Infinity Model Twelve Service Manual page 16

M o d e l T w e l v e
Part Number Description
RABOS PCB
110-16106j26-e
CARBON RESISTOR 10M 1/6W ±5% CF 26mm TAP (RoHS)
116-161000f26-e METAL FILM RESISTOR 100Ω 1/6W ±1% MF 26mm TAP (RoHS)
116-161001f26-e METAL FILM RESISTOR 1K 1/6W ±1% MF26mm TAP (RoHS)
116-161002f26-e METAL FILM RESISTOR 10K 1/6W ±1% MF 26mm TAP (RoHS)
116-161103f26-e
METAL FILM RESISTOR 110K ±1% MF 1/6W 26mm TAP (RoHS)
116-161502f26-e
METAL FILM RESISTOR 15.0K 1/6W ±1% MF 26mm TAP (RoHS)
116-161652f26-e METAL FILM RESISTOR 16.5K 1/6W ±1% MF 26mm TAP (RoHS)
116-162051f26-e METAL FILM RESISTOR 2.05K 1/6W MF 26mm TAP (RoHS)
116-162211f26-e METAL FILM RESISTOR 2.21K 1/6W ±1% MF 26mm TAP (RoHS)
116-162671f26-e
METAL FILM RESISTOR 2.67K 1/6W ±1% MF 26mm TAP (RoHS)
116-163161f26-e METAL FILM RESISTOR3.16K 1/6W MF 26mm TAP ±1% (RoHS)
116-163400f26-e METAL FILM RESISTOR 340Ω 1/6W ±1% MF 26mm TAP (RoHS)
116-163571f26-e METAL FILM RESISTOR 3.57K 1/6W 1% MF 26mm TAP (RoHS)
116-165400f26-e METAL FILM RESISTOR540Ω 1/6W MF 26mm TAP (RoHS)
116-166041f26-e
METAL FILM RESISTOR 6.04K 1/6W ±1% MF TAP 26mm (RoHS)
116-166341f26-e METAL FILM RESISTOR 6.34K 1/6W±1%MF (RoHS)
116-166800f26-e METAL FILM RESISTOR 680Ω 1/6W ±1% MF 26mm TAP (RoHS)
116-168250f26-e METAL FILM RESISTOR 825Ω 1/6W ±1% MF 26mm TAP (RoHS)
116-169092f26-e METAL FILM RESISTOR90.9K 1/6W MF 26mm TAP (RoHS)
116-169311f26-e
METAL FILM RESISTOR 9.31K 1/6W ±1% MF 26mm TAP (RoHS)
115-h103c201-e
VAR RESISTOR RV16A01-20-15K-C10K-3E (RoHS) FREQ
115-h103a203-e
VAR RESISTOR RV16A01-20-15K-A10K-3E (RoHS) LEVL,WIDTH
Capacitors
129-a104j633-e METALIZE CAP 0.1U 63V ±5% MSC TAP (RoHS)
129-a683j633-e METALIZE CAP 0.068uF 63V ±5% MSC TAP (RoHS)
130-3f104z503-e DISC CAPACITOR 0.1U 50V +80/-20% TAP (RoHS)
Semiconductors
190-16tl072n-e
I.C. TL072N @6.5 (RoHS) DUAL OP-AMP
190-16tl074cn-e
I.C TL074CN ST (RoHS) QUAD OP-AMP
CLASS D PCB ASS'Y (RECOMMENDED REPLACE ENTIRE MODULE PART# 051-A05022C-E)
Resistors
112-10180j00-e FUSE RESISTOR FMF 1W 18Ω 5%(RoHS)
118-12061001f-e
SMD RESISTOR 1K 1206 1%(RoHS)
118-12061002f-e SMD RESISTOR 10K 1206 1%(RoHS)
118-12061002j-e SMD RESISTOR 10.0K 1206 5%(RoHS)
118-120610r0j-e SMD RESISTOR 10.0Ω 1206 5%(RoHS)
118-12062002f-e SMD RESISTOR 20K 1206 1%(RoHS)
118-12062201j-e SMD RESISTOR 2.20K 1206 5%(RoHS)
118-12062204j-e SMD RESISTOR 2.20M 1206 5% (RoHS)
118-12062211f-e SMD RESISTOR 2.21K 1206 1% (RoHS)
118-12062550f-e
SMD RESISTOR 1206 255Ω 1%(RoHS)
118-12062701j-e SMD RESISTOR 2.70K 1206 5%(RoHS)
118-12063301j-e SMD RESISTOR 3.30K 1206 5%(RoHS)
118-12063321f-e SMD RESISTOR 3.32K 1206 1%(RoHS)
118-12063922f-e
SMD RESISTOR 1206 39.2K±1%(RoHS)
Q'ty
1 R186
1 R154
1 R180,R187,R252
8 R171,R159,R160,R166,R192,R173,R178
1 R174
2 R162,R168
1 R188
1 R253
1 R172
1 R155
1 R251
2 R164,R169
1 R157
1 R175
2 R165,R170
1 R189
1 R176
2 R161,R167
1 R190
1 R179
1 R163
2 R158,R177
3 C138,C139,C137
C142,C143
2
4 C144,C145,C146,C147
U105
1
1 U104
1
1 R2
1 R25
5 R29,R30,R30B,R7,R9
4 R20,R20B,R22,R23
1 R26
R13,R16,R31,R33,R34,R35,R36,R37,R38,R39,R40,
18
R41,R42,R43,R44,R45,R46,R32
1 R4
1 R6
1 R24
1 R10
4 R14,R15,R27,R28
1 R1
1 R3
15
Cascade
Reference Designator
