American Gourmet
300 Series
Product Guide
Model 11301678
Tools needed for assembly:
Phillips Screwdriver
Flat Head Screwdriver
Adjustable wrenches
IMPORTANT: Fill out the product record information below.
Serial Number
Date Purchased
CAUTION:
Read and follow all safety statements, assembly instructions,
and use and care directions before attempting to assemble
and cook.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
WARNING:
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal inside
homes, vehicles, or tents.
The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American
Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill
Lovers®; Infrared Grilling That's All About U®; Keepers of the Flame®; Magneto®; New Braunfels Smoker Company®; Patio Bistro®; Patio Caddie®; Patio
Kitchen®; Pro-Sear®; RED®; Quantum®; Santa Fe®; Sear and Grill®; Sierra®; Signature Series®; Sure2Burn®; The Big Easy®; U®; Wild West
Tradition®; and the following marks:
The following are trademarks of W.C. Bradley Co.:America's Legendary Barbeque Company™; Advantage Series™; Auto-Clean™;Chef Tested™;
Commercial Series™; Designer Series™;; Diamond Flame™; Double Chef™; Everybody Outside™; FastStart™; FlavorMaster™; Front Avenue™; Grill 2
Go® Advantage™; Grill 2 Go® Ice™; Hog and Yard Bird™; H20 Smoker™; Infrared. Grilling's Juicy Little Secret™; Incredible Taste. Infallible Results™;
Infrared Inside™; Let's Grill Something Together™; Longhorn™;; Precision Flame™; Quick2Burn™; QuickSet™; Ready When You Are™; Season, Set, And
Savor™; Sizzle On The Grill™; SureFire™; Torchfork™; Trentino™; Universal Grill Parts™; You Bring the Party™
Grills.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
Estimated Assembly Time: 1 Hour
FOR OUTDOOR USE ONLY
WARNING:
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
CAUTION:
Some parts may contain sharp edges – especially as
noted in the manual! Wear protective gloves if
necessary.
CAUTION:
THIS UNIT IS HEAVY! DO NOT attempt to
assemble without a helper.
®
®
1-800-241-7548
TEC™ is a trademark of Tec Infrared
TM REVISION 08
.
42804628 - 11/29/10

Advertisement

Table of Contents
loading

Related Manuals for Char-Broil AMERICAN GOURMET 300 SERIES 11301678

Summary of Contents for Char-Broil AMERICAN GOURMET 300 SERIES 11301678

  • Page 1: Product Record Information

    The following are trademarks registered by W.C. Bradley Co. in the U.S. Patent and Trademark Office: Caldera®; Charcoal2Go®; Char-Broil®; American Gourmet®; Bandera®; Brush Hawg®; CB 940®; Char-Diamonds®; Char-Broil Charcoal/Gas®; Everybody Grills®; Grill 2 Go®; Grill 2 Go® Express®; Grill Lovers®;...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Record Information ......1 Safety Symbols........2 Preparing to use your Grill .

  • Page 3: Preparing To Use Your Grill

    Re-season your grates frequently, particularly when new. If rust occurs, it is an indication that the grates have not been seasoned enough or the seasoning has been burned off. Clean with a heavy brush like Char-Broil’s Brush Hawg. Reapply vegetable shortening and heat as indicated above to re-season the grates.

  • Page 4: Cooking Tips

    COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate. We recommend using 1 pound (approximately 15 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.

  • Page 6: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 7: Parts List/ Parts Diagram

    PARTS LIST Description GRILL LID LOGO PLATE KIT LID HANDLE LID HANDLE, SPRING TEMPERATURE GAUGE FIREBOX GREASE TRAY GREASE TRAY BRACKET CHARCOAL GRATE CHARCOAL GRATE HANGER COOKING GRATE NOT Pictured … HARDWARE PACK … ASSEMBLY GUIDE, ENGLISH … ASSEMBLY GUIDE, FRENCH Description AIR DAMPER SIDE SHELF SLAT...

  • Page 8: Assembly

    ASSEMBLY FIRST, GET A HELPER! This unit is heavy and requires a second person for lifting, moving and helping to hold components in place while securing them. NEXT, pick a suitable location to work. Open the carton and slit the corners so that the carton lays flat.
  • Page 9 Attach the Upper Leg Supports to the cart assembly by slipping the ends of the tubes into the ends of the legs. Secure the Upper Leg Supports with 4 each, 1/4-20x3/4" Machine Screws. 1/4-20x3/4” Machine screw Qty. 4 With aid of a helper, turn the Cart Assembly over and allow it to rest on the Upper Leg Supports. Insert a Cotter Pin into one end of the Axle Rod.
  • Page 10 Carefully place the Firebox onto the Upper Leg Supports. The Air Damper hole should be positioned on your RH side. While a helper holds the Firebox in position, secure the Firebox to the Upper Leg Supports with 4 each 1/4-20X1 3/4" Machine Screws and 4 each 1/4-20 Flange nuts.
  • Page 11 Attach the Side Shelf using 4 each 1/4-20x1" Machine Screws. Securely tighten the Side Shelf to the Firebox. 1/4-20x1” Machine Screw Qty. 4 Install the Firebox Damper Wheel by inserting 1 each 1/4-20x3/4" Machine Screw into the screw hole. Place the Damper Wheel onto the screw from inside the firebox, making sure the tab sticks out through the damper holes.
  • Page 12 Assemble the Grill Lid Damper Wheel in the same manner as the Firebox Damper Wheel. See Step 8 for details. Assemble the Temperature Gauge to the Grill Lid by removed the wingnut from the Temperature Gauge, then insert the shaft of the gauge into the lid and reinstall the wingnut from inside the Grill Lid. Assemble the Lid Handle to the Grill Lid by inserting 2 each 1/4-20x3/4"...
  • Page 13 Place the Cooking Grates into the Firebox. Charcoal Grate Hanger Your grill is now completely assembled. Please refer to page 3 for instructions on how to prepare and season your grill prior to cooking. THANK YOU FOR PURCHASING A CHAR-BROIL GRILL! Cooking Grates Charcoal Grate...

  • Page 14: Hardware List

    HARDWARE LIST 1/4-20x3/4” Machine screw 1/4-20x1” Qty. 20 Machine Screw Qty. 4 1/4-20x1 3/4” Machine Screw, Qty. 4 1/4-20 1/4-20 Axle Washer Reversible Flange Nut Qty. 2 Lock Nut Qty. 6 Qty. 2 Cotter Pin Qty. 4 Hinge Pin Qty. 2 Page 14...

  • Page 16: Registration Card

    Warranty Registration Department P.O. Box 1240 Columbus, GA 31902-1240 REGTEMP REV02...
