Toshiba 27D46 Service Manual

Hide thumbs Also See for 27D46:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual

SERVICE MANUAL

COLOR TELEVISION
The above model is classified as a green product (*1), as indicated by the underlined serial number.
This Service Manual describes replacement parts for the green product. When repairing this green
product, use the part(s) described in this manual and lead-free solder (*2).
For (*1) and (*2), see the next page.
FILE NO. 050-200606GR
(MFR'S VERSION A)
27D46
DOCUMENT CREATED IN JAPAN, March, 2006 GREEN
