Dear Customer, Thank you for purchasing this Toshiba TV. This manual will help you use the many exciting features of your new TV. Before operating the TV, please read this manual completely, and keep it nearby for future reference. Safety Precautions...
Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings.
Page 4
Care For better performance and safer operation of your TOSHIBA TV, follow these recommendations and precautions: 27) Always sit approximately 10–25 feet away from the TV and as directly in front of it as possible. The picture can appear dull if you sit too far to the left or right of the TV, or if sunlight or room lights reflect on the screen.
Important Safeguards ... 2-4 Welcome to Toshiba ... 6 Exploring your new TV ... 6 Selecting a location for the TV ... 6 Connecting your TV ... 7 Connecting a VCR ... 7 Connecting a cable converter box or Antenna ... 8 Connecting a DVD player/satellite receiver and a VCR ...
Congratulations! You have purchased one of the finest color TVs on the market. The goal of this manual is to guide you through setting up and operating your Toshiba TV as quickly as possible. You may need to purchase other audio or video cables to connect your equipment.
Connecting your TV • A coaxial cable is the standard cable that comes in from your antenna or cable converter box. Coaxial cables use “F” connectors. • Standard A/V (audio/video) cables are usually color coded accord- ing to use: yellow for video and red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel.
Connecting a cable converter box or Antenna This television has an extended tuning range and can tune most cable channels without using a cable company supplied converter box. Some cable companies offer “premium pay channels” in which the signal is scrambled.
Connecting a DVD player/satellite receiver and a VCR This connection allows you to watch DVD/satellite, VCR, or TV programs. You can record from the satellite receiver and TV, as well as record one TV channel while watching another channel. From satellite DVD player / Satellite Receiver Satellite IN OUT to TV...
Your TV is capable of using ColorStream (component video.) Connecting your TV to a component video compat- ible DVD player, such as a Toshiba DVD player with ColorStream greatly enhance picture quality and performance. DVD player with Component video...
Connecting a DTV receiver / set-top box with ® ColorStream (component video) and a VCR This connection allows you to watch DTV (digital TV), VCR, and TV programs, and record DTV and TV programs. ® Your TV has ColorStream (component video) inputs. Connecting your TV to a DTV receiver with component video can greatly enhance picture quality and realism.
Connecting a camcorder This connection allows you to watch videos recorded on a camcorder. S-VIDEO Front Panel of TV S-VIDEO Back panel of TV J3W41121A(E)_P07-13 VHS Camcorder AUDIO VIDEO S-VHS Camcorder AUDIO VIDEO You will need: • one S-video cable or standard video cable •...
Connecting an audio system Back panel of TV Connecting an AV amplifier with built-in digital surround This connection allows you to use an audio amplifier with built-in digital surround and external speakers. Digital Audio Coaxial AV Amplifier with built-in digital surround The COAXIAL DIGITAL AUDIO OUT jack outputs digital audio only during digital broadcasts with digital audio.
VCRs, and DVD players, regardless of their brand. The remote control is pre-programmed to operate most Toshiba satellite receivers, VCRs, and DVD players. To control a non-Toshiba device (or a Toshiba device that the remote control is not pre-programmed to operate), you must first program the remote control.
This remote control is pre-programmed to operate most Toshiba satellite receivers, VCRs, and DVD players. To control a non-Toshiba device (or a Toshiba device that the remote control is not pre-programmed to operate), you must follow the steps below to program your remote control.
Learning about the remote control TV/VIDEO selects the video input source (page 25) RECALL displays status information on-screen (page 23) CHANNEL NUMBERS allow direct access to channels (page 20) CH 3 3 3 3 3 / 4 4 4 4 4 cycles through programmed channels (page 20) selects TV mode CBL/SAT...
Setting up your TV After you have installed the batteries and programmed the remote control, you need to set some preferences on the TV using the menu system. You can access the menu system with the buttons on the remote control. •...
