CATALOG 1.SUMMARIZATION IMPORTANT SAFETY PRECAUTIONS………………………………………………………………. FEATURES ………………………………………………………………………………………. ABOUT MANUAL…………………………………………………………………………………… TERMS FOR DISCS……………………………………………………………………………….. BEFORE OPERATION……………………………………………………………………………… 1-10 PREPARATIONS BEFORE OPERATION……………………………………………………………. 1-12 CONNECTIONS……………………………………………………………………………………. 1-16 BASIC OPERATIONS……………………………………………………………………………… 1-17 PLAYING A DESIRED SCENE…………………………………………………………………….. 1-21 PLAY DISCS IN VERIOUS WAYS………………………………………………………………… 1-25 FUNCTION SETTING……………………………………………………………………………… 1-30 OTHERS…………………………………………………………………………………………… 1-36 2.REPLACE PARTS REPLACE CHASSIS……………………………………………………………………………..
Page 3
4.IC MATERIAL MT1369E IC MATERIAL…………………………………………………………………………. CS4340 (AUDIO D/A) IC MATERIAL………..………………………………………………... AV 3168 (VIDEO) IC MATERIAL ……………………………………………………………… FLASH 29F080 IC MATERIAL…………………………………………………………………... 4-12 CONTROL PANEL IC MATERIAL…………………………………………………………………. 4-13 16M SDRAM IC MATERIAL……………………………………………………………………..4-14...
IMPORTANT SAFETY PRECAUTIONS The lightning flash with arrowhead symbol, CAUTION within an equilateral triangle, is intended to alert the user to the presence of uninsulated RISK OF ELECTRIC SHOCK “dangerous voltage” within the product’s DO NOT OPEN enclosure that may be of sufficient magnitude to CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, constitute a risk of electric shock.
Page 5
IMPORTANT SAFETY PRECAUTIONS This set has been designed and manufactured to swimming pool. PORTABLE CART WARNING (symbol provided by RETAC) assure personal safety. Improper use can result 8 ACCESSORIES in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you Do not place this observe the following procedures for unit on an...
Page 6
IMPORTANT SAFETY PRECAUTIONS your video dealer or local power company. 14 DISC TRAY For units intended to operate from battery Keep your fingers well clear of the disc as power, or other sources, refer to the it is closing. It may cause serious personal operating instructions.
Page 7
IMPORTANT SAFETY PRECAUTIONS 20 DAMAGE REQUIRING SERVICE perform safety checks recommended by the manufacturer to determine that the Unplug this unit from the wall outlet and unit is in safe operating condition. refer servicing to qualified service personnel under the following conditions. 23 WALL OR CEILING MOUNTING A.
FEATURES OUTSTANDING SOUND QUALITY Dolby Digital system developed by Dolby Laboratories and DTS developed by DTS Inc., features high quality surround sound, can be played in DVD or CD disc at home, to reproduce high quality sound effects. HIGH DEFINITION The unit adopts MPEG2 coding format and brings the high horizontal resolution.
ABOUT MANUAL PRINCIPLES FOR WRITING This manual mainly introduces how to use buttons on the remote control. You may operate the unit if the buttons on the unit have the same or similar names as or to those on the remote control. PLAYABLE DISCS •...
TERMS FOR DISCS TITLE The images or music of a DVD are divided into some units, among which title is the biggest one. When playing a DVD, the movie is the title. When playing a CD, the combined tracks make up the title. CHAPTER It is smaller than title among the units of a DVD.
TERMS FOR DISCS SCENE The menu pictures, motion and motionless pictures of a CD or something discs with PBC function can be divided into some parts, these parts are scenes. Each scene has a number for search. PBC (PLAYBACK CONTROL) It is signals recorded in a CD or something discs to control playback.
BEFORE OPERATION SECURITY • Before operation, check if the voltage of the unit is in line with the local voltage. • Hold the plug to disconnect it from the mains outlet. Do not pull the power cord. • When the plug of the unit is connected to the mains outlet , the unit will be still connected to AC even if the power is turned off.
Page 13
BEFORE OPERATION HANDLING DISC • To keep the disc clean, do not touch the playsides of the disc. • Do not attach paper or tape to the disc. • Keep the disc away from direct sunlight or heat sources. • Store the disc in a disc case after playback. CLEANING DISC •...
PREPARATIONS BEFORE OPERATION FRONT PANEL & @ #$% ! STANDBY/ON button To switch the unit On or Off when connected to AC power outlet @ PLAY button To play the loaded disc. Press this button to go to the preferred item when the menu is displayed on the TV screen.
