HOBIE H14 / H16
REPLACEMENT HULL H16 WHiTE - LEfT 25010001
REPLACEMENT HULL H16 WHiTE - RigHT 25020001
H16 ANCHoR PiN
vENT TUbE 10140000
20100000
foAM PLUg 10060000
H16 ANCHoR bAR 50101701
UPPER gUdgEoN 50101301
SCREW 8030401
CAST gUdgEoN (H16)
50102011
LoWER gUdgEoN 50101401
SCREW 8030401
dRAiN HoUSiNg 10092000
SCREW 8031731
dRAiN gASKET 10092025
dRAiN PLUg
W / gASKET 10091000
H14 / H16 tRAmpOlInE, sIdEBAR
H14 CoMPLETE TRAMPoLiNE
(does not include lace lines)
1097XXXX
(XXXX = Color / See parts list for
available options)
CENTER LACiNg LiNE RH014WHT X 20'
REAR (AfT) LACiNg LiNE RH014WHT X 15' (x2)
LACiNg STRiP 1378XXXX
48 HOBIE 14 / 16
SCREW
8030301
boW TANg 20120000
(oRigiNAL H14 TANg NLA)
NUT 8050311
(NoT oN H14)
CoTTER PiN
8060111
RUddER pIn
NyLoN 10881000
ALUMiNUM 20880001
STAiNLESS STEEL 20880011
fibERgLASS 5051
H16 CoMPLETE TRAMPoLiNE
(does not include lace line)
2097XXXX
(XXXX = Color / See parts list for
available options)
H14 / H16 FROnt CROssBAR
H14 bLACK fRoNT CRoSSbAR W/MAST STEP 10131910
H16 bLACK fRoNT CRoSSbAR W/MAST STEP / iNTEgRATEd TRACK 25131910
See Original Jib Car Options on page 22
Jib SHEET CAR Jib SHEET CAR
W/bLoCK W/SWivEL
21230000 CLEAT
1075
ENd SToP 20260000
SCREW 8031501
H14 bLACK MAST STEP UNdRiLLEd 10170011
H16 bLACK MAST STEP 20200011
Jib SHEET bLoCK TRACK 20250000
fAiRLEAd REPLACEMENT KiT 11952021
SWivEL CAM CLEAT ASSEMbLy
'09 Jib TRAvELER CoNTRoL
50007 SEE PAgE 22
Rf5001 CLEAT
doLPHiN STRiKER
Rf5004 gUidE
PoST 20140001
Rf5005 fAiRLEAd
8030241 SCREW
NUT 8050511
PyLoN boLT
H14 8040371
H16 (oLd) 8040731
H16 (NEWER) 8040361
LEfT (PoRT) fRoNT CoRNER CASTiNg bLACK 10152011
* Starting in '95 boats had newer style castings / pylons.
H14 / H16 REAR CROssBAR
CRoSSbAR EXRTRUSioN w/ iNTEgRATEd TRACK, REAR (AfT)
WiTHoUT CoRNER CASTiNgS, bLACK - iNCLUdES CAR ACCESS PLATE
H16 25191911
H14 10191910
TRAvELER TRACK (dEEP oNLy)
bLACK 50252021
fAiRLEAd REPLACEMENT KiT
11952021
CLEviS PiN 8020041
AdJUSTER RiNg
10860001
TRAvELER CAR ASSy. 105
NEW STyLE ('94 Newer) 111
* Not all '94 boats had newer style castings / pylons.
PyLoN boLT
H14 8040371
H16 (oLd) 8040731
H16 (NEWER) 8040361
bLACK LEfT REAR CoRNER CASTiNg 10212011
iNTEgRATEd TRACK STyLE
25232201 CAR PoRT
25232211 CAR STARboARd
SLidE oNLy 25243003
PLATE oNLy 25244001
3 MAST PivoT
Jib CAR SToP 25231051
bEARiNgS
SCREW 8031501
11110005
SWivEL CLEAT bASE PAd
1162 SEE PAgE 22
H16 doLPHiN STRiKER Rod 20170001
H14 doLPHiN STRiKER Rod 11170030
PyLoN NUT
H14 8050321
H16 (oLd) 8050631
H16 (NEWER) 8050521
RigHT (STbd) fRoNT CoRNER CASTiNg bLACK 10162011
*fRoNT CoRNER CASTiNg
Jib TRAvELER SHEAvE
SHEAvE 60620000
RivET 8011251
'94 ANd NEWER CAR ACCESS PLATE 11810011
SWivEL CAM 50007
PAdEyE 11470000
PAd foR CAM CLEAT
1162 SEE PAgE 22
SCREW 8030111
dECK PLATE 11870000
SPACER 11860000
SHEAvE 11880000
HiNgE 11840100
NUT 8050201
HiNgE WiRE 11850000
LoWER RoLLER UNiT 106
NEW STyLE ('94 Newer brass) LoWER 112
PyLoN NUT
H14 8050321
H16 (oLd) 8050631
H16 (NEWER) 8050521
bLACK RigHT REAR CoRNER CASTiNg 10202011
NUT 08050511
CRoSSbAR
iNTEgRATEd TRACK
STyLE
