  • Page 1 Owner's Manual TKP-7000 Network Keypad...
  • Page 2 THIS MANUAL. The information in this owner’s manual may be subject to change without prior notice. URC - Control the Experience is a registered trademark of Universal Remote Control, Inc. Total Control is a registered trademark of Universal Remote Control, Inc.

  • Page 3: Table Of Contents

    Introducing the TKP-7000 Installing the TKP-7000 Installation Main Menu Navigation Rooms Menu Time & Weather Module Shortcuts Pop-Up Adjusting User Settings on the TKP-7000 Rebooting Your TKP-7000 Specifications Limited Warranty Statement End User Agreement Federal Communication Commission Interference Statement Regulatory Information to the user...

  • Page 4: Introducing The Tkp-7000

    TKP-7000 Introducing the TKP-7000 Thanks for purchasing URC's TKP-7000 in-wall touch-screen. Its easy, intuitive use will help simplify your life while adding control of more things than you thought possible. Enjoy some key features like: Rooms Menu With the touch of a single button, take control of your domain.
  • Page 5 TKP-7000 Capacitive Touch screen Navigation just became easier; it's as simple as a “swipe” or “flick”. By incorporating gesture control, every screen can be explored by simple finger swipes while the on-board accelerometer supports flicking. Time & Weather Module A simple button press opens the Time & Weather Module; a full screen display keeping you “up to date”...

  • Page 6: Installing The Tkp-7000

    The TKP-7000 is wall-mountable and fits easily into a dual-gang opening. Prior to installation, make sure power is available at the preferred location. Power can be supplied to the TKP-7000 in any of the following ways: An Ethernet cable connected to a PoE (power over ethernet)

  • Page 7: Installation

    1. Make sure the dual-gang opening is fitted with a standard two- gang trim box (available from the local electrical supplier/store) 2. Connect the Ethernet cable to the rear of the supplied TKP-7000 wall-plate. 3. Mount the wall-plate to the two-gang retro-box 4.

  • Page 8: Main Menu Navigation

    TKP-7000 Main Menu Navigation Although specific screen design and certain options will be dictated by the custom integrator that programmed the Total Control System, the general layout will remain the same. Actual navigation is performed through screen swipes (Up/Down, Left/Right) while selecting any item is as simple as pressing the icon/text to be selected.
  • Page 9 TKP-7000 Title Bar The Title Bar will be present on all TKP-7000 screens and contains valuable information during normal use. Easily find out the time, weather, now playing information and the room that the keypad is controlling. Time & Weather This data, found on the left-hand side of the Title Bar will show the current time, date and weather information.
  • Page 10 TKP-7000 Now Playing Appearing on the right-hand side of the Title Bar, this displays the source that is currently being used in the room that the keypad is controlling. • The Now Playing display will show the device that is being used (in this case, William's iPod), associated artwork, and metadata information is displayed since it is a URC media device.
  • Page 11 TKP-7000 Categories/Devices Ribbon This ribbon will show the various categories of control that are available to the selected room. The quantity of categories is determined by the system setup and can vary from one to however many categories were programmed by the system designer.
  • Page 12 TKP-7000 Status Bar The Status Bar, located directly above the Core Buttons, provides valuable status and feedback of the Total Control system. The four sections of the Status Bar are determined by the system programmer, and are customizable per keypad,so it is not possible to explain how your keypad looks;...
  • Page 13 Vol-, Vol+ & Mute These audio controls will affect the volume for the room to which the TKP-7000 is assigned. See the Rooms Menu section of this manual for more details. Main Selecting this button will always return the user to the Main screen...
  • Page 14 TKP-7000 Power When pressed, this performs the Room Off function programmedby the custom integrator. If this button is pressed for greater than 3 seconds, the Power Menu appears. In this menu, it is possible to: • Turn Off the ROOM (this is the same as tapping the Power button).

  • Page 15: Rooms Menu

    TKP-7000 Rooms Menu The Rooms Menu is the “landing” screen for a TKP-7000. This menu (see picture below) will be displayed whenever the keypad reboots, loses/regains power or is reset. The most common choice would be to select the room where the TKP-7000 is physically located, however, as we will discover, this is up to the user.
  • Page 16 The Exit button will return the user to the previous screen. Selecting a Room (Room Control) Selecting any room from the room list will allow the TKP-7000 to control that room, as if it were physically in that room. Returning the keypad to control the room where it is physically located requires accessing the Rooms Menu and selecting the appropriate room.
  • Page 17 TKP-7000 Linking Rooms (DMS Audio only) Selecting the Link Rooms button will open up the Link Rooms screen with the current room already selected. Only rooms/areas that are part of the DMS family of products will appear. Select, using the check boxes, the rooms that you would like to LINK.
  • Page 18 TKP-7000 Using Linked Rooms Once a room is linked, pressing the volume or mute buttons for that room will cause the Linked Rooms Volume Pop-Up to display All Linked Rooms This menu will display the volume levels for all rooms in the temporary group.

  • Page 19: Time & Weather Module

    TKP-7000 opens the Time & Weather Module. Selecting Exit will return to the previous screen Selecting Night Mode will place the TKP-7000 into a low light mode to prevent it from overpowering a dark room. This mode will disable any photo slideshow or screen time-out time andremain in this mode until touched again.

