- Page 1 HKTS 5/HKTS 6 Home Theater Speaker System SERVICE MANUAL harman/kardon, Inc. 250 Crossways Park Dr. Rev2 1/2004 Woodbury, New York 11797...
-
Page 2: Table Of Contents
TROUBLESHOOTING……………….……………..………….………….5 SUB-TS5/TS6 EXPLODED VIEW..……………………..…..…….……...6 SUB-TS5/TS6 AMPLIFIER EXPLODED VIEW..….. …...…….….……...7 SUB-TS5/TS6 TEST PROCEDURE..…………………….. ……..……….8 HKTS 5/HKTS 6 MECHANICAL/SATELLITE PARTS LIST………..….9 HKTS 5/HKTS 6 PACKAGE..………………….……………..…….…..10 SUB-TS5/ TS6 BLOCK DIAGRAM..……………………. ………………11 SUB- TS5/ TS6 PCB DRAWINGS……..……………..……….……..12 SUB- TS5/ TS6 ELECTRICAL PARTS LIST …….……….…..………...15 SUB- TS5/ TS6 IC/TRANSISTOR PINOUTS…..……………………..18... - Page 3 HKTS5/HKTS6 harman/kardon SUB-TS5/TS6 Amplifier 100w Powered Subwoofer Amplifier LINE VOLTAGE Yes/No Hi/Lo Line Unit Notes US 120vac/60Hz 108-132 Vrms Normal Operation Parameter Specification Unit QA Test Limits Conditions Notes Amp Section Type (Class AB, D, other) AB AB External Sink required for Class AB Load Impedance (speaker) 4 Ohms Nominal...
-
Page 4: Speaker Connections
HKTS5/HKTS6 harman/kardon SPEAKER CONNECTIONS Use the supplied RCA-type patch cord to connect the line-level SUB or LFE output on your receiver or amplifier to the SUB input on the SUB-TS5 or SUB-TS6 subwoofer. Connect the satellite and center speakers to the corresponding speaker terminals on your receiver or amplifier. -
Page 5: Operation
When the subwoofer senses an If you will be away from home for an to the HKTS 5/6 by your receiver or surround audio signal, it will automatically turn itself extended period of time, or if the sub- on and the LED ¢... -
Page 6: Troubleshooting
HKTS5/HKTS6 harman/kardon TROUBLESHOOTING TROUBLESHOOTING If there is no sound from any of the If there is no sound from the center If there is no sound from the sur- speakers: speaker: round speakers: • Check that receiver/amplifier is on and a •... -
Page 7: Sub-Ts5/Ts6 Exploded View
HKTS5/HKTS6 harman/kardon Ref. Part Number Description Not For Sale HKTS5/HKTS6 Enclosure (HKTS5) sz5321 HK Logo (HKTS6) sz5930 HK Logo 25MF10DZB-DW02 10" woofer (DCR = 3.4 ohms ±10%) 06-t4205012 Amplifier/woofer screw t4*20 wi5448 Foot (bumper) 06-t5345005 Foot screw wi5447 Rubber foot wi5600 Port Tube Not For Sale... -
Page 9: Sub-Ts5/Ts6 Test Procedure
HKTS5/HKTS6 harman/kardon HKTS 5/HKTS 6 TEST PROCEDURE Equipment needed: • Function/signal generator/sweep generator • Integrated Amplifier • Multimeter • Speaker cables • Single RCA cable General Unit Function (UUT = Unit Under Test) 1) From the signal generator, connect one line level (RCA) cable to the single SUB input. -
Page 10: Hkts 5/Hkts 6 Mechanical/Satellite Parts List
Outer carton (HKTS5) wg5452 Outer carton (HKTS6) at5073 warranty card wp5215 Foam set sal063-1 Wire set 20' (center) sal5009 Wire set 40' (surround) sal5020 Wire set 15' (front satellites) sal5044 Single RCA cable OPTIONAL: Floor Stands for HKTS 5/SAT-TS5 satellites - FSTS1... -
Page 11: Hkts 5/Hkts 6 Package
HKTS5/HKTS6 Packaging... -
Page 12: Sub-Ts5/ Ts6 Block Diagram
HKTS5/HKTS6 harman/kardon... -
Page 13: Sub- Ts5/ Ts6 Pcb Drawings
HKTS5/HKTS6 harman/kardon... - Page 14 HKTS5/HKTS6 harman/kardon...
- Page 15 HKTS5/HKTS6 harman/kardon...
-
Page 16: Sub-Ts5/Ts6 Electrical Parts List
HKTS5/HKTS6 harman/kardon SUB-TS5/TS6 Electrical Parts List PART NO. DESCRIPTION Reference Designator Resistors 11014152j26 RESISTOR 1.5K 1/4W ±5% CF R265 11014472j26 RESISTOR 4.7K 1/4W ±5% CF R147,150 11014681j26 RESISTOR 680 ohms 1/4W ±5% CF R148,151 11016101j26 RESISTOR 100 ohms 1/6W ±5% CF R120,215 11016102j26 RESISTOR 1K 1/6W ±5% CF... - Page 17 HKTS5/HKTS6 harman/kardon PART NO. DESCRIPTION Reference Designator Capacitors 1302b101k503 100pf 50V ±10% C220 1302b102k503 1000pf 50V ±10% C116 1302b221k503 220pf 50V ±10% C212,230 1302f104z503 0.1uf 50V +80/-20% C108,113,115,119,232,236,237,240,241 1303f473m503 0.047uf 50V ±20% C106 130sl470k503 47pf 50V +350/-1000 ±10% C229 132104j503 0.1uf 50V ±5% C107,221,222,224 132223ja03...
- Page 18 HKTS5/HKTS6 harman/kardon PART NO. DESCRIPTION Reference Designator 19510204hgw LED 204HGW D209 19700kbl405 4A 500V KBL405 BRIDGE D110 197101n4002 1N4002 D104 Miscellaneous 171udhss124d 5A 24V UDH-SS124D RELAY RY101 1740rcb242vpg JACK RCB JK203 180tms7210v SWITCH SLIDE MS7210V SW201 150e8604107 TRANSFORMER 152u602015 LINE CORD SVT FT-2 6FT 154u25006t0 FUSE 2.5A 250V 20mm FS101...
-
Page 19: Sub- Ts5/ Ts6 Ic/Transistor Pinouts
harman/kardon HKTS5/HKTS6... -
Page 20: Sub- Ts5/ Ts6 Schematics
HKTS5/HKTS6 harman/kardon... - Page 21 HKTS5/HKTS6 harman/kardon...
- Page 22 HKTS5/HKTS6 harman/kardon...
