INTRODUCTION
Thank you for purchasing a Honda engine. We want to help you to
get the best results from your new engine and to operate it safely.
This manual contains information on how to do that; please read it
carefully before operating the engine. If a problem should arise, or
if you have any questions about your engine, consult an
authorized Honda servicing dealer.
All information in this publication is based on the latest product
information available at the time of printing. Honda Motor Co., Ltd.
reserves the right to make changes at any time without notice and
without incurring any obligation. No part of this publication may
be reproduced without written permission.
This manual should be considered a permanent part of the engine
and should remain with the engine if resold.
Review the instructions provided with the equipment powered by
this engine for any additional information regarding engine
startup, shutdown, operation, adjustments or any special
maintenance instructions.
United States, Puerto Rico, and U.S. Virgin Islands:
We suggest you read the warranty policy to fully understand its
coverage and your responsibilities of ownership. The warranty
policy is a separate document that should have been given to you
by your dealer.
SAFETY MESSAGES
Your safety and the safety of others are very important. We have
provided important safety messages in this manual and on the
engine. Please read these messages carefully.
A safety message alerts you to potential hazards that could hurt
you or others. Each safety message is preceded by a safety alert
symbol
and one of three words, DANGER, WARNING, or
CAUTION.
These signal words mean:
Each message tells you what the hazard is, what can happen, and
what you can do to avoid or reduce injury.
DAMAGE PREVENTION MESSAGES
You will also see other important messages that are preceded by
the word NOTICE.
This word means:
Your engine or other property can be damaged if you
don't follow instructions.
The purpose of these messages is to help prevent damage to your
engine, other property, or the environment.
2006 Honda Motor Co., Ltd.
32Z6J602
00X32-Z6J-6020
You WILL be KILLED or SERIOUSLY
HURT if you don't follow instructions.
You CAN be KILLED or SERIOUSLY
HURT if you don't follow instructions.
You CAN be HURT if you don't follow
instructions.
−
All Rights Reserved
GX25NT·GX35NT
OWNER'S MANUAL
MANUEL DE L'UTILISATEUR
MANUAL DEL PROPIETARIO
GX25·GX35
The engine exhaust from this product
contains chemicals known to the State of
California to cause cancer, birth defects
or other reproductive harm.
CONTENTS
INTRODUCTION
.......................
SAFETY MESSAGES
................
..........
.....
COMPONENT & CONTROL
................................
................................
BEFORE OPERATION
....................................
..............................
SAFE OPERATING
PRECAUTIONS
.....................
......
.....
......
.....
MAINTENANCE
....................
......
.......
MAINTENANCE
SCHEDULE
............................
REFUELING
...........................
ENGINE OIL
...........................
............
Oil Level Check
..................
Oil Change
.........................
AIR CLEANER
......................
Inspection
........................
Cleaning
..........................
ENGLISH
.1
......................
.1
COOLING FINS
...................
.2
FUEL FILTER AND FUEL
.2
TANK
...................................
SPARK ARRESTER
.............
.2
HELPFUL TIPS &
.3
SUGGESTIONS
......................
STORING YOUR ENGINE .14
...
.4
TRANSPORTING
................
.4
TAKING CARE OF
UNEXPECTED PROBLEMS
....
.4
TECHNICAL & CONSUMER
.4
INFORMATION
.......................
.5
Serial Number Location
.....
.6
Remote Control Linkage
.....
.6
Carburetor Modifications for
High Altitude Operation
.....
.6
Oxygenated Fuels
...............
.6
Emission Control System
.7
Information
.........................
Air Index
..............................
.7
Specifications
.....................
.8
Tuneup Specifications
........
.8
Quick Reference
.8
Information
.........................
.9
................
.9
.10
.10
Information
.........................
.10
.........................
.11
.11
.12
.12
.14
.15
.16
.16
.16
.16
.17
.17
.17
.18
.18
.19
.19
.19
.