  • Page 20: Shortcuts Pop-Up

    Core Menu. If the screen is not touched, after 60 seconds the Shortcut Popup will close and the TKP-7000 will revert to its previous screen. Selecting a shortcut is the same as navigating to that same icon (within the submenu) and selecting it.
  • Page 21 TKP-7000 Select up to 6 devices/activities by selecting the check box shown for each possibility. Once all 6 are chosen, the remaining devices/activities will be grayed out to show there are no more choices to be made. Reorder devices by selecting the reorder icon at the top of the Add/Edit window;...

  • Page 22: Adjusting User Settings On The Tkp-7000

    System: Quickly view the Memory Usage, Firmware Version and other details about the TKP-7000. Network: View information about the current network as well as set a Dynamic or static IP address for the TKP-7000. Factory Default: Reset the TKP-7000 to factory settings. Page 19...
  • Page 23 TKP-7000 Sleep Settings Decide upon the option that best fits the current needs. LCD Screen is always ON: This option keeps the LCD screen illuminated at all times LCD Screen will turn OFF: This option allows the user to decide on the amount of time that the LCD screen will remain illuminated after it is last used.
  • Page 24 TKP-7000 General The General settings screen allows for setting the Time, Date and decide on the scale used to display the temperature(Fahrenheit/Celsius). To view the rest of the General settings menu, be sure to scroll up/down. Using the arrow found at the left and right sides of each property (hour, minutes, month, etc.) adjusts the value up, or down, respectively.
  • Page 25 TKP-7000 Sound By default, the TKP-7000 emits a low volume beep as a confirmation tone for screen presses. Use this menu to adjust thesound to your liking. Use the + or – buttons to raise or lower the volume of the confirmation beep.
  • Page 26 TKP-7000 Brightness Determine the overall brightness of the TKP-7000's display, or incorporate a light sensor that will adjust the brightness of the unit based upon ambient room lighting. Use the + or – buttons to raise or lower the level of brightness.
  • Page 27 TKP-7000 Vibration Use this menu to adjust the TKP-7000’s touch screen sensitivity level. Use the + or – buttons to raise or lower the sensitivity level. Selecting OK will accept any changes made and return to the Main menu, as well as selecting Cancel will return the user to the Main menu, without incorporating any changes.
  • Page 28 TKP-7000 System Although none of the information can be modified, these System Pages will show important information about your TKP-7000. These pages should only be needed by a custom install professional, or technical support. Page 25...
  • Page 29 • Obtain an IP address automatically: this uses the DHCP method of IP addressing • Use the following address: this option requires that the Static address of the keypad, as well as other network information be entered. This is the recommended method to connect the TKP-7000 Page 26...

  • Page 30: Factory Default

    This should only be attempted by a custom install professional that is familiar with Total Control, or under instruction from the manufacturer. Selecting this option will reset the TKP-7000 to factory default and the unit WILL NOT work until reprogrammed!

  • Page 31: Rebooting Your Tkp-7000

    TKP-7000 Rebooting Your TKP-7000 Using the physical RESET button found on the silver keypad bezel (bottom right-hand corner) will power-cycle the unit. This is the first option to try, if the screen freezes or the unit becomes unresponsive. Reset button...

  • Page 32: Limited Warranty Statement

    Limited Warranty Statement 1. Limited Warranty and Disclaimers Universal Remote Control, Inc. (“URC”) warrants that the URC equipment shall be free from defects in material and workmanship under normal usage for one (1) year from purchase when such is purchased from URC. This limited warranty is valid only in the United States of America.
  • Page 33 TKP-7000 WITHOUT IN ANY WAY LIMITING THE GENERALITY OF THE OTHER PROVISIONS HEREIN, WARRANTY DOES NOT COVER: (I) DAMAGE FROM MISUSE, NEGLECT OR ACTS OR NATURE, (II) MODIFICATIONS, (III) INTEGRATION WITH THIRD PARTY CONTENT (IV) BEYOND THE WARRANTY PERIOD AND/ OR FAILURE TO FOLLOW URC WARRANTY CLAIM PROCEDURE.

  • Page 34: End User Agreement

    TKP-7000 URC’s PC programmable remotes or any of our Total Control® whole-house equipment are authorized for online internet sales. Buying URC’s PC programmable remotes or any of our Total Control® whole-house equipment online means buying equipment that does not have a URC’s limited warranty.

  • Page 35: Federal Communication Commission Interference Statement

    TKP-7000 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 36: Regulatory Information To The User

    : EN 55024 lPower : EN-61000-3-2, 3 n Declaration of Conformity “Hereby, Universal Remote Control Inc. declares that this TKP-2000 is in compliance with the Essential requirements and other relevant provisions of EMC Directive 2004/108/EC.” Certification Type No.(Model No.) TKP-7000 Batch/Serial No.

  • Page 37: Declaration Of Conformity

    TKP-7000 Declaration of Conformity Company Name Universal Remote Control Inc. Company Address 500 Mamaroneck Avenue, Harrison, NY 10528, U.S.A www.universalremote.com Contact Information Phone: (914)835-4484 Fax: (914)835-4532 Brand Name UNIVERSAL remote control Product Name Network Keypad Model Name TKP-7000 This product herewith complies with the requirements of EMC Directive (2004/108/EC)
  • Page 38 Page 35...
  • Page 40 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com OCE-0130A Rev 02...
