- Page 1 2014 F-150 SVT Raptor fordowner.com ford.ca EL3J 19A285 AA September 2013 First Printing Supplement F-150 SVT Raptor Litho in U.S.A.
- Page 2 No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted. © Ford Motor Company 2013 All rights reserved. Part Number: 20130909213112...
-
Page 3: Table Of Contents
Table of Contents Introduction Accessories About This Supplement.........3 Auxiliary Switches..........33 Product History..........3 Warranty Terms and Conditions At a Glance Base Warranty..........35 At a Glance............4 Fuel and Refueling Fuel Quality............7 Terrain Response Principle of Operation........8 Using Hill Descent Control......8 Driving Aids Front View Camera..........9 Towing Towing a Trailer..........12... - Page 4 F150 (TF6)
-
Page 5: Introduction
ABOUT THIS SUPPLEMENT PRODUCT HISTORY The History of Special Vehicle Congratulations on your decision to purchase or lease the latest from Ford SVT Team (SVT) the F-150 SVT Raptor. If you’ve owned The Ford Special Vehicle Team (SVT) was or leased an SVT product in the past, we’re established in 1991 to polish the Ford Oval glad you’re back. -
Page 6: At A Glance
At a Glance E167331 • Unique grille F-150 SVT Raptor-Specific Exterior • Front off-road camera Features • Front camera washer • 6.2L Boss V8 engine • Dual exhaust, 3.5 inch exhaust tips • 6R80 6-speed automatic transmission • Modified rear bumper with integrated •... - Page 7 At a Glance • Longer, cast aluminum lower control • Standard 17 inch Cast Aluminum arms Wheels • Longer, forged steel upper control arms • Optional 17 inch forged aluminum beadlock compatible wheels • Front coil springs and rear leaf springs •...
- Page 8 At a Glance 6.2L V8 Engine A A A C A A A D A A A I A A A H A A A G A A A F A A A E E166495 Windshield washer fluid reservoir Engine oil dipstick Brake fluid reservoir Engine coolant reservoir Air filter assembly...
-
Page 9: Fuel And Refueling
Fuel and Refueling Regular unleaded gasoline with a pump FUEL QUALITY (R+M)/2 octane rating of 87 is recommended. Some stations offer fuels Note: Use of any fuel other than those posted as Regular with an octane rating recommended may cause powertrain below 87, particularly in high altitude areas. -
Page 10: Terrain Response
Terrain Response PRINCIPLE OF OPERATION USING HILL DESCENT CONTROL WARNINGS Hill descent control cannot control descent in all surface conditions and circumstances, such as ice or extremely steep grades. Hill descent control is a driver assist system and cannot substitute for good judgment by the driver. Failure to do so may result in loss of vehicle control, crash or serious injury. -
Page 11: Driving Aids
Driving Aids FRONT VIEW CAMERA Front Off-Road Camera System WARNINGS The off-road mode camera system is an off-road aid supplement device that still requires the driver to use it in conjunction with viewing the front of the vehicle. Due to the limited coverage of the E167336 camera system, objects close to The front camera system is located on the... -
Page 12: Driving Aids
Driving Aids Turning on the Front Off-road Camera Yellow zone System Objects in the red zone are Your vehicle must meet the following closest to your vehicle conditions to turn the system on: Front bumper • You must be in off-road mode with electronic locking differential (ELD) As objects are getting closer to your activated, or in 4L. - Page 13 Driving Aids E167339 O - Front camera washer off. F - Front camera washer on. To use the front camera washer, rotate the dial until the dot mark lines up with the F front camera position. The washer will clean for as long as desired. Return the dial to line up with the O position when you are finished washing the camera.