Page 15
PREPARATIONS BEFORE OPERATION REAR PANEL VIDEO COMPONENT OPTICAL AUDIO S-VIDEO COAXIAL VIDEO OUT & ! AUDIO OUT (L/R TRACK) Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier. @ VIDEO OUT Connects composite video signal to input AV or PHONO sockets of TV or monitor to achieve high fidelity colour reproduction.
Page 16
PREPARATIONS BEFORE OPERATION & PBC DVD AC-3 MUTE RESUME REPEAT 1 ALL OVER ! PLAY/PAUSE/STEP ) TRACK CALENDAR Illuminates the current operation mode. Illuminates the information of the TRACK. @ PBC 1 OVER Indicates the PBC PLAY Illuminates the over than 16 track under play CD or some discs.
PREPARATIONS BEFORE OPERATION NAMES AND LAYOUT OF REMOTE CONTROLS * In case of setting the mode by using SETUP menu (for example, AUDIO select in PREFERENCE SETUP), the setting is kept though you switch the unit off and turn it on. MUTE BUTTON POWER BUTTON OPEN/CLOSE BUTTON...
CONNECTIONS Turn off all equipment before operation. The unit has many kinds of output modes like A/V output, S-VIDEO output and digital signal output (COAXIAL, OPTICAL). You may select as you need. CONNECTED TO A TV AND AN ORDINARY AMPLIFIER VIDEO COMPONENT S-VIDEO...
BASIC OPERATIONS PLAY DISCS Push "POWER" button on the TV and audio system, Push "TV/VIDEO" button on the TV, select VIDEO mode (TV). Select S-Video mode if using an S-VIDEO connection. TV/VIDEO N ote: Select the right audio input on the amplifier. The Step2 can be •...
Page 20
BASIC OPERATIONS SYSTEM SETTING According to the system of the TV to be connected, set the system of the unit to make it match the TV. Push SYSTEM button on the remote control, then choose TV TYPE. SYSTEM • If the system of the TV is PAL, push "SYSTEM" once. •...
Page 21
BASIC OPERATIONS FAST PLAY When playing disc, you may play it forward fast or reverse it fast to find what you need. N ote: Push to play forward fast. Each Push PLAY to play time you push the button, the speed of normally when picture changes like the right sides.
Page 22
BASIC OPERATIONS SELECT AUDIO LANGUAGE You can choose the language according to your choice when playing mulit- *Attention: language DVD. Please select Press “AUDIO” button, select different languages. the AUDIO language in N ote: SETUP menu to 1. Different disc has different languages keep the AUDIO 2.
PLAYING A DESIRED SCENE TO SKIP SCENES IN A DISC Push to move to next chapter (or track). The current chapter (or track) moves to the next chapter (or track). Push to move to previous chapter (or track). The current chapter (or track) moves to the previous chapter (or track) or first scene of current chapter (or track).
Page 24
PLAYING A DESIRED SCENE PLAYING A DISC CONTAINING MP3 FILES When a MP3 disc is loaded, MP3 menu screen is displayed automatically depending on MP3 disc’s folder structure. Use the direction button to select the folder you want to play, by pressing [PLAY] button.
Page 25
PLAYING A DESIRED SCENE REPEATING A DEFINED PERIOD FROM A TO B You may press A-B to enjoy some parts repeatedly when playing a disc. 1. Press “A-B” to set a starting point A. N ote: 2. Press “A-B” twice to an end point B. A MP3 disc may Afterwards, the unit plays from A to B.
Page 26
PLAYING A DESIRED SCENE SEARCHING CD AND SOMETHING DISC WITH A TIME OR TRACK TIME You may directly enter a disc or track time to search fast on a disc. The unit plays from the point. If you want to search with a disc DISC GOTO : - - : - - time, press [SEARCH] button one...
PLAY DISCS IN VERIOUS WAYS SELECT ANGLE N ote: Some discs have images with different screen angles, you may select among Multi Angle them. For example, when you watch a running train, you may select to watch it function is limited from the front, the left window or the right window without stopping it.
Page 28
PLAY DISCS IN VERIOUS WAYS PROGRAM PLAY (DVD) You may program the title and chapter on a disc and play them in the programmed order. Push "PROGRAM" button, the screen PROGRAM:TT(05) / CH (- -) shows: 01 TT: CH 06 TT: CH 02 TT: CH 07 TT: CH 03 TT: CH...
Page 29
PLAY DISCS IN VERIOUS WAYS DIGEST PLAY (DVD) Push "INTRO" button when the unit is SELECT DIGEST TYPE playing disc, the screen shows : TITLE DIGEST CHAPTER DIGEST TITLE INTERVAL CHAPTER INTERVAL Push direction button to select the INTRO digest type. N ote: •...
