PPDW12
Pressurized
Dome Camera
Housing
PRODUCT FEATURES
• Pressurized camera housing for
Panasonic unitized dome cameras
• Constructed of aluminum, UV stable
ABS plastic, stainless steel and acrylic
• Pressurized to 5 psi
• Schraeder valve
• Relief valve
• Pressurized indicator
7
• Multi-pin sealed connector
• 50W heater turns on at 40°F and off at
60°F
• Power and video surge protector
• Wall mount included
• Weighs 18.5 lbs. (without camera)
• 14.9"H x 18.09"W x 18.25"D
The PPDW12 pressurized dome housing
is sealed and charged with dry nitrogen.
The nitrogen charge provides maximum
protection from moisture, dust and
insects, elements that normally would
cause costly deterioration of video
components in other housings.
110
PRODUCT FEATURES
®
Camera Housings & Mounting Hardware
Advertisement
Related Manuals for Panasonic PPDW12
Summary of Contents for Panasonic PPDW12
- Page 1 • Power and video surge protector • Wall mount included • Weighs 18.5 lbs. (without camera) • 14.9"H x 18.09"W x 18.25"D The PPDW12 pressurized dome housing is sealed and charged with dry nitrogen. The nitrogen charge provides maximum protection from moisture, dust and...
-
Page 2: Technical Specifications
68W including Unitized Camera. The blower shall draw 1.4W continuous power. The 50W heater shall turn on at 40°F and turn off at 60°F. A ground isolation transformer, Panasonic model PWBT1621, shall be available as an option . The housing shall support a temperature range of 20° to 120°F. The unit shall have a weight not to exceed 18.5 lbs. - Page 3 CAMERA/HOUSING CAMERAS COMPATIBILITY CHART BLACK & WHITE COLOR Legend Compatible Compatible with listed Panasonic camera with Panasonic fixed and varifocal lens • Compatible with listed Panasonic camera with Panasonic fixed or zoom lens Contact Panasonic Sales Engineering for compatibility (tel. 201-392-6614)
