Summary of Contents for Samsung AS09V Series
- Page 1 USER’S MANUAL ✴ AS09V Series ✴ AS12V Series Split - type Air Conditioner (Cooling) DB98-28213A...
- Page 2 Contents ◆ REPARATION Safety Precautions ......................3 ■ Name of Each Part ......................8 ■ Remote Control – Buttons and Display ............... 10 ■ Inserting the Remote Control Batteries ............... 10 ■ Getting Started ....................... 11 ■ ◆ PERATION Selecting Auto Mode ....................12 ■...
- Page 9 ✴✴ Outdoor Unit AS09V Series Air Inlet (Rear) Air Outlet Connection Valve (Inside) Outdoor Unit ✴ ✴ AS12V Series Air inlet(Rear) Air Outlet Connection Valve (Inside)
- Page 12 You can select Auto mode if you want to cool your room automatically. You can adjust the temperature in this mode. Press the (On/Off) button. Result: The operation indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used.
- Page 13 You can select Cool mode if you want to cool your room. You can adjust the temperature and the fan speed when cooling. Press the (On/Off) button. Result: The operation indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used.
- Page 14 Select Dry mode if you want to dehumidify your room. You can adjust the temperature in this mode. Press the (On/Off) button. Result: The operation indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used.
- Page 15 Select Fan mode if you want to ventilate your room. It helps to refresh the air in your room. You can adjust the fan speed in this mode. Press the (On/Off) button. Result: The operation indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used.
- Page 16 You can select the Turbo Function if you want to cool your room as quickly as possible. The Turbo function operates for 30 minutes with the maximum settings before returning automatically to the mode and temperature previously selected. Press the (On/Off) button.
- Page 17 You can select the Energy Saving Function to save energy when cooling. The temperature range decreases in order to perform this function. Press the (On/Off) button. Result: The operation indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used.
- Page 18 mode helps users to fall asleep well after going to bed whether being too hot to sleep or being awakened by coldness. The mode can be selected only when the air conditioner is switched on or off in cool mode. (On/Off) button.
- Page 19 mode keeps the skin temperature at the best during the 3 stages such as, Falling Asleep Stage Sound Sleep Stage Wake Up Stage in order. Falling Asleep Stage : This stage supports the environment to quickly cool down. Together with comfortable intermittent air, you will be able to fall asleep quickly.
-
Page 26: Keeping Filters Clean
Keeping Filters clean Cleaning Cathechin Filter Cathechin filter protects you from allergy-causing particles, even if you raise pets at home. Open the upper front panel by pulling the lower right and left tabs of the panel. Detach the cathechin filter(green) by pulling it forwards. Deodorizing Filter Wash the filter with clean water. - Page 27 Cathechin Filter Deodorizing Filter Note You should clean the filters every year even if the replacing period might be different depending on how long and where you are using. You can purchase deodorizing filter at the customer care center. The filter function is not affected even if deodorizing filter and cathechin filter are inverted.
-
Page 30: Contact Samsung World Wide
Contact SAMSUNG WORLD WIDE If you have any comments or questions regarding a Samsung products, contact the SAMSUNG customer care center. Country Web Site Customer Care Center INDIA 3030 8282, 1800 1100 11 www.samsung.com/in INDONESIA 0800-112-8888 www.samsung.com/id MALAYSIA 1800-88-9999 www.samsung.com/my...
