HG532t Home Gateway

User Guide

HUAWEI TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading

Related Manuals for Huawei HG532t

Summary of Contents for Huawei HG532t

  • Page 1: User Guide

    HG532t Home Gateway User Guide HUAWEI TECHNOLOGIES CO., LTD.
  • Page 2 User Guide Issue Date 2012-10-26 Part Number 202534 Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters. Huawei Technologies Co., Ltd. Address: Huawei Industrial Base Bantian, Longgang...
  • Page 3 Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.

  • Page 4: Table Of Contents

    Contents 1 Connecting the Cables and Getting Started ......1 1.1 Adjusting the Antenna ..............1 1.2 Connecting Cables Using the ADSL Port ........1 1.3 Connecting Cables Using the USB Port .......... 3 1.4 Getting Started ................3 2 Setting Network Access Parameters ........4 2.1 Logging In to the Web-based Configuration Utility ......
  • Page 5 7.2 Ports and Buttons ................ 20 7.3 Default Settings ................22 7.4 Technical Specifications .............. 22...

  • Page 6: Connecting The Cables And Getting Started

    The following figure shows an example of how to connect cables using the ADSL port. In this example, the HG532t is connected to a desktop computer, a laptop computer, and a telephone.
  • Page 7 1. Power adapter 2. Desktop computer 3. Laptop computer 4. Telephone 5. Splitter 6. Telephone wall jack 7. HG532t a. Splitter MODEM port b. Splitter PHONE port c. Splitter LINE port...

  • Page 8: Connecting Cables Using The Usb Port

    1.3 Connecting Cables Using the USB Port The following figure shows an example of how to connect cables using the USB port. In this example, the HG532t is connected to a desktop computer, a laptop computer, and a telephone. 1. Power adapter 2.

  • Page 9: Setting Network Access Parameters

    After you power on the HG532t, the Power indicator turns on, indicates that the HG532t is working properly. To power off the HG532t, press the On/Off button on the side panel, and then unplug the power adapter. 2 Setting Network Access Parameters 2.1 Logging In to the Web-based Configuration...

  • Page 10: Configuring A Dial-Up Connection For Internet Access

    2.2 Configuring a Dial-up Connection for Internet Access The HG532t works in routing mode by default. And the HG532t starts to set up a dial-up connection automatically after the startup. You can access the network after you power on your computer. You do not need to install any special dial-up software on your computer or perform dial-up operations on your computer.

  • Page 11: Setting Up A Wireless Connection

    Windows 7 supports the WPS function. Windows XP supports the WPS function using the wireless network adapter. Step 1 Press and hold the WPS button on the HG532t's side panel for at least 1 second. The WPS indicator on the HG532t starts blinking, indicating that the...

  • Page 12: Setting Up A Wireless Connection Manually

    Wait for a while (about 10~120 seconds), the WPS indicator on the HG532t stops blinking and turns steady on (This state for about 300 seconds and then turns off), indicating that a wireless connection is set up between the HG532t and computer.
  • Page 13 You need to set up a wireless connection only once. Then you can access the wireless network anytime you want as long as that the wireless network name and password are not changed. When the HG532t is working properly, your computer connects to the HG532t automatically after its wireless function is enabled.

  • Page 14: Using The Usb Port

    4 Using the USB Port 4.1 Going Online Using a USB Modem By default, the HSPA uplink service is enabled. When the HG532t is working in USB modem mode, connect the USB modem to the HG532t so that your device can access the Internet through the HSPA uplink service.

  • Page 15: Accessing A Portable Storage Device Using The Samba Server

    Samba Server The HG532t supports a home storage and printing function. After a portable storage device is connected to the USB port, you can configure the HG532t through the samba service to access the portable storage device from the LAN or Internet.

  • Page 16: Accessing A Printer Using The Printer Server

    4.3 Accessing a Printer Using the Printer Server The HG532t supports a printing function. After a printer is connected to the USB port, you can configure the HG532t through the samba server to access and use the printer. For details about how to use the printer: Step 1 Log in to the HG532t's web-based configuration utility.

  • Page 17: Maintenance Guide

    5.2 Enabling or Disabling the Wireless Network Function To enable or disable the wireless network function, press the WLAN button on the side panel of the HG532t over 1 second. The WLAN indicator indicates the status of the wireless network function.

  • Page 18: Changing The Wireless Network Name And Password

    Password When your HG532t is delivered, the wireless network name and password are preset. You can find them on the HG532t’s rear panel label. For security reasons or to make the password easier to remember, change the wireless network name and password as follows: (Take default wireless network encryption mode TKIP+AES as an example) Step 1 Log in to the HG532t's web-based configuration utility.

  • Page 19: Restoring Default Settings

    Reset button on the rear panel for over 6 seconds, and then release the button. You can also do the following to restore the HG532t to its default settings from the web-based configuration utility: Step 1 Log in to the HG532t's web-based configuration utility.

  • Page 20: Faqs

    Yes. The HG532t incorporates the DHCP server software. How can I quickly restore the default settings of the HG532t? When the HG532t is powered on, press and hold the Reset button for 6 or more seconds, and then release it. The HG532t then automatically restarts and the default settings are restored.
  • Page 21 Step 2 Check whether the WLAN indicator of the HG532t is on. If the WLAN indicator is off, the WLAN function of the HG532t is disabled. If this is the case, enable the WLAN function. For details about how to enable the WLAN function, see section 5.2 "5.2 Enabling or Disabling the Wireless Network Function".
  • Page 22 Place your HG532t and computer in a different direction. Step 5 Avoid using your HG532t to access a WLAN during thunderstorms. What can I do if the WLAN of the HG532t is not encrypted and the computer cannot access the WLAN? Step 1 Delete the settings of wireless network connections from your computer.

  • Page 23: Appendix

    Description Power The HG532t is powered on. The HG532t is powered off or faulty. Eth1 ~ The HG532t is connected to a device properly. Eth4 Blinking Data is being transmitted between the HG532t and the device connected. No connection is set up on the port.
  • Page 24 Description Blinking A wireless client, such as a computer  installed with a wireless network adapter, is connecting to the HG532t using the WPS function. This process lasts for no longer than 120  seconds. The WPS function is disabled or faulty.

  • Page 25: Ports And Buttons

    Description Button Used to enable the WPS function. Reset To restore the HG532t to its factory settings, power it on, press and hold the Reset button for at least 6 seconds, and then release it. NOTE After you restore the HG532t to its factory settings, your user settings will be lost.
  • Page 26 USB port is 5 V/1 A. That is, the input voltage/current of the USB device connected to the USB port cannot exceed 5 V/1 A. Otherwise, the HG532t may not work correctly. Used to connect Ethernet devices, such as 7 ~ 10 Eth1 ~ Eth4 computers and switches, to the HG532t.

  • Page 27: Default Settings

    Password used to log in to user the web-based configuration utility SSID used to access wireless Check the label on the HG532t's rear network panel WLAN key used to access wireless Check the label on the HG532t's rear...
  • Page 28 Item Specification WLAN standards 802.11b, 802.11g and 802.11n (2.4 GHz) Wireless transmission rates 802.11b Up to 11 Mbit/s 802.11g Up to 54 Mbit/s 802.11n Up to 300 Mbit/s (with 2T2R external antenna used)
  • Page 29 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com...
