This is a supplemental Service Manual for Models R-314FS and R-316FS. These model are quite
similar to base model R-301FW. Use this supplemental manual together with the Base Model
Service Manual (Refer No. is S2204R301FPW/) for complete operation, service information, etc..
BEFORE SERVICING ...................................................................................................... INSIDE FRONT COVER
WARNING TO SERVICE PERSONNEL ................................................................................................................ 1
MICROWAVE MEASUREMENT PROCEDURE ................................................................................................... 2
FOREWORD AND WARNING ............................................................................................................................... 3
PRODUCT SPECIFICATION ................................................................................................................................. 4
OVEN DIAGRAM ................................................................................................................................................... 5
OVEN SCHEMATIC ............................................................................................................................................... 6
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE ................................................................. 6
PICTORIAL DIAGRAM ......................................................................................................................................... 8
PARTS LIST .......................................................................................................................................................... 9
PACKING AND ACCESSORIES ......................................................................................................................... 13
