DOD FX75C Quick Manual

FLANGER
STEREO
What the FX75C Stereo Flanger Does
The FX75C splits your guitar signal, adds a short
delay to one of the signals, and then changes the
delay time at an even rate.This results in a slight
fluctuation in pitch of the delayed signal The FX75C
then adds a "whooshing up, and down" sound to
your guitar by incorporating regeneration into the
delayed signal.
Connecting The FX75C
Connect your guitar to the input of the FX75C.
Connect the output of the FX75C to the input of
your amplifier (or to the input of another effect
device you may be running). For stereo sound, con-
nect the Stereo output to the input of a second
amplifier..To eliminate the need for a 9 volt battery,
connect the PS200R to the AC power jack on the
FX75C
China in Printed
75C
FX
18-1075-A#01 FX75C
notice. without change
to subject are manual this in
Corp. Electronics DOD 1999
568-7638 (801) Fax International
568-7642 (801) Phone
566-7005 (801)
566-8800 (801) Telephone
84070 UT Sandy,
Parkway Sandy S.
Corporation Electronics
Features
• LED indicator shows status of effect and battery.
• Stereo effect generation from mono input.
• Active switching for noiseless operation.
• Easy access battery compartment.
• Adapter jack for AC operation.
• Rugged die-cast metal chassis.
• Three year limited warranty.
• Rubber non-skid bottom.
Controls
Level - This knob adjusts the overall volume level of
the Flange Effect.
Speed - This knob adjusts the rate of the modulat-
ing delay time.
Depth - This knob adjusts the intensity of the mod-
ulation
Regen - This knob sets the amount of regeneration
which is perceived as the up and down
motion.
Footswitch - Bypasses, and re-engages the effect
LED Indicator - Lights when the Flange is active and
is not lit when the effect is
bypassed.
Jacks - Input, Output, AC adapter (use only the
PS200R).
