AX4S-U/AX4S Plus-U
DOC. NO.: AX4SPLUSU-OL-E0211A
1

Advertisement

Table of Contents
loading

Related Manuals for AOpen AX4S-U

Summary of Contents for AOpen AX4S-U

  • Page 1 AX4S-U/AX4S Plus-U DOC. NO.: AX4SPLUSU-OL-E0211A...

  • Page 2: Table Of Contents

    ’ ’ AX4S-U/AX4S Plus-U ........................1 What’s in this manual ..............................2 You Must Notice ................................8 Before You Start ................................9 Overview ..................................10 Feature Highlight ................................11 Quick Installation Procedure ............................14 Motherboard Map ................................15 Hardware Installation ........................16 About “User Upgrade Optional” and “Manufacture Upgrade Optional”… ...............17 CPU Installation................................18...
  • Page 3 AC Power Auto Recovery ..............................26 IDE and Floppy Connector ............................27 ATA100 Supported.................................29 PC99 Color Coded Back Panel............................30 Connecting 68pin Ultra320 SCSI Cable (AX4S Plus-U Only)..................31 Support Two USB1.1 Channels (four Ports)........................33 Resettable Fuse ................................35 Low ESR Capacitor ...............................36 Driver and Utility........................37 BIOS Setup Utility ........................38 Entering Setup................................39 System Information................................42...
  • Page 4 Disk Drives Over 1 GByte ............................118 When to Use the Extended Translation........................119 Glossary ...........................120 AC97 ...................................120 ACPI (Advanced Configuration & Power Interface)......................120 AGP (Accelerated Graphic Port) ..........................120 AMR (Audio/Modem Riser) ............................121 AOpen Bonus Pack CD ...............................121 APM (Advanced Power Management) .........................121 ATA (AT Attachment)..............................121...
  • Page 5 ATA/66 ..................................121 ATA/100 ..................................122 BIOS (Basic Input/Output System) ..........................122 Bus Master IDE (DMA mode)............................122 CNR (Communication and Networking Riser) ......................122 CODEC (Coding and Decoding) ..........................123 DDR (Double Data Rated) SDRAM..........................123 DIMM (Dual In Line Memory Module) ..........................123 DMA (Direct Memory Access) ............................123 ECC (Error Checking and Correction)..........................124 EDO (Extended Data Output) Memory.........................124 EEPROM (Electronic Erasable Programmable ROM) ....................124...
  • Page 6 IEEE 1394 ...................................126 Parity Bit..................................127 PBSRAM (Pipelined Burst SRAM) ..........................127 PC-100 DIMM ................................127 PC-133 DIMM ................................127 PC-1600 or PC-2100 DDR DRAM ..........................127 PCI (Peripheral Component Interface) Bus........................128 PDF Format .................................128 PnP (Plug and Play) ..............................128 POST (Power-On Self Test) ............................128 RDRAM (Rambus DRAM)............................129 RIMM (Rambus Inline Memory Module)........................129 SDRAM (Synchronous DRAM) ............................129...
  • Page 7 VCM (Virtual Channel Memory) ...........................132 ZIP file ..................................132 Troubleshooting ........................133 Technical Support........................137 Product Registration .......................140 How to Contact Us........................141...

  • Page 8: You Must Notice

    All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that may appear in this manual, including the products and software described in it.

  • Page 9: Before You Start

    This Online Manual will introduce you how this product is installed. All useful information will be described in later chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved in format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc or you can get free download from...

  • Page 10: Overview

    320MB/s (AX4S Plus-U only). The AX4S-U/AX4S Plus-U also integrates Intel® 82540 GbE PCI Ethernet controller that supports 1 Gbites function for better remote site management. According to different customer’s requirements, the chipset memory interface supports ECC DDR SDRAM devices with densities of 64, 128, 256, 512Mb, and 1Gb DDRAM DIMM modules and the maximum memory size can be up to 4GB.

  • Page 11: Feature Highlight

    ® Supports Intel Pentium4 1.7GHz above with FSB400/533MHz (Front Side Bus) designed for Socket 478 technology. Chipset ® ® With Intel Server Works GC-SL chipset is designed for use with the Intel Pentium4 processor in the 478-pin package. It is ®...

  • Page 12: Video Subsystem

    Video Subsystem The ATI Rage XL harbors 2D and 3D display capacities that bring life to any multimedia and work applications. With a remarkable color depths and high resolutions of up to 1280*1024 for an enhanced visual experience on your system. The on-board ATI Rage XL chipset comes with 8MB of video memory and supports up to 1280*1024 display mode at high colors with a maximum of 8MB video memory option.
  • Page 13 Power Management/Plug and Play Supports the power management function that conforms to the power-saving standards of the U.S. Environmental Protection Agency (EPA) Energy Star program. It also offers Plug-and-Play, helping save users from configuration problems and makes the system user-friendly. Hardware Monitoring Management Supports CPU or system fans’...

  • Page 14: Quick Installation Procedure

    This page gives you a quick procedure on how to install your system. Follow each step accordingly. Installing CPU and Fan Installing System Memory (DIMM) Connecting Front Panel Cable Connecting IDE and Floppy Cable Connecting ATX Power Cable Connecting Back Panel Cable Power-on and Load BIOS Setup Default Setting CPU Frequency Reboot...

