BEFORE OPERATION

REMOTE CONTROL PREPARATION

Replacing Batteries
1
Remove the cover of the
battery compartment at the
back of the remote control by
sliding it out in the direction of
the arrow.
RST TA
LR03(AM4)1.5V
LR03(AM4)1.5V
• Do not fit use the used batteries or batteries of a different type. Such use may cause the unit to malfunction.
• Changing batteries should be done after turning off the unit.
• The average battery life during normal use is approximately one year.
• When the air conditioner does not operate normally after replacing the batteries, remove the batteries, refit
them and repress the RST button after 5 seconds.
Setting Current Time
4
Press the TA button with a sharp
object and the current time
indication symbol flashes. In the
beginning, 6:00A.M. will flash.
RST TA
LR03(AM4)1.5V
LR03(AM4)1.5V
Matching Address between Indoor Unit and Remote Control
1
When two units are used in the same room, you can match the address of the remote control to that of the unit.
Remove the lid of the battery case. Assign the address switch of one remote control as B.
2
Press the RST button with a sharp object.
Turn off the unit and pull out the power plug. Remove the front panel, Terminal block cover, and Frame grille.
3
Pull out the PCB. Assign the address switch of one indoor unit as B.
• This function must only be performed by qualified service personnel.
2
Remove the used batteries and
insert new batteries. The remote
control uses two alkaline batteries.
(1.5V, LR03x2)
RST TA
LR03(AM4)1.5V
LR03(AM4)1.5V
NOTE
5
Set the current time with the hour
and the minute buttons while the
current time indication flashes.
SLEEP
ON/OFF
.
TEMP
MODE FAN FLAP
CLOCK EVERYDAY HOUR MINUTE
.
TIMER RESERV CANCEL
ON OFF
NOTE
OWNER
3
Press the RST button with a sharp
object to reset the remote control
before closing the cover of the
battery compartment.
RST TA
LR03(AM4)1.5V
LR03(AM4)1.5V
6
Press the TA button again.
The flashing will stop and the
current time will be set.
RST TA
LR03(AM4)1.5V
LR03(AM4)1.5V
,
S MANUAL -11