.20
.20
1
Advertisement
Table of Contents
Related Manuals for Honda GX25
Summary of Contents for Honda GX25
-
Page 1: Table Of Contents
− All Rights Reserved 32Z6J602 00X32-Z6J-6020 OWNER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL PROPIETARIO GX25·GX35 The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. CONTENTS INTRODUCTION... -
Page 2: Spark Plug
Standard/Pump type: READ OWNER’S MANUAL BEFORE OPERATION. Tiller type: READ OWNER’S MANUAL BEFORE OPERATION. The illustrations in this manual are based on the GX25. The illustrations may vary according to the type. COMPONENT & CONTROL LOCATION Standard/Pump type: OIL FILLER CAP... -
Page 3: Features
FUEL FILLER CAP OIL FILLER CAP/ DIPSTICK MUFFLER SPARK PLUG (inside the top cover) (inside the top cover) ENGINE CONTROLS GX25 CHOKE LEVER GX35 CHOKE LEVER FEATURES Centrifugal Clutch (Standard/Tiller type) RECOIL STARTER The centrifugal clutch automatically engages and transmits power when engine speed is increased above approximately 4,200 rpm. -
Page 4: Checks
06/11/06 12:20:58 32Z6J600_004 BEFORE OPERATION CHECKS IS YOUR ENGINE READY TO GO? For your safety, and to maximize the service life of your equipment, it is very important to take a few moments before you operate the engine to check its condition. Be sure to take care of any problem you find, or have your servicing dealer correct it, before you operate the engine. -
Page 5: Setting Engine Speed
05/12/16 14:59:18 32Z6J600_005 Pull the starter grip lightly until you feel resistance, then pull briskly. Return the starter grip gently. Standard/Pump type: Tiller type: STARTER GRIP STARTER GRIP (EQUIPMENT SIDE) Do not allow the starter grip to snap back against the engine. Return it gently to prevent damage to the starter. -
Page 6: Stopping The Engine
05/12/16 14:59:35 32Z6J600_006 STOPPING THE ENGINE Standard/Tiller type: To stop the engine in an emergency, simply turn the engine switch on the equipment to the OFF position. Under normal conditions, use the following procedure. Move the throttle lever to the MIN. position. The throttle lever shown here will be connected to a remote control on the equipment powered by this engine. -
Page 7: Safety Precautions
06/11/06 12:22:11 32Z6J600_007 SAFETY PRECAUTIONS Make sure the engine is off before you begin any maintenance or repairs. This will eliminate several potential hazards: − Carbon monoxide poisoning from engine exhaust. Be sure there is adequate ventilation whenever you operate the engine. -
Page 8: Recommended Oil
06/11/06 12:22:36 32Z6J600_008 REFUELING Recommended Fuel Unleaded gasoline U.S. Pump octane rating 86 or higher Except U.S. Research octane rating 91 or higher Pump octane rating 86 or higher This engine is certified to operate on unleaded gasoline with a pump octane rating of 86 or higher (a research octane rating of 91 or higher). - Page 9 06/11/06 12:22:57 32Z6J600_009 Oil Level Check Check the engine oil level before each use, or every 10 hours if operated continuously. Check the engine oil level with the engine stopped and in a level position. Remove the oil filler cap/dipstick and wipe it clean. Insert and remove the oil filler cap/dipstick without screwing it into the oil filler neck, then remove it to check the oil level shown on the dipstick.
- Page 10 Always replace damaged filter elements. Refer to this page for instructions that apply to the air cleaner and filter service. Reinstall the filter element and air cleaner cover. GX25 Standard/Pump type: Tiller type: AIR CLEANER BODY AIR CLEANER BODY...
-
Page 11: Spark Plug
06/11/06 12:23:40 32Z6J600_011 SPARK PLUG Recommended Spark Plug: CM5H (NGK) CMR5H (NGK) The recommended spark plug has the correct heat range for normal engine operating temperatures. An incorrect spark plug can cause engine damage. For good performance, the spark plug must be properly gapped and free of deposits. - Page 12 If the engine has been running, the muffler will be hot. Allow it to cool before servicing the spark arrester. GX25 Standard/Pump type: Spark Arrester Removal Loosen the 5 mm hex bolt, then remove the top cover (see page Remove the 4 mm screws from the spark arrester, and remove the spark arrester from the muffler.
- Page 13 06/11/06 12:24:32 32Z6J600_013 Tiller type Spark Arrester Removal Loosen the 5 mm hex bolt, then remove the top cover (see page Remove the 3 × 6 mm self-tapping screws from the spark arrester, and remove the spark arrester from the muffler. ×...
- Page 14 06/11/06 12:25:00 32Z6J600_014 Tiller type: Spark Arrester Removal Loosen the 5 mm hex bolt, then remove the top cover (see page Remove the 4 × 6 mm self-tapping screws from the spark arrester, and remove the spark arrester from the muffler. MUFFLER EXHAUST FILTER SPARK ARRESTER...
- Page 15 05/12/16 15:02:29 32Z6J600_015 Draining the Fuel Tank and Carburetor Gasoline is highly flammable and explosive, and you can be burned or seriously injured when handling fuel. Stop engine and keep heat, sparks, and flame away. Handle fuel only outdoors. Wipe up spills immediately. Make sure the engine oil filler cap is tightened securely.
-
Page 16: Taking Care Of Unexpected Problems
05/12/16 15:02:48 32Z6J600_016 TAKING CARE OF UNEXPECTED PROBLEMS ENGINE WILL Possible Cause NOT START Check control Choke open. positions. Engine switch OFF.(on the equipment) Check fuel. Out of fuel. Bad fuel; engine stored without treating or draining gasoline, or refueled with bad gasoline. - Page 17 06/11/07 17:37:03 32Z6J600_017 Carburetor Modifications for High Altitude Operation At high altitude, the standard carburetor air-fuel mixture will be too rich. Performance will decrease, and fuel consumption will increase. A very rich mixture will also foul the spark plug and cause hard starting.
- Page 18 1,000 hours [225 cm (225 cc) and greater] The Air Index Information hang tag/label must remain on the engine until it is sold. Remove the hang tag before operating the engine. Specifications GX25 (Basic types) Type Power equipment description code Length...
-
Page 19: Wiring Diagrams
06/11/06 12:27:06 32Z6J600_019 Tuneup Specifications ITEM SPECIFICATION Spark plug gap 0.60 0.70 mm − (0.024 0.028 in) − Idle speed 3,100 200 rpm ± Valve clearance IN: 0.08 ± 0.02 mm (cold) EX: 0.11 ± 0.02 mm Other No other adjustments needed. specifications Quick Reference Information Fuel... -
Page 20: Consumer Information
05/12/16 15:04:22 32Z6J600_020 CONSUMER INFORMATION Distributor/Dealer Locator Information United States, Puerto Rico, and U.S. Virgin Islands: Call (800) 426-7701 or visit our website: www.honda-engines.com Canada: Call (888) 9HONDA9 or visit our website: www.honda.ca For European Area: visit our website: http://www.honda-engines-eu.com Customer Service Information Servicing dealership personnel are trained professionals.