Adding channels to the TV’s memory When you press Channel L / M on the TV or CH 3 / 4 on the remote control, your TV will stop only on the channels you have programmed into the TV's channel memory. Follow the steps below to program channels into the channel memory.
Using the TV’s features Adjusting the channel settings Switching between two channels You can switch between two channels without entering an actual channel number each time. To switch between two channels: 1. Select the first channel you want to view. 2.
Using the LOCKS menu Note: The V-Chip feature is available for the U.S. V-Chip system only. The Canadian V-Chip system is not supported. You can prevent others from viewing certain programs or channels by blocking them using the V-Chip feature. Selecting a password Before you can use the V-Chip feature to block programs and channels, you must select a password.
Using the V-Chip (parental control) feature The Motion Picture Association of America (MPAA) uses a rating system to qualify motion picture content. Television broadcasters also employ a rating system to qualify the content of television programs. The TV and MOVIE ratings work with the V-Chip feature and allow you to block programs according to the rating limits you set.
Locking channels With the CH LOCK feature, you can lock specific channels. You will not be able to tune locked channels unless you clear the setting. You can choose to lock up to 12 TV channels and 12 cable channels. To lock channels: 1.
Locking the video inputs With the VIDEO LOCK feature, you can lock out the input sources (VIDEO1, VIDEO2, ColorStream and channels 3 and 4.) You will not be able to select the input sources with the TV/VIDEO button or Channel Number buttons unless you unlock the video inputs. To set up the video lock: 1.
Selecting the video input source Press TV/VIDEO to view a signal from another device connected to your TV, such as a VCR or DVD player. You can select ANT, VIDEO 1, VIDEO 2, or ColorStream, depending on which input jacks you used to connect your devices (see “Connecting your TV”...
Viewing the wide-screen picture formats You can view 480i format programs in a variety of picture sizes—4:3, 16:9, ZOOM. The way the image displays in any of the picture sizes will vary depending on the format of the program you are viewing. Select the picture size that displays the current program the way that looks best to you.
Page 29
16:9 picture size • If receiving a 4:3 format digital program, the 16:9 PIC SIZE is not available. • If receiving a 4:3 format analog program, selecting 16:9 PIC SIZE will typically display the image stretched wider with bars at the top and bottom.
Adjusting the picture Adjusting the picture quality You can adjust the picture quality to your personal preferences, including the brightness, contrast, color, tint, and sharpness. The qualities you choose will be stored automatically in the PICTURE menu’s MEMORY mode so you can recall them at any time. To adjust the picture quality: 1.
Using the closed caption feature The Closed Caption feature has two options: • Captions—An on-screen display of the dialogue, narration, and sound effects of programs and videos that are closed-captioned (usually identified in your local TV listings as “CC”). • Text—An on-screen display of information not related to the program, such as weather or stock data (if available in your viewing area).
Adjusting the sound Muting the sound Press MUTE to temporarily turn off the sound. While the sound is off, the screen will display the word MUTE in the lower right-hand corner. To restore the sound, either press MUTE again or press VOL+/–. Selecting stereo/SAP broadcasts The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound.
Selecting the audio languages When two or more audio languages are included in a digital signal, you can select one of the audio languages. To select the audio language: 1. Press MENU, then press 2. Press L or M to highlight AUDIO LANGUAGE, then press A U D I O M T S S T E R E O...
Using the surround sound feature The surround sound feature expands the audio listening field wider and deeper to create exceptional sound quality from the TV’s speakers. The feature uses stereo signals from a TV broadcast or video input. To turn on the surround sound feature: 1.
Auto power off The TV will automatically turn off after approximately 15 minutes if it is tuned to a vacant channel or a station that completes its broadcast for the day and stops broadcasting on that channel. This feature does not work in VIDEO mode. Understanding the Power Return feature If the power is cut off while you are viewing the TV and the power is resupplied, the Power Return feature will turn the TV on automatically.
