Char-Broil 11301674 Product Manual

Char-Broil 11301674 Product Manual

740x charcoal grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product Guide
Model 11301674
740x Charcoal Grill
Tools needed for assembly:
Phillips Screwdriver
Flat Head Screwdriver
Two adjustable wrenches
Hammer
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
CAUTION:
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off
carbon monoxide, which has no odor. NEVER burn
charcoal inside homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®;
Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®; Infrared Grilling
That's All About U®; Keepers of the Flame®; Magneto®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio Kitchen®; Pro-Sear®; RED®;
Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®; Sure2Burn®; The Big Easy®; U®; Wild West Tradition®; and the following marks:
The following are trademarks of W.C. Bradley Co.:America's Legendary Barbeque Company™; Advantage Series™; Auto-Clean™;Chef Tested™; Commercial Series™;
Designer Series™;; Diamond Flame™; Double Chef™; Everybody Outside™; FastStart™; FlavorMaster™; Front Avenue™; Grill 2 Go® Advantage™; Grill 2 Go® Ice™;
Hog and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little Secret™; Incredible Taste. Infallible Results™; Infrared Inside™; Let's Grill Something Together™;
Longhorn™;; Precision Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And Savor™; Sizzle On The Grill™; SureFire™; Torchfork™;
Trentino™; Universal Grill Parts™; You Bring the Party™
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
FOR OUTDOOR USE ONLY
®
TEC™ is a trademark of Tec Infrared Grills.
Estimated Assembly Time: 1 Hour
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
®
1-800-241-7548
TM REVISION 08
.
42804740 - 10/25/10

Advertisement

Table of Contents
loading

Related Manuals for Char-Broil 11301674

Summary of Contents for Char-Broil 11301674

  • Page 1: Product Record Information

    TEC™ is a trademark of Tec Infrared Grills. TM REVISION 08 If you have questions or need assistance during assembly, please call 1-800-241-7548 To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register 42804740 - 10/25/10...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR For Your Safety .

  • Page 3: Preparing To Use Your Grill

    PREPARING TO USE YOUR GRILL Before cooking with your grill, the following steps should be closely followed to both cure the finish and season the interior steel. Failure to properly follow these steps may damage the finish and/or impart metallic flavors to your first foods. Brush all interior surfaces including grills and grates with vegetable cooking oil.

  • Page 4: Cooking Tips

    COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate or ash pan. We recommend using 2 pounds (approximately 30 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.

  • Page 6: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 7: Parts List/ Parts Diagram

    PARTS LIST Key Qty Description Key Qty Description 1 LID KIT 2 COOKING GRATE 1 LOGO PLATE KIT 1 CHARCOAL GRATE 2 HINGE KIT, F/ LID 2 CHARCOAL GRATE LIFTER 1 HANDLE, F/ LID 1 ASH PAN 2 STANDOFF, F/ HANDLE 1 BOTTOM SHELF 1 TEMPERATURE GAUGE 2 SIDE SHELF WOOD INSERT...

  • Page 8: Assembly

    ASSEMBLY To begin assembly, Attach Firebox End Panels to the Front and Rear Firebox Panels using 8 each1/4-20x1/2” screws and 8 each 1/4-20 flange nuts. Be sure to use the screw holes shown below. When complete, turn the firebox over in preparation for the next step. Firebox Rear 1/4-20x1/2”...
  • Page 9 Attach the Bottom Shelf to the Legs using 4 each 1/4-20x1/2 ” screws. 1/4-20x1/2” Machine Screws 1/4-20x1/2” Machine Screws Thread the two Locking Casters into the ends of the legs on the same side of the grill shown below. Thread the Non-Locking casters into the opposite side legs. With the aid of a helper - turn the grill cart over to its upright position and tighten all hardware previously installed.
  • Page 10 Attach 2 Lower Hinge Assemblies to the Rear Panel using 4 each 1/4-20x1 5/8” screws and 4 each 1/4-20 flange nuts. Attach Spacers and Handle to Grill Lid using 2 each 1/4-20x3 1/4" Machine Screws and 2 1/4-20 Flange Nuts. Install Temperature gauge by placing the stem through the large hole in front of the grill lid.
  • Page 11 Attach 2 Upper Hinge Assemblies to the rear of the Grill Lid using 4 each 1/4-20x1-5/8” Screws and 4 each 1/4-20 flange nuts. Insert Vent Knob into side of Grill Lid from the outside. Inside the Grill Lid, slide the Vent Plate with the flat washer facing outside the grill lid onto the Vent Knob stud.
  • Page 12 With the aid of a helper, attach the Grill Lid to the Firebox Bottom by aligning the Hinges at the rear of the Grill Lid with the hinges at the rear of the Firebox Bottom. When Aligned - insert the hinge pins through the holes in the hinge as shown and secure the hinge pins by inserting a small hitch pin through the Hinge Pin holes, Small Hitch Pin Hinge Pins...
  • Page 13 Attach 2 Fire Grate Hangers to Fire Grate (Hooks point inward toward Grate). Lower into the Grill Bottom and hang from Tabs on each side. Place Cooking Grates and Ash Pan into Position as shown below. Note: Grill Lid not shown for clarity.

  • Page 14: Hardware List

    HARDWARE LIST #1/4x20 Jamb Nut 1/4-20 1/4-20x1/2” Qty. 2 #14x20x5/8” Machine screw Flange Nut Shoulder Screw, Qty. 20 Qty. 18 Qty. 8 1/4-20x1-5/8” Machine screw, Qty. 8 #1/4-20x3-1/4” Machine Screw, Qty. 2 Wavy Washer Qty. 2...

  • Page 16: Registration Card

    Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240 REGTEMP REV02...
