Multimedia Projector
PLC-WXL46A
MODEL
Owner's Manual
Network Supported
* Refer to the owner's manual
below for details about network
function.
■ Network Set-up and Operation
■ PJ Network Manager

Advertisement

Table of Contents
loading

Related Manuals for Sanyo PLC-WXL46A

Summary of Contents for Sanyo PLC-WXL46A

  • Page 1 Multimedia Projector Network Supported * Refer to the owner’s manual below for details about network function. ■ Network Set-up and Operation ■ PJ Network Manager PLC-WXL46A MODEL Owner’s Manual...

  • Page 2: Features And Desi�N

    Features and Desi�n This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology.  Lar�e Screen in Limited Space Di�ital Zoom (for Computer) Lar�e Screen in Limited Space Short focus lens allows you to project large images...

  • Page 3: Table Of Contents

    Table of Contents Features and Desi�n . . . . . . . . . . . . . . . . . . . . . .  Image Level Adjustment Screen Size Adjustment Table of Contents .

  • Page 4: To The Owner

    To the Owner Before installing and operating the projector, read this Safety Precaution manual thoroughly. WARNING: ● THIS APPARATUS MUST BE EARTHED . The projector provides many convenient features and ● TO REDUCE THE RISK OF FIRE OR functions. Operating the projector properly enables ELECTRIC SHOCK, DO NOT EXPOSE THIS you to manage those features and maintain it in good APPLIANCE TO RAIN OR MOISTURE .

  • Page 5: Safety Instructions

    Safety Instructions All the safety and operating instructions should be read before This projector should be operated only from the type of power the product is operated. source indicated on the marking label. If you are not sure of the type of power supplied, consult your authorized dealer or Read all of the instructions given here and retain them for local power company.

  • Page 6: Air Circulation

    Safety Instructions Installin� the Projector in Proper Air Circulation Position Openings in the cabinet are provided for ventilation. To Install the projector properly. Improper Installation may ensure reliable operation of the product and to protect it reduce the lamp life and cause fire hazard. from overheating, these openings must not be blocked Do not roll the projector more than or covered.

  • Page 7: Compliance

    Model Number : PLC-WXL46A Trade Name : Sanyo SANYO NORTH AMERICA CORPORATION Responsible party Address : 21605 Plummer Street, Chatsworth, California 91311 Telephone No. : (818)998-7322 AC Power Cord Requirement The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.

  • Page 8: Part Names And Functions

    Part Names and Functions Front ① Focus Lever ② Projection Lens ③ Lens Cover (See p . 5 for attachin�) CAUTION Do not turn on the projector with putting the lens cover on. The light beam may damage lens cover and result in fire hazard.

  • Page 9: Rear Terminal

    Part Names and Functions Rear Terminal ① ② ③ ④ ⑤ ⑥ ⑦ (VARIABLE) AUDIO OUT COMPUTER IN 2 / MONITOR OUT COMPUTER / VIDEO IN COMPONENT (MONO) S-VIDEO IN AUDIO IN ⑨ ⑧ ① ⑥ COMPUTER IN 1/COMPONENT IN AUDIO IN Connect output signal from a computer, RGB scart Connect the audio output from video equipment...

  • Page 10: Top Control

    Part Names and Functions Top Control ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ① SELECT button ⑥ WARNING indicator –Execute the selected item (p.20). –Lights red light when the projector detects an –Expand or compress the image in Digital zoom abnormal condition.

  • Page 11: Remote Control

    Part Names and Functions Remote Control ① POWER ON/STAND-BY button Turn the projector on or off (pp.18, 19). ③ ② ① ② VIDEO button Select VIDEO input port (pp.23, 34). ③ COMPUTER button Select COMPUTER input port (pp.23, 25, 35). ④...

  • Page 12: Remote Control Battery Installation

    Part Names and Functions Remote Control Battery Installation Open the battery Install new batteries into Replace the compartment lid. the compartment. compartment lid. Two AA size batteries For correct polarity (+ and –), be sure battery terminals are in contact with pins in the compartment.