  • Page 15: Motherboard Map

    Motherboard Map ® Intel 82540 GbE Ethernet Controller PC99 Colored Back Panel ATI RageXL Controller Housing Fan3 with Monitoring Function 32bit/33MHz PCI Slot Resettable Fuse Buzzer 184-pin DIMM Sockets x4 supporting DDR200/266 DDR RAM Housing Fan2 with Monitoring 604-pin CPU socket x2 Function ®...

  • Page 16: Hardware Installation

    This chapter describes jumpers, connectors and hardware devices of this motherboard. Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. Always observe the following precautions before you install a system component. Do not remove a component from its protective packaging until you are ready to install it. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a component.

  • Page 17: About "User Upgrade Optional" And "Manufacture Upgrade Optional

    When you read this online manual and start to assemble your computer system, you may notice that some of the functions are marked as “User Upgrade Optional” or “Manufacture Upgrade Optional”. Although all of AOpen’s motherboards have included many amazing and powerful features, sometimes not every user is familiar with these powerful features. As a result of this we define features that can be upgraded by users as “User Upgrade Optional”.

  • Page 18: Cpu Installation

    ® This motherboard supports Intel Pentium4 Socket 478 series CPU. Be careful of CPU orientation when you plug it into CPU socket. CPU socket lever Pull up the CPU socket level and up to 90-degree angle. Locate Pin 1 in the socket and look for a (golden) cut edge on the CPU upper interface.

  • Page 19: Installing Cpu And Housing Fans

    Plug in the CPU fan cable to the 3-pin CPU FAN connector and housing fan cable to the HFan connectors. +12V +12V SENSOR SENSOR CPU FAN HFan 3 +12V +12V SENSOR SENSOR HFan 1 HFan 2 Note: Some CPU fans do not have sensor pin, so that cannot support fan monitoring.

  • Page 20: Jp14 Clear Cmos Data Jumper

    You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. Turn off the system and unplug the AC power. Remove ATX power cable from connector PWR2. Locate JP14 and short pins 2-3 for a few seconds. Return JP14 to its normal setting by shorting pin 1 &...
  • Page 21 If the BIOS flash procedure is done improperly, the BIOS code can become corrupted, which will cause the system to go into an unbootable state. The system come with a feature where a 4 KB "boot block" program is included as part of the BIOS. This is a tiny piece of code whose job it is to recover from a situation where the BIOS code is incorrect or corrupted.

  • Page 22: Dimm Sockets

    DDR200 /DDR266 This motherboard has four 184-pin DDR DIMM sockets that allow you to install memory up to 4GB. ECC DDR RAM is supported. DIMM 1 DIMM 2 DIMM 3 DIMM 4...
  • Page 23 Please follow the procedure as shown below to finish memory installation. Make sure the DIMM module’s pin face down and match the socket’s size as depicted below. Pin 1 52 pins 40 pins Insert the module straight down to the DIMM slot with both hands and press down firmly until the DIMM module is securely in place.

  • Page 24: Front Panel Connector

    Attaching such as power switch, reset switch, HDD LED connector, etc to corresponding pins. Locate the power switch cable from your ATX housing. It is 2-pin female connector from the housing front panel. Plug this connector to the soft-power switch connector marked SPWR. Reset Switch Power Switch...

  • Page 25: Atx Power Connector

    This motherboard comes with a 20-pin and 4-pin ATX power connector. Make sure you plug in the right direction. We strongly recommend you to connect the 4-pin 12V ATX connector before connecting the 20-pin ATX power connector...

  • Page 26: Ac Power Auto Recovery

    A traditional ATX system remains at power off stage when AC power resumes from power failure. This design is inconvenient for a network server or workstation without an UPS. This motherboard implements an AC Power Auto Recovery function to solve this problem.

  • Page 27: Ide And Floppy Connector

    Connect 34-pin floppy cable and 40-pin, 80-wire IDE cable to floppy connector FDC and IDE connector. Be careful of the pin1 orientation. Wrong orientation may cause system damage. Pin1 IDE 2 Channel IDE 1 Channel Pin1 Connector...
  • Page 28 Each channel supports two IDE devices that make a total of six devices. In order to work together, the two devices on each channel must be set differently to Master and Slave mode. Either one can be the hard disk or the CDROM. The setting as master or slave mode depends on the jumper on your IDE device, so please refer to your hard disk and CDROM manual accordingly.
  • Page 29 This motherboard supports ATA66 ATA100 IDE devices. Following table lists the transfer rate of IDE PIO and DMA modes. Mode Clock Period Clock Count Cycle Time Data Transfer Rate PIO mode 0 30ns 600ns (1/600ns) x 2byte = 3.3MB/s PIO mode 1 30ns 383ns (1/383ns) x 2byte = 5.2MB/s...
  • Page 30 The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, COM1/COM2, VGA, Printer and USB1.1. The view angle of drawing shown here is from the back panel of the housing. 1 GbE Ethernet SPP/EPP/ECP Parallel Port PS/2 Mouse Port Connector COM 1 Port COM 2 Port USB1.1 VGA Port...
  • Page 31 The motherboard provides one 68-pin Ultra320 SCSI connectors for 16-bit or 16-bit differential SCSI devices. The Adaptec AIC-7901X controller provides 160MB/sec maximum data throughput per channel available.
  • Page 32 A ZCR card is a PCI card that allows a RAID card to use the onboard SCSI chip, thus lowering cost of RAID solution. A "Zero-channel" RAID adapter is a PCI RAID controller that doesn't have any SCSI channels on board. Instead, it is designed to use the on-board SCSI channels of the motherboard to implement a cost-effective hardware RAID solution.