Limited United States Warranty for Non-FST PURE Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TELEVISION AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE.
Page 38
National Service Division ColorStream, TheaterView, and StableSound are registered trademarks of Toshiba America Consumer Products, L.L.C. GameTimer is a trademark of Toshiba America Consumer Products, L.L.C. PRINTED IN THAILAND J3W41121A(E)_P31-Back 14/03/2006, 3:41 PM...
Page 39
27D46 32D46 J3W41121A SH 06/04 2006 Todos los derechos reservados J3W41121A(S)_COVER 14/03/2006, 3:41 PM...
Estimado cliente: Le agradecemos que haya comprado este televisor TOSHIBA. Este manual le ayudará a utilizar las numerosas e interesantes funciones de su nuevo televisor. Antes de hacer funcionar el televisor, lea este manual en su totalidad y consérvelo en un lugar conveniente para consultarlo en el futuro.
Page 41
Instrucciones de seguridad importantes 1) Lea estas instrucciones. 2) Conserve estas instrucciones. 3) Preste atención a todas las advertencias. 4) Siga todas las instrucciones. 5) No use este aparato cerca del agua. 6) Límpielo únicamente con un paño seco. 7) No bloquee las rejillas de ventilación. Instale el aparato de acuerdo con las instrucciones del fabricante.
Page 42
Abrir o quitar las tapas puede exponerlo a voltajes peligrosos u otros riesgos. Encargue las reparaciones a un centro de servicio autorizado de TOSHIBA. 35) Si le reparan el televisor: • Pídale al técnico que utilice únicamente repuestos especificados por el fabricante.
Page 43
Información importante sobre seguridad ... Bienvenido a Toshiba ... Explorando su nueva TV ... 6 Seleccionando un lugar para la TV ... 6 Conectando su TV ... Conectando una videograbadora ... 7 Conectando una caja convertidora para cable TV ... 8 Conectando un reproductor de DVD/receptor satelital y una videograbadora ...
Bienvenido a Toshiba ¡Felicitaciones! Usted ha comprado uno de los televisores a color más finos del mercado. La meta de este manual es guiarlo completamente para preparar y a operar su televisor tan rápidamente como sea posible. Usted tal vez necesite comprar otros cables de audio o video para conectar su equipo.
Conectando su TV • Un cable coaxial es un cable normal que entra de su antena o de la caja convertidora de cable TV. Los cables coaxiales usan conectores “F”. • Los cables normales de A/V (audio/video) usualmente están codificados con colores según su uso: amarillo para video, rojo y blanco para audio.
Conectando una caja convertidora para cable TV Este televisor puede sintonizar la mayoría de los canales por cable sin necesidad de recurrir al convertidor suministrado por los canales de cable. Algunas compañías de cable ofrecen “canales pagados exclusivos” en los cuales la señal esta codificada.
Conectando un reproductor de DVD/receptor satelital y una videograbadora Esta conexión le permite ver DVD o canales satelitales, videocintas o programas de televisión. Podrá grabar del receptor satelital y la televisión, así como grabar un canal de televisión mientras esté viendo otro canal.
ColorStream (un componente de video). Al conectar su televisor a un reproductor de DVD compatible con el video de componentes, tal como un reproductor de DVD Toshiba con ColorStream la calidad de la imagen y el desempeño. Reproductor de DVD con composante de video...
Conectando un receptor de DTV o caja de conexión con un video de componente ColorStream ® y una videograbadora Esta conexión le permite mirar DTV (Televisor Digital), la videograbadora, los programas de televisión y grabar los programas de DTV y TV. Su televisor tiene entradas para video de componente ®...
Conectando una videocámara Esta conexión le permite ver los materiales de videos grabados en una videocámara. S-VIDEO Panel delantero de la TV S-VIDEO Panel trasero de la TV J3W41121A(S)_P07-13 Videocámara VHS VIDEO AUDIO Videocámara S-VHS AUDIO VIDEO Usted necesitará lo siguiente: •...
