Service Manual
Color Television
CHASSIS : CN-001M
Model
DTQ-14P2/P3FCM
DTQ-14P2/V1FCWM/P2SCM
DTQ-14V1/V5FCM/V1/V4SCM
DTQ-14V5FCNM/15U5SCM
DTQ-14V6FCBM/FCPM/FBBM/FPPM
DTQ-14J4FCGM/FCCM
DTQ-20V1/V4/V5FCM
DTQ-20V1/V4SCM
DTQ-20P2/P3FCM/P2SCM
DTQ-14V6NBM/NPM
DTQ-14V1/V3/V5FSM
DTQ-14V1/V3/V4/V5/V8/V9SSM
DTQ-14U1FSM/SSM/20U1FSM/SSM
DTQ-20P2SSM/15U5FSM
DTQ-20V1/V3/V4FSM
DTQ-20V1/V3/V4/V8/V9SSM
DTQ-14V1/V4/V5FSPM
DTQ-14V1/V4/V5/U1SSPM
DTQ-14V6NBPM/NPPM
DTQ-20V1/V4FSPM
DTQ-20V1/V3/V4/U1SSPM
DTQ-15U5SSPM
DTQ-14V1/V4SSFM
DTQ-20V1/V4SSFM
DTQ-14V4/20V4FCFM
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD
http : //svc.dwe.co.kr
S/M No.:TCN001MEF0
U.S.A
CANADA
(AC120V)
Middle America
(AC 110V)
Chile, Peru, Philippines
(AC220V)
Dominica
(AC60~180)
Korea, USA, Japen(AC90~250V)
May. 2002