  • Page 13: Installation

    Installation Positionin� the Projector For the projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. Note: •This projector is not equipped with an optical zoom. To adjust the screen size, change the throw distance. •...

  • Page 14: Connecting To A Computer

    Installation Connectin� to a Computer Cables used for connection • VGA Cables (Mini D-sub 15 pin)* • Audio Cables (Mini Plug: stereo) (*One cable is supplied; other cables are not supplied with the projector.) Monitor Output Audio Output Monitor Output External Audio Equipment Monitor Input Audio Input...

  • Page 15: Connecting To Video Equipment

    Installation Connectin� to Video Equipment Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Mini Plug: stereo) (Cables are not supplied with the projector.) S-Video Output Composite Video and Audio Output (R) (L) (Video) External Audio Equipment...

  • Page 16: Connecting To Component Video Equipment

    Installation Connectin� to Component Video Equipment Cables used for connection • Audio Cables (Mini Plug: stereo) • Scart-VGA Cable • Component Cable • Component-VGA Cable (Cables are not supplied with the projector.) Audio Output RGB Scart 21- Component Video Output pin Output (Y, Pb/Cb, Pr/Cr) Component...

  • Page 17: Connecting The Ac Power Cord

    Installation Connectin� the AC Power Cord This projector uses nominal input voltages of 100–120 V or 200–240 V AC and it automatically selects the correct input voltage. It is designed to work with single-phase power systems having a grounded neutral conductor. To reduce the risk of electrical shock, do not plug into any other type of power system.

  • Page 18: Basic Operation

    Basic Operation Turnin� On the Projector Complete peripheral connections (with a computer, VCR, etc.) before turning on the projector. Connect the projector’s AC power cord into an AC outlet. The POWER indicator turns red. Open the lens cover. Press the POWER ON/STAND-BY button on the remote control.

  • Page 19: Turning Off The Projector

    Basic Operation Turnin� Off the Projector Press the POWER ON/STAND-BY button on the remote control, and “Power off?” appears on the screen. Power off? Press the POWER ON/STAND-BY button again to turn off the projector. The POWER indicator starts to blink red, and the cooling fans keep running.

  • Page 20: How To Operate The On-Screen Menu

    Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Top Control Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Press the MENU button on the top control or on the MENU button remote control to display the On-Screen Menu.

  • Page 21: Menu Bar

    Basic Operation Menu Bar For detailed functions, see Menu Tree on pages 59-60. For computer source ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ① Guide Window ⑦ Screen Menu Shows the selected Menu of the On-Screen Menu. Used to adjust the size of image from Normal, ②...

  • Page 22: Focus Adjustment

    Basic Operation Focus Adjustment Adjust the lens focus with the focus lever. Focus Lever Keystone Correction If a projected picture has keystone distortion, correct the image with the Keystone function. Press the KEYSTONE button on the top control or on the •The arrows are white when there is no correction.

  • Page 23: Sound Adjustment

    Basic Operation Sound Adjustment Direct Operation Top Control Volume VOLUME+/- button Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Remote Control VOLUME- button...

  • Page 24: Keystone Button

    Basic Operation Remote Control AUTO PC button Press the AUTO PC button to operate the Auto PC function. KEYSTONE button VOLUME +/- (See page 22.) See page 27 for more details. buttons POINT ▲▼ (See page 23.) buttons D .ZOOM buttons AUTO PC button Press the D.ZOOM buttons to zoom in and zoom out the...

  • Page 25: Computer Input

    Computer Input Input Source Selection Direct Operation Top Control INPUT button Select either Computer 1 or Computer 2 by pressing the INPUT button INPUT button on the top control or the COMPUTER button on the remote control. Computer 1 Before using INPUT or COMPUTER button, select the correct input source through Menu operation as described Computer  below.

  • Page 26: Computer System Selection

    Computer Input Computer System Selection The projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If computer is selected as a signal source, the projector automatically detects the signal format and tunes to project proper images without any additional setting.