Conectando un sistema de audio Panel trasero de la TV Conectando un amplificador AV con sonido surround digital incorporado Esta conexión le permite usar un amplificador de audio con sonido surround digital incorporado y altavoces externos. Digital Audio Coaxial Amplificador AV con sonido surround digital incorporado Las salidas de audio coaxial digital (COAXIAL DIGITAL AUDIO OUT) sólo para las emisiones digitales con sonido de difusión digital.
El mando a distancia es preprogramado para manejar la mayoría de los receptores de satélite, grabadores de vídeo, y lectores de DVD de Toshiba. Para controlar un dispositivo de no Toshiba (o un dispositivo de Toshiba cuyo mando a distancia no haya sido preprogramado para manejar), usted debe programar primero el mando a distancia.
DVD, o convertidores de cable TV diferentes a los modelos de Toshiba, usted deberá seguir los pasos de abajo para programar su control remoto. 1. Refiérase a las tablas de códigos (en las páginas 16 y 17) para encontrar el código correspondiente para su marca.
Aprendiendo sobre el control remoto TV/VIDEO selecciona la fuente de entrada del video (página 25) RECALL despliega la información del estado en la pantalla (página 23) CHANNEL NUMBERS permite el acceso directo a los canales (página 20) hace los ciclos a través de los canales programados 3 3 3 3 3 4 4 4 4 4 (página 20)
Configurando su televisor Después que haya instalado las baterías y haya programado el control remoto, necesitará establecer algunas preferencias en el televisor que usa el sistema de menú. Podrá acceder al sistema de menú con los botones en el control remoto.
Agregando canales a la memoria del televisor Cuando presione Channel L / M en la TV o CH 3 / 4 en el control remoto, su televisor sólo se detendrá en los canales que usted haya guardado en la memoria del canal de canales del televisor. Siga los pasos de abajo para programar los canales en la memoria.
Usando las funciones del televisor Ajustando la configuración de los canales Cambiando entre dos canales Podrá cambiar entre dos canales sin ingresar un número de canal actual cada vez. Para cambiar entre dos canales: 1. Seleccione el primer canal que desee ver. 2.
Usando el menú de BLOQUEAR Nota: La función Chip V sólo está disponible para el sistema Chip V para los EE.UU. EI sistema V-Chip canadiense no es respaldado. Podrá prevenir a otros que vean ciertos programas o canales bloqueándolos al usar la función de Chip V. Seleccionando una Contraseña Antes de que pueda usar la función de Chip V para bloquear los programas y canales, deberá...
La función del V-Chip (control paterno) La Asociación de Películas de América (MPAA - Motion Picture Association of America) usa un sistema de clasificación para calificar el contenido de la película. Las estaciones de televisión también emplean un sistema de clasificación para calificar el contenido de los programas televisivos.
Bloqueando los canales Con la función CH LOCK, puede bloquear el acceso a ciertos canales. No podrá sintonizar los canales bloqueados a no ser que borre el ajuste. Puede bloquear hasta 12 canales de TV y 12 canales de TV por cable. Para bloquear los canales: 1.
Bloqueando la entrada de video Con la función de VIDEO LOCK, podrá bloquear las fuentes de entrada (VIDEO1, VIDEO2, ColorStream y los canales 3 y 4). No podrá seleccionar las fuentes de entrada con el botón de TV/ VIDEO o los botones de Channel a menos que limpie la configuración. Para configurar el bloqueo de video haga lo siguiente: 1.
O P T I O N M E N U : A D J U S T E N T E R : S E T E X I T: E N D — Panel frontal del televisor (27D46) Botones que se pueden bloquear Panel frontal del televisor (27D46) Recall Números de...
Seleccionando la fuente de entrada de video Presione TV/VIDEO para ver una señal de otro dispositivo conectado a su televisor, como una videograbadora o reproductor de DVD. Podrá seleccionar ANT, VIDEO 1, VIDEO 2 o ColorStream dependiendo qué conectores de entrada usó para conectar sus dispositivos (vea “Conectando su TV”...