  • Page 33: Support Two Usb1.1 Channels (Four Ports)

    This motherboard provides two channels to link USB devices, such as mouse, keyboard, modem, printer, etc. There are two connectors on the PC99 back panel. You can use proper cable to connect other USB connectors to the back panel or front panel of chassis.
  • Page 34 The Intel 82540EM integrates Intel’s fourth-generation Gigabit MAC design with fully integrated, physical-layer circuitry to provide a standard IEEE 802.3 Ethernet interface for 1000BASE-T and 100BASE-TX applications. The left green LED indicates the link mode, it lights when linking to network and blinking when transferring data. The right green LED indicates the transfer mode, and it lights when data is transferring in 1Gbps/100Mbps mode.

  • Page 35: Resettable Fuse

    Traditional motherboard uses fuses to prevent Keyboard and port from over-current or shortage. These fuses are soldered onboard that when it is broken (function to protect motherboard), user cannot replace them and result in malfunction of motherboard. With expensive Resettable Fuse, the motherboard can be resumed back to normal function even after the fuse had done its protection job.

  • Page 36: Low Esr Capacitor

    The quality of low ESR capacitor (Low Equivalent Series Resistance) during high frequency operation is very important for stability of CPU power. The location of where to put these capacitors is another know-how that requires experience and detail calculation.

  • Page 37: Driver And Utility

    There are motherboard drivers and utilities included in AOpen Bonus CD. You don’t need to install all of them in order to boot your system. But after you finish the hardware installation, you have to install your operation system first before you can install...

  • Page 38: Bios Setup Utility

    Most of system had already configured by the manufacturer or the dealer. There is no need to run BIOS setup program when starting the computer unless you get a run setup program message. The setup program loads configuration values into the battery-backed nonvolatile memory called CMOS RAM.

  • Page 39: Entering Setup

    The system will reboot immediately after you exit Setup. To enter Setup, press the DELETE key. You must press DELETE while the system is booting. This key does not work during any other time. The Setup Utility Main Menu appears:...
  • Page 40 The system supports two BIOS Utility levels: Basic and Advanced. If you are an advanced user, you may want to check the detailed configuration of your system. Detailed system configurations are contained in the Advanced Level. To view the Advanced Level, press The asterisk (*) mark indicates that the parameter appears only when you are in the Advanced Level.
  • Page 41 The grayed items on the screens have fixed settings and are not user-configurable. Use the arrow keys to move around the Setup Utility screen. to move to the next page or to return to the previous page if the setup screen has more than one page available.

  • Page 42: System Information

    The following screen appears if you select System Information from the Main menu: The System Information menu shows the current basic configuration of your system. The sections below explain the parameters.

  • Page 43: Processor Speed

    Processor The Processor parameter specifies the type of processor currently installed in your system. The system supports Intel Xeon 1.8 GHz above. Processor Speed The Processor Speed parameter specifies the speed of the processor currently installed in your system. CPU/SDRAM BUS Frequency This parameter specifies the currently FSB (Front Side Bus) frequency of the CPU/SDRAM.
  • Page 44 Diskette Drive A This parameter specifies the system’s current diskette drive A settings. Diskette Drive B This parameter specifies the system’s current diskette drive B settings. IDE Primary Channel Master This parameter specifies the current configuration of the IDE device connected to the master port of the primary IDE channel.
  • Page 45 installed in DIMM sockets 1, 2, 3 and 4 respectively. The “None” setting indicates that there is no DRAM installed. Bank Type and Size of DRAM installed in DIMM socket 1, 2, 3 and 4 respectively. The “None” setting indicates that there is no DRAM installed. Serial Port 1 This parameter shows the serial port 1 address and IRQ setting.

  • Page 46: Product Information

    The Product Information contains the general data about the system, such as the product name, serial number, BIOS version, etc. This information is necessary for troubleshooting (may be required when asking for technical support). The following shows how the Product Information screen appears:...
  • Page 47 Product Name This parameter specifies the official name of the system. System S/N This parameter specifies the system’s serial number.