  • Page 27: Auto Pc Adjustment

    Computer Input Auto PC Adjustment Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal, and Vertical positions to conform to your computer. Direct Operation Remote Control The Auto PC adjustment function can be operated directly with the AUTO PC button on the remote control.

  • Page 28: Manual Pc Adjustment

    Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas (Mode 1–5) to store those parameters manually adjusted, which allows you to recall the setting for a specific computer.
  • Page 29 Computer Input Display area H Use the Point ◄► buttons to adjust the horizontal area displayed by this projector. Display area V Use the Point ◄► buttons to adjust the vertical area displayed by this projector. Reset To reset the adjusted data, select “Reset” and press the Move the red frame pointer SELECT button.

  • Page 30: Image Level Selection

    Computer Input Ima�e Level Selection Direct Operation Remote Control IMAGE button Select an image level from among Dynamic, Standard, Real, Blackboard (Green), Colorboard, Image 1, Image 2, Dynamic Image 3, and Image 4 with the IMAGE button on the remote control.

  • Page 31: Image Level Adjustment

    Computer Input Ima�e Level Adjustment Press the MENU button to display the On-Screen Ima�e Adjust Menu Menu. Use the Point ◄► buttons to move the red frame pointer to the Image Adjust Menu icon. Use the Point ▲▼ buttons to move the red frame Image Adjust Menu icon pointer to the desired item, and then press the Move the red frame pointer...

  • Page 32: Screen Size Adjustment

    Computer Input Store To store the adjusted data, select “Store” and press the Move the red frame pointer to the desired SELECT button. The Image Level Menu appears. Use the Point ▲▼ buttons to choose one of the four image level and image level (from Image 1 to 4) and then press press the SELECT button.
  • Page 33 Computer Input Custom Adjust the screen scale and position manually with this function. Press the SELECT button at Custom and the “Custom” is displayed on the screen for a few seconds and then the Aspect dialog box appears. Scale H/V……… Adjust the Horizontal/Vertical screen scale. H&V ……………...

  • Page 34: Video Input

    Video Input Input Source Selection (Video, S-video) Top Control Direct Operation INPUT button Select Video by pressing the INPUT button on the top INPUT button control or the VIDEO button on the remote control. Before using INPUT or VIDEO button, select the correct Video input source through menu operation as described below.

  • Page 35: Input Source Selection

    Video Input Input Source Selection (Component, RGB Scart 1-pin) Direct Operation Top Control INPUT button Select Computer 1 by pressing the INPUT button on the top INPUT button control or COMPUTER button on the remote control. Before using INPUT or COMPUTER button, select the Computer 1 correct input source through Menu operation as described below.

  • Page 36: Video System Selection

    Video Input Video System Selection Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red frame pointer to the AV System Menu icon. Use the Point ▲▼ buttons to move the red arrow pointer to the desired system and then press the SELECT button.

  • Page 37: Image Level Selection

    Video Input Ima�e Level Selection IMAGE button Remote Control Direct Operation Select an image level from among Dynamic, Standard, Dynamic Cinema, Blackboard (Green), Colorboard, Image 1, Image 2, Image 3, and Image 4 with the IMAGE button on the Standard remote control.

  • Page 38: Image Level Adjustment

    Video Input Ima�e Level Adjustment Press the MENU button to display the On-Screen Menu. Ima�e Adjust Menu Use the Point ◄► buttons to move the red frame pointer to the Image Adjust Menu icon. Use the Point ▲▼ buttons to move the red frame Image Adjust Menu icon pointer to the desired item and then press the SELECT button.
  • Page 39 Video Input Sharpness Press the Point ◄ button to decrease the sharpness of the image; press the Point ► button to increase the sharpness of the image (from 0 to 15). Gamma Use the Point ◄► buttons to adjust the gamma value to get better balance of contrast (from 0 to 15).

  • Page 40: Screen Size Adjustment

    Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen Screen Menu Menu. Use the Point ◄► buttons to move the red frame pointer to the Screen Menu icon.

