DUAL VOLTAGE REFRIGERATORS
120 VOLTS AC AND 12/24 VOLTS DC
INSTALLATION AND OWNER'S
If service or parts are required, contact the nearest Norcold Service Center. To
find an authorized Norcold Service Center near you, please telephone the Norcold
Customer Support Dept. at 800-543-1219 (option-1) or visit our web site at www.
norcold.com.
Norcold Customer Support Dept.
Telephone : 800-543-1219
Fax : 937-497-3183
Web Site: www.norcold.com
Model No.
MANUAL
Service Information
Serial No.
5/07
Part No. 631342A
#5490 351 0000
Advertisement
Table of Contents
Related Manuals for Norcold AC Series
Summary of Contents for Norcold AC Series
- Page 1 MANUAL Service Information If service or parts are required, contact the nearest Norcold Service Center. To find an authorized Norcold Service Center near you, please telephone the Norcold Customer Support Dept. at 800-543-1219 (option-1) or visit our web site at www.
- Page 2 Limitation of Remedy 1. The responsibility of NORCOLD under this or any warranty is limited to the repair or replacement (at NORCOLD’S option) of the defective part or assembly. 2. In no event and under no circumstances shall NORCOLD be responsible under this...
-
Page 3: Safety Awareness
Safety Awareness Read this manual carefully and understand the contents before you install the refrigera- tor. Be aware of possible safety hazards when you see the safety alert symbol on the re- frigerator and in this manual. A signal word follows the safety alert symbol and identifies the danger of the hazard. -
Page 4: Over Heating Shut-Off Device Operation
DC power supply. If the refrigerator still does not operate, another problem can exist in the inverter. Have an authorized Norcold Service Center check the refrigerator. Cleaning and Defrosting Defrosting It is normal for frost to collect on the freezer plate inside the refrigerator. -
Page 5: Battery Maintenance
- Empty the drip tray. - Remove the wet towels (etc.) and dry the inside of the refrigerator - Turn the thermostat to the desired setting. - Put the drip tray and all food in the refrigerator. Cleaning A good time to clean the refrigerator is just after you defrost it. Clean the inside of the refrigerator as often as necessary to avoid food odors: - Remove all food from the refrigerator. -
Page 6: For Your Reference
For your reference The wiring diagram shown below is recommended for dual battery hookup (See Art01516) *Recommended source: Sure Power Industries, Inc. 1-800-845-6269 www.Surepower.com Installation The refrigerator should be located and secured on a solid surface in the vehicle. Before installing the refrigerator into the opening, make sure the DC supply is prop- erly connected. -
Page 7: Installation Options
Be sure the refrigerator is not in direct sunlight or near a gas stove, a heater, or other heat-generating appliances. Avoid installing your refrigerator close to warm water lines or warm air ducts. Your refrigerator was thoroughly cleaned before shipment from the factory. It is ad- visable, however, to clean the interior once more before using. -
Page 8: Reverse The Door Swing
2. Remove the panel retainer by removing the three (3) screws that attach the panel retainer (See Art01891). 3. Gently pull the door panel out of the door (Art01895). 4. Push a new door panel into the door slot. Art01891 CAUTION: Do not overtigten the screws and bolts. - Page 9 6. Move the latch to the opposite side of the door (See Art01892): - Remove the four (4) screws that attach the latch plate and the cover plate to the door. Cover plate Latch plate Latch pull Latch pin Latch handle pin Coil spring Screw Art01892...
- Page 10 If he wire size is too small for the distance, a voltage drop oc- curs. The voltage drop decreases the cooling performance of the refrigerator. 1. Norcold recommends that you use the following wire and fuse sizes: - Measure the distance from the vehicle battery to the refrigerator: - If the distance is less than 12 feet, use 16 AWG wire and a 10 Amp fuse.
- Page 11 - Twist the lead wires to reduce the radio interference and induction of a high voltage surge from the outside (See Art01518). INCORRECT CORRECT Electrical equipment Refrigerator Refrigerator Battery Battery Twist lead wires Art01518 2. Connect the DC power supply (See Fastener Art01509): Screw...