  • Page 48: Disk Drives

    Main Board ID This parameter specifies the motherboard’s identification number. Main Board S/N This parameter specifies the motherboard’s serial number. System BIOS Version This parameter specifies the version of the BIOS utility. SMBIOS Version This parameter specifies the version of the SMBIOS version. Select Disk Drives to input configuration values for disk drives.
  • Page 49 Floppy Drives To enter the configuration value for the first floppy drive, highlight the Floppy Drive A parameter. Press , key to view the options and select the appropriate value. Drive A/Drive B These items select the floppy drive type. The available settings and types...
  • Page 50 None supported by the motherboard are listed to the left. 360KB 5.25" 1.2MB 5.25" 720KB 3.5" 1.44MB 3.5" 2.88MB 3.5" Follow the same procedure to configure floppy drive B. Choose “None” if you do not have a second floppy drive. IDE Drives To configure the IDE drives connected to your system, select the parameter that represents the channel and port where the desired hard disk to configure is connected.
  • Page 51 Device Detection Mode Device Detection If you select “Manual”, you need to fill in all remaining field, such as Cylinder, Mode Head, and Sector on this selected item. If the item “Auto” is selected, the items will remain “0”. And when the system boot up, system will detect the Auto (Default) hard disk and configure it automatically.
  • Page 52 Cylinder This parameter specifies the number of cylinders of your hard disk, and is automatically set depending on your Type parameter setting. Head This parameter specifies the number of heads of your hard disk, and is automatically set depending on your Type parameter setting. Sector This parameter specifies the number of sectors of your hard disk, and is automatically set depending on your Type parameter setting.

  • Page 53: Onboard Peripherals

    Auto (Default) detects if the installed hard disk drive supports the Block Mode function. If supported, it allows data transfer in blocks (multiple sectors) at a rate Disabled of 256 bytes per cycle. To disregard the feature, change the setting to “Disable”.
  • Page 54 This page is the lower half of Onboard Peripherals submenu.
  • Page 55 Serial Ports 1 and 2 Serial Port 1 & 2 These parameters allow you to enable or disable serial ports 1 and 2. Enabled (Default) Disabled...
  • Page 56 Base Address Base Address This item allows you to assign address and interrupt for the board serial port. Serial Port 1: 3F8h (Default) 3E8h 2E8h Serial Port 2: 2F8h (Default) 2E8h 3E8h This function lets you assign an interrupt for serial ports 1 and 2.
  • Page 57 The Base Address and IRQ parameters for each port are configurable only if the port is enabled. Parallel Port Parallel Port This parameter allows you to enable or disable the parallel port. Enabled (Default) Disabled Base Address Base Address This item allows you to assign address and interrupt for the board serial port.
  • Page 58 This function lets you assign an interrupt for the parallel port. The options are IRQ 5 and 7. 7 (Default), 5 The Base Address and IRQ parameters are configurable only if Parallel Port is enabled. If you install an add-on card that has a parallel port whose address conflicts with the onboard parallel port, a warning appears on the screen.
  • Page 59 Setting Function Standard Parallel Port (Standard) Allows normal speed one-way operation Bi-directional Parallel Port Allows normal speed operation in a two-way (Bi-directional) mode Enhanced Parallel Port (EPP) Allows bi-directional parallel port operation at maximum speed Extended Capabilities Port (ECP) Allows parallel port to operate in bi-directional mode and at a speed higher than the maximum data transfer rate ECP DMA Channel...
  • Page 60 Onboard Device Settings The Onboard Device Settings menu allows you to configure the onboard communication ports and the onboard devices. Selecting this option from the Onboard Peripherals menu displays the following screen:...
  • Page 61 Floppy Disk Controller...
  • Page 62 Floppy Disk This parameter lets you enable or disable the onboard floppy disk Controller controller. Enabled (Default) Disabled IDE Controller IDE Controller Set this parameter to “Primary” to enable only the primary IDE controller; “Both” to enable both primary and secondary IDE Both (Default) controllers;...
  • Page 63 USB Host This parameter lets you enable or disable the USB controller on Controller board. When enabled, it activates the USB function of the system. When disabled, it deactivates the function. Enabled (Default) Disabled USB Legacy Mode USB Legacy Mode This parameter lets you enable or disable the USB controller on board.

  • Page 64: Power Management

    On-board This parameter allows you to enable or disable the onboard Ethernet Chip network feature. Enabled (Default) Disabled The Power Management menu allows you to configure the system power-management feature. The following screen shows the Power Management parameters and their default settings:...
  • Page 65 This page is the lower half of Power Management submenu.
  • Page 66 A parameter with an asterisk (*) mark indicates that the parameter appears only when you are using in the Advanced Level. See “Entering Setup” on Page...
  • Page 67 Power Management Mode Power This parameter allows you to reduce power consumption. Management When this parameter is set to “Enabled”, you can configure the Mode IDE hard disk and system timers. Setting it to “Disabled” deactivates the power-management feature and its timers. Enabled (Default) Disabled IDE Hard Disk Standby Timer...
  • Page 68 System Sleep This parameter sets the system to the lowest power-saving mode Timer after a specified period of inactivity. Any keyboard or mouse action or any activity detected from the IRQ channels resumes Off (Default) system operation. 120, 110, 100…20, 15, 10, 5, 2min Sleep Mode Sleep Mode...
  • Page 69 Power Switch < 4 sec. Power Switch < 4 When set to ”Power Off”, the system automatically turns off Sec. when the power switch is pressed for less than 4 seconds. When set to ”Suspend”, the system enters the suspend mode when Suspend pressed for less than 4 seconds.
  • Page 70 PCI Power This item allows you to enable or disable the PCI power Management management function. Enabled (Default) Disabled RTC Alarm RTC Alarm This item allows you to set a certain time on a certain day to wake-up the system from suspend mode. Enabled Disabled (Default) Resume Day...
  • Page 71 Resume Time This item is displayed when you enable the RTC Wake Up Timer option. Here you can specify what time you want to wake up the Hh:mm:ss system. Restart On AC/Power Failure Restart On When “Enabled”, the system automatically turns on when the AC/Power Failure power comes back.