-
Page 14: Towing
Towing TOWING A TRAILER Towing Capacity Vehicle type Maximum tow weight Gross combination weight rating (GCWR) SuperCab 6000 lb (2721 kg) 12500 lb (5670 kg) SuperCrew 8000 lb (3629 kg) 14700 lb (6668 kg) Refer to the Towing chapter in your Owner s Manual for additional towing information. -
Page 15: Towing The Vehicle On Four Wheels
Do not placing the transfer case in its neutral tow with a slingbelt. Ford Motor Company position and engaging the has not approved a slingbelt towing four-wheel-down towing feature. Perform procedure. - Page 16 Towing Note: You may hear an audible noise as the WARNINGS transfer case shifts out of its neutral Do not disconnect the battery during position. This is normal. recreational towing. Doing so will prevent the transfer case from 5. Apply the parking brake, and then shifting properly and may cause the vehicle disconnect the vehicle from the tow to roll even if the transmission is in P...
-
Page 17: Driving Hints
Ford joins • Engine throttle calibration— The the U.S. Forest Service and Bureau of Land engine throttle calibration is altered for Management in encouraging you to help improved off-road performance. -
Page 18: Driving Hints
Driving Hints Enabling off-road mode AdvanceTrac Modes During off-road mode the AdvanceTrac WARNING system provides the vehicle with Off-road mode is specifically alternative AdvanceTrac calibrations, calibrated for off-road driving which improve off-road performance. conditions and should never be used Off-road AdvanceTrac calibrations are on pavement. - Page 19 Driving Hints • AdvanceTrac Sport— Pressing the • AdvanceTrac Disabled— Pressing stability control off button once places and holding the stability control off the vehicle in the off-road sport mode. button will disable AdvanceTrac. In this In this mode Electronic Stability Control mode only off-road calibrated ABS (ESC), Traction Control Stability (TCS) remains active.
- Page 20 Driving Hints Off - Button Sliding Advan- Off- Road Func- Car Icon ceTrac Road Mode tions Informa- Mode tion Informa- Display tion Display Vehicle Disabled Sport Street speed exceeds 35 mph (56 km/ while/ after button pressed held for more than 5 seconds Button...
- Page 21 Even if your local law or upset the vehicle, especially while does not prohibit alcohol use while on sloped terrain or while crossing driving off-road, Ford strongly obstacles such as rocks or logs. recommends against drinking if you •...
-
Page 22: Driving In Sand
Driving Hints Driving in Sand Before operating your vehicle at higher than normal speeds: WARNING • Make sure your tires are at the correct tire pressure. See Tire Care (page 26). Tires must be returned to normal recommended tire pressures before •... -
Page 23: Driving In Deep Snow
Driving Hints Driving in Deep Snow • Always attempt to climb a steep hill along the fall line of the slope and not • Maintain vehicle momentum. diagonally. • Apply the throttle very gently to avoid • If the vehicle is unable to make it up spinning the tires. - Page 24 The off-road driving discussed thus far has Ford SVT has engineered your vehicle for focused on the type of events typically off-road use beyond what is normal for a encountered during slow speed off-road F-150.
- Page 25 Driving Hints Some points to consider: • As speed increases, it is wise to look farther ahead of the vehicle so that • Build up speed slowly. Initially, drive at there is time to react to oncoming a pace which allows ample time to fully obstacles.