Page 30
PLAY DISCS IN VERIOUS WAYS PLAY MP3 OR PIC-CD DISC USE NUMBER BUTTONS SELECT TRACKS (MP3 OR PIC-CD) The screen will display as right after the MENU disc is loaded Cd 01 Cd 02 Cd 03 Cd 04 Cd 05 Cd 06 PLAY MODE FOLDER...
Page 31
PLAY DISCS IN VERIOUS WAYS SELECT PLAYING MODE (MP3 OR PIC-CD) Push direction button to select the play mode area under stop status, then push direction button to select different play mode. These play modes list as the following : •...
FUNCTION SETTING MENU SETTING According to the recorded information and external equipment, set the following functions for DVD to obtain the best playing status. Push "SETUP" button to set the main menu.
Page 34
FUNCTION SETTING BASIC NAVIGATION To navigation through the setting on the screen, use the direction buttons to scroll through the list of settings and use “PLAY” button to select the high lighted function. SETUP MENU Press the SETUP button to enter the On Screen Display and to exit at any time.
Page 35
FUNCTION SETTING ANGLE MARK This only works when there is an angle mark on the disc. • Select "ON", the screen shows the mark when playing a DVD. • Select "OFF", the mark is not shown. OSD LANGUAGE N ote: “OSD”...
Page 36
FUNCTION SETTING DOLBY DIGITAL SETUP DUAL MONO This is the output mode of the L and R signals of the set audio output. If it is set to "MIX MONO", the function only works when the DVD being played is 2.0-channel. •...
Page 37
FUNCTION SETTING DISC MENU • Selecting Disc Menu language. Please set it as the preferred DISC MENU language. In case the DISC MENU language is set and recorded in the DISC, it is automatically played in the set language in every playing. For example, English is set and recorded as a DISC MENU language in the DISC, it is played in English.
OTHERS TON CONTROL You may change the pitch to adapt to your voice • Push to raise the pitch. Each time you push the button, the pitch is raised by one step. It can be raised by 7 steps at the most. •...
Page 39
OTHERS TROUBLESHOOTING If you experience the following problems while using the unit, this troubleshooting guide can help you. • NO SOUND - Check if the unit is connected securely. - Make sure you operate the TV or amplifier correctly. • NO IMAGE , IMAGE ROLLS AND NO COLOR - Check if the unit is connected securely.
Page 40
OTHERS TECHNICAL SPECIFICATIONS Laser wavelength 650nm Video PAL/AUTO/NTSC Frequency response 20Hz ~ 20KHz (±1dB) Signal/noise ratio 90dB Channel separation 85dB ( 1KHz) Dynamic range 80dB ( 1KHz) output level : 2.0 + 0/-0.2Vrms Analog (Load impedance : 10K ) Output Audio output level : 0.5 ±...
2. REPLACE PARTS REPLACE CHASSIS ........................2 TOP COVER........................... 2 FRONT PANEL ........................2 BACK PANEL........................3 REPLACE PCB BOARD ......................4 MAIN PC BOARD ......................... 4 POWER SUPPLY PC BOARD ....................4 VFD POWER SWITCH PC BOARD ..................5 MIC PC BOARD ........................
NOTICE: 1. There are some malfunctions because of the influence from static electricity, so you should properly earth. 2. This system includes lots of screws, please operate with magnetic screwdriver in order to prevent dropping screws. You should pay more attention to some special screws, which puts the screw on mold.
REPLACE PCB BOARD MAIN PC BOARD NOTICE: to make sure the output protect point of laser diode is short before you dismantle main PC board (3). After you replace main PC board, insert flexible cables and open protect point. 1. Draw out four flexible cables (1). 2.
REPLACE DVD LOADER NOTICE: To make sure the output protect point of laser diode is short before you draw out joint and soft cable. After you replace mechanical chassis parts and insert joint and soft cable, then open protect point. 1.
POWER SCHEMATIC CIRCUIT DIAGRAM 1000 250V H E R TC 100 T1 BYBYQDVD868 L 250 1N4007 1N4007 470U 470U CON2 0.22UF 275V S12V 1N4007 1N4007 47UF 400V H E R CNS-4P 2200 18,15 240K 470U LD1117 K( O P E N) 240K CON4 I N4...
Page 53
MT1369AE INDEX & POWER GVG1369M6-2.5 MT1369E (LQFP208) DVD MP Board for Hitachi HOP1120/1200 1 INDEX & POWER, RESET 2 RF / SERVO & MPEG - MT1336E / MT1369E 3 MEMORY - SDRAM, FLASH/EEPROM 4 AUDIO -WM8746/8726/4340, VIDEO - AV3168 5 AV FILTER. NAME TYPE DEVICE...
