONT'D)
2414H-1, 25.4 mm (1 in) polymer
diaphragm, neodymium compression
driver
3.60 ohm ±0.2%
Balanced XLR / /14 inch TRS combo
jack with XLR loop through
1/4 inch TRS jack
Balanced male XLR,+20 dBu (peak)
o/p level in Mix position
Pin 2 (+), Pin 3 (-), Pin 1 (GND)
Ch1 Input all pots full clockwise
5.0V Input, 10 Hz to 300 Hz
0.75V Input, 500 Hz to 1.5 kHz
490 x 313 x 262 mm D
(19.3 x12.3 x 10.3 in D)
17 lb (7.7 kg)
Driver, Low Freq.
261F
(364742-003X)
Cone Repl
C2R261
- +
GRN
Amplifier Assembly
Wire Harness Assembly
364836-001
04-13