  • Page 72: Boot Options

    This option allows you to specify your preferred setting for boot up. The following screen appears if you select Boot Options from the Basic Configuration menu:...

  • Page 73: Boot Sequence

    Boot Sequence This parameter allows you to specify the boot search sequence during POST. . The system checks this drive first. . The system then checks this drive if it can not boot from the 1 specified drive. . If the 1 and 2 searches fail then it boots from this drive.

  • Page 74: Silent Boot

    Silent Boot Silent Boot This parameter enables or disables the Silent Boot function. When set to ”Enabled”, BIOS is in graphical mode and displays Enabled (Default) only an identification logo during POST and while booting. After Disabled booting the screen displays the operating system prompt (such as DOS) or logo (such as Windows 95).
  • Page 75 Memory Test Memory Test When set to ”Enabled”, this parameter allows the system to perform a RAM test during the POST routine. When set to Enabled “Disabled”, the system detects only the memory size and Disabled (Default) bypasses the test routine. Release All Blocked Memory Release All When set to “Enabled”, this parameter allows system to bypass...

  • Page 76: Date And Time

    The real-time clock keeps the system date and time. After setting the date and time, you do not need to enter them every time you turn on the system. As long as the internal battery remains good (approximately seven years) and connected, the clock continues to keep the date and time accurately even when the power is off.
  • Page 77 Date Date Highlight the items on the Date parameter and press to set the date following the weekday-month-day-year ww:mm:dd:yy format. Valid values for weekday, month, day, and year are: Weekday: Sun, Mon, Tue, Wed, Thu, Fri, Sat Month: Jan, Feb, Mar, Apr, May, Jun, Jul, Aug, Sep, Oct, Nov, Dec Day: 1 to 31 Year:...

  • Page 78: System Security

    The Setup program has a number of security features to prevent unauthorized access to the system and its data. The following screen appears if you select System Security from the Main menu:...
  • Page 79 Supervisor Password Supervisor This item can prevent unauthorized access to the BIOS utility. Password The “Present” setting allows you to set a setup password. None (Default) Present...

