Datavideo HDR-45 Quick Start Manual

Hd/sd recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

HD/SD Recorder
HDR-45
Quick Start Guide
www.datavideo-tek.com

Advertisement

Table of Contents
loading

Related Manuals for Datavideo HDR-45

Summary of Contents for Datavideo HDR-45

  • Page 1 HD/SD Recorder HDR-45 Quick Start Guide www.datavideo-tek.com...

  • Page 2: Table Of Contents

    Table of contents Warnings and Precautions ............................. 2 Warranty ................................... 3 Disposal.................................... 3 Packing List ..................................4 Introduction..................................4 Features.................................... 4 How to Assemble 2.5" HDD in Removable Rack......................5 Connections & Controls ..............................6 Front Panel ................................6 Rear Panel................................7 Powering On ..................................

  • Page 3: Warnings And Precautions

    7. This product should only be operated from the type of power source indicated on the marking label of the AC adapter. If you are not sure of the type of power available, consult your Datavideo dealer or your local power company.

  • Page 4: Warranty

    Datavideo warrants that the equipment it manufactures shall be free from defects in material and workmanship for a period of 2 years from the date of product purchased. If equipment fails due to such defects, Datavideo will, at its option, repair or provide a replacement for the defective part or product.

  • Page 5: Packing List

    Instruction Manual Introduction The Datavideo HDR-45 is a hard drive based video recorder & player, with a removable hard drive enclosure. The HDR-45 records from standard and high definition video via SDI with a convenient loop through / pass through for monitoring.

  • Page 6: How To Assemble 2.5" Hdd In Removable Rack

    How to Assemble the 2.5” HDD in a Removable Rack 1. Remove the screws from the back cover of the enclosure and pull out the PCB board. NOTE: DO NOT REMOVE THE SCREWS ON THE FRONT COVER. 2. Place the 2.5” hard drive on the PCB board and slide the drive towards the rear SATA connectors on the board.

  • Page 7: Connections & Controls

    The HDR-45 has "auto Rewind and Playback" function. You just need to press "Rew" key first +"PLAY" key then the HDR-45 will replay the last segment just recorded (2G file size maximum).

  • Page 8: Rear Panel

    Rear Panel The GPI socket can be used for simple external control. The HDR-45 can accept pulse or level trigger inputs, which can trigger record or playback and pause commands See GPI Mode & Function Menus for more details. RS-422 / RS-232 Port. The HDR-45 can be controlled via RS-422 from external devices, or via RS- 232 from PC.

  • Page 9: Powering On

    Menu Options The HDR-45 is a menu driven unit; The menu settings are non-volatile (they are stored even when the unit is switched off), so many of the settings, such as date and time, you will only need to set once. We will look at each individual menu in more detail, but here is a quick overview of them.
  • Page 10 See GPI Mode & Function Menus for more details. SET DATE & TIME Sets the date and time on the HDR-45; the setting is non-volatile so it is stored when the unit is powered off. See Set Date & Time Menu for more details.
  • Page 11 The 9 pin D-SUB can be set to either RS-422 (differential) or RS-232 (single end) transmission mode - Select RS-232 mode, you can control HDR-45 via RS-232 from PC. - Select RS-422 mode, you can control HDR-45 via RS-422 from external devices.

  • Page 12: Hdd Mode Menu

    The last file in the sequence is likely to be smaller than 2GB. Connecting to a PC / MAC NB: Although your PC / MAC may see the HDR-45 as an AVC compliant DV Device it is not intended to be operated as such.

  • Page 13: Hd Mpeg2 Bit Rate Menu

    HD MPEG2 BIT RATE Menu To select the HD MPEG2 encoding BIT RATE: Press the Menu Button, to enter the menu mode Press the FWD (►►) Button to navigate the menus until HD MPEG2 BIT RATE is displayed Press the Next (▲) Button(right) to enter the HD MPEG2 BIT RATE menu Use the FWD(►►) or REW(◄◄) Button to select the desire bit rates (20,25,30,35,40,45,50,55,60) To confirm your selection and exit the menu press the Next (▲) Button(right).