  • Page 41: Settin

    Settin� Settin� This projector has Setting menu that allows you to set up Settin� Menu (Lan�ua�e) the other various functions described as follows: Press the MENU button to display the On-Screen Menu. Use the Point ◄► buttons to move the red Setting Menu Set the red framed frame pointer to the Setting Menu icon.
  • Page 42 Settin� Lo�o select Lo�o (Lo�o and Lo�o PIN code lock settin�s) This function allows you to customize the screen logo with Logo select, Capture, and Logo PIN code lock functions. Note: When “On” is selected in Logo PIN code lock function, Logo select and Capture functions cannot be selected.
  • Page 43 Settin� Lo�o PIN code lock Lo�o PIN code lock This function prevents an unauthorized person from changing the screen logo. Off…… the screen logo can be changed freely from the Logo select menu (p.42). On…… the screen logo cannot be changed without the Logo PIN code.
  • Page 44 Settin� Ceilin� Ceilin� When this function is set to “On”, the picture is top/bottom and left/right reversed. This function is used to project the image from a ceiling-mounted projector. Rear Rear When this function is set to “On”, the picture is left/right reversed.
  • Page 45 Settin� Standby mode This function is available when operating the projector via network. Network..Supply the power to the network function even after turning off the projector You can turn on/ off the projector via network, modify network environment, and receive an e-mail about projector status while the projector is powered off.
  • Page 46 Settin� On start On start When this function is set to “On,” the projector is automatically turned on just by connecting the AC power cord to an outlet. Note: Be sure to turn the projector off properly (see “Turning Off the Projector”...
  • Page 47 Settin� Security (Key lock and PIN code lock settin�s) This function allows you to use Key lock and PIN code lock function to set the security for the projector operation. Key lock Key lock This function locks operation of the top control or the remote control.
  • Page 48 Settin� Enter a PIN code Enter a PIN code Select a number by pressing the Point ▲▼ buttons. And then press the Point ◄► button to fix the number and move the pointer. The number changes to "". If you fixed an incorrect number, move the pointer to the number you want to correct by pressing the Point ◄►...
  • Page 49 Settin� This function provides the following options in the cooling Note: fans’ operation after turning off the projector (p.19). Setting “Fan control” to On1 or On2 affects L2 L1 …… Normal operation operation in “Fan.” L2 …… Slower and lower-sound than the normal operation (L1), but it takes longer to cool down the projector.
  • Page 50 Settin� Warnin� lo� This function records anomalous operations while the projector is in operation and use it when diagnosing faults. Up to 10 warning logs are displayed with the latest warning message at the top of the list, followed by previous warning messages in chronological order.

  • Page 51: Maintenance And Cleanin

    Maintenance and Cleanin� Warnin� Indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING WARNING Top Control indicator is blinkin�...

  • Page 52: Cleaning The Air Filters

    Maintenance and Cleanin� Cleanin� the Air Filters Air filters prevent dust from accumulating on the surface of the optical elements inside the projector. Should the air filters become clogged with dust particles, they will reduce cooling fans’ effectiveness and may result in a buildup of internal heat and adversely affect the life of the projector.

  • Page 53: Attaching The Lens Cover

    Maintenance and Cleanin� Attachin� the Lens Cover When moving the projector or while it is not in use, replace the lens cover. Thread the string through the hole on the lens cover and then tie a knot in the string to secure it in place. Thread the other end of the string through the hole on the bottom of the projector.

  • Page 54: Lamp Replacement

    ORDER REPLACEMENT LAMP Replacement lamp can be ordered through your dealer. When ordering a projection lamp, give the following information to the dealer. ● Model No . of your projector : PLC-WXL46A ● Replacement Lamp Type No . : POA-LMP106 POA-LMP106...

  • Page 55: Lamp Replacement Counter

    Maintenance and Cleanin� Lamp Replacement Counter Be sure to reset the Lamp replacement counter after the lamp is replaced. When the Lamp replacement counter is reset, the LAMP REPLACE indicator stops lighting. Lamp counter Turn the projector on and press the MENU button ◄►...