  • Page 80: User Password

    Enable the Supervisor Password parameter in the System Security menu by pressing the ENTER key. The Supervisor Password windows will appear as shown above. Type a password. The password may consist of up to seven characters. Be very careful when typing your password because the actual characters do not appear on the screen.
  • Page 81 Disk Drive Control The disk drive control features allow you to control the floppy drive or the hard disk drive boot function to prevent loading operating systems or other programs from a certain drive while the other drives are operational (under DOS mode only). The table below lists the drive control settings and their corresponding functions.
  • Page 82 Write Protect Boot Sector Disables the write function only on the boot sector The system event log enables you to record and monitor events that occurs in your system like system temperature, fan stops, and others. This feature allows you to specify the appropriate settings for your system’s event handling.
  • Page 83 This page is the lower half of System Event Log submenu.
  • Page 84 System Event Logging This option allows you to record monitored events that occur during the operation of your system.
  • Page 85 Event Logging Event Logging This item allows you to enable or disable the system event logging function. Enabled (Default) Disabled Clear Event Logs Clear Event Logs This item allows you to enable or disable the system event logs clearing function. Please enable it if you want to clear the event Enabled log whenever the event log area is full.
  • Page 86 Available Space for Event Logs Available Space The percentage of space that is still available for logging system for Event Logs events. View Event Logs View Event Logs Opens the system event log file for viewing. Events Control This parameter monitors the following events and logs them into the event log file if there is a change in status.
  • Page 87 Temperature/Volta Enable or disable the monitoring of the system’s temperature, ge/ Fan voltage, and CPU fan. Enabled (Default) Disabled ECC or Error-Correcting Code tests the accuracy of data as it passes in and out of memory. This parameter enables or disables Enabled (Default) the monitoring of this function.
  • Page 88 Event Process Action After Critical Event Action After This parameter allows you to select the action after BIOS finds a Critical Event critical event. The critical events include multiple bits ECC error and PCI device error. NMI (Default) Power Cycle Reset POST Error Stop Post Error Stop...
  • Page 89 Threshold Event Control Threshold Event This parameter lets you enabled or disabled the threshold event Control control function. Enabled Disabled (Default) Temperature Threshold Setting This item allows you to set the CPU critical temperature value. User Input System System This item allows you to set the system critical temperature value. User Input...
  • Page 90 Voltage Threshold Setting Voltage Threshold This parameter lets you setting CPU core voltage lower critical Setting threshold value.
  • Page 91 Use this option to load the default settings for the optimized system configuration. When you load the default settings, some of the parameters are grayed-out with their fixed settings. These grayed parameters are not user-configurable. The following dialog box appears when you select Load Default Settings from the main menu: Select “Yes”...
  • Page 92 Use this option to disregard your changes to the BIOS and reload your previous settings. The following dialog box appears when you select Abort Settings Change from the main menu: Select “Yes” to disregard your changes and reload your previous settings. After reload, the main menu appears on screen.
  • Page 93 ™ ™ The SCSISelect™ utility allows you to change SCSI controller settings without opening the system or changing jumpers. The table below lists the settings that you can change using the SCSISelect™ utility and the default value for each setting. Some settings apply globally to the SCSI controller and all SCSI devices on the bus.
  • Page 94 Settings for the SCSI Controller and All Devices Item Default Host Adapter SCSI ID SCSI Parity Checking Enabled Host Adapter SCSI Termination Enabled Boot Device Option 0 (zero) Host Adapter BIOS * Enabled Support Removable Disks under BIOS as Hard Disks Boot only Extended BIOS Translation for DOS Drives >...
  • Page 95 Individual Settings for SCSI Drives Item Default Initiate Sync Negotiation Maximum Sync Transfer Rate 160MB/sec. Enable Disconnection Send Start Unit SCSI Command * Initiate Wide Negotiation When to Use the SCSISelect™ Utility Use the SCSI Select utility if you need to do any one of the following: Change any of the default values listed in the SCSI Controller and All Devices Table.
  • Page 96 ™ ™ A screen message giving the option to access the SCSISelect™ utility appears after the BIOS and POST routine. To start the utility, press + A when the following message appears during power-on or system reset: Press <Ctrl> <A> for SCSISelect Utility! Your screen may show the key sequence as + <Hot Key>...
  • Page 97 When the SCSI Select utility detects that the AIC-7901X SCSI controller is in the system, it displays the following Options menu: When the SCSI Select utility detects that the AIC-7901X SCSI controller is in the system, it displays the following Options menu: Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 Bus:Device:Channel You have an AIC-7901W...
  • Page 98 Configuring Channel A The following screens appear if you select Channel A: If you choose to configure Channel B, a similar SCSI Utility Screen will appear. The only difference is the I/O Port Address: A000h Channel A A400h Channel B...
  • Page 99 Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 AIC-7901X at Bus:02h Device:09h Channel: A Would you like to configure the host adapter, or run the SCSI disk utilities? Select the option and press <Enter>. Press <F5> to switch between color and monochrome modes. Options Configure/View Host Adapter Settings SCSI Disk Utilities...
  • Page 100 The Configure/View Host Adapter Settings menu lists three settings under SCSI Bus Interface Definitions and three additional The Configure/View Host Adapter Settings menu lists three settings under SCSI Bus Interface Definitions and three additional options. options. Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 AIC-7901X at Bus:02h Device:09h Channel:A Configuration SCSI Bus Interface Definitions...
  • Page 101 parameter. Press at any time to return to the previous menu. SCSI controller default settings are marked with an asterisk (*) throughout the selection submenus. Host Adapter SCSI ID This parameter allows you to change the host controller SCSI ID. The following screen shows the available IDs used for the AIC-7901X.
  • Page 102 Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 AIC-7901X at Bus:02h Device:09h Channel:A Configuration SCSI Bus Interface Definitions Host Adapter SCSI ID ………………………………….7 SCSI Parity Checking ………………………………...Enabled Host Adapter SCSI Termination……………………….Enabled Additional Options Boot Device Options……………………..……….Press BIOS Informa on Interrupt (IRQ) Chan nel………………………………..1 I/O P t Add A000h...
  • Page 103 SCSI Parity Checking SCSI Parity Checking Select this option to enable or disable the SCSI parity checking function on the SCSI controller. Select this option to enable or disable the SCSI parity checking function on the SCSI controller. The screen below displays the The screen below displays the selections.
  • Page 104 The SCSI controller always checks parity when reading from the SCSI bus to verify the correct transmission of data from the The SCSI controller always checks parity when reading from the SCSI bus to verify the correct transmission of data from the SCSI devices.
  • Page 105 Boot Channel Options Boot Channel Options This parameter lets you choosing boot the system from SCSI channel A or B first. The default setting is A (zero). We recommend This parameter lets you choosing boot the system from SCSI channel A or B first. The default setting is A (zero). We recommend that you keep the default setting since most system applications run only in this setting.
  • Page 106 Boot SCSI ID Options Boot SCSI ID Options This parameter lets you choosing the SCSI ID of SCSI device to be a boot device. The default setting is 0 (zero). We This parameter lets you choosing the SCSI ID of SCSI device to be a boot device. The default setting is 0 (zero). We recommend that you keep the default setting since most system applications run only in this setting.
  • Page 107 Boot LUN Number Options Boot LUN Number Options Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 AIC-7901X at Bus:02h Device:09h Channel:A Configursation SCSI Bus Interface Definitions Host Adapter SCSI ID …… ……… ……………………7 Boot Devi ce Con figuration Select SCSI peripheral from which to boot.
  • Page 108 Boot LUN Number LUN (Logic unit number) can support more devices, like RAID box or RAID card. SCSI Device Configuration This parameter allows you to configure details of each SCSI device on the SCSI bus. The screen shows a column of information for each SCSI ID, even if some SCSI IDs are not assigned to a device.
  • Page 109 Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 SCSI Device Configuration SCSI Device ID --------------------------------------------------------------------------------------------------------------- Sync Transfer Rate (MB/Sec).160.0 160.0 160.0 160.0 160.0 160.0 160.0 160.0 Initiate Wide Negotiation………Yes Enable Disconnection………….Yes Send Start Unit Command…….Yes Enable Write Back Cache…..…N/C -------------Options Listed Below Have NO EFFECT if the BIOS is Disabled------------- BIOS Multiple LUN Support…...No Include in BIOS Scan………..…Yes Arrow keys to move cursor, <Enter>...
  • Page 110 Sync Transfer Rate This option determines the maximum synchronous data transfer rate that the SCSI controller can support. The SCSI controller supports rates up to the Fast Wide SCSI maximum of 80.0 MB per second. The default value is 80.0. In most cases, you can use the maximum value of 80.0.
  • Page 111 When set to Yes, the SCSI device may disconnect from the SCSI bus. The SCSI device, however, may choose not to disconnect, even if permitted by the SCSI controller. When set to No, the SCSI device is not allowed to disconnect from the SCSI bus. The default setting is Yes.
  • Page 112 Selecting the Advanced Configuration Options displays a screen as shown below. Do not change the settings of the items under this parameter unless it is absolutely necessary. Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 AIC-7901X at Bus:02h Device:09h Channel:A Configuration Advanced Configuration Options SCSI Bus Interface Definitions Reset SCSI Bus at IC Initialization………………………………..Enabled Host Adapter SCSI ID …………………………………7...
  • Page 113 Host Adapter BIOS This option enables or disables the SCSI controller BIOS. The default setting is Enabled. The SCSI controller BIOS must be enabled if you want the system to boot from a SCSI hard disk drive connected to the SCSI controller.
  • Page 114 Support Removable Disks Under BIOS as Fixed Disks This option allows you to control which removable-media drives are supported by the SCSI controller BIOS. This is only valid when the SCSI controller BIOS is enabled. The default setting is Boot Only. The following choices are available: Boot Only - Only the removable-media drive designated as the boot device is treated as a hard disk drive.
  • Page 115 When you select SCSI Disk Utilities from the Options menu, the SCSISelect™ Utility scans the SCSI bus and lists all SCSI devices installed on the SCSI bus. The list shows the individual SCSI IDs assigned to each device on the SCSI bus. Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 Scanning SCSI ID:0 Number:0...
  • Page 116 Adaptec AIC-7901X SCSISelect (TM) Utility v2.10 AIC-7901W at Bus:02h Device:09h Channel:A Select SCSI Disk and press <Enter> SCSI ID #0: No device SCSI ID #1: No device SCSI ID #2: No device SCSI ID #3: No device SCSI ID #4: No device SCSI ID #5: No device...
  • Page 117 Format Disk The Format Disk utility performs a low-level format on disk devices. Most SCSI disk devices are preformatted and do not need to be formatted again. The Adaptec Format Disk utility is compatible with the vast majority of SCSI disk drives. Run it on hard disk drives or removable-media drives that were previously used with a non-Adaptec SCSI controller.

