HP 4320t Quickspecs

Mobile thin client
Hide thumbs Also See for 4320t:

Advertisement

Quick Links

Download this manual See also: Maintenance and Service Manual
QuickSpecs
Overview
1. WLAN antennas
2. Integrated microphone
3. Power button with LED indicator
4. Stereo speakers
5. Wireless switch with LED indicator
6. Optical drive (select models)
7. Optional RJ-11/modem port
8. (2) USB 2.0 ports
1. Kensington Lock slot
2. Power connector
3. Battery charging LED indicator
4. VGA connector (external monitor/projector)
5. RJ-45/Ethernet port
DA - 13613 North America — Version 7 — September 29, 2011
9
ClickPad with left and right ClickPad buttons
10. Stereo microphone in
11. Stereo headphone/line out
12. Media Card Reader
13. Hard drive activity LED indicator
14. Volume mute button
15. Volume down button
16. Volume up button
6.
HDMI port
7.
eSATA/USB 2.0 combo port
8.
ExpressCard/34 slot
9.
USB 2.0 port
HP 4320t Mobile Thin Client
Page 1

Advertisement

loading

Related Manuals for HP 4320t

Summary of Contents for HP 4320t

  • Page 1 QuickSpecs HP 4320t Mobile Thin Client Overview 1. WLAN antennas ClickPad with left and right ClickPad buttons 2. Integrated microphone 10. Stereo microphone in 3. Power button with LED indicator 11. Stereo headphone/line out 4. Stereo speakers 12. Media Card Reader 5.
  • Page 2 Widescreen 13.3-inch diagonal LED-backlit HD display with 16:9 aspect ratio HP Thin State Tools to configure thin clients via a USB flash drive or over the network HP Client Automation – Starter Edition and Altiris Deployment Solution for rich management options...

  • Page 3: Standard Features (Availability May Vary By Country)

    * Memory speed is processor dependent. NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
  • Page 4 WiFi Adapter Keyboard The HP spill-resistant keyboard is designed using a Mylar film that minimizes the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard features a full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys.
  • Page 5 QuickSpecs HP 4320t Mobile Thin Client Standard Features (availability may vary by country) Storage Internal Storage Device 2 GB, 4 GB, or 8 GB Solid State Module Optional Fixed Optical DVD-ROM Drive Drive Interfaces HDMI Stereo microphone in Stereo headphone/line...
  • Page 6 6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet (3.66 meter) HP Fast Charge* * HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast Charge does not apply to the HP 9-cell battery.
  • Page 7 Standard Features (availability may vary by country) Service and Support HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x 24 hardware technical phone support (depending on model). Warranty upgrades are also available. HP Care Pack Services extend service contracts beyond the standard warranties.
  • Page 8 The various product features and capabilities will vary in terms of configurable vs. aftermarket options (AMOs). There may be options and capabilities available through CTO that are not available as AMOs. Memory HP 1 GB (DDR3 1333 MHz) SODIMM AT911AA HP 2 GB (DDR3 1333 MHz) SODIMM...
  • Page 9 QuickSpecs HP 4320t Mobile Thin Client Options (availability may vary by country) Security HP/Kensington MicroSaver Security Lock PC766A HP Notebook Cable Lock AY475AA HP Privacy Filter For 13.3 in AU649AA Input/Output Devices HP USB/PS2 Optical 2-Button Scroll Mouse DC369A HP USB Keyboard & Mouse Bundle...
  • Page 10 NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

  • Page 11: Internal Storage Device

    QuickSpecs HP 4320t Mobile Thin Client Storage Removable Media Drive Support Quantity Supported Drive Bay DVD-ROM Drive Fixed optical drive bay Internal Storage Device Quantity Supported Drive Bay Hard Drives 2 GB Solid State Module Hard Drive Bay 4 GB Solid State Module...

  • Page 12: Technical Specifications

    QuickSpecs HP 4320t Mobile Thin Client Technical Specifications System Unit Dimensions (HxWxD) 1.08 in (at front) x 12.74 in x 8.98 in 27.49 mm (at front) x 323.50 mm x 228.08 mm Weight Starting at 4.27 lb (1.93 kg) without optical drive or 4.58 lb (2.07 kg) with optical drive...
  • Page 13 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications UKRSERTCOMPUTER NOTE: For accessibility information on HP products, please visit: http://www.hp.com/accessibility. HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm) Weight 0.62 lb (280 g)
  • Page 14 System ON 3 to 5 hours (depending on system power consumption) HP Fast Charge Technology Charges the battery up to 90% within 90 minutes when system is OFF Displays DA - 13613 North America — Version 7 — September 29, 2011...
  • Page 15 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications 13.3-inch LED HD (1366 x Active Area (W x H) 11.53 x 6.49 in (29.3 x 16.5 cm) 768) Diagonal Size 13.3 in (33.8cm) anti-glare Surface Treatment Anti-glare Contrast Ratio 400:1 (typical)
  • Page 16 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications 4 GB Solid State Module Interface SATA II, 3.0 Gbps (SSM) Connector 7-pin SATA male connector 15-pin SATA power connector Capacities 4 GB Transfer mode up to PIO mode-4, Multiword DMA mode-2, UDMA mode-5...
  • Page 17 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications Audio Output Quality Frequency Response 20 Hz - 20 kHz Signal to Noise Ratio >85 dB Total Harmonic Distortion 0.01% Noise Floor -110 dB Play/Record Sampling 8 kHz - 48kHz Rate(s) 16, 20 or 24-bit...
  • Page 18 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications V.92 56K Data/Fax Modem Form Factor MDC 1.5 Daughtercard Power Management APM Revision 1.2, ACPI Support Approvals/ UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other...
  • Page 19 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications Interoperability Wi-Fi certified (802.11abg only) Cisco Compatible Extensions Program compliant (802.11abg only) with Microsoft Windows Vista and XP (details at: http://www.hp.com/go/notebooks/WLAN) Frequency Band 2.4 GHz and 5 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps...
  • Page 20 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications Humidity Operating 10% to 90% (non-condensing) Non-operating 5% to 95% (non-condensing) Altitude Operating 0 to 10,000 ft (3,048 m) Non-operating 0 to 50,000 ft (15,240 m) LED Activity LED Off - Radio OFF; Solid LED On - Radio ON Check latest software/driver release for updates on supported security features.
  • Page 21 QuickSpecs HP 4320t Mobile Thin Client Technical Specifications Power Management ACPI compliant power management 802.11 compliant power saving mode Receiver Sensitivity 54 Mbps: -71 dBm, 11 Mbps: -85 dBm , 1 Mbps: -95 dBm Antenna type High efficiency dual band antenna with spatial diversity, mounted in the...
  • Page 22 This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive – 2002/95/EC. information: This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive – 2002/96/EC. This product is in compliance with California Proposition 65 (State of California;...
  • Page 23 Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards. Material Usage This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer to the HP General Specification of the Environment (http://www.hp.com/hpinfo/globalcitizenship/environment/ supplychain/gen_specifications.html):...
  • Page 24 HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
