Summary of Contents for Universal Remote Control KP-900i
- Page 1 Operating Your System With The KP-900i Wireless Keypad/Remote...
- Page 2 The information in this owner’s manual is protected by the copyright laws of the United States and other countries. No part of this manual may be copied or reproduced in any form without prior written consent from Universal Remote Control, Inc.
-
Page 3: Table Of Contents
Optional RF “No Rules” Operation Relocating the Wall Bracket Installing Batteries Programming the KP-900i Selecting a New “Activity” Using the KP-900i to Control an “Activity” Displaying the Setup Screen Selecting from the Setup Screen Setting the LCD Light Settings Sound Volume... -
Page 4: Introduction
WNERS ANUAL Congratulations! You’ve purchased a unique wireless control. The KP-900i can be used as both a wall mounted keypad and as a hand-held remote control. The KP-900i achieves a magnificent combination of power and flexibility, simplifying and automating operation of even the most complex home theater system. -
Page 5: Optional Rf "No Rules" Operation
In combination with a Complete Control RF Base Station, the KP-900i can control your system without being in line-of-sight of the equipment. On the wall or off, that means that you never need to point the KP-900i. The MSC-400, the MRF-350i and the MRF-260i RF base stations are compati- ble with the KP-900i. -
Page 6: Relocating The Wall Bracket
Relocating the Wall Bracket A professional installer has the expertise and materials to mount the KP- 900i to any kind of wall material. The KP-900i includes a wall bracket, four screws and four plastic caps to conceal the screwheads. The included screws may not be appropriate for your walls. -
Page 7: Programming The Kp-900I
We highly recommend that you use a professional audio/video installer to program your KP-900i so you will be able to enjoy all the benefits of the KP-900i as well as one touch operation via macros. -
Page 8: Selecting A New "Activity
Selecting a New “Activity” The KP-900i’s MAIN button displays the activities you can control with your KP-900i. When you want to listen to the radio or to a CD, touch the MAIN button and select what you would like to listen to. -
Page 9: Using The Kp-900I To Control An "Activity
LCD the page number is dis- Press the PAGE but- played. ton to use the other pages of LCD labeled buttons. All of the KP-900i’s hard buttons change their function and now control the selected activity. Page 6... -
Page 10: Displaying The Setup Screen
ANUAL Displaying the Setup Screen You can adjust the settings of the KP-900i whenever you like by pressing and holding both the MAIN and the SELECT buttons at the same time for three seconds. When you do, the screen will change to the SETUP screen. If you do not press any button on the SETUP screen within 30 seconds, the KP-900i will time out and automatically return to normal operation. -
Page 11: Setting The Lcd
ANUAL Setting the LCD With these settings, you can set the KP-900i to constantly display the LCD when not in use, or show a blank screen when not in use. Additionally, you can control the contrast of the screen and the color of the backlighting. - Page 12 KP-900i O WNERS ANUAL Setting LCD Contrast You can adjust the contrast of the LCD screen using the LEFT and RIGHT arrow keys once the LCD contrast screen has been selected (shown on the previous page). The current CONTRAST is displayed here via a bar graph.
-
Page 13: Light Settings
LEFT and RIGHT keys as shown in the previous pages. Sound Volume Your KP-900i beeps whenever a button is pressed. However, you can adjust the volume of the beep to one of four levels as shown here: SLIGHT BEEP... -
Page 14: System Settings
KP-900i O WNERS ANUAL System Settings You can set your KP-900i to display the Low Battery warning at a power level between 0% and 20% (in 5% increments). The Power bar indicates avail- able power with Black. Press here to adjust the battery warning level. -
Page 15: Factory Default
It will be neccessary to reinstall the original configuration file using a windows PC equipped with KP-900i Editor and a copy of the original file. Press here to erase your config- uration and load the factory configuration. -
Page 16: Limited Warranty Statement
Limited Warranty Statement 1. Limited Warranty and Disclaimers Universal Remote Control, Inc. (“URC”) warrants that the URC equipment shall be free from defects in material and workmanship under normal usage for one (1) year from purchase when such is purchased from URC. This limited warranty is valid only in the United States of America. - Page 17 KP-900i O WNERS ANUAL WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER PROVISIONS HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE FROM MISUSE, NEGLECT OR ACTS OR NATURE, (II) MODIFICATIONS, (III) INTEGRATION WITH THIRD PARTY CONTENT (IV) BEYOND THE WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW URC WARRANTY CLAIM PROCEDURE.
-
Page 18: End User Agreement
KP-900i O WNERS ANUAL programmable remotes or any of our Total Control® whole-house equipment online means buying equipment that does not have a URC’s limited warranty. Such equipment is not eligible for URC tech support or software support, either. 2. URC’S Limitations of Liability... -
Page 19: Specifications
RF Frequency: 433.92 MHz Weight: 14 ounces (with batteries) Size (KP-900i only): 4-11/16” H x 5-7/16”” W x 9/16” D Size (KP-900i with the wall bracket): 4-5/8” H x 6-1/16”” W x 3/4” D Batteries: 4 AAA batteries Contact Us Need assistance or have questions? Our Customer Service Support Center is here to help. -
Page 20: Regulatory Information To The User
KP-900i O WNERS ANUAL Regulatory Information to the user n FCC Compliance statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential Installation. -
Page 21: Warning
: EN 55024 3) Low Voltage Directive lProduct safety : EN 60950-1 n Declaration of Conformity “Hereby, Ohsung Electronics co.Ltd, declares that this KP-900i is in compliance with the Essential requirements and other relevant provi- sions of Directive 1999/5/EC.” Certification Type No.(Model No.) -
Page 22: Notes: Your Activities
KP-900i O WNERS ANUAL Your Activities Describe the inputs you must set to watch or listen to TV, DVD etc. in your home entertainment system. Activity (Watch TV, Watch DVD etc.) TV Input Audio Input... - Page 24 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com OCE-0063B Rev03...