  • Page 118: Extended Translation

    Extended Translation Adaptec SCSI controllers have always supported the full range of disk drive capacities under all major operating systems. As disk drives have recently grown beyond 1 GB in formatted capacity, they have run up against the DOS 1024-cylinder limit. To continue its support for all SCSI disk drive capacities under DOS, Adaptec has included an extended translation scheme for the AIC-7902W SCSI controllers.
  • Page 119 With DOS 5.0 and above NetWare 386 (version 3.0 and above) and some versions of UNIX that do not share the 1024 cylinder limit of DOS do not require extended translation to support large disk drives and should not be enabled. Drives with mixed partitions Use standard translation (not extended translation) on drives formatted with two or more partitions for different operating systems.
  • Page 120 AGP uses both rising and falling edge of the 66MHz clock, for 2X AGP, the data transfer rate is 66MHz x 4byte x 2 = 528MB/s. AGP is now moving to 4X mode, 66MHz x 4byte x 4 = 1056MB/s. AOpen is the...
  • Page 121 Unlike ACPI, BIOS controls most APM power management functions. AOpen Suspend to Hard Drive is a good example of APM power management. ATA is the specification of diskette interface. In 80’s, many software and hardware manufacturers instituted the ATA specification together.
  • Page 122 ATA/100 is a new IDE specification under developing. ATA/100 uses both rising edge and falling edge as ATA/66 but clock cycle time is reduced to 40ns. The data transfer rate is (1/40ns) x 2 bytes x 2 = 100MB/s. To use ATA/100, you need special 80-wire IDE cable, the same as ATA/66.
  • Page 123 Normally, CODEC means a circuit that can do digital to analog conversion and also the analog to digital conversion. It is part of AC97 sound/modem solution. DDR SDRAM utilizes the existing DRAM infrastructure and technology while doubling the nominal bandwidth available to systems in an easy to design and simple to adopt way.
  • Page 124 The ECC mode needs 8 ECC bits for 64-bit data. Each time memory is accessed; ECC bits are updated and checked by a special algorithm. The ECC algorithm has the ability to detect double-bit error and automatically correct single-bit error while parity mode can only detect single-bit error.

