- Page 1 NSX-T9 COMPACT DISC STEREO CASSETTE RECEIVER • TYPE SIMPLE MANUAL • Replace this Service Manual with "Revision Publishing" when it is issued. S/M Code No 09–993–407–1T2...
- Page 2 ELECTRICAL MAIN PARTS LIST - 1/8 NOTE: The characters in the suffix column indicate the part usage. HASM ....XX........D....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-040 CAP,E 100-16 ABCD....87-010-186-080 CAP,CHIP 4700P ABCD....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD....87-010-197-080 CAP, CHIP 0.01 DM ABCD....
- Page 3 ELECTRICAL MAIN PARTS LIST - 2/8 87-010-194-080 CAP, CHIP 0.047 ABCD....87-010-182-080 C-CAP,S 2200P-50 B ABCD....87-010-197-080 CAP, CHIP 0.01 DM ABCD....87-010-194-080 CAP, CHIP 0.047 ABCD....87-010-194-080 CAP, CHIP 0.047 ABCD....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD....87-012-158-080 C-CAP,S 390P-50 CH ABCD....
- Page 4 ELECTRICAL MAIN PARTS LIST - 3/8 87-A91-111-010 SW,RTRY EC12E12404-20MM ABCD....87-010-071-040 CAP,E 1-50 M 5L SRE ABCD....87-010-176-080 C-CAP,S 680P-50 SL ABCD....87-010-187-080 CAP CHIP S5600P ABCD....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCD....87-010-213-080 C-CAP,S 0.015-50 B ABCD....87-012-145-080 CAP, CHIP S 270P CH ...D....
- Page 5 ELECTRICAL MAIN PARTS LIST - 4/8 SFR 301 87-024-355-080 SFR,33K DIA6 H ABCD....SFR 304 87-024-355-080 SFR,33K DIA6 H ABCD....SFR 306 87-024-356-080 SFR,47K DIA6 H ABCD....SFR 305 87-024-356-080 SFR,47K DIA6 H ABCD....87-010-188-080 CAP,CHIP 6800P ABCD....87-010-188-080 CAP,CHIP 6800P ABCD....
- Page 6 ELECTRICAL MAIN PARTS LIST - 5/8 87-A40-553-080 DIODE,1N4003 LES ABCD....87-A40-553-080 DIODE,1N4003 LES ABCD....87-A40-553-080 DIODE,1N4003 LES ABCD....87-A40-553-080 DIODE,1N4003 LES ABCD....87-A40-345-080 ZENER,MTZJ10C ABCD....87-070-274-080 DIODE,1N4003 SEM ABCD....87-A40-004-080 ZENER,MTZJ16A ABCD....87-A40-269-080 C-DIODE,MC2836 ABCD....87-A40-270-080 C-DIODE,MC2838 ABCD....87-020-465-080 DIODE,1SS133 (110MA) ABCD....
- Page 7 ELECTRICAL MAIN PARTS LIST - 6/8 87-010-263-080 CAP, ELECT 100-10V ABCD....87-010-263-080 CAP, ELECT 100-10V ABCD....87-010-992-080 C-CAP,S 0.047-25 B ABCD....87-010-992-080 C-CAP,S 0.047-25 B ABCD....87-010-314-080 C-CAP,S 22P-50V ABCD....87-010-322-080 C-CAP,S 100P-50 CH ABCD....87-010-322-080 C-CAP,S 100P-50 CH ABCD....87-010-322-080 C-CAP,S 100P-50 CH ABCD....
- Page 8 ELECTRICAL MAIN PARTS LIST - 7/8 87-010-186-080 CAP,CHIP 4700P ABCD....87-010-186-080 CAP,CHIP 4700P ABCD....87-010-322-080 C-CAP,S 100P-50 CH ABCD....87-010-404-080 CAP, ELECT 4.7-50V ABCD....87-010-404-080 CAP, ELECT 4.7-50V ABCD....87-010-544-080 CAP, ELECT 0.1-50V ABCD....87-010-544-080 CAP, ELECT 0.1-50V ABCD....87-010-260-080 CAP, ELECT 47-25V ABCD....
- Page 9 ELECTRICAL MAIN PARTS LIST - 8/8 87-A00-258-080 RES,M/F 0.22-1W J ABCD....87-A00-258-080 RES,M/F 0.22-1W J ABCD....87-A91-042-080 C-THMS,100K 55001 ABCD....87-A91-042-080 C-THMS,100K 55001 ABCD....
- Page 10 MECHANICAL PARTS LIST - 1/2 NOTE: The characters in the suffix column indicate the part usage. HASM ....XX........D....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-NF3-090-010 RING,FOOT ABCD....8Z-NF3-001-010 CABI,FR H AB.D....8Z-NF3-002-010 CABI,FR U ..C....8Z-NF3-008-010 CABI,STEEL U ....8Z-NF3-009-010 CABI,STEEL ABCD....
- Page 11 MECHANICAL PARTS LIST - 2/2 87-067-975-010 S-SCREW,IT+4-8 ABCD....87-591-095-410 TAPPING SCREW, QIT+3-8 (GLD) ABCD....87-721-096-410 QT2+3-10 GLD ...D....87-721-097-410 QT2+3-12 GLD ABCD....87-NF4-224-010 S-SCREW,IT3B+3-8 CU ABCD....87-085-185-010 BUSHING, AC CORD (E) AB.D....87-085-189-010 BUSHING, CORD (U) ..C....87-A80-105-010 AC CORD ASSY,AZ ...D....
- Page 12 ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. HASM ....XX........D....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-NF3-901-010 IB,U (ESF)M ..C....8Z-NF3-902-010 IB,H (ECA)M A....8Z-NF3-903-010 IB,LH (ESP)M .B.D....8Z-NF3-904-010 IB,EZ (9L)M ....
- Page 13 SCHEMATIC DIAGRAM _ 1 (MAIN 1/3)
- Page 14 SCHEMATIC DIAGRAM _ 2 (MAIN 2/3)
- Page 15 SCHEMATIC DIAGRAM _ 3 (MAIN 3/3)
- Page 16 SCHEMATIC DIAGRAM _ 4 (FRONT)
- Page 17 SCHEMATIC DIAGRAM _ 5 (PRO)
- Page 18 SCHEMATIC DIAGRAM _ 6 (AC)
- Page 19 9620450 Tokyo Japan Printed in Singapore...
