- Page 1 Always there to help you Register your product and get support at www.philips.com/welcome MCD1165 Question? Contact Philips User manual...
-
Page 3: Table Of Contents
Contents 7 Listen to the radio 1 Important Tune to a radio station Safety Program radio stations automatically Program radio stations manually 2 Your micro system Select a preset radio station Introduction What's in the box 8 Other features Overview of the main unit Set the alarm timer Overview of the remote control Set the sleep timer... -
Page 4: Important
1 Important • Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the device. • Only use attachments/accessories specified by the manufacturer. Safety • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the device. - Page 5 • Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. Warning • Never remove the casing of this device. • Never lubricate any part of this device. • Never place this device on other electrical equipment.
-
Page 6: Your Micro System
DVD region code Countries Latin America system Congratulations on your purchase, and What's in the box welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Check and identify the contents of your package: [Fig. 1] • Main unit Introduction •... -
Page 7: Overview Of The Main Unit
Overview of the main unit [Fig. 2] • Skip to the previous/next track. • Turn the unit on or off. • Press to tune to a radio station. • Switch to standby mode or Eco • Press and hold to search for radio standby mode. -
Page 8: Overview Of The Remote Control
Overview of the remote • Navigate through the menu. control • Skip to previous/next album. • Select a preset radio station. [Fig. 3] • Set subtitle or audio language. • Set time. • Return to previous display menu. g +/- • Adjust volume. - Page 9 • Mute or restore volume. r SOUND • Enrich sound effect with Digital Sound Control (DSC). s OK • Confirm a selection. t FM/AUX • Select FM or AUX source. u EJECT • Press to open or close the disc compartment.
-
Page 10: Connect
3 Connect [Fig. 4] SPEAKER OUT Place the unit Connect video cables You can select the best video connection that your TV supports. Option 1: Connect through a composite • video (CVBS) cable (for a standard TV). Option 2: Connect through component •... -
Page 11: Connect An External Audio Device
Option 2: Connect through Connect power component video cables Caution Note • Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back • The progressive scan video quality is only available or the underside of the unit. when a progressive scan TV is connected. •... -
Page 12: Get Started
Always follow the instructions in this chapter in [12H] hour format sequence. Press CLOCK SET to confirm. If you contact Philips, you will be asked for the » The hour digits are displayed and begin model and serial number of this apparatus. The to blink. -
Page 13: Find The Correct Viewing Channel
• [NTSC] - For TV with NTSC color Note system. • The unit switches to Eco Power Standby mode after 15 To return to the previous menu, press minutes in standby mode. To exit the menu, press . Switch between standby mode and ECO standby mode: Change system menu language Press and hold... -
Page 14: Play
5 Play Use the disc menu When you load a DVD/(S)VCD disc, a menu may be displayed on the TV screen. Press MENU to access or exit disc menu manually. Play from disc For VCD with PlayBack Control (PBC) feature (version 2.0 only): Caution With the PBC feature, you can play VCD... -
Page 15: Play From Usb Or Recored Discs
Play from USB or recored Play a slideshow with discs background music You can play DivX (Home Theater 3.1)/MP3/ This device can play MP3 files and JPEG photos JPEG picture files copied onto a CD-R/RW, simultaneously. recordable DVD, or USB storage device. Note Select a source. • Press DISC/USB repeatedly to select • The MP3 and JPEG files must be stored on the same DISC or USB source. -
Page 16: Control Play
[GOTO]: during video play, specify a • Control play position to start play by entering the desired time or number. Select a folder. [Slow Backward] & [Slow Forward]: • Fast backward/forward. during video play, select a slow backward/ forward speed. Skip to previous or next title/ chapter/track/file. -
Page 17: Enjoy Karaoke
6 Enjoy karaoke 1) In the [Karaoke Scoring] option, select a level (basic/intermediate/advance). 2) In the [Karaoke Idol] option, turn on the contest. You can connect a microphone (not supplied) » The song selection menu is displayed. to sing along with a music source. 3) Input a track (VCD/SVCD) or a title/ chapter (DVD) as the first song. -
Page 18: Listen To The Radio
7 Listen to the Program radio stations radio manually Tune to a radio station. Tune to a radio station Press PROG, and then press select a number from 1–20. Press PROG to confirm. » [SAVE] (save) is displayed. • Position the antenna as far as possible from TV, VCR, or other radiation source. -
Page 19: Other Features
8 Other features Set the sleep timer To set the sleep timer, in turn on mode, press TIME/SLEEP repeatedly to select a set period of time (in minutes). » When sleep timer is activated, Set the alarm timer displayed. To deactivate sleep timer: This unit can be used as an alarm clock. -
Page 20: Adjust Settings
9 Adjust settings [Multi] - For TV that is compatible with • both PAL and NTSC. [NTSC] - For TV with NTSC color • system. Press . [TV Display] The TV format determines the aspect ratio of Select the [Setup] page. display according to the type of TV you have Select a setting and press OK. -
Page 21: Preferences
[Stereo] • 1) Press OK. [LT/RT] • 2) Select a rating level, and then press OK. [Sound Mode] 3) Press the numeric keys to enter the Turn off or select your preferred sound mode. password. • [3D] • [Movie Mode] Note [Music Mode] •... - Page 22 Note • Ensure that the subtitle file has the exact same file name as the movie file. If for example the file name of the movie is ‘Movie.avi’, and then you will need to name the text file ‘Movie.sub’ or ‘Movie.srt’. [Version Info] Display the software version of this device. [Default] Reset all the settings to factory default, except for the password and parental settings.
-
Page 23: Product Information
10 Product Disc information Laser Type Semiconductor Disc Diameter 12 cm/8 cm Video Decoding MPEG-1 / MPEG-2 / DivX Note Video DAC 12 Bits Signal System PAL / NTSC • Product information is subject to change without prior notice. Video Format 4:3 / 16:9 Video S/N >57 dB... -
Page 24: Supported Disc Formats
Supported USB formats: Supported disc formats • USB or memory file format: FAT12, FAT16, FAT32 (sector size: 512 bytes) • Digital Video Discs (DVDs) • MP3 bit rate (data rate): 32-320 Kbps • Video CDs (VCDs) and variable bit rate • Super Video CDs (SVCDs) • Directory nesting up to a maximum of •... -
Page 25: Troubleshooting
Check for any scratches or requesting service. If the problem remains smudges on the disc. unsolved, go to the Philips Web page (www. • Press to exit the system setup menu. philips.com/support). When you contact Philips, •... - Page 26 DivX video files cannot be played. • Ensure that the DivX video file is complete. • Ensure that the file extension is correct. • Due to Digital Rights issue, the DRM- protected video files cannot be played through an analog video connection (e.g. composite, component and scart). Transfer the video content onto the Disc Media and play these files. Audio or subtitle languages cannot be set •...
- Page 27 ABOUT DIVX VIDEO-ON-DEMAND: This DivX Please visit www.recycle.philips.com for additional Certified device must be registered in order to ® information on a recycling center in your area. play purchased DivX Video-on-Demand (VOD) Environmental information movies.
- Page 28 WOOX Innovations, and is the manufacturer of the product. WOOX Innovations is the warrantor in relation to the product with which this booklet was packaged. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. MCD1165_UM_55_EN_V2.0...