  • Page 56: Appendix

    Appendix Troubleshootin� Before calling your dealer or service center for assistance, check the items below once again. – Make sure you have properly connected the projector to peripheral equipment as described on pages 14-16. – Make sure all equipment is connected to the AC outlet and the power is turned on. –...
  • Page 57 Appendix – Check if "Contrast" or "Brightness" are adjusted properly (see Check if "Contrast" or "Brightness" are adjusted properly (see Check if "Contrast" or "Brightness" are adjusted properly (see (see pages 31, 38). , 38). 38). . – Check if "Image level" is selected properly (see pages 30, 37). Check if "Image level"...
  • Page 58 Appendix – Check the status of the projector with referring to "indicators and Check the status of the projector with referring to "indicators and Indicator blinks or li�hts . Projector Condition" (see page 61). Computer  cannot be selected . –...

  • Page 59: Menu Tree

    Appendix Menu Tree Computer Input/Video Input Input Computer 1 Go to System Component Go to System RGB( Scart ) Quit Computer 2 Go to System Video Auto Go to System Video Go to System S-video Go to System Quit Sound Sound Volume 0 - 63...
  • Page 60 Appendix Video Input Settin� System Settin� Auto Language 16 languages provided. 1080i Quit 1035i Keystone Store / Reset 720p Blue back On / Off 575p Display Off / Countdown off / On 480p Logo Logo select 575i 480i Default User System Auto Capture...

  • Page 61: Indicators And Projector Condition

    Appendix Indicators and Projector Condition Check the indicators for projector condition. Indicators Projector Condition LAMP POWER WARNING REPLACE red/�reen yellow The projector is off. (The AC power cord is unplugged.) The projector is preparing for stand-by or the projection lamp is being cooled down.

  • Page 62: Compatible Computer Specifications

    Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock. When selecting these modes, Screen, Auto PC adjustment and PC adjustment can be limited. ON-SCREEN H-Freq .
  • Page 63 Appendix ON-SCREEN H-Freq . V-Freq . ON-SCREEN H-Freq . V-Freq . RESOLUTION RESOLUTION DISPLAY (kHz) (Hz) DISPLAY (kHz) (Hz) UXGA1 1600x1200 75.00 60.00 720p 1280x720 45.00 60.00 60.00 UXGA2 1600x1200 81.25 65.00 1035i 1920x1035 33.75 (Interlace) UXGA3 1600x1200 87.5 70.00 60.00 1080i 1920x1080...

  • Page 64: Technical Specifications

    Appendix Technical Specifications Mechanical Information Projector Type Multi-media Projector Dimensions (W x H x D) 12.59" x 5.73" x 11.85" (319.9 mm x 145.5 x 300.9 mm) (Not including protrusions) Net Weight 7.5 lbs (3.4 kg) 0˚ to 10.0˚ Feet Adjustment Panel Resolution LCD Panel System 0.59”...

  • Page 65: Dimensions

    Appendix Accessories Owner’s Manual(CD-ROM) Network Application (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable Lens Cover with String PIN Code Label ● The specifications are subject to change without notice. ● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels (0.01% or less) may be ineffective by the characteristics of the LCD panels.

  • Page 66: Pj Link Notice

    Appendix PJ Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1. For PJ Link password, see page 21 on the owner’s manual “Network Set-up and Operation.”...

  • Page 67: Configurations Of Terminals

    Appendix Confi�urations of Terminals COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG) Terminal : Analo� RGB (Mini D-sub 15 pin) Red (R/Cr) Input / Output +5V Power / ----- Green (G/Y) Input / Output Ground (Vert.sync.) Blue (B/Cb) Input / Output Ground / ----- DDC data / ----- ----- Ground (Horiz.sync.)

  • Page 68: Pin Code Number Memo

    Appendix PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No . Factory default set No: 1 2 3 4* Lo�o PIN Code Lock No .
