TopPage
This model is based on the LC-32D42U and is changed some parts. This Service Manual covers the modifications
alone. For the other points, refer to the LC-32/37D42U Service Manual.
LIST OF CHANGED PARTS .................. . ............i
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOR TELEVISION

MODEL
In the interests of user-safety (Required by safety regulations in some countries) the set should
be restored to its original condition and only parts identical to those specified should be used.
OUTLINE
CONTENTS
LC-C3242U
No. S17B8LCC3242U
LC-C3242U
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

Advertisement

Table of Contents
loading

Related Manuals for Sharp LC-C3242U

Summary of Contents for Sharp LC-C3242U

  • Page 1: Table Of Contents

    TopPage LC-C3242U SERVICE MANUAL No. S17B8LCC3242U LCD COLOR TELEVISION LC-C3242U MODEL In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.

  • Page 2: Differences From Base Model

    LC-C3242U LC-C3242U DIFFERENCES FROM BASE MODEL Service Manual LIST OF CHANGED PARTS Ref. No. Description LC-32D42U LC-C3242U Note PWB ASSEMBLIES ← MAIN Unit DUNTKD862FM04 — ← R/C, LED Unit DUNTKD909FM02 — ← KEY Unit DUNTKD910FM02 — ← AV TERMINAL Unit DUNTKD999FM04 —...

  • Page 3: Safety Precaution Important Service Safety Pre- Caution

    LC-C3242U LC-C3242U SAFETY PRECAUTION Service Manual IMPORTANT SERVICE SAFETY PRECAUTION Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING • Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 4: Precautions A Prendre Lors De La Reparation

    LC-C3242U PRECAUTIONS A PRENDRE LORS DE LA REPARATION Ne peut effectuer la réparation qu' un technicien spécialisé qui s'est parfaitement accoutumé à toute vérification de sécurité et aux conseils suivants. AVERTISSEMENT • A l'aide de deux fils à pinces, brancher une résistance de 1.5 kΩ...

  • Page 5: Precautions For Using Lead-Free Solder

    LC-C3242U PRECAUTIONS FOR USING LEAD-FREE SOLDER Employing lead-free solder • “PWBs” of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.

  • Page 6: Precautions In Servicing The Hdcp-Key Rom

    LC-C3242U PRECAUTIONS IN SERVICING THE HDCP-KEY ROM Applied part: HDCP-KEY ROM IC8451 RH-IXB979WJQZY (updated ROM) The HDCP-KEY ROM shall be protected and managed for its information inside. In servicing this ROM, therefore, take the following information pro- tection/management measures. 1) When disposing of the component parts and PWBs, destruct the IC itself in a proper way.

  • Page 7: Parts Guide

    LC-C3242U PartsGuide PARTS GUIDE No. S17B8LCC3242U Note: The reference numbers on the PWB LC-C3242U are arranged in alphabetical order. MODEL CONTENTS LCD PANEL (NOTE: THE PARTS PACKING PARTS (NOT HERE SHOWN ARE SUPPLIED AS REPLACEMENT ITEM) AN ASSEMBLY BUT NOT INDEPENDENTLY.)
  • Page 8 LC-C3242U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [1] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN- DENTLY.) 32" WIDE LCD Panel Module Unit R1LK315T3LZ50Z...
  • Page 9 LC-C3242U [2] CABINET AND MECHANICAL PARTS KEY Unit 43-2 43-1 1-11 1-11 1-11 1-10 R/C, LED Unit 1-12 1-13 POWER Unit MAIN Unit AV TERMINAL Unit...
  • Page 10 LC-C3242U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] CABINET AND MECHANICAL PARTS Front Cabinet Ass'y CCABAB612WJ04 Front Cabinet Not Available LED Cover Not Available Front Cover Not Available Badge, SHARP Not Available SP-Net HPNLSA100WJSB Spacer, x2 Not Available...
  • Page 11 LC-C3242U [3] SUPPLIED ACCESSORIES Cable Band Cable Clamp AC Cord Remote Control Unit Operation Manual "AAA" Size Battery Stand Unit X9-1 PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [3] SUPPLIED ACCESSORIES Cable Band LHLDWA083WJ00 Cable Clamp LHLDWA131WJKZ AC Cord...
  • Page 12 LC-C3242U [4] PACKING PARTS (NOT REPLACEMENT ITEM)
  • Page 13 LC-C3242U PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [4] PACKING PARTS (NOT REPLACEMENT ITEM) Packing Case SPAKCD468WJZZ Stand Case SPAKFB119WJZZ Stand Pad SPAKFB120WJZZ Wrapping Paper (Monitor) SPAKPA794WJZZ Mirror Mat Base SPAKPA796WJZZ Mirror Mat Sup SPAKPA798WJZZ Packing Add. SPAKXB306WJZZ Polyethylene Bag...
  • Page 14 LC-C3242U COPYRIGHT 2007 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