  • Page 14: Sd Mpeg2 Bit Rate Menu

    SD MPEG2 BIT RATE Menu To select the SD MPEG2 encoding BIT RATE: Press the Menu Button, to enter the menu mode Press the FWD (►►) Button to navigate the menus until SD MPEG2 BIT RATE is displayed Press the Next (▲) Button(right) to enter the SD MPEG2 BIT RATE menu Use the FWD(►►) or REW(◄◄) Button to select the desire bit rates (5,10,15) To confirm your selection and exit the menu press the Next (▲) Button(right).

  • Page 15: Set 1080I H-Res. Menu

    SET 1080i H-RES. Menu Press the Menu Button, to enter the menu mode Press the FWD (►►) Button to navigate the menus until SET 1080i H-RES. is displayed. Press the Next (▲) Button(right) to enter the SET 1080i H-RES. menu Press the FWD (►►) Button to select either 1440 or 1920.

  • Page 16: Gpi Mode & Functions Menus

    GPI Mode & Functions Menus The HDR-45 can be set to receive either pulse or level GPI triggers, which can be set to activate Play / Pause or Rec / Pause. To select the GPI Mode: Press the Menu Button, to enter menu mode Press the FWD (►►) Button to navigate the menus until SET GPI TRIGGER MODE is displayed...

  • Page 17: Select The Gpi Function

    Select the GPI Function Press the Menu Button, to enter the menu mode Press the FWD (►►) Button to navigate the menus until SET GPI FUNCTION is displayed Press the Next (▲) Button(right) to enter the SET GPI FUNCTION menu Press the FWD (►►) Button to select either Pulse Trigger or Level Trigger To confirm your selection and exit the menu press the Next (▲) Button(right).

  • Page 18: Set Date & Time Menu

    Set Date & Time Menu To set the Date & Time on the HDR-45 Press the Menu Button, to enter menu mode Press the REW (◄◄) Button to navigate the menus until SET DATE & TIME is displayed Press the Next (▲) Button(right) to enter the SET Date & Time menu You will see a flashing cursor on the date value.

  • Page 19: Format Hard Disk Menu

    You will see ARE YOU SURE? displayed Press the Next (▲) Button(right)again to confirm that you want to format the hard disk. After a few seconds the HDR-45 will reboot and the display will return to normal Erase Track Menu Erase Track is used for deleting individual tracks from the HDR-45.

  • Page 20: Hdd Surface Scan Menu

    Press the Next (▲) Button(right) to exit the surface scan. A txt file called Result will have been created in the root directory of the HDR-45 HDD, this can be accessed via a PC, by connecting the HDR-45 as a HDD.

  • Page 21: Playing A Track

    Button. It is also possible to set the HDR-45 to loop play. In loop play the track will looped until stopped. To set up loop play press the Menu Button to enter menu mode and then the FWD (►►) Button until SETUP LOOP PLAY is displayed.

  • Page 22: Recording A Track

    Press the Video Input Button so that it is illuminated. You should see the video source on your output monitor Use the Next / Previous Buttons to select an empty track from the HDR-45 track list, one that shows a duration of 00:00:00:00 in the LCD display.

  • Page 23: Connecting To A Computer

    Connecting to a PC NB: Although a PC may see the HDR-45 as an AVC compliant DV Device it is not intended to be operated as such. If your PC sees an AVC DV Device select Take No Action.
  • Page 24 Folder to View Files. The drive should also appear in My Computer as an internal HDD. Once connected the HDR-45 can be used just like any HDD. You can select the required files and drag and drop them to the required destination.

  • Page 25: Connecting To A Mac

    You can select the required files and drag and drop them to the required destination. To un-mount the HDR-45 from your MAC either “Eject” the drive, or drag it to the Trash Can. Once the HDR-45 is un- mounted from the MAC the LCD display will return to normal.

  • Page 26: Rs-422 Protocol Reference V1.0

    RS-422 Protocol Reference V1.0 1. Interface Overview Conforming to EIA RS-422A. Full duplex communications channel is utilized. Data is transmitted asynchronously, bit serial, word serial with data exchange between devices. Standard transmission rate on the interface bus is 38400 bits per seconds (bps) The data word utilized by the interface system is as follows : PARITY START...
  • Page 27 (Least Significant) nibble. It (CMD-1) indicates the command or return group to which the command belongs as per the table below CMD-1 Function Initiator System Control Controller System Control Return Device (HDR-45/55) Transport Control Controller Preset And Select Control Controller Sense Request Controller Sense Return...

