Product Manual
Model 07701413
CAUTION
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your Cb600x™ online at
FOR OUTDOOR USE ONLY
www.grillregistration.com
WARNING
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
1-800-241-7548
07701413
.
07701413 • 42804301 • 12-03-08
Advertisement
Related Manuals for Char-Broil 7701413
Summary of Contents for Char-Broil 7701413
- Page 1 THIS UNIT IS HEAVY! DO NOT assemble without a helper. If you have questions or need assistance during assembly, please call 1-800-241-7548 To insure your satisfaction and for follow-up service, register your Cb600x™ online at www.grillregistration.com 07701413 • 42804301 • 12-03-08...
- Page 2 WARNING CAUTION CAUTION: Indicates a potentially hazardous situation or unsafe practice which, if not avoided, may result in minor or moderate injury. CAUTION For residential use only. Do not use for commercial cooking. 2 • 07701413...
-
Page 3: Table Of Contents
8:00 A.M. To 6:00 P.M. EST Monday - Friday. manufacturer. • To order non-warranty replacement parts or accessories please visit us on the web at www.charbroil.com or call 1-800-241-7548 and one of our friendly and knowledgeable agents will be glad to assist you. - Page 4 Check the telephone • LP gas is highly flammable and may ignite unexpectedly when directory under “Gas Companies” for nearest certified LP mixed with air. dealers. 4 • 07701413...
-
Page 5: For Your Safety
Nipple has to be centered into the LP cylinder valve. WARNING If “growing” bubbles appear do not use or move the LP cylinder. Contact an LP gas supplier or your fire department! 07701413 • 5... -
Page 6: Grill Service Center
• If a leak is detected at any time, STOP and call the fire turning hand wheel clockwise. department. • If you cannot stop a gas leak, immediately close LP cylinder valve and call LP gas supplier or your fire department! 6 • 07701413... - Page 7 If a grease fire develops, turn knobs and LP cylinder off. • Do not leave unattended while burning appliance off food residue. If has not been regularly appliance 24” cleaned, a grease fire can occur that may damage the product. 07701413 • 7...
- Page 8 Use only in direction of brushed finish to avoid damage. Do not use abrasive pad on areas with graphics. Match Control Knob View is from side of appliance 8 • 07701413...
-
Page 9: Spider Alert
4. Remove 4 Control Panel screws and nuts. Shown C 5. Disengage Control Panel/control Valve from burner.. 6. Slide Control Panel Assembly from unit, shown D. Proper Venturi Tube to Valve Alignment shown. (Some parts not shown for clarity) 07701413 • 9... - Page 10 Tools Required for Assembly: #2 Phillips or Standard Flat blade Screwdriver (Not Provided) Small Adjustable Wrench (Not Provided) 7/16” Combination Wrench (Not Provided) Time Required for Assembly: 45 minutes to 1 hour 10 • 07701413...
- Page 11 Resist the temptation to open the door during After filling the smoker, close the door and leave cooking time. Opening the door will cause a loss of undisturbed until suggested minimum cooking heat, which will result in longer cooking times. time. 07701413 • 11...
- Page 12 PARTS DIAGRAM – CB600x™ Model No. 07701413 Key Qty Description Part # Key Qty Description Part # HANDLE KIT ....55710430 SMOKER CHAMBER.
-
Page 13: Assembly
ASSEMBLY – Model No. 07701413 • Remove two nuts from the burner assembly. • Insert burner assembly into burner housing as shown. Insert Venturi Tube through hole in Burner Housing as shown.. • Install the two nuts removed previously to secure the burner assembly to the burner housing. - Page 14 NOTE: The venturi tube MUST face up (towards the door opening). NOTE: The venturi tube #1/4-20x1/2" MUST be installed Combo Truss Head Bolts as shown Qty: 3 #1/4-20x1/2" Combo Truss Head Bolt Venturi Tube Burner Housing with Burner 14 • 07701413...
- Page 15 Burner Assembly Screw Hole Housing 14 • 07701413 • Be sure the electrode wire exits the hole UNDER the venturi tube hole. DO NOT route the wire through the same hole as the burner venturi tube. • Install Ignitor Wire by pushing the round connector onto the Ignitor as shown.
- Page 16 • With the assistance of a helper - stand the unit upright on its legs. CAUTION: THIS UNIT IS HEAVY! Stand the unit upright on its legs CAUTION: This unit is HEAVY! Do not attempt this step without assistance! 16 • 07701413...
- Page 17 • Slide the Drawer, with Water Pan, into the Smoker body. Water Pan Frame Qty: 2 Qty: 2 #1/4-20 Keps Nut #1/4-20x3/4" Combo Truss Head Bolt Smoker Drawer Water Pan 1/4-20 Keps nuts 1/4-20x3/4” bolts Smoker Drawer 07701413 • 17...
- Page 18 • Press the Control Knob onto the Control Valve Shaft. Turn the Control Knob to the “Off” position. • Press the Ignitor Knob onto the Ignitor Shaft. Control Knob Thermometer Wing Nut Ignitor Knob NOTE: Turn Control Knob to the “OFF” position after installation to prevent vapor lock. 18 • 07701413...
-
Page 19: Troubleshooting
• Clean wire and/or electrode with rubbing alcohol and clean swab. cooking residue. • Wire is loose or disconnected. • Reconnect wire or replace electrode/wire assembly. • Wire is shorting (sparking) between • Replace ignitor wire/electrode assembly. ignitor and electrode. 07701413 • 19... - Page 20 D416,441; D416,441; D417,587; D422,516; D423,274; D423,876; D428,303; D435,396; D436,004; D438,059; D438,060; D438,427; D439,110; D442,505; D443,179; D443,354; D447,384; D447,385; D447,909; D448,610; D448,614; D448,615; D448,616; D448,975; D449,492; D451,759; D456,202S; D460,313, D461,359 and D504,048. Canada: 87743; 87744; 92607; 92608 and 1,316,424. Other Patents Pending. Assembly instructions © 2007. 20 • 07701413...
-
Page 21: Limited Warranty
Defective or missing parts subject to this limited warranty will not be replaced without registration or proof of purchase. Register online at http://www.charbroil.com or complete and return via mail the Product Registration Card located on the last page of the Use & Care manual included with this product and retain your sales receipt for proof of purchase. - Page 22 Page Intentionally Blank 22 • 07701413...
- Page 23 Page Intentionally Blank 07701413 • 23...
- Page 24 Always ensure control knobs are in OFF position and regulator is attached to tank BEFORE opening tank valve to avoid low flames. Perform leak test regularly. Thank You for Your Purchase! © 2007 Char-Broil, LLC • Columbus, GA 31902 • Printed in China 24 • 07701413...
