Summary of Contents for Emotiva UPA-500
-
Page 3: Important Safety Precautions And Explanation Of Symbols
Do not install the UPA-500 on any stand, shelf, or other piece of furniture that is unable to support its weight. If a cart is used to move the unit, use caution to avoid injury from tip-over. - Page 4 NEVER spray liquids into the vents. Care should be taken so that small objects do not fall into the inside of the unit. You should seek service for your UPA-500 by qualified service personnel if any of the following occur: 1. The power-supply cord or the plug has been damaged.
-
Page 5: Table Of Contents
About This Manual ................4 Features .....................5 Unpacking...................6 Indicators and Controls...............7 Quick Start ..................8 Connections..................9 Configuration and Operation ............10 Care and Maintenance ..............11 Specifications ...................12 Troubleshooting ................14 Emotiva Audio Corporation Five-Year Limited Warranty ....15 Accessories ..................17 Notes ....................18 Page 1... - Page 6 UPA-500 Page 2...
-
Page 7: Introduction
Emotiva is known for, but we’ve also designed into the UPA-500 is the most important feature of all: incredible value. We believe that the UPA-500 is the most exceptional five-channel home theater power amplifier available today and, at it’s price, we’re convinced you’ll agree. -
Page 8: About This Manual
About This Manual This manual will provide you with all the information you need to achieve great performance, accurate sound, and many years of reliable service from your UPA-500 five- channel power amplifier. We suggest that you read through the entire manual; we kept things as short and direct as possible. -
Page 9: Features
When connected directly to a preamp or pre/pro, the UPA-500 will serve as centerpiece of a true audiophile quality home theater system. When connected to the preamp outputs of your current receiver, you will attain a step up in both performance and musical enjoyment. -
Page 10: Unpacking
UPA-500 Unpacking Your UPA-500 was carefully packed and should reach you in perfect condition. If you notice any shipping damage or other issues when you unpack it, please contact Emotiva immediately. Gently remove your UPA-500 from the packing carton and remove all wrappings and shipping material. -
Page 11: Indicators And Controls
UPA-500 Indicators and Controls UPA-500 UPA-500 Standby / Power Status LEDs Button Status LED Audio Inputs AC Voltage AC Power Switch Indicators Switch Trigger Input Speaker AC Power and Output Outputs Inlet (cord) Page 7... -
Page 12: Quick Start
UPA-500 Quick Start To get the most from your UPA-500, we urge you to read the entire manual. If you just can’t wait to listen to it, this section will cover the basics you need to get started. • Find a secure location for your UPA-500. -
Page 13: Connections
UPA-500 will return to Standby mode. The Trigger Output sends out 12 VDC whenever the main power to the UPA-500 is On (and NOT when it is in Standby mode) which can be used to switch on other units with trigger capabilities. -
Page 14: Configuration And Operation
AC Power Switch (rear panel) The rear panel AC power switch controls the main AC power to your UPA-500. When this switch is in the Off position, the amplifier will not operate. Turning it On will put the UPA-500 into Standby mode. -
Page 15: Care And Maintenance
When necessary, the UPA-500 should be cleaned gently with a soft rag. • If something sticky gets on the front panel or case of the UPA-500, it should be cleaned with a mild cleaning solution applied to a soft rag, followed by wiping with a clean rag dampened with plain water, and drying with a soft dry rag or cloth. -
Page 16: Specifications
UPA-500 Specifications Topology: Fully discrete, dual differential, high current, short signal path Class A/B Number of Channels: Power Output (rated power; THD < 0.01%): 140 watts / channel (4 ohms; all channels driven) 80 watts / channel (8 ohms; all channels driven) Rated Power Bandwidth (at rated power; 8 Ohm load): 10 Hz to 20 kHz + /- 0.06 dB... - Page 17 The UPA-500 is protected against excessive operating temperature, shorted speaker connections, ground faults, and other common fault conditions. If a fault occurs, the UPA-500 will return to Standby mode, the Standby push button will light amber, and the Status LEDs will flash red.
-
Page 18: Troubleshooting
We really doubt you’ll ever have any problems with your UPA-500, but if you do, here are a few solutions you could try: Problem: No sound is heard from any channel (nothing is lit) You have no AC power. -
Page 19: Emotiva Audio Corporation Five-Year Limited Warranty
NOT APPLY TO YOU. A claim under this warranty must be made by you within the Term. A claim shall not be valid (and Emotiva has no obligation related to the claim) if it is not made within the Term and if it is not made in strict compliance with the requirements of the “How do you get service?”... - Page 20 2. The CSR will provide you with a returned material authorization number (“RMA”). 3. Ship the product to Emotiva at the following address, with the RMA written in large, bold numbers on the outside of the box, and with the letters “RMA” written before the number.
-
Page 21: Accessories
(you will find them in the Interconnects section of our website at www.emotiva.com) Rack ears and rack mount brackets for the UPA-500 are available in in the accessories section of our website at www.emotiva.com... -
Page 22: Notes
UPA-500 Notes All information contained in this manual is accurate to the best of our knowledge at the time of publication. In keeping with our policy of ongoing product improvement, we reserve the right to make changes to the design and features of our products without prior notice.
