Infinity Model Twelve Service Manual page 18

M o d e l T w e l v e
Part Number Description
MISCELLANEOUS/MECHANICAL
236-AL-05001-0LAE Aluminium bar band (RoHS)
302-AL-05066-0BAE
Aluminium Panel 300*200*2.5mm ,White and Black
306-ABS-00177 Plastic rear cover , 198*298*102mm
311-ABS-00028-0BAE Plastic knob, 46077-W P.V.C.
323-AL-05000-0LAE Heatsink (RoHS)
325-FE-00400-0LAE PCB bracket , 58*9*13.5T (RoHS)
333-EVA-00220-0BAE EVA Gasket ,225*15*1t UL
333-EVA-00783-0BAE EVA W 198*12*2.0T
333-EVA-00807-0BAE EVA L 274*12*2.0T (RoHS)
333-EVA-00826-0BAE EVA W 198*12*1.0T (RoHS)
333-EVA-00835-0BAE EVA L 274*12*1.0T (RoHS)
333-EVA-00866 Flame prevention EVA 48*18*1.5T
335-NYL-00002-0BAE Power cord, 4K-4 NO-BB(RoHS)
336-RUB-05103-0BAE RUB gasket, 97*16*3.0T ,Black
350-EM04012D024-E 4￠*12,wooden screw, crossed round head,electronic black,
351-AM03008A078-E M3*8 mechanical screw ,crossed
351-AM03008A079-E M3*8 mechanical screw ,crossed,electronic black
351-AM03018A364-E M3*8 mechanical screw ,crossed,electronic black
351-HM03006A308-E M3*6mm mechanical screw ,crossed,electronic black
351-HM04010A217-E M4＊10 mechanical screw ,crossed,electronic black
352-AM03008D040-E ￠3*8 B Screw ,crossed
352-AM03008D041-E ￠3*8 B Screw ,crossed
352-AM03010D065-E ￠3*10 P screw,crossed
355-P07049-E flat washer 7.2*12*0.5t
361-FE-00002-0LAE Holder of transformer 90*70*15mm (RoHS)
361-FE-05016-0LAE SECC bracket 36*12.5*8.5 (RoHS)
362-FE-00013-0LAE PCB bracket L TYPE t=1.6mm
128-c117ja01-e capacitor,110uF±5% DF3% 100V ψ22*37
Q'ty
1
1
1
5
1
1
1
2
2
2
2
2
2
2
4
4
7
2
1
4
2
2
1
2
1
1
S.P.C.C 89*9*1.6T (RoHS)
1
1
17
Reference Designator
at Woofer Terminal
Cascade