Viendo los formatos de imágenes de pantalla amplia Podrá ver programas en formato de 480i en una variedad de tamaños—4:3, 16:9, y ZOOM. La manera en que se despliegue la imagen en cualquiera de los tamaños de la imagen variará, dependiendo del formato del programa que esté...
Page 67
Tamaño 16:9 de la imagen • Si recibe un programa de formato 4:3 (digital), la función 16:9 PIC SIZE no estará disponible. • Si recibe un programa de formato 4:3 (análogo), seleccionando 16:9 PIC SIZE, la imagen se verá estirada a lo ancho con barras en las partes superior e inferior.
Ajustando la imagen Ajustando la calidad de la imagen Podrá ajustar la calidad de la imagen a sus preferencias personales, incluyendo el CONTRAST (contraste), BRIGHTNESS (brillo), COLOR (color), TINT (tinte) y SHARPNESS (nitidez). Las calidades que escoja se guardarán automáticamente en la memoria de su televisor para que pueda hacerlos volver en cualquier momento.
Usando la función de subtítulos La función Closed Caption tiene dos opciones: • Desplegar subtítulos en la pantalla de diálogo, narración y efectos de sonido de los programas y videos que tengan subtítulos (normalmente identificados en su lista de televisión local como “CC”): •...
Ajustando el sonido Enmudeciendo el sonido Presione MUTE para apagar el sonido temporalmente. Mientras que el sonido esté apagado, la pantalla desplegará la palabra MUTE en la esquina inferior derecha. Para restaurar el sonido, presione MUTE o presione VOL+/–. Seleccionando las estaciones en estéreo/SAP El sonido multicanal de televisión (MTS - Multi-channel TV) proporciona sonido estereofónico de alta fidelidad.
Selección del idioma del audio Si una señal digital incluye dos o más idiomas de audio, puede seleccionar cuál desea escuchar. Para selección del idioma del audio: 1. Presione MENU, luego presione 2. Presione L o M para resaltar AUDIO LANGUAGE, luego presione A U D I O M T S...
Usando la función de sonido Surround La función de sonido surround expande el campo de escucha de audio de forma más amplia y profunda para crear la calidad excepcional de sonido de las bocinas de la televisión. La función usa señales estereofónicas de una transmisión de televisión o una entrada de video.
Apagado automático El televisor se apagará automáticamente después de aproximadamente 15 minutos si se sintoniza en un canal libre o una estación que termine su transmisión por el día y deje de transmitir en ese canal. Esta función no trabaja en el modo de VIDEO. Entendiendo la función de Retorno de Energía Si la energía se interrumpe mientras esté...
Tipo de los altavoces Teminales de Video/Audio Dimensiones Peso Accesorios incluidos J3W41121A(S)_P31-Back 27D46 27 pulgadas (676,0 mm) diagonalmente (El tamaño de pantalla es aproximado.) NTSC standard, ATSC standard (8VSB), QAM VHF: 2 a 13 UHF: 14 a 69 Cable TV: 4A, A-5 a A-1, A-I, J–W, W + 1 a W + 84...
Lea el manual del propietario en su totalidad antes de usar este televisor. Llene y devuelva por correo la tarjeta de registro del producto adjunta al presente, o registre su televisor lo más pronto posible en línea en www.tacp.toshiba.com/service. Al registrar su televisor, TACP podrá ofrecerle nuevos productos específicamente diseñados para satisfacer sus necesidades, y permitirá...
Page 76
National Service Division ColorStream ® , TheaterView y StableSound ® son marcas registradas de Toshiba America Consumer Products, L.L.C. GameTimer es una marca comercial de Toshiba America Consumer Products, L.L.C. IMPRESO EN TAILANDIA J3W41121A(S)_P31-Back 14/03/2006, 3:58 PM...