-
Page 26: After Off-Road Driving
Driving Hints • • Inspect the tires for any cuts in the tread or sidewall area. Also inspect the • It is highly encouraged that you switch sidewall for any bulge indicating to off-road mode and perform an damage to the tire. AdvanceTrac single press to make sure improved off-road braking •... -
Page 27: Vehicle Care
Vehicle Care CLEANING THE EXTERIOR Do not drive your vehicle through an automated, commercial car wash due to the vehicle’s tire width and track. Wash your vehicle by hand, or by using a touchless commercial wash with no mechanical tracks on the floor. Do not use a commercial or high-pressure wand on the bed-side graphic surface or graphics edges. -
Page 28: Wheels And Tires
Wheels and Tires Your vehicle is equipped with high GENERAL INFORMATION performance, all-terrain tires designed to optimize handling, steering and braking to Your vehicle is equipped with unique provide the performance you expect in an wheels and tires designed to enhance SVT vehicle. -
Page 29: Using Snow Chains
Wheel Spare Tire and Wheel Note: SVT only recommends using Your vehicle is equipped with an bead-lock rings from Ford Racing, in LT315/70R17 spare tire. The spare conjunction with the OEM tire. Any other tire/wheel assembly has the same combination using this wheel could result capability as the road tire/wheel assembly, in air loss or tire failure. -
Page 30: Wheels And Tires
See your local Ford Racing Parts Dealer for more information. F150 (TF6) -
Page 31: Capacities And Specifications
Capacities and Specifications ENGINE SPECIFICATIONS Engine 6.2L V8 engine Bore x Stroke 102 x 95 mm (4.01 x 3.74 in) Displacement 6.2L (6207 cc) Compression ratio 9.8:1 Horsepower (SAE net) 401 hp at 5500 rpm on 87 octane, 411 hp at 5500 rpm on 91 octane Torque 434 lb-ft at 4500 rpm on 87 octane, 434 lb-ft... -
Page 32: Motorcraft Parts
For spark plug replacement, see your authorized dealer. Refer your scheduled maintenance information for the appropriate intervals for changing the spark plugs. Replace the spark plugs with ones that meet Ford material and design specifications for your vehicle, such as Motorcraft or equivalent replacement parts. The customer warranty may be void for any damage to the engine if such spark plugs are not used. -
Page 33: Technical Specifications
Capacities and Specifications TECHNICAL SPECIFICATIONS Item Capacity Ford part name or Ford part number / equivalent Ford specification 6.6L (7.0 qt) Motorcraft SAE 5W- XO-5W20-QSP or Engine oil (includes filter 20 Motor Oil XO-5W20-QFS change) (U.S.); CXO-5W20- LSP12 or CXO-... -
Page 34: Capacities And Specifications
Your engine has been designed to use Motorcraft motor oils or equivalent oil brands that meet Ford's specifications. It is also acceptable to use motor oils of the recommended viscosity grade that meet API SN requirements and displays the API Certification Mark for gasoline engines. -
Page 35: Accessories
Accessories The switches control relays and fuses that AUXILIARY SWITCHES are located under the hood in the auxiliary switch pass through circuits. See At a The auxiliary switchboard on the center Glance (page 4). console makes aftermarket customization easier, with four prewired switches attached to the power distribution box for electrical accessories. - Page 36 Accessories The relays are coded as follows: Switch Circuit number Wire color Fuse AUX 1 CAC05 Yellow AUX 2 CAC06 Green with brown trace AUX 3 CAC07 Violet with green trace AUX 4 CAC08 Brown F150 (TF6)
-
Page 37: Warranty Terms And Conditions
Subjecting your The F-150 Raptor carries the same New vehicle to competition conditions even Vehicle Limited Warranty as other Ford with these proposed modifications may F-150 models. This information is covered render repairs non-reimbursable under the in its entirety in your warranty information. - Page 38 F150 (TF6)
- Page 39 Index About This Supplement.........3 Introduction............3 Accessories............33 At a Glance............4 6.2L V8 Engine............6 Motorcraft Parts..........30 F-150 SVT Raptor-Specific Exterior Features..............4 F-150 SVT Raptor-Specific Interior Features..............5 Auxiliary Switches..........33 Off-Road Driving..........15 After Off-Road Driving........24 Basic Off-road Driving Techniques....19 Crossing Obstacles..........21 Base Warranty..........35 Driving in Deep Snow...........21 Driving in Mud............20 Driving in Sand............20 High Speed Off-Roading........22...
- Page 40 Index Towing a Trailer..........12 Towing Capacity............12 Towing the Vehicle on Four Wheels..13 Emergency Towing..........13 Recreational Towing..........13 Towing..............12 Transporting the Vehicle.......12 Using Hill Descent Control......8 Disabling Hill Descent Control......8 Using Snow Chains........27 Vehicle Care............25 Warranty Terms and Conditions....35 Washers See: Cleaning the Exterior.........25 Wheels and Tires..........26 General Information..........26 Wheels..............27...