4. IC MATERIAL MT1369E IC MATERIAL ....................4-2 DECAL ......................... 4-2 PIN FUNCTION DESCRIPTION ................4-3 CS4340(AUDIO D/A) IC MATERIAL ................4-8 DECAL ......................... 4-8 PIN FUNCTION DESCRIPTION ................4-8 AV 3168 VIDEO IC MATERIAL................... 4-9 DECAL ......................... 4-9 PIN FUNCTION DESCRIPTION ................4-10 FLASH 29F800 IC MATERIAL..................
Page 61
PIN FUNCTION DESCRIPTION Symbol Type Description IREF Analog Input Current reference input. It generate reference current for data PLL. Connect an external 100K resistor to this pin and PLLVSS. PLLVSS Ground Ground for data PLL and related analog circuitry LPIOP Analog Output Positive output of the low pass filter LPION...
Page 62
Symbol Type Description IOA4 Inout, Pull Up Microcontroller address 4 / GPIO4 IOA5 Inout, Pull Up Microcontroller address 5 / GPIO5 IOA6 Inout, Pull Up Microcontroller address 6 / GPIO6 IOA7 Inout, Pull Up Microcontroller address 7 / GPIO7 Output Flash address 16 Output Flash address 17...
Page 63
Symbol Type Description DVDD3 Power 3.3V power RD15 Inout, Pull Up/Down DRAM data 15 RD14 Inout, Pull Up/Down DRAM data 14 RD13 Inout, Pull Up/Down DRAM data 13 RD12 Inout, Pull Up/Down DRAM data 12 DVSS Ground Ground RD11 Inout, Pull Up/Down DRAM data 11 RD10 Inout, Pull Up/Down...
Page 64
Symbol Type Description RD22 Inout, Pull Up/Down DRAM data 22 DVDD2 Power 2.5V power RD21 Inout, Pull Up/Down DRAM data 21 RD20 Inout, Pull Up/Down DRAM data 20 RD19 Inout, Pull Up/Down DRAM data 19 RD18 Inout, Pull Up/Down DRAM data 18 DVSS Ground Ground...
Page 65
Symbol Type Description PDMVDD3 Power Power for PDM circuitry PWMVREF Analog Input A reference voltage input for PWM circuitry. A typical value of 2.8 v PWM2VREF Analog Input A reference voltage input for PWM circuitry. A typical value of 1.4 v PDMVSS Ground Ground for PDM circuitry...
CS4340(AUDIO D/A) IC MATERIAL DECAL MUTEC SDATA AOUTL SCLK/DEM1 AGND LRCK AOUTR MCLK FRF_GND DIF1 DIF0 DEM0 FILT+ PIN FUNCTION DESCRIPTION Pin Name # Pin Description 1 Reset(Input)-Powers down device. SDATA 2 Serial Audio Data(Input)- Input for two's complement serial audio data. SCLK 3 Serial Clock(Input)-Serial clock for the serial audio interface.
PIN FUNCTION DESCRIPTION Pin Name Pin # Type Description PD<7 -0> 11-16 Multiplexed Cb, Y, and Cr digital video input bus. 18-19 HSYN In Slave Mode (MSTR pin is low) Horizontal Synch input. In Master Mode (MSTR pin is high) Horizontal Synch output. VSYN In slave mode (MSTR pin is low) Vertical Sync input.
Page 69
Serial bus clock Serial bus address and data input and output pin. Open drain output. General Purpose Clock. Clock frequency is determined by the state of GOUT[1:0] when RST pin is low. 00 : 40.5 MHz clock output. 0 1: 54.0 MHz clock output. 1 0: 67.5 Mhz clock output.
CONTROL PANEL IC MATERIAL DECAL 39 Grid 38 Grid 37 Grid 36 Seg /Grid 35 Seg /Grid 34 V 33 V 32 Seg /Grid 31 Seg /Grid 30 Seg /Grid 29 Seg /Grid 28 Seg /Grid 27 Seg /Grid PIN FUNCTION DESCRIPTION Symbol Pin Name Description...
16M SDRAM IC MATERIAL DECAL DQ15 DQ15 DQ14 DQ14 VSSQ VSSQ DQ13 DQ13 DQ 12 DQ 12 VDDQ VDDQ DQ11 DQ11 DQ10 DQ10 VSSQ VSSQ VDDQ VDDQ 50pin TSOP II 50pin TSOP II VDDQ VDDQ 400mil x 825mil 400mil x 825mil LDQM LDQM 0.8mm pin pitch...
Page 73
PIN FUNCTION DESCRIPTION PIN NAME DESCRIPTION The system clock input. All other inputs are referenced to the SDRAM on the Clock rising edge of CLK. Controls internal clock signal and when deactivated, the SDRAM will be one Clock Enable of the states among power down, suspend or self refresh. Chip Select Command input enable or mask except CLK, CKE and DQM Bank Address...
