- Page 1 CS-1004 MP3 OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • RDS (Radio Data System) Operation • Digital Compact Disc Player • Automatic Memory Storing • Full Detachable Panel • Preset Equalization...
-
Page 2: Table Of Contents
CONTENTS Installation ...........3 MP3 operation ........14 Take out screw before installation..3 Disc notes ...........17 DIN Front-Mount (Method A) ....3 Specification........18 Installing the unit .........3 Trouble shooting .......19 Removing the unit .......4 DIN Rear-Mount (Method B) ....5 Using the detachable front panel ..6 Wiring Connection ......7 Operation ..........8 Location of keys........8... -
Page 3: Installation
INSTALLATION Notes: TAKE OUT SCREW BEFORE INSTALLATION • Choose the mounting location where Before install the unit, please remove the the unit will not interfere with the two screws. normal driving function of the driver. Take out screw before installation •... -
Page 4: Removing The Unit
INSTALLATION Sleeve Spring Washer L Key Hex Nut Outer Trim Ring Metal Strap Front Panel Mounting Bolt Plain Washer Tapping Screw R Key 6. Mount the sleeve by inserting the sleeve into the opening of the dashboard and bend open the tabs located around the 10. -
Page 5: Din Rear-Mount (Method B)
INSTALLATION DIN REAR-MOUNT (Method B) If your vehicle is a Nissan, Toyota, follow these mounting instructions. Use the screw holes marked T (Toyota), N (Nissan) located on both sides of the unit to fasten the unit to the factory radio mounting brackets supplied with your vehicle. -
Page 6: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL REMOVING THE FRONT PANEL Precautions when handing 1. Press the release button (REL) on the 1. Do not drop the front panel. front panel and pull off the front panel. 2. Do not put pressure on the display or control buttons when removing or installing the front panel. -
Page 7: Wiring Connection
WIRING CONNECTION ISO Connection BLUE AUTO ANTENNA Rch RED BROWN Lch WHITE 13 16 19 Part C 12 15 18 11 14 17 20 Part B Part A ISO SOCKET PIN OUT Part A Power Connection Part B Speaker Connection Free RR = Rear right Free... -
Page 8: Operation
OPERATION LOCATION OF KEYS 18 15 GB-8... -
Page 9: Switching On/Off The Unit
OPERATION SWITCHING ON/OFF THE UNIT - TA ALARM mode: Switch on the unit by pressing any button When this mode is selected, any (except REL button (7) and EJECT automatic retune mode is not button (4)). When system is on, press activated. -
Page 10: Loudness
OPERATION c) RETUNE L, RETUNE S mode e) BEEP 2’ND, BEEP ALL, BEEP OFF The initial time of automatic TA mode search or PI search mode is selected. The situation of beep sound is When PI information is not caught for selected. -
Page 11: Equalization
OPERATION “NO PTY” -> The reception band will change in the following order: Each displaying time is several seconds, and come back to 1’st position after several seconds. • SELECTING STATION Notes: Press TUNE/SEEK/TRACK - CT = clock time button (17) or TUNE/SEEK/TRACK - FREQ. - Page 12 OPERATION immediately to switch on or off R.D.S. the preset number is used for PTY mode. selection as follows: Whenever R.D.S. is switched on, MUSIC group symbol “AF” appears on the display. - POP M, ROCK M Program name is displayed on - EASY M, LIGHT M receiving a R.D.S.
-
Page 13: Cd Operation
OPERATION R.D.S. TA information was received R.D.S.: Enhanced Other Networks from current station and the radio Information Broadcasting switched to that R.D.S. linked station, information on PI, AF, TP, TA, but no information could not be etc. relating to networks other received because the R.D.S. -
Page 14: Playing All Tracks In Random
OPERATION • PLAYING ALL TRACKS IN RANDOM directory, there is no function of Press SHF button (23) to play all pressing M5 button or M6 button. tracks on CD in random order. Press • PAUSING PLAYING again to cancel the function. Press PAU button (20) to pause MP3 •... - Page 15 OPERATION unit searches the track after few title. seconds, even if the enter button is not - Press BND/LOU (ENTER) pressed. button to confirm and start the play. - Repeat the above steps if the newly Searching Directory or File Name selected title is again a directory.
- Page 16 OPERATION KEY Assigned IN Searching mode (Table 1) MIXED-CD OPERATION If available, the unit can play the mixed- CD disc (the disc contains both CD audio tracks and MP3 files). Mode Select When you insert a mixed-CD disc into LOUD/BAND ENTER the CD slot, it starts to play the CD audio tracks.
-
Page 17: Disc Notes
OPERATION DISC NOTES: file name extension is “.MP3”. 3. For a non-MP3 file, even though the A. Notes on discs: file name extension is “.MP3”, the unit cannot recognize it. 1. Attempting to use nonstandard shape discs (e.g. square, start, heart) D. -
Page 18: Specification
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 160 (D) x 50 (H) Tone Controls : ± 10 dB - Bass (at 100 Hz) : ± 10 dB - Treble (at 10 KHz) Maximum Output Power : 4 x 15 Watts Current Drain... -
Page 19: Trouble Shooting
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom Cause Solution No power. The car ignition switch is If the power supply is properly not on.