  • Page 28: Connector Pin Assignment

    3. Connector Pin Assignment Interface : 9 pin D-Sub female The RS-422 pin assignment of the Controller and HDR-45/55 is shown in the following table: Signal Controller HDR-45/55 Frame Ground Frame Ground Receive A(RX-) Transmit A(TX-) Transmit B(TX+) Receive B(RX+)

  • Page 29: Communication Protocol

    • The CONTROLLER must transmit of bytes in a COMMAND block for with intervals less than 10 milliseconds. If a DEVICE (HDR-45/55) detects an interruption of a byte in a COMMAND block that exceeds 10 milliseconds, it executes a TIME-OUT error sequence, voids the receiving COMMAND block, and transmit a NAK (TIME OUT).
  • Page 30 5. Command Table (without Checksum byte) Command Name Response Name 10h 01h Acknowledge (ACK) – command succeeded 12h 11h Device Return 11h 12h Negative Acknowledge (NAK) – command failed 00h 11h Device Type Request 12h 11h Device Type Response 20h 00h Stop 10h 01h 20h 01h...
  • Page 31 6. Detailed Description of Commands 00h 11h : DEVICE TYPE REQUEST Send: 00h 11h 11h Return: 12h 11h B0h 12h E4h (HDR-45/55) 20h 00h : STOP Send: 20h 00h 20h Return: 10h 01h 11h 20h 01h : PLAY Send: 20h 01h 21h...
  • Page 32 41h 61h NNh : SELECT AUDIO INPUT SOURCE NN = Audio Source, 0 = Analog audio, 1 = SDI Embedded Audio Send: 41h 61h 00h A2h (Analog audio input) Return: 10h 01h 11h Send: 41h 61h 01h A3h (SDI Embedded Audio) Return: 10h 01h 11h 41h 63h NNh : SELECT SD VIDEO ASPECT RATIO NN = Aspect Ratio, 2 = 4:3, 3 = 16:9, 0, 1 = Reserved...
  • Page 33 12h 11h : DEVICE TYTPE The “00h 11h : DEVICE TYPE REQUEST” command is used for asking the specifications of the HDR-45/55 used as DEVICE. When the DEVICE receives this command, it attaches 2-bytes specification data to “12h 11h : DEVICE TYPE” and sends the information to the CONTROLLER.
  • Page 34 8. Status return data 7xh 20h : Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Hardware Data 0 Busy Disk Out Local Error Data 1 Standby On Stop Eject Rewind Fast Forward Record Play Still...
  • Page 35 This bit will set to 1 when the device goes into the REC mode. BIT-2 FAST FORWARD This bit will be set to 1 when the device goes into the FAST FORWARD mode. BIT-3 REWIND This bit will be set to 1 when the device goes into the FAST REWIND mode. BIT-4 EJECT This bit will be set to 1 when the device EJECTs hard disk.

  • Page 36: Revision History

    Data-11 BIT-0 ~ 3 HUNDREDS OF TRACK NUMBER Hundreds of Track number in BCD BIT-4 ~ 7 0 Data-14 BIT-1 ENCODE SDI This bit will be set to 1 if the device is encoding SDI source. BIT-2 DECODE MPEG-2 This bit will be set to 1 if the device is decoding MPEG-2. BIT-4 ANALOGUE AUDIO This bit will be set to 1 if the audio input source is analogue.

  • Page 37: Dimension

    Dimension...

  • Page 38: Specifications

    Specifications • 1x BNC connector for HD/SD-SDI input Inputs Interface • 2x XLR connector for audio input • 1x BNC connector for HD/SD-SDI pass through output • 1x BNC connector for SDI output Outputs Interface • 1x HDMI connector for HDMI output (1.1) •...

  • Page 39: Service & Support

    It is our goal to make your products ownership a satisfying experience. Our supporting staff is available to assist you in setting up and operating your system. Please refer to our web site www.datavideo-tek.com for answers to common questions, support requests or contact your local office below.