  • Page 125: Flash Rom

    Flash ROM can be re-programmed by electronic signals. It is easier for BIOS to upgrade by a flash utility, but it is also easier to be infected by virus. Because of increase of new functions, BIOS size is increased from 64KB to 256KB (2M bit). AOpen AX5T is the first board to implement 256KB (2Mbit) Flash ROM.
  • Page 126 FSB Clock means CPU external bus clock. CPU internal clock = CPU FSB Clock x CPU Clock Ratio See SMBus. IEEE 1394 is a low-cost digital interface originated by Apple Computer as a desktop LAN and developed by the IEEE 1394 working group.
  • Page 127 The parity mode uses 1 parity bit for each byte, normally it is even parity mode, that is, each time the memory data is updated, parity bit will be adjusted to have even count "1" for each byte. When next time, if memory is read with odd number of "1", the parity error is occurred and this is called single bit error detection.
  • Page 128 Bus for the internal connection of peripheral devices, high-speed data channel between the computer and expansion card. A file format for electronic document, PDF format is independent from platform, you can read PDF file under Windows, Unix, Linux, Mac … with different PDF reader. You can also read PDF file by web browser such as IE and Netscape, note that you need to install PDF plug-in first (Included in Acrobat Reader).
  • Page 129 SDRAM comes in 64-bit 168-pin DIMM and operates at 3.3V. AOpen is the first company to support dual-SDRAM DIMMs onboard (AP5V), from Q1 1996 A memory space in Flash-ROM to simulate E PROM operation, AOpen motherboard uses Shadow E...

  • Page 130: Ipmb Bus

    SIMM socket is only 72-pin, and is only single side. The golden finger signals on each side of PCB are identical. That is why it was called Single In Line. SIMM is made by FPM or DRAM and supports 32-bit data. SIMM had been phased out on current motherboard design.

  • Page 131: Ultra Dma

    Ultra DMA (or, more accurately, Ultra DMA/33) is a protocol for transferring data between a hard disk drive through the computer’s data path (or bus) to the computer’s random access memory (RAM). The Ultra DMA/33 protocol transfers data in burst mode at a rate of 33.3MB/s, twice as fast as the previous Direct Access Memory (DMA) interface.
  • Page 132 NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements. VCM increases memory bus efficiency and performance of any DRAM technology by providing a set of fast static registers between the memory core and I/O pins. Using VCM technology results in reduced data access latency and reduced power consumption.
  • Page 133 If you encounter any trouble to boot you system, follow the procedures accordingly to resolve the problem. If you encounter any trouble to boot you system, follow the procedures accordingly to resolve the problem. Start Turn off the power and unplug the AC power cable, then remove all of the add-on cards and cables, including VGA, IDE, FDD, COM1, COM2 and printer.
  • Page 134 Then connect your monitor and keyboard. Turn on the power and check if the power supply and CPU fan work properly. The problem is probably caused by power supply or motherboard failure. Next Please contact your reseller or local distributor for repairing.
  • Page 135 Continue Perhaps your monitor is Check if there is display? defective. Press <Ctrl> and <Alt> key at the same time, hold them and then press <Del> to reboot the system. It is very possible that your Check if the system keyboard is defective.
  • Page 136 Continue During system rebooting, press <Del> to enter BIOS setup. Choose “Load Setup Default”. Turn off the system and re-connect IDE cable. The problem should be Check if the system can caused reboot successfully? cable or HDD itself. Re-install the operating system such as Windows2000.
  • Page 137 Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time. We recommend you follow the procedures below and seek help before contact us.
  • Page 138 News Group: News posted by computer experts. You are welcome to join any discussion. http://club.aopen.com.tw/forum/ Contact Distributors/Resellers: We sell our products through resellers and integrators. They should know your system configuration very well and should be able to solve your problem more efficiently than us. After all, their attitude of service is an important reference for you if next time you want to buy something else from them.
  • Page 139 BIOS version can be found on upper left corner of first boot screen (POST screen). For example: BIOS V4.1 R2.04 ------------------------------------------------ 01048192KB Memory Good R2.04 is BIOS version.

  • Page 140: Product Registration

    Be able to join the discussions of web-based news groups. AOpen makes sure that the information you provide is encrypted, so that it cannot be read or intercepted by other people or AOpen makes sure that the information you provide is encrypted, so that it cannot be read or intercepted by other people or companies.
  • Page 141 Pacific Rim Europe America AOpen America Inc. AOpen Inc. AOpen Computer b.v. Tel: 886-2-3789-5888 Tel: 31-73-645-9516 Tel: 1-510-489-8928 Fax: 886-2-3789-5899 Fax: 31-73-645-9604 Fax: 1-510-489-1998 Japan China Germany AOpen Computer GmbH. AOpen Japan Inc. 艾爾鵬國際貿易(上海)有限公司 Tel: 86-21-6225-8622 Tel: 49-1805-559191 Tel: 81-048-290-1800...

This manual is also suitable for:

Ax4s plus-u

Table of Contents
